TYK+ 15

  • Long-lasting floodlighting for landscape and any architecture, also applying dynamic color. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free (<1%) precision die-cast aluminum housing, and adjustable stainless steel mounting bracket.
  • - Stainless steel graduated ferrules for aiming purposes on both sides of the fixture.
  • - Extra-clear, tempered, silk-screened, flat glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Custom MCPCB utilized to maximize heat dissipation and promote long LED life.
  • - High-transparency polycarbonate optics for optimized light transmission.
  • - Circular Intensive optics (C/I).
  • - Circular Medium optics (C/M).
  • - NEMA 5H x 5V light distribution (C/IW)
  • - Elliptical optics (ELL).
  • - Input voltage: 120-277 V (50 / 60 Hz), integral 0-10 V dimming driver.
  • - Standard tear-proof nickel-plated brass cable gland M20x1.5 for cables Ø0.4” - Ø0.55”.
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Contact factory for any Buy American Act (BAA) or Build America Buy America Act (BABAA) requirements.
  • - 5-year warranty.
TYK+ 15 C/I

TYK+ 15 C/I

Optic | Circular Intensive
  • Long-lasting floodlighting for landscape and any architecture, also applying dynamic color. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free (<1%) precision die-cast aluminum housing, and adjustable stainless steel mounting bracket.
  • - Stainless steel graduated ferrules for aiming purposes on both sides of the fixture.
  • - Extra-clear, tempered, silk-screened, flat glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Custom MCPCB utilized to maximize heat dissipation and promote long LED life.
  • - High-transparency polycarbonate optics for optimized light transmission.
  • - Circular Intensive optics (C/I).
  • - Input voltage: 120-277 V (50 / 60 Hz), integral 0-10 V dimming driver.
  • - Standard tear-proof nickel-plated brass cable gland M20x1.5 for cables Ø0.4” - Ø0.55”.
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Contact factory for any Buy American Act (BAA) or Build America Buy America Act (BABAA) requirements.
  • - 5-year warranty.
Product codes
Part number Finishing Lampholder Wattage Voltage CRI Kelvin Optic Beam
angle		 Lightsource
lumen
output
[lm]		 Luminaire
lumen
output
[lm]		 L B Lifetime Downloads
High Power LEDS 120-277 V Dimmable 0-10 V
078076 LED 30 W 120/277 V 90 2700 Type V 10° 2100 1370 L90 B10 70000 TYK+ 15 C/I Download

Documentation: TYK+ 15 C/I - 078076
078077 LED 30 W 120/277 V 80 3000 Type V 10° 2800 1765 L90 B10 70000 TYK+ 15 C/I Download

Documentation: TYK+ 15 C/I - 078077
078078 LED 30 W 120/277 V 80 4000 Type V 10° 3000 1890 L90 B10 70000 TYK+ 15 C/I Download

Documentation: TYK+ 15 C/I - 078078

Sources

LED 30 W
TYK+ 15 C/IW

TYK+ 15 C/IW

Optic | Circular Intensive-Wide
  • Long-lasting floodlighting for landscape and any architecture, also applying dynamic color. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free (<1%) precision die-cast aluminum housing, and adjustable stainless steel mounting bracket.
  • - Stainless steel graduated ferrules for aiming purposes on both sides of the fixture.
  • - Extra-clear, tempered, silk-screened, flat glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Custom MCPCB utilized to maximize heat dissipation and promote long LED life.
  • - High-transparency polycarbonate optics for optimized light transmission.
  • - NEMA 5H x 5V light distribution (C/IW)
  • - Input voltage: 120-277 V (50 / 60 Hz), integral 0-10 V dimming driver.
  • - Standard tear-proof nickel-plated brass cable gland M20x1.5 for cables Ø0.4” - Ø0.55”.
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Contact factory for any Buy American Act (BAA) or Build America Buy America Act (BABAA) requirements.
  • - 5-year warranty.
Product codes
Part number Finishing Lampholder Wattage Voltage CRI Kelvin Optic Beam
angle		 Lightsource
lumen
output
[lm]		 Luminaire
lumen
output
[lm]		 L B Lifetime Downloads
High Power LEDS 120-277 V Dimmable 0-10 V
078082 LED 30 W 120/277 V 90 2700 Type V 65° 2100 1515 L90 B10 70000 TYK+ 15 C/IW Download

Documentation: TYK+ 15 C/IW - 078082
078083 LED 30 W 120/277 V 80 3000 Type V 65° 2800 1940 L90 B10 70000 TYK+ 15 C/IW Download

Documentation: TYK+ 15 C/IW - 078083
078084 LED 30 W 120/277 V 80 4000 Type V 65° 3000 2085 L90 B10 70000 TYK+ 15 C/IW Download

Documentation: TYK+ 15 C/IW - 078084

Sources

LED 30 W
TYK+ 15 C/M

TYK+ 15 C/M

Optic | Circular Medium
  • Long-lasting floodlighting for landscape and any architecture, also applying dynamic color. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free (<1%) precision die-cast aluminum housing, and adjustable stainless steel mounting bracket.
  • - Stainless steel graduated ferrules for aiming purposes on both sides of the fixture.
  • - Extra-clear, tempered, silk-screened, flat glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Custom MCPCB utilized to maximize heat dissipation and promote long LED life.
  • - High-transparency polycarbonate optics for optimized light transmission.
  • - Circular Medium optics (C/M).
  • - Input voltage: 120-277 V (50 / 60 Hz), integral 0-10 V dimming driver.
  • - Standard tear-proof nickel-plated brass cable gland M20x1.5 for cables Ø0.4” - Ø0.55”.
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Contact factory for any Buy American Act (BAA) or Build America Buy America Act (BABAA) requirements.
  • - 5-year warranty.
Product codes
Part number Finishing Lampholder Wattage Voltage CRI Kelvin Optic Beam
angle		 Lightsource
lumen
output
[lm]		 Luminaire
lumen
output
[lm]		 L B Lifetime Downloads
High Power LEDS 120-277 V Dimmable 0-10 V
078079 LED 30 W 120/277 V 90 2700 Type V 34° 2100 1535 L90 B10 70000 TYK+ 15 C/M Download

Documentation: TYK+ 15 C/M - 078079
078080 LED 30 W 120/277 V 80 3000 Type V 34° 2800 1975 L90 B10 70000 TYK+ 15 C/M Download

Documentation: TYK+ 15 C/M - 078080
078081 LED 30 W 120/277 V 80 4000 Type V 34° 3000 2135 L90 B10 70000 TYK+ 15 C/M Download

Documentation: TYK+ 15 C/M - 078081

Sources

LED 30 W
TYK+ 15 ELL

TYK+ 15 ELL

Optic | Elliptical - ELL
  • Long-lasting floodlighting for landscape and any architecture, also applying dynamic color. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free (<1%) precision die-cast aluminum housing, and adjustable stainless steel mounting bracket.
  • - Stainless steel graduated ferrules for aiming purposes on both sides of the fixture.
  • - Extra-clear, tempered, silk-screened, flat glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Custom MCPCB utilized to maximize heat dissipation and promote long LED life.
  • - High-transparency polycarbonate optics for optimized light transmission.
  • - Circular Intensive optics (C/I).
  • - Circular Medium optics (C/M).
  • - NEMA 5H x 5V light distribution (C/IW)
  • - Elliptical optics (ELL).
  • - Input voltage: 120-277 V (50 / 60 Hz), integral 0-10 V dimming driver.
  • - Standard tear-proof nickel-plated brass cable gland M20x1.5 for cables Ø0.4” - Ø0.55”.
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Contact factory for any Buy American Act (BAA) or Build America Buy America Act (BABAA) requirements.
  • - 5-year warranty.
Product codes
Part number Finishing Lampholder Wattage Voltage CRI Kelvin Optic Beam
angle		 Lightsource
lumen
output
[lm]		 Luminaire
lumen
output
[lm]		 L B Lifetime Downloads
High Power LEDS 120-277 V Dimmable 0-10 V
078085 LED 30 W 120/277 V 90 2700 Type I 35°x65° 2100 925 L90 B10 70000 TYK+ 15 ELL Download

Documentation: TYK+ 15 ELL - 078085
078086 LED 30 W 120/277 V 80 3000 Type I 35°x65° 2800 1205 L90 B10 70000 TYK+ 15 ELL Download

Documentation: TYK+ 15 ELL - 078086
078087 LED 30 W 120/277 V 80 4000 Type I 35°x65° 3000 1275 L90 B10 70000 TYK+ 15 ELL Download

Documentation: TYK+ 15 ELL - 078087
078088 LED 30 W 120/277 V 90 2700 Type I 65°x35° 2100 925 L90 B10 70000 TYK+ 15 ELL Download

Documentation: TYK+ 15 ELL - 078088
078089 LED 30 W 120/277 V 80 3000 Type I 65°x35° 2800 1205 L90 B10 70000 TYK+ 15 ELL Download

Documentation: TYK+ 15 ELL - 078089
078090 LED 30 W 120/277 V 80 4000 Type I 65°x35° 3000 1275 L90 B10 70000 TYK+ 15 ELL Download

Documentation: TYK+ 15 ELL - 078090

Sources

LED 30 W

Product Family

TYK+ 30 TYK+ 30
TYK+ 20 TYK+ 20
TYK+ 10 TYK+ 10
