FOCUS+ 1

IN
  • Long-lasting energy-efficient architectural, landscape and professional flood light series. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free precision die-cast aluminum housing, trim and adjustable mounting bracket.
  • - Extra-clear, flat, tempered silk screened soda-lime glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Custom MCPCB utilized to maximize heat dissipation and promote a long LED life.
  • - High-transmittance transparent optics.
  • - NEMA 3H x 3V light distribution (C/I).
  • - Input voltage: 120-277 V (50 / 60 Hz), integral 0-10 V dimming driver.
  • - Pre-wired cable is factory sealed to housing with a cable gland allowing external electrical connections.
  • - Matching junction box cover plate optional accessory available (ordered separately).
  • - Consult factory for dimming options, custom finishes and non-cataloged CCT (Kelvin) options.
  • - Consult factory for custom optics options.
  • - Product meets Buy American requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finish Lampholder Wattage Voltage CRI Kelvin Optic Optic
Beam
Lightsource
lumen
output
Luminaire
lumen
output
L B Lifetime Download
HIGH POWER LEDS 120-277 V DIMMABLE 0-10V
071833 LED 19 W 120-277V 70 3000 - 17° 1680 1247 L70 B10 60000 Download

Documentation: FOCUS+ 1 C/I - 071833

071839 LED 19 W 120-277V 70 4000 - 17° 1880 1395 L70 B10 60000 Download

Documentation: FOCUS+ 1 C/I - 071839

Sources

LED 19 W
  • Long-lasting energy-efficient architectural, landscape and professional flood light series. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free precision die-cast aluminum housing, trim and adjustable mounting bracket.
  • - Extra-clear, flat, tempered silk screened soda-lime glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Custom MCPCB utilized to maximize heat dissipation and promote a long LED life.
  • - High-transmittance transparent optics.
  • - NEMA 4H x 4V light distribution (C/M).
  • - Input voltage: 120-277 V (50 / 60 Hz), integral 0-10 V dimming driver.
  • - Pre-wired cable is factory sealed to housing with a cable gland allowing external electrical connections.
  • - Matching junction box cover plate optional accessory available (ordered separately).
  • - Consult factory for dimming options, custom finishes and non-cataloged CCT (Kelvin) options.
  • - Consult factory for custom optics options.
  • - Product meets Buy American requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finish Lampholder Wattage Voltage CRI Kelvin Optic Optic
Beam
Lightsource
lumen
output
Luminaire
lumen
output
L B Lifetime Download
HIGH POWER LEDS 120-277 V DIMMABLE 0-10V
071834 LED 19 W 120-277V 70 3000 - 34° 1680 1242 L70 B10 60000 Download

Documentation: FOCUS+ 1 C/M - 071834

071840 LED 19 W 120-277V 70 4000 - 34° 1880 1389 L70 B10 60000 Download

Documentation: FOCUS+ 1 C/M - 071840

Sources

LED 19 W
  • Long-lasting energy-efficient architectural, landscape and professional flood light series. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free precision die-cast aluminum housing, trim and adjustable mounting bracket.
  • - Extra-clear, flat, tempered silk screened soda-lime glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Custom MCPCB utilized to maximize heat dissipation and promote a long LED life.
  • - High-transmittance transparent optics.
  • - NEMA 5H x 5V light distribution (C/W).
  • - Input voltage: 120-277 V (50 / 60 Hz), integral 0-10 V dimming driver.
  • - Pre-wired cable is factory sealed to housing with a cable gland allowing external electrical connections.
  • - Matching junction box cover plate optional accessory available (ordered separately).
  • - Consult factory for dimming options, custom finishes and non-cataloged CCT (Kelvin) options.
  • - Consult factory for custom optics options.
  • - Product meets Buy American requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finish Lampholder Wattage Voltage CRI Kelvin Optic Optic
Beam
Lightsource
lumen
output
Luminaire
lumen
output
L B Lifetime Download
HIGH POWER LEDS 120-277 V DIMMABLE 0-10V
071835 LED 19 W 120-277V 70 3000 - 56° 1680 1180 L70 B10 60000 Download

Documentation: FOCUS+ 1 C/W - 071835

071841 LED 19 W 120-277V 70 4000 - 56° 1880 1320 L70 B10 60000 Download

Documentation: FOCUS+ 1 C/W - 071841

Sources

LED 19 W
  • Long-lasting energy-efficient architectural, landscape and professional flood light series. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free precision die-cast aluminum housing, trim and adjustable mounting bracket.
  • - Extra-clear, flat, tempered silk screened soda-lime glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Custom MCPCB utilized to maximize heat dissipation and promote a long LED life.
  • - High-transmittance transparent optics.
  • - NEMA 4H x 3V light distribution (ELL).
  • - Input voltage: 120-277 V (50 / 60 Hz), integral 0-10 V dimming driver.
  • - Pre-wired cable is factory sealed to housing with a cable gland allowing external electrical connections.
  • - Matching junction box cover plate optional accessory available (ordered separately).
  • - Consult factory for dimming options, custom finishes and non-cataloged CCT (Kelvin) options.
  • - Consult factory for custom optics options.
  • - Product meets Buy American requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finish Lampholder Wattage Voltage CRI Kelvin Optic Optic
Beam
Lightsource
lumen
output
Luminaire
lumen
output
L B Lifetime Download
HIGH POWER LEDS 120-277 V DIMMABLE 0-10V
071836 LED 19 W 120-277V 70 3000 - 15°x40° 1680 1307 L70 B10 60000 Download

Documentation: FOCUS+ 1 ELL - 071836

071842 LED 19 W 120-277V 70 4000 - 15°x40° 1880 1462 L70 B10 60000 Download

Documentation: FOCUS+ 1 ELL - 071842

Sources

LED 19 W
  • Long-lasting energy-efficient architectural, landscape and professional flood light series. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free precision die-cast aluminum housing, trim and adjustable mounting bracket.
  • - Extra-clear, flat, tempered silk screened soda-lime glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Custom MCPCB utilized to maximize heat dissipation and promote a long LED life.
  • - High-transmittance transparent optics.
  • - NEMA 3H x 3V light distribution (C/I).
  • - Input voltage: 120-277 V (50 / 60 Hz), integral 0-10 V dimming driver.
  • - Pre-wired cable is factory sealed to housing with a cable gland allowing external electrical connections.
  • - Standard robust ½” NPS knuckle mount with 180° adjustable swivel arm (SA versions) and rugged, locking teeth for a simplified installation.
  • - Matching junction box cover plate optional accessory available (ordered separately).
  • - Consult factory for dimming options, custom finishes and non-cataloged CCT (Kelvin) options.
  • - Consult factory for custom optics options.
  • - Product meets Buy American requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finish Lampholder Wattage Voltage CRI Kelvin Optic Optic
Beam
Lightsource
lumen
output
Luminaire
lumen
output
L B Lifetime Download
HIGH POWER LEDS 120-277 V DIMMABLE 0-10V
070460 LED 19 W 120-277V 50/60HZ 70 3000 - 17° 1680 1247 L70 B10 60000 Download

Documentation: FOCUS+ 1 SA C/I - 070460

070461 LED 19 W 120-277V 50/60HZ 70 3000 - 17° 1680 1247 L70 B10 60000 Download

Documentation: FOCUS+ 1 SA C/I - 070461

070472 LED 19 W 120-277V 50/60HZ 70 4000 - 17° 1880 1395 L70 B10 60000 Download

Documentation: FOCUS+ 1 SA C/I - 070472

070473 LED 19 W 120-277V 50/60HZ 70 4000 - 17° 1880 1395 L70 B10 60000 Download

Documentation: FOCUS+ 1 SA C/I - 070473

Sources

LED 19 W
  • Long-lasting energy-efficient architectural, landscape and professional flood light series. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free precision die-cast aluminum housing, trim and adjustable mounting bracket.
  • - Extra-clear, flat, tempered silk screened soda-lime glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Custom MCPCB utilized to maximize heat dissipation and promote a long LED life.
  • - High-transmittance transparent optics.
  • - NEMA 4H x 4V light distribution (C/M).
  • - Input voltage: 120-277 V (50 / 60 Hz), integral 0-10 V dimming driver.
  • - Pre-wired cable is factory sealed to housing with a cable gland allowing external electrical connections.
  • - Standard robust ½” NPS knuckle mount with 180° adjustable swivel arm (SA versions) and rugged, locking teeth for a simplified installation.
  • - Matching junction box cover plate optional accessory available (ordered separately).
  • - Consult factory for dimming options, custom finishes and non-cataloged CCT (Kelvin) options.
  • - Consult factory for custom optics options.
  • - Product meets Buy American requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finish Lampholder Wattage Voltage CRI Kelvin Optic Optic
Beam
Lightsource
lumen
output
Luminaire
lumen
output
L B Lifetime Download
HIGH POWER LEDS 120-277 V DIMMABLE 0-10V
070462 LED 19 W 120-277V 50/60HZ 70 3000 - 34° 1680 1242 L70 B10 60000 Download

Documentation: FOCUS+ 1 SA C/M - 070462

070463 LED 19 W 120-277V 50/60HZ 70 3000 - 34° 1680 1242 L70 B10 60000 Download

Documentation: FOCUS+ 1 SA C/M - 070463

070474 LED 19 W 120-277V 50/60HZ 70 4000 - 34° 1880 1389 L70 B10 60000 Download

Documentation: FOCUS+ 1 SA C/M - 070474

070475 LED 19 W 120-277V 50/60HZ 70 4000 - 34° 1880 1389 L70 B10 60000 Download

Documentation: FOCUS+ 1 SA C/M - 070475

Sources

LED 19 W
  • Long-lasting energy-efficient architectural, landscape and professional flood light series. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free precision die-cast aluminum housing, trim and adjustable mounting bracket.
  • - Extra-clear, flat, tempered silk screened soda-lime glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Custom MCPCB utilized to maximize heat dissipation and promote a long LED life.
  • - High-transmittance transparent optics.
  • - NEMA 5H x 5V light distribution (C/W).
  • - Input voltage: 120-277 V (50 / 60 Hz), integral 0-10 V dimming driver.
  • - Pre-wired cable is factory sealed to housing with a cable gland allowing external electrical connections.
  • - Standard robust ½” NPS knuckle mount with 180° adjustable swivel arm (SA versions) and rugged, locking teeth for a simplified installation.
  • - Matching junction box cover plate optional accessory available (ordered separately).
  • - Consult factory for dimming options, custom finishes and non-cataloged CCT (Kelvin) options.
  • - Consult factory for custom optics options.
  • - Product meets Buy American requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finish Lampholder Wattage Voltage CRI Kelvin Optic Optic
Beam
Lightsource
lumen
output
Luminaire
lumen
output
L B Lifetime Download
HIGH POWER LEDS 120-277 V DIMMABLE 0-10V
070464 LED 19 W 120-277V 50/60HZ 70 3000 - 56° 1680 1180 L70 B10 60000 Download

Documentation: FOCUS+ 1 SA C/W - 070464

070465 LED 19 W 120-277V 50/60HZ 70 3000 - 56° 1680 1180 L70 B10 60000 Download

Documentation: FOCUS+ 1 SA C/W - 070465

070476 LED 19 W 120-277V 50/60HZ 70 4000 - 56° 1880 1320 L70 B10 60000 Download

Documentation: FOCUS+ 1 SA C/W - 070476

070477 LED 19 W 120-277V 50/60HZ 70 4000 - 56° 1880 1320 L70 B10 60000 Download

Documentation: FOCUS+ 1 SA C/W - 070477

Sources

LED 19 W
  • Long-lasting energy-efficient architectural, landscape and professional flood light series. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free precision die-cast aluminum housing, trim and adjustable mounting bracket.
  • - Extra-clear, flat, tempered silk screened soda-lime glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Custom MCPCB utilized to maximize heat dissipation and promote a long LED life.
  • - High-transmittance transparent optics.
  • - NEMA 4H x 3V light distribution (ELL).
  • - Input voltage: 120-277 V (50 / 60 Hz), integral 0-10 V dimming driver.
  • - Pre-wired cable is factory sealed to housing with a cable gland allowing external electrical connections.
  • - Standard robust ½” NPS knuckle mount with 180° adjustable swivel arm (SA versions) and rugged, locking teeth for a simplified installation.
  • - Matching junction box cover plate optional accessory available (ordered separately).
  • - Consult factory for dimming options, custom finishes and non-cataloged CCT (Kelvin) options.
  • - Consult factory for custom optics options.
  • - Product meets Buy American requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finish Lampholder Wattage Voltage CRI Kelvin Optic Optic
Beam
Lightsource
lumen
output
Luminaire
lumen
output
L B Lifetime Download
HIGH POWER LEDS 120-277 V DIMMABLE 0-10V
070466 LED 19 W 120-277V 50/60HZ 70 3000 - 15°x40° 1680 1307 L70 B10 60000 Download

Documentation: FOCUS+ 1 SA ELL - 070466

070467 LED 19 W 120-277V 50/60HZ 70 3000 - 15°x40° 1680 1307 L70 B10 60000 Download

Documentation: FOCUS+ 1 SA ELL - 070467

070478 LED 19 W 120-277V 50/60HZ 70 4000 - 15°x40° 1880 1462 L70 B10 60000 Download

Documentation: FOCUS+ 1 SA ELL - 070478

070479 LED 19 W 120-277V 50/60HZ 70 4000 - 15°x40° 1880 1462 L70 B10 60000 Download

Documentation: FOCUS+ 1 SA ELL - 070479

Sources

LED 19 W
  • Long-lasting energy-efficient architectural, landscape and professional flood light series. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free precision die-cast aluminum housing, trim and adjustable mounting bracket.
  • - Extra-clear, flat, tempered silk screened soda-lime glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Custom MCPCB utilized to maximize heat dissipation and promote a long LED life.
  • - High-transmittance transparent optics.
  • - NEMA 3H x 7V light distribution (Type I).
  • - Input voltage: 120-277 V (50 / 60 Hz), integral 0-10 V dimming driver.
  • - Pre-wired cable is factory sealed to housing with a cable gland allowing external electrical connections.
  • - Standard robust ½” NPS knuckle mount with 180° adjustable swivel arm (SA versions) and rugged, locking teeth for a simplified installation.
  • - Matching junction box cover plate optional accessory available (ordered separately).
  • - Consult factory for dimming options, custom finishes and non-cataloged CCT (Kelvin) options.
  • - Consult factory for custom optics options.
  • - Product meets Buy American requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finish Lampholder Wattage Voltage CRI Kelvin Optic Optic
Beam
Lightsource
lumen
output
Luminaire
lumen
output
L B Lifetime Download
HIGH POWER LEDS 120-277 V DIMMABLE 0-10V
070468 LED 19 W 120-277V 50/60HZ 70 3000 Type I - 1680 1170 L70 B10 60000 Download

Documentation: FOCUS+ 1 SA TYPE I - 070468

070469 LED 19 W 120-277V 50/60HZ 70 3000 Type I - 1680 1170 L70 B10 60000 Download

Documentation: FOCUS+ 1 SA TYPE I - 070469

070480 LED 19 W 120-277V 50/60HZ 70 4000 Type I - 1880 1308 L70 B10 60000 Download

Documentation: FOCUS+ 1 SA TYPE I - 070480

070481 LED 19 W 120-277V 50/60HZ 70 4000 Type I - 1880 1308 L70 B10 60000 Download

Documentation: FOCUS+ 1 SA TYPE I - 070481

Sources

LED 19 W
  • Long-lasting energy-efficient architectural, landscape and professional flood light series. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free precision die-cast aluminum housing, trim and adjustable mounting bracket.
  • - Extra-clear, flat, tempered silk screened soda-lime glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Custom MCPCB utilized to maximize heat dissipation and promote a long LED life.
  • - High-transmittance transparent optics.
  • - NEMA 5H x 6V light distribution (Type III).
  • - Input voltage: 120-277 V (50 / 60 Hz), integral 0-10 V dimming driver.
  • - Pre-wired cable is factory sealed to housing with a cable gland allowing external electrical connections.
  • - Matching junction box cover plate optional accessory available (ordered separately).
  • - Standard robust ½” NPS knuckle mount with 180° adjustable swivel arm (SA versions) and rugged, locking teeth for a simplified installation.
  • - Consult factory for dimming options, custom finishes and non-cataloged CCT (Kelvin) options.
  • - Consult factory for custom optics options.
  • - Product meets Buy American requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finish Lampholder Wattage Voltage CRI Kelvin Optic Optic
Beam
Lightsource
lumen
output
Luminaire
lumen
output
L B Lifetime Download
HIGH POWER LEDS 120-277 V DIMMABLE 0-10V
070470 LED 19 W 120-277V 50/60HZ 70 3000 Type III - 1680 1108 L70 B10 60000 Download

Documentation: FOCUS+ 1 SA TYPE III - 070470

070471 LED 19 W 120-277V 50/60HZ 70 3000 Type III - 1680 1108 L70 B10 60000 Download

Documentation: FOCUS+ 1 SA TYPE III - 070471

070482 LED 19 W 120-277V 50/60HZ 70 4000 Type III - 1880 1239 L70 B10 60000 Download

Documentation: FOCUS+ 1 SA TYPE III - 070482

070483 LED 19 W 120-277V 50/60HZ 70 4000 Type III - 1880 1239 L70 B10 60000 Download

Documentation: FOCUS+ 1 SA TYPE III - 070483

Sources

LED 19 W
  • Long-lasting energy-efficient architectural, landscape and professional flood light series. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free precision die-cast aluminum housing, trim and adjustable mounting bracket.
  • - Extra-clear, flat, tempered silk screened soda-lime glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Custom MCPCB utilized to maximize heat dissipation and promote a long LED life.
  • - High-transmittance transparent optics.
  • - NEMA 3H x 7V light distribution (Type I).
  • - Input voltage: 120-277 V (50 / 60 Hz), integral 0-10 V dimming driver.
  • - Pre-wired cable is factory sealed to housing with a cable gland allowing external electrical connections.
  • - Matching junction box cover plate optional accessory available (ordered separately).
  • - Consult factory for dimming options, custom finishes and non-cataloged CCT (Kelvin) options.
  • - Consult factory for custom optics options.
  • - Product meets Buy American requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finish Lampholder Wattage Voltage CRI Kelvin Optic Optic
Beam
Lightsource
lumen
output
Luminaire
lumen
output
L B Lifetime Download
HIGH POWER LEDS 120-277 V DIMMABLE 0-10V
071837 LED 19 W 120-277V 70 3000 Type I - 1680 1170 L70 B10 60000 Download

Documentation: FOCUS+ 1 TYPE I - 071837

071843 LED 19 W 120-277V 70 4000 Type I - 1880 1308 L70 B10 60000 Download

Documentation: FOCUS+ 1 TYPE I - 071843

Sources

LED 19 W
  • Long-lasting energy-efficient architectural, landscape and professional flood light series. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free precision die-cast aluminum housing, trim and adjustable mounting bracket.
  • - Extra-clear, flat, tempered silk screened soda-lime glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Custom MCPCB utilized to maximize heat dissipation and promote a long LED life.
  • - High-transmittance transparent optics.
  • - NEMA 5H x 6V light distribution (Type III).
  • - Input voltage: 120-277 V (50 / 60 Hz), integral 0-10 V dimming driver.
  • - Pre-wired cable is factory sealed to housing with a cable gland allowing external electrical connections.
  • - Matching junction box cover plate optional accessory available (ordered separately).
  • - Consult factory for dimming options, custom finishes and non-cataloged CCT (Kelvin) options.
  • - Consult factory for custom optics options.
  • - Product meets Buy American requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finish Lampholder Wattage Voltage CRI Kelvin Optic Optic
Beam
Lightsource
lumen
output
Luminaire
lumen
output
L B Lifetime Download
HIGH POWER LEDS 120-277 V DIMMABLE 0-10V
071838 LED 19 W 120-277V 70 3000 Type III - 1680 1108 L70 B10 60000 Download

Documentation: FOCUS+ 1 TYPE III - 071838

071844 LED 19 W 120-277V 70 4000 Type III - 1880 1239 L70 B10 60000 Download

Documentation: FOCUS+ 1 TYPE III - 071844

Sources

LED 19 W
to top
I cookie ci aiutano a fornire i nostri servizi. Utilizzando tali servizi, accetti l'utilizzo dei cookie da parte nostra. Info
