Starry light
The SPILLO is set to inspire the design community with the newest form factor in site, area, and pedestrian lighting. Combining classic details and a modern aesthetic, the SPILLO partners top performance with a cutting edge look. Offering Type II and V optical distributions and an industry-leading sensor option that gives you precise energy controls, the SPILLO is not only the most beautiful exterior fixture available, but it’s also the smartest too. With a complimentary bollard in the form of the SPILLO MINI, this is the new standard in urban lighting.In compliance with the latest international light pollution/dark sky requirements, this product series is the perfect choice for your residential and commercial projects.
Design-coordinated area and site lighting (SPILLO) and bollard (SPILLO MINI) series. Fixtures consists of:
Construction
  • Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • Copper-free (<1%) precision die-cast aluminum housing and top cap.
  • Copper-free (<1%) aluminum extruded post.
  • Custom MCPCB utilized to maximize heat dissipation and promote long LED life.
  • High-transparency polycarbonate optics for optimized light transmission.
  • Custom molded, anti-aging gasket(s).
  • Stainless steel external hardware.
Installation
  • Available in two standard sizes of Ø14.2" (SPILLO MINI) and Ø22.8" (SPILLO).
  • The "Secure Light Distribution" system can bypass individual diodes in the event of a single LED failure to ensure continuous uniform light distribution.
  • Pre-wired factory sealed cable for external electrical connection included.
  • Ø3” and Ø4” post top adapters, and poles in 8’ / 10’ / 12 ’/ 14’ options available (ordered separately).
  • Anchor bolts available for bollards (ordered separately).
Optics
  • Type V and Type II (SPILLO only) light distributions.
Electrical
  • Input voltage: 120-277 V (50 / 60 Hz), integral 0-10 V dimming driver.
Options
  • The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
Listings
  • UL Wet location listed. IP65 rated.
  • Product meets Buy American Act (BAA) requirements within ARRA.
  • Photometric data measured according to UNI EN 13032-1/4 and IES LM-79-08
  • The light distribution complies with the IESNA Full Cut-Off Classification and is eligible for all “Dark Sky” applications when aimed down.
  • Actual performance may differ as a result of the end-user environment and application. All values are design or typical values, measured under laboratory conditions at 25 °C. Specifications are subject to change without notice.
Warranty
  • 5-year limited warranty. Complete warranty terms located at www.performanceinlighting.com
