Yes, we've regenerated the SystemPark Line due to overwhelming specifications and upgraded into SYSTEMLINE+ to perform even better. This product family is extremely versatile, offering a wide range of lighting solutions. Ideal for signage using banner arms. Available in three different lengths, the slim profile offers a clean, minimalistic profile. The distinctly designed slip fitters allow the fixtures to be installed using various combinations of heights and angles.The highly versatile and diverse system of accessories provided for this product family offers a wide range of lighting solutions for pedestrian areas, city streets, parking lots, and urban areas. This modem lighting solution contains an added value for urban centers, architecture, and the economy. The aesthetics and functionality, economic saving, and safeguard of sources allow sustainable lighting that makes areas more alluring and liveable without waste or light pollution.
Area and site lighting series.
Fixtures consist of:
Copper-free (<1%) aluminum die-cast end-caps, extruded, and anodized housing.
Multi-step powder-coat painting process, optimized against UV rays and corrosion.
Custom MCPCB utilized to maximize heat dissipation and promote long LED life.
High-transparency polycarbonate optics for optimized light transmission.
Overall standard size of H3.5" x D3.4”. Available in three standard lengths of 41", 53” and 65”.
Range of accessories, including posts and painted aluminum arms, suitable for a variety of configurations for diverse settings (parks, gardens, pedestrian areas, squares, parking areas, etc.) available (ordered separately).
Type I, Type II, and Asymmetrical Wide (A/W) - Type II for 53" and 65" and Type III for 41" versions - light distributions.
Input voltage: 120-277 V (50 / 60 Hz), integral 0-10 V dimming driver.
The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
UL Wet location listed. IP66 rated.
Product meets Buy American Act (BAA) requirements within ARRA.
Photometric data measured according to UNI EN 13032-1/4 and IES LM-79-08
The light distribution complies with the IESNA Full Cut-Off Classification and is eligible for all “Dark Sky” applications when aimed down.
Actual performance may differ as a result of the end-user environment and application. All values are design or typical values, measured under laboratory conditions at 25 °C. Specifications are subject to change without notice.
5-year limited warranty. Complete warranty terms located at www.performanceinlighting.com
