KHA CITY 24

IN
  • - Coastal for good
  • - KHA CITY are contemporary high-performance bollards and light poles, combining style with a robust design manufactured in high-quality materials and finishing. KHA CITY products provide functional and dramatic effect lighting with aesthetics suitable for entrances, paths, walkways, courtyards, gardens, public areas, and security lighting. Consult factory for more options such as individual heights and house side shield options. Also available are COMFORT and MARINE options.
KHA CITY 24 TYPE III

KHA CITY 24 TYPE III

Optic | Asymmetric Medium
  • Pathway bollard series. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free (<1%) precision die-cast aluminum housing and top cap.
  • - Copper-free (<1%) aluminum extruded post.
  • - Corrosion-resistant AISI 316 stainless steel post and top cap.
  • - Clear UV-stabilized, high-impact resistant diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Internal specular reflector coated with 5-layers of PVD 99.98% pure aluminum providing >95% reflection.
  • - Black aluminum reflector provides full-cutoff, no glare design, and precision optical control (COMFORT options).
  • - ustom MCPCB utilized to maximize heat dissipation and promote long LED life.
  • - High-transparency polycarbonate optics for optimized light transmission.
  • - Type III light distribution.
  • - Input voltage: 120-277 V (50 / 60 Hz), integral 0-10 V dimming driver.
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Concrete installation fixing rods available (ordered separately).
  • - Bolt-on root galvanized steel direct burial or stainless steel flange plate (anchor plugs not included) floor mounting options available for all KHA CITY 24 options (ordered separately)
  • - Suitable for most coastal applications (stainless steel versions).
  • - Product meets Buy American Act (BAA) requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finishing Lampholder Wattage Voltage CRI Kelvin Optic Beam
angle		 Lightsource
lumen
output
[lm]		 Luminaire
lumen
output
[lm]		 L B Lifetime Downloads
High Power LEDS 120-277 V - Dimmable 0-10 V
076522 LED 20 W 120/277 V 80 3000 - - 2800 1474 L80 B10 80000 Download

Documentation: KHA CITY 24 TYPE III - 076522
076523 LED 20 W 120/277 V 80 3000 - - 2800 1474 L80 B10 80000 Download

Documentation: KHA CITY 24 TYPE III - 076523
076525 LED 20 W 120/277 V 80 4000 - - 2900 1538 L80 B10 80000 Download

Documentation: KHA CITY 24 TYPE III - 076525
076526 LED 20 W 120/277 V 80 4000 - - 2900 1538 L80 B10 80000 Download

Documentation: KHA CITY 24 TYPE III - 076526

Sources

LED 20 W
KHA CITY 24 TYPE V

KHA CITY 24 TYPE V

Optic | Circular Extra-Wide
  • Pathway bollard series. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free (<1%) precision die-cast aluminum housing and top cap.
  • - Copper-free (<1%) aluminum extruded post.
  • - Corrosion-resistant AISI 316 stainless steel post and top cap.
  • - Clear UV-stabilized, high-impact resistant diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Internal specular reflector coated with 5-layers of PVD 99.98% pure aluminum providing >95% reflection.
  • - Black aluminum reflector provides full-cutoff, no glare design, and precision optical control (COMFORT options).
  • - ustom MCPCB utilized to maximize heat dissipation and promote long LED life.
  • - High-transparency polycarbonate optics for optimized light transmission.
  • - Type V light distribution.
  • - Input voltage: 120-277 V (50 / 60 Hz), integral 0-10 V dimming driver.
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Concrete installation fixing rods available (ordered separately).
  • - Bolt-on root galvanized steel direct burial or stainless steel flange plate (anchor plugs not included) floor mounting options available for all KHA CITY 24 options (ordered separately)
  • - Suitable for most coastal applications (stainless steel versions).
  • - Product meets Buy American Act (BAA) requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finishing Lampholder Wattage Voltage CRI Kelvin Optic Beam
angle		 Lightsource
lumen
output
[lm]		 Luminaire
lumen
output
[lm]		 L B Lifetime Downloads
High Power LEDS 120-277 V - Dimmable 0-10 V
076495 LED 23 W 120/277 V 80 3000 - - 3220 2313 L80 B10 220000 Download

Documentation: KHA CITY 24 TYPE V - 076495
076496 LED 23 W 120/277 V 80 3000 - - 3220 2313 L80 B10 220000 Download

Documentation: KHA CITY 24 TYPE V - 076496
076498 LED 23 W 120/277 V 80 4000 - - 3335 2434 L80 B10 220000 Download

Documentation: KHA CITY 24 TYPE V - 076498
076499 LED 23 W 120/277 V 80 4000 - - 3335 2434 L80 B10 220000 Download

Documentation: KHA CITY 24 TYPE V - 076499

Sources

LED 23 W
KHA CITY COMFORT 24 TYPE III

KHA CITY COMFORT 24 TYPE III

Optic | Asymmetric Medium
  • Pathway bollard series. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free (<1%) precision die-cast aluminum housing and top cap.
  • - Copper-free (<1%) aluminum extruded post.
  • - Corrosion-resistant AISI 316 stainless steel post and top cap.
  • - Clear UV-stabilized, high-impact resistant diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Internal specular reflector coated with 5-layers of PVD 99.98% pure aluminum providing >95% reflection.
  • - Black aluminum reflector provides full-cutoff, no glare design, and precision optical control (COMFORT options).
  • - ustom MCPCB utilized to maximize heat dissipation and promote long LED life.
  • - High-transparency polycarbonate optics for optimized light transmission.
  • - Type III light distribution.
  • - Input voltage: 120-277 V (50 / 60 Hz), integral 0-10 V dimming driver.
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Concrete installation fixing rods available (ordered separately).
  • - Bolt-on root galvanized steel direct burial or stainless steel flange plate (anchor plugs not included) floor mounting options available for all KHA CITY 24 options (ordered separately)
  • - Suitable for most coastal applications (stainless steel versions).
  • - Product meets Buy American Act (BAA) requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finishing Lampholder Wattage Voltage CRI Kelvin Optic Beam
angle		 Lightsource
lumen
output
[lm]		 Luminaire
lumen
output
[lm]		 L B Lifetime Downloads
High Power LEDS 120-277 V - Dimmable 0-10 V
076517 LED 20 W 120/277 V 80 3000 - - 2800 1290 L80 B10 80000 Download

Documentation: KHA CITY COMFORT 24 TYPE III - 076517
076518 LED 20 W 120/277 V 80 3000 - - 2800 1290 L80 B10 80000 Download

Documentation: KHA CITY COMFORT 24 TYPE III - 076518
076519 LED 20 W 120/277 V 80 4000 - - 2900 1345 L80 B10 80000 Download

Documentation: KHA CITY COMFORT 24 TYPE III - 076519
076520 LED 20 W 120/277 V 80 4000 - - 2900 1345 L80 B10 80000 Download

Documentation: KHA CITY COMFORT 24 TYPE III - 076520

Sources

LED 20 W
KHA CITY COMFORT 24 TYPE V

KHA CITY COMFORT 24 TYPE V

Optic | Circular Extra-Wide
  • Pathway bollard series. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free (<1%) precision die-cast aluminum housing and top cap.
  • - Copper-free (<1%) aluminum extruded post.
  • - Corrosion-resistant AISI 316 stainless steel post and top cap.
  • - Clear UV-stabilized, high-impact resistant diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Internal specular reflector coated with 5-layers of PVD 99.98% pure aluminum providing >95% reflection.
  • - Black aluminum reflector provides full-cutoff, no glare design, and precision optical control (COMFORT options).
  • - ustom MCPCB utilized to maximize heat dissipation and promote long LED life.
  • - High-transparency polycarbonate optics for optimized light transmission.
  • - Type V light distribution.
  • - Input voltage: 120-277 V (50 / 60 Hz), integral 0-10 V dimming driver.
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Concrete installation fixing rods available (ordered separately).
  • - Bolt-on root galvanized steel direct burial or stainless steel flange plate (anchor plugs not included) floor mounting options available for all KHA CITY 24 options (ordered separately)
  • - Suitable for most coastal applications (stainless steel versions).
  • - Product meets Buy American Act (BAA) requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finishing Lampholder Wattage Voltage CRI Kelvin Optic Beam
angle		 Lightsource
lumen
output
[lm]		 Luminaire
lumen
output
[lm]		 L B Lifetime Downloads
High Power LEDS 120-277 V - Dimmable 0-10 V
076513 LED 23 W 120/277 V 80 3000 - - 3220 1955 L80 B10 220000 Download

Documentation: KHA CITY COMFORT 24 TYPE V - 076513
076514 LED 23 W 120/277 V 80 3000 - - 3220 1955 L80 B10 220000 Download

Documentation: KHA CITY COMFORT 24 TYPE V - 076514
076515 LED 23 W 120/277 V 80 4000 - - 3335 2056 L80 B10 220000 Download

Documentation: KHA CITY COMFORT 24 TYPE V - 076515
076516 LED 23 W 120/277 V 80 4000 - - 3335 2056 L80 B10 220000 Download

Documentation: KHA CITY COMFORT 24 TYPE V - 076516

Sources

LED 23 W
KHA CITY MARINE 24 TYPE III

KHA CITY MARINE 24 TYPE III

Optic | Asymmetric Medium
  • Pathway bollard series. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free (<1%) precision die-cast aluminum housing and top cap.
  • - Copper-free (<1%) aluminum extruded post.
  • - Corrosion-resistant AISI 316 stainless steel post and top cap.
  • - Clear UV-stabilized, high-impact resistant diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Internal specular reflector coated with 5-layers of PVD 99.98% pure aluminum providing >95% reflection.
  • - Black aluminum reflector provides full-cutoff, no glare design, and precision optical control (COMFORT options).
  • - ustom MCPCB utilized to maximize heat dissipation and promote long LED life.
  • - High-transparency polycarbonate optics for optimized light transmission.
  • - Type III light distribution.
  • - Input voltage: 120-277 V (50 / 60 Hz), integral 0-10 V dimming driver.
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Concrete installation fixing rods available (ordered separately).
  • - Bolt-on root galvanized steel direct burial or stainless steel flange plate (anchor plugs not included) floor mounting options available for all KHA CITY 24 options (ordered separately)
  • - Suitable for most coastal applications (stainless steel versions).
  • - Product meets Buy American Act (BAA) requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finishing Lampholder Wattage Voltage CRI Kelvin Optic Beam
angle		 Lightsource
lumen
output
[lm]		 Luminaire
lumen
output
[lm]		 L B Lifetime Downloads
High Power LEDS 120-277 V - Dimmable 0-10 V
076524 LED 20 W 120/277 V 80 3000 - - 2800 1474 L80 B10 80000 Download

Documentation: KHA CITY MARINE 24 TYPE III - 076524
076527 LED 20 W 120/277 V 80 4000 - - 2900 1538 L80 B10 80000 Download

Documentation: KHA CITY MARINE 24 TYPE III - 076527

Sources

LED 20 W
KHA CITY MARINE 24 TYPE V

KHA CITY MARINE 24 TYPE V

Optic | Circular Extra-Wide
  • Pathway bollard series. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free (<1%) precision die-cast aluminum housing and top cap.
  • - Copper-free (<1%) aluminum extruded post.
  • - Corrosion-resistant AISI 316 stainless steel post and top cap.
  • - Clear UV-stabilized, high-impact resistant diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Internal specular reflector coated with 5-layers of PVD 99.98% pure aluminum providing >95% reflection.
  • - Black aluminum reflector provides full-cutoff, no glare design, and precision optical control (COMFORT options).
  • - ustom MCPCB utilized to maximize heat dissipation and promote long LED life.
  • - High-transparency polycarbonate optics for optimized light transmission.
  • - Type V light distribution.
  • - Input voltage: 120-277 V (50 / 60 Hz), integral 0-10 V dimming driver.
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Concrete installation fixing rods available (ordered separately).
  • - Bolt-on root galvanized steel direct burial or stainless steel flange plate (anchor plugs not included) floor mounting options available for all KHA CITY 24 options (ordered separately)
  • - Suitable for most coastal applications (stainless steel versions).
  • - Product meets Buy American Act (BAA) requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finishing Lampholder Wattage Voltage CRI Kelvin Optic Beam
angle		 Lightsource
lumen
output
[lm]		 Luminaire
lumen
output
[lm]		 L B Lifetime Downloads
High Power LEDS 120-277 V - Dimmable 0-10 V
076497 LED 23 W 120/277 V 80 3000 - - 3220 2313 L80 B10 220000 Download

Documentation: KHA CITY MARINE 24 TYPE V - 076497
076521 LED 23 W 120/277 V 80 4000 - - 3335 2434 L80 B10 220000 Download

Documentation: KHA CITY MARINE 24 TYPE V - 076521

Sources

LED 23 W

Product Family

KHA CITY 12 KHA CITY 12
to top
Request information
Products search
You can search for products in our catalog by entering here the name or the code of the product or accessory.
