SHIELD+ 1

IN
  • Long-lasting energy-efficient wall pack series. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free precision die-cast aluminum housing and mounting plate.
  • - Extra-clear, flat, tempered silk-screened soda-lime glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - High-efficiency COB, combined with an optimized passive cooling system, provides a long LED life.
  • - Specular vacuum metallized polycarbonate reflector provides full-cutoff, no glare design, and precision optical control.
  • - IESNA Type III light distribution.
  • - Input voltage: 120-277 V (50 / 60 Hz), integral 1-10 V dimming driver.
  • - Field settable integral tri-level lumen/wattage packages proprietary DIP switch driver for SHIELD+ 1 (stating factory setting at the lowest level).
  • - Standard knock-out template for multiple junction box mounting options.
  • - Suitable for three surface mounted conduit entry points with 1/2" NPS plugs.
  • - BUTTON and SWIVEL photoelectric switch options available (ordered separately).
  • - Consult factory for dimming options, custom finishes (please specify RAL color), and non-cataloged CCT (Kelvin) options.
  • - Consult factory for remote emergency battery pack options (EMPK).
  • - Product meets Buy American Act requirements within ARRA.
  • - 5-year warranty.
SHIELD+1 TYPE III

SHIELD+1 TYPE III

Asymmetric extra wide reflector
  • Long-lasting energy-efficient wall pack series. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free precision die-cast aluminum housing and mounting plate.
  • - Extra-clear, flat, tempered silk-screened soda-lime glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - High-efficiency COB, combined with an optimized passive cooling system, provides a long LED life.
  • - Specular vacuum metallized polycarbonate reflector provides full-cutoff, no glare design, and precision optical control.
  • - IESNA Type III light distribution.
  • - Input voltage: 120-277 V (50 / 60 Hz), integral 1-10 V dimming driver.
  • - Field settable integral tri-level lumen/wattage packages proprietary DIP switch driver for SHIELD+ 1 (stating factory setting at the lowest level).
  • - Standard knock-out template for multiple junction box mounting options.
  • - Suitable for three surface mounted conduit entry points with 1/2" NPS plugs.
  • - BUTTON and SWIVEL photoelectric switch options available (ordered separately).
  • - Consult factory for dimming options, custom finishes (please specify RAL color), and non-cataloged CCT (Kelvin) options.
  • - Consult factory for remote emergency battery pack options (EMPK).
  • - Product meets Buy American Act requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finish Lampholder Wattage Voltage CRI Kelvin Optic Optic
Beam		 Lightsource
lumen
output		 Luminaire
lumen
output		 L B Lifetime Download
High Power LEDS 120-277 V - Dimmable 1-10 V
070440 LED 13.5/18.5/27 W 120-277 V 50/60 Hz 80 4000 - - 3605 3072 L80 B10 200000 Download

Documentation: SHIELD+1 TYPE III - 070440
070441 LED 13.5/18.5/27 W 120-277 V 50/60 Hz 80 4000 - - 3605 3072 L80 B10 200000 Download

Documentation: SHIELD+1 TYPE III - 070441
070442 LED 13.5/18.5/27 W 120-277 V 50/60 Hz 80 4000 - - 3605 3072 L80 B10 200000 Download

Documentation: SHIELD+1 TYPE III - 070442
070443 LED 13.5/18.5/27 W 120-277 V 50/60 Hz 80 4000 - - 3605 3072 L80 B10 200000 Download

Documentation: SHIELD+1 TYPE III - 070443

Sources

LED 13.5/18.5/27 W
