ALU TECH RV

Recessed wall steplight series. Fixtures consist of:
- Multi-step powder-coat painting process, optimized against UV rays and corrosion.
- Copper-free (<1%) precision machined anodized aluminum housing and optical compartment.
- Frosted, tempered, silk-screened, flat glass diffuser.
- Custom molded, anti-aging gasket(s).
- Custom MCPCB utilized to maximize heat dissipation and promote long LED life.
- Type III light distribution.
- Input voltage: 120-277 V (50 / 60 Hz), integral driver.
- Pre-wired factory sealed cable for external electrical connection included.
- Stainless steel grounding tether included.
- The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
- Stainless steel recessed rough-in kit to be ordered separately.
- 5-year warranty.
- Contact factory for any Buy American Act (BAA) or Build America Buy America Act (BABAA) requirements.

Optic | Asymmetric Wide

Recessed wall steplight series. Fixtures consist of:
- Multi-step powder-coat painting process, optimized against UV rays and corrosion.
- Copper-free (<1%) precision machined anodized aluminum housing and optical compartment.
- Frosted, tempered, silk-screened, flat glass diffuser.
- Custom molded, anti-aging gasket(s).
- Custom MCPCB utilized to maximize heat dissipation and promote long LED life.
- Type III light distribution.
- Input voltage: 120-277 V (50 / 60 Hz), integral driver.
- Pre-wired factory sealed cable for external electrical connection included.
- Stainless steel grounding tether included.
- Stainless steel recessed rough-in kit to be ordered separately.
- The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
- Contact factory for any Buy American Act (BAA) or Build America Buy America Act (BABAA) requirements.
- 5-year warranty.

Product codes

Part number	Lampholder	Wattage	Voltage	CRI	Kelvin	Optic	Beam angle	Lightsource lumen output [lm]	Luminaire lumen output [lm]	L	B	Lifetime	Downloads
Mid Power LEDS 120-277 V
074680	LED	6 W	120/277 V	85	3000	-	-	612	207	-	-	35000	Documentation: ALU TECH RV - 074680
074682	LED	6 W	120/277 V	85	4000	-	-	632	212	-	-	35000	Documentation: ALU TECH RV - 074682

Sources

LED

6 W
