SQUARE +2

IN
  • Long-lasting energy-efficient architectural, landscape and professional flood light series. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free precision die-cast aluminum housing and ring/faceplate.
  • - Extra-clear, flat, tempered silk-screened soda-lime glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Custom MCPCB utilized to maximize heat dissipation and promote a long LED life.
  • - High-transmittance transparent optics.
  • - IESNA Type II light distribution.
  • - IESNA Type III light distribution.
  • - IESNA Type IV light distribution.
  • - Integral surge protector can withstand up to 10 kV transient line surge.
  • - Input voltage: 120-277 V (50 / 60 Hz), integral 0-10 V dimming driver.
  • - Standard cable gland and graduated ferrule allow for a cable (Ø0.35” - Ø0.55”) to be wired inside the fixtures and retain its IP66 rating.
  • - Consult factory for dimming options, custom finishes, and non-cataloged CCT (Kelvin) options.
  • - Consult factory for custom pre-wired factory sealed cable length options.
  • - Consult factory for custom optics options.
  • - Consult factory for pole information.
  • - Matching junction box plate optional accessory available (ordered separately).
  • - Range of accessories, including posts and painted aluminum arms, suitable for a variety of configurations for diverse settings (parks, gardens, pedestrian areas, squares, parking areas, etc.) available (ordered separately).
  • - For the 210 W versions, up-light installation is permitted outdoors only.
  • - Product meets Buy American Act requirements within ARRA.
  • - 5-year warranty.
  • Long-lasting energy-efficient architectural, landscape and professional flood light series. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free precision die-cast aluminum housing and ring/faceplate.
  • - Extra-clear, flat, tempered silk-screened soda-lime glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Custom MCPCB utilized to maximize heat dissipation and promote a long LED life.
  • - High-transmittance transparent optics.
  • - IESNA Type II light distribution.
  • - Input voltage: 120-277 V (50 / 60 Hz), integral driver.
  • - Integral surge protector can withstand up to 10 kV transient line surge.
  • - Standard cable gland and graduated ferrule allow for a cable (Ø0.35” - Ø0.55”) to be wired inside the fixtures and retain its IP66 rating.
  • - Range of accessories, including posts and painted aluminum arms, suitable for a variety of configurations for diverse settings (parks, gardens, pedestrian areas, squares, parking areas, etc.) available (ordered separately).
  • - For the 210 W versions, up-light installation is permitted outdoors only.
  • - Consult factory for dimming options, custom finishes, and non-cataloged CCT (Kelvin) options.
  • - Consult factory for custom pre-wired factory sealed cable length options.
  • - Consult factory for custom optics options.
  • - Consult factory for pole information.
  • - Product meets Buy American Act requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finish Lampholder Wattage Voltage CRI Kelvin Optic Optic
Beam
Lightsource
lumen
output
Luminaire
lumen
output
L B Lifetime Download
High Power LEDS 120-277 V
071776 LED 210 W 120-277 V 70 4000 Type II - 26700 22999 L70 B10 55000 Download

Documentation: SQUARE +2 TYPE II - 071776

071778 LED 139 W 120-277 V 70 4000 Type II - 17800 15483 L70 B10 55000 Download

Documentation: SQUARE +2 TYPE II - 071778

Sources

LED 210 W
LED 139 W
  • Long-lasting energy-efficient architectural, landscape and professional flood light series. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free precision die-cast aluminum housing and ring/faceplate.
  • - Extra-clear, flat, tempered silk-screened soda-lime glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Custom MCPCB utilized to maximize heat dissipation and promote a long LED life.
  • - High-transmittance transparent optics.
  • - IESNA Type III light distribution.
  • - Input voltage: 120-277 V (50 / 60 Hz), integral driver.
  • - Integral surge protector can withstand up to 10 kV transient line surge.
  • - Standard cable gland and graduated ferrule allow for a cable (Ø0.35” - Ø0.55”) to be wired inside the fixtures and retain its IP66 rating.
  • - Range of accessories, including posts and painted aluminum arms, suitable for a variety of configurations for diverse settings (parks, gardens, pedestrian areas, squares, parking areas, etc.) available (ordered separately).
  • - For the 210 W versions, up-light installation is permitted outdoors only.
  • - Consult factory for dimming options, custom finishes, and non-cataloged CCT (Kelvin) options.
  • - Consult factory for custom pre-wired factory sealed cable length options.
  • - Consult factory for custom optics options.
  • - Consult factory for pole information.
  • - Product meets Buy American Act requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finish Lampholder Wattage Voltage CRI Kelvin Optic Optic
Beam
Lightsource
lumen
output
Luminaire
lumen
output
L B Lifetime Download
High Power LEDS 120-277 V
071780 LED 210 W 120-277 V 70 4000 Type III - 26700 22033 L70 B10 55000 Download

Documentation: SQUARE +2 TYPE III - 071780

071782 LED 139 W 120-277 V 70 4000 Type III - 17800 15082 L70 B10 55000 Download

Documentation: SQUARE +2 TYPE III - 071782

Sources

LED 210 W
LED 139 W
  • Long-lasting energy-efficient architectural, landscape and professional flood light series. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free precision die-cast aluminum housing and ring/faceplate.
  • - Extra-clear, flat, tempered silk-screened soda-lime glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Custom MCPCB utilized to maximize heat dissipation and promote a long LED life.
  • - High-transmittance transparent optics.
  • - IESNA Type IV light distribution.
  • - Input voltage: 120-277 V (50 / 60 Hz), integral driver.
  • - Integral surge protector can withstand up to 10 kV transient line surge.
  • - Standard cable gland and graduated ferrule allow for a cable (Ø0.35” - Ø0.55”) to be wired inside the fixtures and retain its IP66 rating.
  • - Range of accessories, including posts and painted aluminum arms, suitable for a variety of configurations for diverse settings (parks, gardens, pedestrian areas, squares, parking areas, etc.) available (ordered separately).
  • - For the 210 W versions, up-light installation is permitted outdoors only.
  • - Consult factory for dimming options, custom finishes, and non-cataloged CCT (Kelvin) options.
  • - Consult factory for custom pre-wired factory sealed cable length options.
  • - Consult factory for custom optics options.
  • - Consult factory for pole information.
  • - Product meets Buy American Act requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finish Lampholder Wattage Voltage CRI Kelvin Optic Optic
Beam
Lightsource
lumen
output
Luminaire
lumen
output
L B Lifetime Download
High Power LEDS 120-277 V
071784 LED 210 W 120-277 V 70 4000 Type IV - 26700 22099 L70 B10 55000 Download

Documentation: SQUARE +2 TYPE IV - 071784

071786 LED 139 W 120-277 V 70 4000 Type IV - 17800 15013 L70 B10 55000 Download

Documentation: SQUARE +2 TYPE IV - 071786

Sources

LED 210 W
LED 139 W
