Coastal for good
KHA CITY are contemporary high-performance bollards and light poles, combining style with a robust design manufactured in high-quality materials and finishing. KHA CITY products provide functional and dramatic effect lighting with aesthetics suitable for entrances, paths, walkways, courtyards, gardens, public areas, and security lighting. Consult factory for more options such as individual heights and house side shield options. Also available are COMFORT and MARINE options.
Design coordinated area lighting column and bollard series. Fixtures consist of:
Construction
  • Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • Corrosion-resistant AISI 316 stainless steel post and top cap.
  • Copper-free precision die-cast aluminum housing, top cap and copper-free aluminum extruded post (Iron Gray and Textured Black versions).
  • Custom MCPCB utilized to maximize heat dissipation and promote long LED life.
  • High-transparency polycarbonate optics for optimized light transmission.
  • Internal specular reflector coated with 5-layers of PVD 99.98% pure aluminum providing >95% reflection.
  • Black aluminum reflector provides full-cutoff, no glare design, and precision optical control (COMFORT options).
  • Clear UV-stabilized, high-impact resistant diffuser.
  • Custom molded, anti-aging gasket(s).
  • Stainless steel external hardware.
Installation
  • Available in two standard heights: 47” and 8’. Custom heights available upon request.
  • Anchor bolts available for bollards (ordered separately).
  • Suitable for most coastal applications (stainless steel versions).
  • Steel ground base plate included for bollards.
Optics
  • Type III light distribution.
  • Type V light distribution.
Electrical
  • Input voltage: 120-277 V (50 / 60 Hz), integral 0-10 V dimming driver.
  • 347/480V input options available.
Options
  • The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • Concrete installation fixing rods available (ordered separately).
Listings
  • UL Wet location listed. IP66 rated.
  • Product meets Buy American Act (BAA) requirements within ARRA.
  • Photometric data measured according to UNI EN 13032-1/4 and IES LM-79-08
  • Actual performance may differ as a result of the end-user environment and application. All values are design or typical values, measured under laboratory conditions at 25 °C. Specifications are subject to change without notice.
Warranty
  • 5-year limited warranty. Complete warranty terms located at www.performanceinlighting.com
