CRICKET+ 10

IN
  • In-ground series. Fixtures consist of:
  • - Copper-free die-cast corrosion-resistant aluminum housing and trim.
  • - Copper-free die-cast corrosion-resistant aluminum housing.
  • - AISI 316 stainless steel trim.
  • - Extra-clear, tempered, silk-screened, flat glass diffuser.
  • - Frosted, tempered, silk-screened, flat glass diffuser (C/EW versions).
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Custom MCPCB utilized to maximize heat dissipation and promote long LED life.
  • - High-transmittance transparent optics.
  • - Circular Intensive beam angle (C/I).
  • - Circular Medium beam angle (C/M).
  • - Diffuse light emission (C/EW).
  • - Input voltage: 120-277 V (50 / 60 Hz), integral driver.
  • - Pre-wired factory sealed cable for external electrical connection included.
  • - Each rough-in kit is provided with a protective faceplate to avoid possible deformations during the installation in concrete to simplify installation.
  • - Thermoplastic compression-molded rough-in kit to be ordered separately.
  • - For outdoor inground applications, provide drainage gravel at least 12" below the rough-in or a suitable drainage system.
  • - Frosted (FRST) and Non-Slip (NS) glass option available - add suffix to any part number.
  • - Consult factory for additional optic options.
  • - Consult factory for dimming options, marine-grade, custom finishes (please specify RAL color), and non-cataloged CCT (Kelvin) options including static colors.
  • - Product meets Buy American Act requirements within ARRA.
  • - 5-year warranty.
  • In-ground series. Fixtures consist of:
  • - Copper-free die-cast corrosion-resistant aluminum housing and trim.
  • - Copper-free die-cast corrosion-resistant aluminum housing.
  • - AISI 316 stainless steel trim.
  • - Frosted, tempered, silk-screened, flat glass diffuser (C/EW versions).
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Custom MCPCB utilized to maximize heat dissipation and promote long LED life.
  • - High-transmittance transparent optics.
  • - Diffuse light emission (C/EW).
  • - Input voltage: 120-277 V (50 / 60 Hz), integral driver.
  • - Pre-wired factory sealed cable for external electrical connection included.
  • - Each rough-in kit is provided with a protective faceplate to avoid possible deformations during the installation in concrete to simplify installation.
  • - Thermoplastic compression-molded rough-in kit to be ordered separately.
  • - For outdoor inground applications, provide drainage gravel at least 12" below the rough-in or a suitable drainage system.
  • - Frosted (FRST) and Non-Slip (NS) glass option available - add suffix to any part number.
  • - Consult factory for additional optic options.
  • - Five optional finishes available. Add finish suffix to any part number for textured Black (BK-81), Iron gray (AN-96), Aluminum metallic (GR-94), White (WH-87), Iron rust (RB-10) when not standard.
  • - Consult factory for dimming options, marine-grade, custom finishes (please specify RAL color), and non-cataloged CCT (Kelvin) options including static colors.
  • - Product meets Buy American Act requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finish Lampholder Wattage Voltage CRI Kelvin Optic Optic
Beam
Lightsource
lumen
output
Luminaire
lumen
output
L B Lifetime Download
High Power LEDS 120-277 V
073075 LED 6 W 100/277 V 80 3000 - 88° 475 258 L90 B10 94000 Download

Documentation: CRICKET+ 10 C/EW - 073075

073076 LED 6 W 100/277 V 80 3000 - 88° 475 258 L90 B10 94000 Download

Documentation: CRICKET+ 10 C/EW - 073076

073081 LED 6 W 100/277 V 80 4000 - 88° 475 277 L90 B10 94000 Download

Documentation: CRICKET+ 10 C/EW - 073081

073082 LED 6 W 100/277 V 80 4000 - 88° 475 277 L90 B10 94000 Download

Documentation: CRICKET+ 10 C/EW - 073082

Sources

LED 6 W
  • In-ground series. Fixtures consist of:
  • - Copper-free die-cast corrosion-resistant aluminum housing and trim.
  • - Copper-free die-cast corrosion-resistant aluminum housing.
  • - AISI 316 stainless steel trim.
  • - Extra-clear, tempered, silk-screened, flat glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Custom MCPCB utilized to maximize heat dissipation and promote long LED life.
  • - High-transmittance transparent optics.
  • - Circular Intensive beam angle (C/I).
  • - Input voltage: 120-277 V (50 / 60 Hz), integral driver.
  • - Pre-wired factory sealed cable for external electrical connection included.
  • - Each rough-in kit is provided with a protective faceplate to avoid possible deformations during the installation in concrete to simplify installation.
  • - Thermoplastic compression-molded rough-in kit to be ordered separately.
  • - For outdoor inground applications, provide drainage gravel at least 12" below the rough-in or a suitable drainage system.
  • - Frosted (FRST) and Non-Slip (NS) glass option available - add suffix to any part number.
  • - Consult factory for additional optic options.
  • - Five optional finishes available. Add finish suffix to any part number for textured Black (BK-81), Iron gray (AN-96), Aluminum metallic (GR-94), White (WH-87), Iron rust (RB-10) when not standard.
  • - Consult factory for dimming options, marine-grade, custom finishes (please specify RAL color), and non-cataloged CCT (Kelvin) options including static colors.
  • - Product meets Buy American Act requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finish Lampholder Wattage Voltage CRI Kelvin Optic Optic
Beam
Lightsource
lumen
output
Luminaire
lumen
output
L B Lifetime Download
High Power LEDS 120-277 V
073071 LED 6 W 100/277 V 80 3000 - 475 415 L90 B10 94000 Download

Documentation: CRICKET+ 10 C/I - 073071

073072 LED 6 W 100/277 V 80 3000 - 475 415 L90 B10 94000 Download

Documentation: CRICKET+ 10 C/I - 073072

073077 LED 6 W 100/277 V 80 4000 - 475 446 L90 B10 94000 Download

Documentation: CRICKET+ 10 C/I - 073077

073078 LED 6 W 100/277 V 80 4000 - 475 446 L90 B10 94000 Download

Documentation: CRICKET+ 10 C/I - 073078

Sources

LED 6 W
  • In-ground series. Fixtures consist of:
  • - Copper-free die-cast corrosion-resistant aluminum housing and trim.
  • - Copper-free die-cast corrosion-resistant aluminum housing.
  • - AISI 316 stainless steel trim.
  • - Extra-clear, tempered, silk-screened, flat glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Custom MCPCB utilized to maximize heat dissipation and promote long LED life.
  • - High-transmittance transparent optics.
  • - Circular Medium beam angle (C/M).
  • - Input voltage: 120-277 V (50 / 60 Hz), integral driver.
  • - Pre-wired factory sealed cable for external electrical connection included.
  • - Each rough-in kit is provided with a protective faceplate to avoid possible deformations during the installation in concrete to simplify installation.
  • - Thermoplastic compression-molded rough-in kit to be ordered separately.
  • - For outdoor inground applications, provide drainage gravel at least 12" below the rough-in or a suitable drainage system.
  • - Frosted (FRST) and Non-Slip (NS) glass option available - add suffix to any part number.
  • - Consult factory for additional optic options.
  • - Five optional finishes available. Add finish suffix to any part number for textured Black (BK-81), Iron gray (AN-96), Aluminum metallic (GR-94), White (WH-87), Iron rust (RB-10) when not standard.
  • - Consult factory for dimming options, marine-grade, custom finishes (please specify RAL color), and non-cataloged CCT (Kelvin) options including static colors.
  • - Product meets Buy American Act requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finish Lampholder Wattage Voltage CRI Kelvin Optic Optic
Beam
Lightsource
lumen
output
Luminaire
lumen
output
L B Lifetime Download
High Power LEDS 120-277 V
073073 LED 6 W 100/277 V 80 3000 - 30° 475 406 L90 B10 94000 Download

Documentation: CRICKET+ 10 C/M - 073073

073074 LED 6 W 100/277 V 80 3000 - 30° 475 406 L90 B10 94000 Download

Documentation: CRICKET+ 10 C/M - 073074

073079 LED 6 W 100/277 V 80 4000 - 30° 475 436 L90 B10 94000 Download

Documentation: CRICKET+ 10 C/M - 073079

073080 LED 6 W 100/277 V 80 4000 - 30° 475 436 L90 B10 94000 Download

Documentation: CRICKET+ 10 C/M - 073080

Sources

LED 6 W
