CRICKET+ 15

IN
  • In-ground series. Fixtures consist of:
  • - Copper-free die-cast corrosion-resistant aluminum housing and trim.
  • - Copper-free die-cast corrosion-resistant aluminum AISI 316 stainless steel covered trim.
  • - Extra-clear, tempered, silk-screened, flat glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Custom MCPCB utilized to maximize heat dissipation and promote long LED life.
  • - High-transmittance transparent optics.
  • - Circular Intensive beam angle (C/I).
  • - Circular Medium beam angle (C/M).
  • - Asymmetric Wallwasher light distribution (A5/W).
  • - Input voltage: 120-277 V (50 / 60 Hz), integral 0-10 V dimming driver.
  • - Pre-wired cable connects luminaire with WATER-STOP connection system, suitable for through wiring. Included cable glands accept cables from Ø0.35" up to Ø0.63".
  • - Each rough-in kit is provided with a protective faceplate to avoid possible deformations during the installation in concrete to simplify installation.
  • - Thermoplastic compression-molded rough-in kit to be ordered separately.
  • - For outdoor inground applications, provide drainage gravel at least 12" below the rough-in or a suitable drainage system.
  • - Frosted (FRST) and Non-Slip (NS) glass option available - add suffix to any part number.
  • - Consult factory for additional optic options.
  • - Consult factory for dimming options, marine-grade, custom finishes (please specify RAL color), and non-cataloged CCT (Kelvin) options including static colors.
  • - Product meets Buy American Act requirements within ARRA.
  • - 5-year warranty.
CRICKET+ 15 A/M

CRICKET+ 15 A/M

Asymmetric medium reflector
  • In-ground series. Fixtures consist of:
  • - Copper-free die-cast corrosion-resistant aluminum housing and trim.
  • - Copper-free die-cast corrosion-resistant aluminum AISI 316 stainless steel covered trim.
  • - Extra-clear, tempered, silk-screened, flat glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Custom MCPCB utilized to maximize heat dissipation and promote long LED life.
  • - High-transmittance transparent optics.
  • - Asymmetric Wallwasher light distribution (A5/W).
  • - Input voltage: 120-277 V (50 / 60 Hz), integral 0-10 V dimming driver.
  • - Pre-wired cable connects luminaire with WATER-STOP connection system, suitable for through wiring. Included cable glands accept cables from Ø0.35" up to Ø0.63".
  • - Each rough-in kit is provided with a protective faceplate to avoid possible deformations during the installation in concrete to simplify installation.
  • - Thermoplastic compression-molded rough-in kit to be ordered separately.
  • - For outdoor inground applications, provide drainage gravel at least 12" below the rough-in or a suitable drainage system.
  • - Frosted (FRST) and Non-Slip (NS) glass option available - add suffix to any part number.
  • - Consult factory for additional optic options.
  • - Five optional finishes available. Add finish suffix to any part number for textured Black (BK-81), Iron gray (AN-96), Aluminum metallic (GR-94), White (WH-87), Iron rust (RB-10) when not standard.
  • - Consult factory for dimming options, marine-grade, custom finishes (please specify RAL color), and non-cataloged CCT (Kelvin) options including static colors.
  • - Product meets Buy American Act requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finish Lampholder Wattage Voltage CRI Kelvin Optic Optic
Beam		 Lightsource
lumen
output		 Luminaire
lumen
output		 L B Lifetime Download
High Power LEDS 120-277 V - Dimmable 0-10 V
073105 LED 14 W 100/277 V 80 3000 - 30° 1300 671 L90 B10 94000 Download

Documentation: CRICKET+ 15 A/M - 073105
073106 LED 14 W 100/277 V 80 3000 - 30° 1300 671 L90 B10 94000 Download

Documentation: CRICKET+ 15 A/M - 073106
073111 LED 14 W 100/277 V 80 4000 - 30° 1403 717 L90 B10 94000 Download

Documentation: CRICKET+ 15 A/M - 073111
073112 LED 14 W 100/277 V 80 4000 - 30° 1403 717 L90 B10 94000 Download

Documentation: CRICKET+ 15 A/M - 073112

Sources

LED 14 W
CRICKET+ 15 C/I

CRICKET+ 15 C/I

Intensive circle reflector
  • In-ground series. Fixtures consist of:
  • - Copper-free die-cast corrosion-resistant aluminum housing and trim.
  • - Copper-free die-cast corrosion-resistant aluminum AISI 316 stainless steel covered trim.
  • - Extra-clear, tempered, silk-screened, flat glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Custom MCPCB utilized to maximize heat dissipation and promote long LED life.
  • - High-transmittance transparent optics.
  • - Circular Intensive beam angle (C/I).
  • - Input voltage: 120-277 V (50 / 60 Hz), integral 0-10 V dimming driver.
  • - Pre-wired cable connects luminaire with WATER-STOP connection system, suitable for through wiring. Included cable glands accept cables from Ø0.35" up to Ø0.63".
  • - Each rough-in kit is provided with a protective faceplate to avoid possible deformations during the installation in concrete to simplify installation.
  • - Thermoplastic compression-molded rough-in kit to be ordered separately.
  • - For outdoor inground applications, provide drainage gravel at least 12" below the rough-in or a suitable drainage system.
  • - Frosted (FRST) and Non-Slip (NS) glass option available - add suffix to any part number.
  • - Consult factory for additional optic options.
  • - Five optional finishes available. Add finish suffix to any part number for textured Black (BK-81), Iron gray (AN-96), Aluminum metallic (GR-94), White (WH-87), Iron rust (RB-10) when not standard.
  • - Consult factory for dimming options, marine-grade, custom finishes (please specify RAL color), and non-cataloged CCT (Kelvin) options including static colors.
  • - Product meets Buy American Act requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finish Lampholder Wattage Voltage CRI Kelvin Optic Optic
Beam		 Lightsource
lumen
output		 Luminaire
lumen
output		 L B Lifetime Download
High Power LEDS 120-277 V - Dimmable 0-10 V
073101 LED 14 W 100/277 V 80 3000 - 8° 1300 1000 L90 B10 94000 Download

Documentation: CRICKET+ 15 C/I - 073101
073102 LED 14 W 100/277 V 80 3000 - 8° 1300 1000 L90 B10 94000 Download

Documentation: CRICKET+ 15 C/I - 073102
073107 LED 14 W 100/277 V 80 4000 - 8° 1403 1069 L90 B10 94000 Download

Documentation: CRICKET+ 15 C/I - 073107
073108 LED 14 W 100/277 V 80 4000 - 8° 1403 1069 L90 B10 94000 Download

Documentation: CRICKET+ 15 C/I - 073108

Sources

LED 14 W
CRICKET+ 15 C/M

CRICKET+ 15 C/M

Medium circle reflector
  • In-ground series. Fixtures consist of:
  • - Copper-free die-cast corrosion-resistant aluminum housing and trim.
  • - Copper-free die-cast corrosion-resistant aluminum AISI 316 stainless steel covered trim.
  • - Extra-clear, tempered, silk-screened, flat glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Custom MCPCB utilized to maximize heat dissipation and promote long LED life.
  • - High-transmittance transparent optics.
  • - Circular Medium beam angle (C/M).
  • - Input voltage: 120-277 V (50 / 60 Hz), integral 0-10 V dimming driver.
  • - Pre-wired cable connects luminaire with WATER-STOP connection system, suitable for through wiring. Included cable glands accept cables from Ø0.35" up to Ø0.63".
  • - Each rough-in kit is provided with a protective faceplate to avoid possible deformations during the installation in concrete to simplify installation.
  • - Thermoplastic compression-molded rough-in kit to be ordered separately.
  • - For outdoor inground applications, provide drainage gravel at least 12" below the rough-in or a suitable drainage system.
  • - Frosted (FRST) and Non-Slip (NS) glass option available - add suffix to any part number.
  • - Consult factory for additional optic options.
  • - Five optional finishes available. Add finish suffix to any part number for textured Black (BK-81), Iron gray (AN-96), Aluminum metallic (GR-94), White (WH-87), Iron rust (RB-10) when not standard.
  • - Consult factory for dimming options, marine-grade, custom finishes (please specify RAL color), and non-cataloged CCT (Kelvin) options including static colors.
  • - Product meets Buy American Act requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finish Lampholder Wattage Voltage CRI Kelvin Optic Optic
Beam		 Lightsource
lumen
output		 Luminaire
lumen
output		 L B Lifetime Download
High Power LEDS 120-277 V - Dimmable 0-10 V
073103 LED 14 W 100/277 V 80 3000 - 30° 1300 1125 L90 B10 94000 Download

Documentation: CRICKET+ 15 C/M - 073103
073104 LED 14 W 100/277 V 80 3000 - 30° 1300 1125 L90 B10 94000 Download

Documentation: CRICKET+ 15 C/M - 073104
073109 LED 14 W 100/277 V 80 4000 - 30° 1403 1203 L90 B10 94000 Download

Documentation: CRICKET+ 15 C/M - 073109
073110 LED 14 W 100/277 V 80 4000 - 30° 1403 1203 L90 B10 94000 Download

Documentation: CRICKET+ 15 C/M - 073110

Sources

LED 14 W
