INDEX+

  • Pathway bollard series. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free (<1%) precision die-cast aluminum and top cap.
  • - Copper-free (<1%) aluminum extruded post.
  • - Clear UV-stabilized, high-impact resistant diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - ustom MCPCB utilized to maximize heat dissipation and promote long LED life.
  • - High-transparency polycarbonate optics for optimized light transmission.
  • - Type V light distribution.
  • - Input voltage: 120-277 V (50 / 60 Hz), integral 0-10 V dimming driver.
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - nchor bolts available for bollards (ordered separately).
  • - Product meets Buy American Act (BAA) requirements within ARRA.
  • - 5-year warranty.
  • - Patent optical system IN SIDEIS®
  • Pathway bollard series. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free (<1%) precision die-cast aluminum housing and top cap.
  • - Copper-free (<1%) aluminum extruded post.
  • - Clear UV-stabilized, high-impact resistant diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - ustom MCPCB utilized to maximize heat dissipation and promote long LED life.
  • - High-transparency polycarbonate optics for optimized light transmission.
  • - Type V light distribution.
  • - Input voltage: 120-277 V (50 / 60 Hz), integral 0-10 V dimming driver.
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - nchor bolts available for bollards (ordered separately).
  • - Product meets Buy American Act (BAA) requirements within ARRA.
  • - 5-year warranty.
  • - Patent optical system IN SIDEIS®
Product codes
Part number Finishing Lampholder Wattage Voltage CRI Kelvin Optic Beam
angle
Lightsource
lumen
output
[lm]
Luminaire
lumen
output
[lm]
L B Lifetime Downloads
Mid Power LEDS 120-277 V - Dimmable 0-10 V
074151 LED 13 W 120/277 V 80 3000 - - 2130 1547 L70 B10 147000 Download

Documentation: INDEX+ 46 C/EW - 074151

074153 LED 13 W 120/277 V 80 3000 - - 2130 1547 L70 B10 147000 Download

Documentation: INDEX+ 46 C/EW - 074153

074155 LED 13 W 120/277 V 80 4000 - - 2250 1605 L70 B10 147000 Download

Documentation: INDEX+ 46 C/EW - 074155

074157 LED 13 W 120/277 V 80 4000 - - 2250 1605 L70 B10 147000 Download

Documentation: INDEX+ 46 C/EW - 074157

Sources

LED 13 W
  • Pathway bollard series. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free (<1%) precision die-cast aluminum housing and top cap.
  • - Copper-free (<1%) aluminum extruded post.
  • - Clear UV-stabilized, high-impact resistant diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - ustom MCPCB utilized to maximize heat dissipation and promote long LED life.
  • - High-transparency polycarbonate optics for optimized light transmission.
  • - Type V light distribution.
  • - Input voltage: 120-277 V (50 / 60 Hz), integral 0-10 V dimming driver.
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - nchor bolts available for bollards (ordered separately).
  • - Product meets Buy American Act (BAA) requirements within ARRA.
  • - 5-year warranty.
  • - Patent optical system IN SIDEIS®
Product codes
Part number Finishing Lampholder Wattage Voltage CRI Kelvin Optic Beam
angle
Lightsource
lumen
output
[lm]
Luminaire
lumen
output
[lm]
L B Lifetime Downloads
Mid Power LEDS 120-277 V - Dimmable 0-10 V
074159 LED 13 W 120/277 V 80 3000 - - 2130 1547 L70 B10 147000 Download

Documentation: INDEX+ 86 C/EW - 074159

074161 LED 13 W 120/277 V 80 3000 - - 2130 1547 L70 B10 147000 Download

Documentation: INDEX+ 86 C/EW - 074161

074163 LED 13 W 120/277 V 80 4000 - - 2250 1605 L70 B10 147000 Download

Documentation: INDEX+ 86 C/EW - 074163

074165 LED 13 W 120/277 V 80 4000 - - 2250 1605 L70 B10 147000 Download

Documentation: INDEX+ 86 C/EW - 074165

074167 LED 18 W 120/277 V 80 3000 - - 2870 2049 L70 B10 147000 Download

Documentation: INDEX+ 86 C/EW - 074167

074169 LED 18 W 120/277 V 80 3000 - - 2870 2049 L70 B10 147000 Download

Documentation: INDEX+ 86 C/EW - 074169

074171 LED 18 W 120/277 V 80 4000 - - 3120 2120 L70 B10 147000 Download

Documentation: INDEX+ 86 C/EW - 074171

074173 LED 18 W 120/277 V 80 4000 - - 3120 2120 L70 B10 147000 Download

Documentation: INDEX+ 86 C/EW - 074173

Sources

LED 13 W
LED 18 W
