SPILLO

Area and site lighting series. Fixtures consist of:
- Multi-step powder-coat painting process, optimized against UV rays and corrosion.
- Copper-free (<1%) precision die-cast aluminum housing and top cap.
- Custom molded, anti-aging gasket(s).
- Stainless steel external hardware.
- Custom MCPCB utilized to maximize heat dissipation and promote long LED life.
- The "Secure Light Distribution" system can bypass individual diodes in the event of a single LED failure to ensure continuous uniform light distribution.
- Type II light distribution.
- Type V light distribution.
- Input voltage: 120-277 V (50 / 60 Hz), integral 0-10 V dimming driver.
- Pre-wired factory sealed cable for external electrical connection included.
- The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
- Ø3” and Ø4” post top adapters, and poles in 8’ / 10’ / 12 ’/ 14’ options available (ordered separately).
- Product meets Buy American Act (BAA) requirements within ARRA.
- 5-year warranty.

Area and site lighting series. Fixtures consist of:
- Multi-step powder-coat painting process, optimized against UV rays and corrosion.
- Copper-free (<1%) precision die-cast aluminum housing and top cap.
- Custom molded, anti-aging gasket(s).
- Stainless steel external hardware.
- Custom MCPCB utilized to maximize heat dissipation and promote long LED life.
- High-transparency polycarbonate optics for optimized light transmission.
- The "Secure Light Distribution" system can bypass individual diodes in the event of a single LED failure to ensure continuous uniform light distribution.
- Type II light distribution.
- Type V light distribution.
- Input voltage: 120-277 V (50 / 60 Hz), integral 0-10 V dimming driver.
- Pre-wired factory sealed cable for external electrical connection included.
- Ø3” and Ø4” post top adapters, and poles in 8’ / 10’ / 12 ’/ 14’ options available (ordered separately).
- The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
- Product meets Buy American Act (BAA) requirements within ARRA.
- 5-year warranty.

Product codes

Part number	Lampholder	Wattage	Voltage	CRI	Kelvin	Optic	Beam angle	Lightsource lumen output [lm]	Luminaire lumen output [lm]	L	B	Lifetime	Downloads
High Power LEDS 120-277 V Dimmable 0-10 V
071425	LED	65 W	120/277 V	70	3000	Type V	-	6104	4052	L90	-	60000	Documentation: SPILLO - 071425
071426	LED	65 W	120/277 V	70	4000	Type V	-	6972	4357	L90	-	60000	Documentation: SPILLO - 071426
071427	LED	65 W	120/277 V	70	3000	Type II	-	6104	4177	L90	-	60000	Documentation: SPILLO - 071427
071428	LED	65 W	120/277 V	70	4000	Type II	-	6972	4492	L90	-	60000	Documentation: SPILLO - 071428

Sources

LED

65 W
