AMON MAXI

IN
  • Lighting column series. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Robust copper-free extruded aluminum column profile and copper-free precision die-cast aluminum housing, trim, top cap, and inspection access door (MAXI versions only).
  • - Satin UV-stabilized, high-impact resistant diffuser (SOFT versions).
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Custom MCPCB utilized to maximize heat dissipation and promote a long LED life.
  • - IESNA Type V light distribution.
  • - Diffuse light emission (SOFT).
  • - Input voltage: 120-277 V (50 / 60 Hz), integral 0-10 V dimming driver.
  • - Integral surge protector can withstand up to 10 kV transient line surge.
  • - Painted aluminum wiring inspection access door included (MAXI versions only).
  • - Steel ground base plate included for bollards.
  • - Base cover, anchor bolts, and direct-burial support available for AMON MINI / MAXI (ordered separately).
  • - Consult factory for dimming options, custom finishes and non-cataloged CCT (Kelvin) options.
  • - Consult factory for custom post height options.
  • - 5-year warranty.
  • - Product meets Buy American requirements within ARRA.
Product codes
Part number Finish Lampholder Wattage Voltage CRI Kelvin Optic Optic
Beam
Lightsource
lumen
output
Luminaire
lumen
output
L B Lifetime Download
HIGH POWER LEDS 120-277 V DIMMABLE 0-10V
070251 LED 80 W 120-277V 80 4000 Type V - 7046 4144 L70 B10 50000 Download

Documentation: AMON MAXI SOFT TYPE V - 070251

070266 LED 80 W 120-277V 80 3000 Type V - 5885 3937 L70 B10 50000 Download

Documentation: AMON MAXI SOFT TYPE V - 070266

Sources

LED 80 W
  • Lighting column series. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Robust copper-free extruded aluminum column profile and copper-free precision die-cast aluminum housing, trim, top cap, and inspection access door (MAXI versions only).
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Extra-clear, flat, tempered silk screened soda-lime glass diffuser.
  • - Custom MCPCB utilized to maximize heat dissipation and promote a long LED life.
  • - High-transmittance transparent optics.
  • - IESNA Type I light distribution.
  • - Input voltage: 120-277 V (50 / 60 Hz), integral 0-10 V dimming driver.
  • - Integral surge protector can withstand up to 10 kV transient line surge.
  • - Painted aluminum wiring inspection access door included (MAXI versions only).
  • - Steel ground base plate included for bollards.
  • - Base cover, anchor bolts, and direct-burial support available for AMON MINI / MAXI (ordered separately).
  • - Consult factory for dimming options, custom finishes and non-cataloged CCT (Kelvin) options.
  • - Consult factory for custom post height options.
  • - 5-year warranty.
  • - Product meets Buy American requirements within ARRA.
Product codes
Part number Finish Lampholder Wattage Voltage CRI Kelvin Optic Optic
Beam
Lightsource
lumen
output
Luminaire
lumen
output
L B Lifetime Download
HIGH POWER LEDS 120-277 V DIMMABLE 0-10V
070248 LED 28 W 120-277V 80 4000 Type I - 3120 1526 L70 B10 80000 Download

Documentation: AMON MAXI TYPE I - 070248

070263 LED 28 W 120-277V 80 3000 Type I - 2850 1404 L70 B10 80000 Download

Documentation: AMON MAXI TYPE I - 070263

Sources

LED 28 W
  • Lighting column series. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Robust copper-free extruded aluminum column profile and copper-free precision die-cast aluminum housing, trim, top cap, and inspection access door (MAXI versions only).
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Extra-clear, flat, tempered silk screened soda-lime glass diffuser.
  • - Custom MCPCB utilized to maximize heat dissipation and promote a long LED life.
  • - High-transmittance transparent optics.
  • - IESNA Type II light distribution.
  • - Input voltage: 120-277 V (50 / 60 Hz), integral 0-10 V dimming driver.
  • - Integral surge protector can withstand up to 10 kV transient line surge.
  • - Painted aluminum wiring inspection access door included (MAXI versions only).
  • - Steel ground base plate included for bollards.
  • - Base cover, anchor bolts, and direct-burial support available for AMON MINI / MAXI (ordered separately).
  • - Consult factory for dimming options, custom finishes and non-cataloged CCT (Kelvin) options.
  • - Consult factory for custom post height options.
  • - 5-year warranty.
  • - Product meets Buy American requirements within ARRA.
Product codes
Part number Finish Lampholder Wattage Voltage CRI Kelvin Optic Optic
Beam
Lightsource
lumen
output
Luminaire
lumen
output
L B Lifetime Download
HIGH POWER LEDS 120-277 V DIMMABLE 0-10V
070249 LED 28 W 120-277V 80 4000 Type II - 3120 1514 L70 B10 80000 Download

Documentation: AMON MAXI TYPE II - 070249

070264 LED 28 W 120-277V 80 3000 Type II - 2850 1393 L70 B10 80000 Download

Documentation: AMON MAXI TYPE II - 070264

Sources

LED 28 W
  • Lighting column series. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Robust copper-free extruded aluminum column profile and copper-free precision die-cast aluminum housing, trim, top cap, and inspection access door (MAXI versions only).
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Extra-clear, flat, tempered silk screened soda-lime glass diffuser.
  • - High-efficiency COB combined with an optimized passive cooling system provides a long LED life.
  • - Internal specular reflector coated with 5-layers of PVD 99.98% pure aluminum providing >95% reflection.
  • - IESNA Type V light distribution.
  • - Input voltage: 120-277 V (50 / 60 Hz), integral 0-10 V dimming driver.
  • - Integral surge protector can withstand up to 10 kV transient line surge.
  • - Painted aluminum wiring inspection access door included (MAXI versions only).
  • - Steel ground base plate included for bollards.
  • - Base cover, anchor bolts, and direct-burial support available for AMON MINI / MAXI (ordered separately).
  • - Consult factory for dimming options, custom finishes and non-cataloged CCT (Kelvin) options.
  • - Consult factory for custom post height options.
  • - 5-year warranty.
  • - Product meets Buy American requirements within ARRA.
Product codes
Part number Finish Lampholder Wattage Voltage CRI Kelvin Optic Optic
Beam
Lightsource
lumen
output
Luminaire
lumen
output
L B Lifetime Download
HIGH POWER LEDS 120-277 V DIMMABLE 0-10V
070247 LED 90 W 120-277V 80 4000 Type V - 10092 3684 L70 B10 80000 Download

Documentation: AMON MAXI TYPE V - 070247

070250 LED 43 W 120-277V 80 4000 Type V - 4992 2081 L70 B10 80000 Download

Documentation: AMON MAXI TYPE V - 070250

070262 LED 90 W 120-277V 80 3000 Type V - 9770 3574 L70 B10 80000 Download

Documentation: AMON MAXI TYPE V - 070262

070265 LED 43 W 120-277V 80 3000 Type V - 4512 1881 L70 B10 80000 Download

Documentation: AMON MAXI TYPE V - 070265

Sources

LED 90 W
LED 43 W
