AMON MINI

IN
  • Pathway bollard series. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Robust copper-free extruded aluminum column profile and copper-free precision die-cast aluminum housing, ring/faceplate, top cap, and inspection access door.
  • - Extra-clear, tempered, silk-screened, flat glass diffuser.
  • - Satin UV-stabilized, high-impact resistant diffuser (SOFT versions).
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - High-efficiency COB, combined with an optimized passive cooling system, provides a long LED life.
  • - Internal specular reflector coated with 5-layers of PVD 99.98% pure aluminum providing >95% reflection.
  • - Type V light distribution.
  • - Diffuse light emission (SOFT).
  • - Input voltage: 120-277 V (50 / 60 Hz), integral 0-10 V dimming driver.
  • - Steel ground base plate included for bollards.
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Base heavy-duty cover, anchor bolts, and direct-burial support available for AMON MINI / MAXI (ordered separately).
  • - Product meets Buy American Act (BAA) requirements within ARRA.
  • - 5-year warranty.
  • Lighting column series. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Robust copper-free extruded aluminum column profile and copper-free precision die-cast aluminum housing, ring/faceplate, top cap, and inspection access door.
  • - Satin UV-stabilized, high-impact resistant diffuser (SOFT versions).
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - High-efficiency COB, combined with an optimized passive cooling system, provides a long LED life.
  • - Internal specular reflector coated with 5-layers of PVD 99.98% pure aluminum providing >95% reflection.
  • - Type V light distribution.
  • - Diffuse light emission (SOFT).
  • - Input voltage: 120-277 V (50 / 60 Hz), integral 0-10 V dimming driver.
  • - Steel ground base plate included for bollards.
  • - Base heavy-duty cover, anchor bolts, and direct-burial support available for AMON MINI / MAXI (ordered separately).
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - 5-year warranty.
  • - Product meets Buy American Act (BAA) requirements within ARRA.
Product codes
Part number Finishing Lampholder Wattage Voltage CRI Kelvin Optic Beam
angle
Lightsource
lumen
output
[lm]
Luminaire
lumen
output
[lm]
L B Lifetime Downloads
High Power LEDS 120-277 V - Dimmable 0-10 V
070254 LED 45 W 120/277 V 80 4000 Type V - 5046 1357 L70 B10 150000 Download

Documentation: AMON MINI SOFT TYPE V - 070254

070269 LED 45 W 120/277 V 80 3000 Type V - 4885 1314 L70 B10 150000 Download

Documentation: AMON MINI SOFT TYPE V - 070269

Sources

LED 45 W
  • Lighting column series. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Robust copper-free extruded aluminum column profile and copper-free precision die-cast aluminum housing, ring/faceplate, top cap, and inspection access door.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Extra-clear, tempered, silk-screened, flat glass diffuser.
  • - High-efficiency COB, combined with an optimized passive cooling system, provides a long LED life.
  • - Internal specular reflector coated with 5-layers of PVD 99.98% pure aluminum providing >95% reflection.
  • - Type V light distribution.
  • - Input voltage: 120-277 V (50 / 60 Hz), integral 0-10 V dimming driver.
  • - Steel ground base plate included for bollards.
  • - Base heavy-duty cover, anchor bolts, and direct-burial support available for AMON MINI / MAXI (ordered separately).
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - 5-year warranty.
  • - Product meets Buy American Act (BAA) requirements within ARRA.
Product codes
Part number Finishing Lampholder Wattage Voltage CRI Kelvin Optic Beam
angle
Lightsource
lumen
output
[lm]
Luminaire
lumen
output
[lm]
L B Lifetime Downloads
High Power LEDS 120-277 V - Dimmable 0-10 V
070260 LED 45 W 120/277 V 80 3000 Type V - 4885 1963 L70 B10 150000 Download

Documentation: AMON MINI TYPE V - 070260

070275 LED 45 W 120/277 V 80 4000 Type V - 5046 2025 L70 B10 150000 Download

Documentation: AMON MINI TYPE V - 070275

Sources

LED 45 W
