STRIP SQUARE+ INGROUND 550 ELL

Description

• Linear in-ground series. Fixtures consist of:
• - Copper-free aluminum die-cast end-caps, extruded, and anodized housing.
• - Extra-clear, tempered, silk-screened, flat glass diffuser.
• - Custom molded, anti-aging gasket(s).
• - Stainless steel external hardware.
• - Custom MCPCB utilized to maximize heat dissipation and promote a long LED life.
• - High-transmittance transparent optics.
• - 9° x 9° beam angle (C/I).
• - 15° x 45° beam angle (ELL).
• - 40° x 60° beam angle (ELL).
• - NEMA 5H x 4V light distribution (A18/M).
• - 15° x 45° beam angle (RGBW).
• - 15° x 45° beam angle (2700K - 6500K Dynamic Tunable White).
• - Input voltage: 120-277 V (50 / 60 Hz), integral 0-10 V dimming driver.
• - Input voltage: 48 V DC, separate driver (Dynamic Color Change versions).
• - Pre-wired cable connects luminaire with WATER-STOP connection system, suitable for through wiring. Included cable glands accept cables from Ø0.35" up to Ø0.63".
• - Stainless steel grounding tether included.
• - Each rough-in kit is provided with a protective faceplate to avoid possible deformations during the installation in concrete to simplify installation.
• - Consult factory for dimming options, marine-grade, custom finishes (please specify RAL color), and non-cataloged CCT (Kelvin) options including static colors.
• - Consult factory for custom pre-wired factory sealed cable length options.
• - Frosted (FRST) and Non-Slip (NS) glass option available - add suffix to any part number.
• - Product meets Buy American Act requirements within ARRA.
• - 5-year warranty.
