STRIP SQUARE+ INGROUND

IN
  • Linear in-ground series. Fixtures consist of:
  • - Copper-free (<1%) aluminum die-cast end-caps, extruded, and anodized housing.
  • - Extra-clear, tempered, silk-screened, flat glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Custom MCPCB utilized to maximize heat dissipation and promote long LED life.
  • - High-transparency polycarbonate optics for optimized light transmission.
  • - Circular Intensive optics (C/I).
  • - Elliptical optics (ELL).
  • - RGBW (2700K) color mixing for high emotional impact scenographic effects.
  • - Dynamic Tunable White (TW) options enable smooth variations in color temperature, from 2700K to 6500K, in response to how a space is used.
  • - NEMA 5H x 4V light distribution (A18/M).
  • - Input voltage: 120-277 V (50 / 60 Hz), integral 0-10 V dimming driver.
  • - Input voltage: 48 V DC, separate driver for RGBW color mixing and/or dynamic Tunable White versions (ordered separately).
  • - Pre-wired cable connects luminaire with WATER-STOP connection system, suitable for through wiring. Included cable glands accept cables from Ø0.35" up to Ø0.63".
  • - Stainless steel grounding tether included.
  • - Each rough-in kit is provided with a protective faceplate to avoid possible deformations during the installation in concrete to simplify installation.
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Product meets Buy American Act (BAA) requirements within ARRA.
  • - 5-year warranty.
  • Linear in-ground series. Fixtures consist of:
  • - Copper-free (<1%) aluminum die-cast end-caps, extruded, and anodized housing.
  • - Extra-clear, tempered, silk-screened, flat glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Custom MCPCB utilized to maximize heat dissipation and promote long LED life.
  • - High-transparency polycarbonate optics for optimized light transmission.
  • - NEMA 5H x 4V light distribution (A18/M).
  • - Input voltage: 120-277 V (50 / 60 Hz), integral 0-10 V dimming driver.
  • - Pre-wired cable connects luminaire with WATER-STOP connection system, suitable for through wiring. Included cable glands accept cables from Ø0.35" up to Ø0.63".
  • - Stainless steel grounding tether included.
  • - Each rough-in kit is provided with a protective faceplate to avoid possible deformations during the installation in concrete to simplify installation.
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Product meets Buy American Act (BAA) requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finishing Lampholder Wattage Voltage CRI Kelvin Optic Beam
angle
Lightsource
lumen
output
[lm]
Luminaire
lumen
output
[lm]
L B Lifetime Downloads
High Power LEDS 120-277 V - Dimmable 0-10 V
072048 LED 14 W 120/277 V 80 3000 - 18° 2000 1374 L80 B10 60000 Download

Documentation: STRIP SQUARE+ INGROUND 550 (21.65") A/M - 072048

072049 LED 14 W 120/277 V 80 4000 - 18° 2130 1468 L80 B10 60000 Download

Documentation: STRIP SQUARE+ INGROUND 550 (21.65") A/M - 072049

072648 LED 30 W 120/277 V 80 3000 - 18° 3550 2437 L80 B10 60000 Download

Documentation: STRIP SQUARE+ INGROUND 550 (21.65") A/M - 072648

072649 LED 30 W 120/277 V 80 4000 - 18° 3780 2602 L80 B10 60000 Download

Documentation: STRIP SQUARE+ INGROUND 550 (21.65") A/M - 072649

Sources

LED 14 W
LED 30 W
  • Linear in-ground series. Fixtures consist of:
  • - Copper-free (<1%) aluminum die-cast end-caps, extruded, and anodized housing.
  • - Extra-clear, tempered, silk-screened, flat glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Custom MCPCB utilized to maximize heat dissipation and promote long LED life.
  • - High-transparency polycarbonate optics for optimized light transmission.
  • - Circular Intensive optics (C/I).
  • - Input voltage: 120-277 V (50 / 60 Hz), integral 0-10 V dimming driver.
  • - Pre-wired cable connects luminaire with WATER-STOP connection system, suitable for through wiring. Included cable glands accept cables from Ø0.35" up to Ø0.63".
  • - Stainless steel grounding tether included.
  • - Each rough-in kit is provided with a protective faceplate to avoid possible deformations during the installation in concrete to simplify installation.
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Product meets Buy American Act (BAA) requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finishing Lampholder Wattage Voltage CRI Kelvin Optic Beam
angle
Lightsource
lumen
output
[lm]
Luminaire
lumen
output
[lm]
L B Lifetime Downloads
High Power LEDS 120-277 V - Dimmable 0-10 V
072040 LED 14 W 120/277 V 80 3000 - 2000 1425 L80 B10 60000 Download

Documentation: STRIP SQUARE+ INGROUND 550 (21.65") C/I - 072040

072041 LED 14 W 120/277 V 80 4000 - 2130 1519 L80 B10 60000 Download

Documentation: STRIP SQUARE+ INGROUND 550 (21.65") C/I - 072041

072640 LED 30 W 120/277 V 80 3000 - 3550 2527 L80 B10 60000 Download

Documentation: STRIP SQUARE+ INGROUND 550 (21.65") C/I - 072640

072641 LED 30 W 120/277 V 80 4000 - 3780 2694 L80 B10 60000 Download

Documentation: STRIP SQUARE+ INGROUND 550 (21.65") C/I - 072641

Sources

LED 14 W
LED 30 W
  • Linear in-ground series. Fixtures consist of:
  • - Copper-free (<1%) aluminum die-cast end-caps, extruded, and anodized housing.
  • - Extra-clear, tempered, silk-screened, flat glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Custom MCPCB utilized to maximize heat dissipation and promote long LED life.
  • - High-transparency polycarbonate optics for optimized light transmission.
  • - Elliptical optics (ELL).
  • - Input voltage: 120-277 V (50 / 60 Hz), integral 0-10 V dimming driver.
  • - Pre-wired cable connects luminaire with WATER-STOP connection system, suitable for through wiring. Included cable glands accept cables from Ø0.35" up to Ø0.63".
  • - Stainless steel grounding tether included.
  • - Each rough-in kit is provided with a protective faceplate to avoid possible deformations during the installation in concrete to simplify installation.
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Product meets Buy American Act (BAA) requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finishing Lampholder Wattage Voltage CRI Kelvin Optic Beam
angle
Lightsource
lumen
output
[lm]
Luminaire
lumen
output
[lm]
L B Lifetime Downloads
High Power LEDS 120-277 V - Dimmable 0-10 V
072043 LED 14 W 120/277 V 80 3000 - 15°x45° 2000 1385 L80 B10 60000 Download

Documentation: STRIP SQUARE+ INGROUND 550 (21.65") ELL - 072043

072044 LED 14 W 120/277 V 80 4000 - 15°x45° 2130 1479 L80 B10 60000 Download

Documentation: STRIP SQUARE+ INGROUND 550 (21.65") ELL - 072044

072046 LED 14 W 120/277 V 80 3000 - 40°x60° 2000 1384 L80 B10 60000 Download

Documentation: STRIP SQUARE+ INGROUND 550 (21.65") ELL - 072046

072047 LED 14 W 120/277 V 80 4000 - 40°x60° 2130 1478 L80 B10 60000 Download

Documentation: STRIP SQUARE+ INGROUND 550 (21.65") ELL - 072047

072643 LED 30 W 120/277 V 80 3000 - 15°x45° 3550 2455 L80 B10 60000 Download

Documentation: STRIP SQUARE+ INGROUND 550 (21.65") ELL - 072643

072644 LED 30 W 120/277 V 80 4000 - 15°x45° 3780 2622 L80 B10 60000 Download

Documentation: STRIP SQUARE+ INGROUND 550 (21.65") ELL - 072644

072646 LED 30 W 120/277 V 80 3000 - 40°x60° 3550 2454 L80 B10 60000 Download

Documentation: STRIP SQUARE+ INGROUND 550 (21.65") ELL - 072646

072647 LED 30 W 120/277 V 80 4000 - 40°x60° 3780 2621 L80 B10 60000 Download

Documentation: STRIP SQUARE+ INGROUND 550 (21.65") ELL - 072647

Sources

LED 14 W
LED 30 W
  • Linear in-ground series. Fixtures consist of:
  • - Copper-free (<1%) aluminum die-cast end-caps, extruded, and anodized housing.
  • - Extra-clear, tempered, silk-screened, flat glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Custom MCPCB utilized to maximize heat dissipation and promote long LED life.
  • - High-transparency polycarbonate optics for optimized light transmission.
  • - Elliptical optics (ELL).
  • - RGBW (2700K) color mixing for high emotional impact scenographic effects.
  • - Input voltage: 48 V DC, separate driver for RGBW color mixing and/or dynamic Tunable White versions (ordered separately).
  • - Pre-wired cable connects luminaire with WATER-STOP connection system, suitable for through wiring. Included cable glands accept cables from Ø0.35" up to Ø0.63".
  • - Stainless steel grounding tether included.
  • - Each rough-in kit is provided with a protective faceplate to avoid possible deformations during the installation in concrete to simplify installation.
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Product meets Buy American Act (BAA) requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finishing Lampholder Wattage Voltage CRI Kelvin Optic Beam
angle
Lightsource
lumen
output
[lm]
Luminaire
lumen
output
[lm]
L B Lifetime Downloads
RGBW LED
072045 LED 18.5 W 80 RGBW 2700 - 15°x45° 1880 1108 L80 B10 60000 Download

Documentation: STRIP SQUARE+ INGROUND 550 RGBW (21.65" - 072045

Sources

LED 18.5 W
  • Linear in-ground series. Fixtures consist of:
  • - Copper-free (<1%) aluminum die-cast end-caps, extruded, and anodized housing.
  • - Extra-clear, tempered, silk-screened, flat glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Custom MCPCB utilized to maximize heat dissipation and promote long LED life.
  • - High-transparency polycarbonate optics for optimized light transmission.
  • - Elliptical optics (ELL).
  • - Dynamic Tunable White (TW) options enable smooth variations in color temperature, from 2700K to 6500K, in response to how a space is used.
  • - Input voltage: 48 V DC, separate driver for RGBW color mixing and/or dynamic Tunable White versions (ordered separately).
  • - Pre-wired cable connects luminaire with WATER-STOP connection system, suitable for through wiring. Included cable glands accept cables from Ø0.35" up to Ø0.63".
  • - Stainless steel grounding tether included.
  • - Each rough-in kit is provided with a protective faceplate to avoid possible deformations during the installation in concrete to simplify installation.
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Product meets Buy American Act (BAA) requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finishing Lampholder Wattage Voltage CRI Kelvin Optic Beam
angle
Lightsource
lumen
output
[lm]
Luminaire
lumen
output
[lm]
L B Lifetime Downloads
TunableWhite High Power LED
072042 LED 16 W 80 TW 2700-6500 - 15°x45° 2216 1142 L80 B10 60000 Download

Documentation: STRIP SQUARE+ INGROUND 550 TW (21.65") - 072042

Sources

LED 16 W
  • Linear in-ground series. Fixtures consist of:
  • - Copper-free (<1%) aluminum die-cast end-caps, extruded, and anodized housing.
  • - Extra-clear, tempered, silk-screened, flat glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Custom MCPCB utilized to maximize heat dissipation and promote long LED life.
  • - High-transparency polycarbonate optics for optimized light transmission.
  • - NEMA 5H x 4V light distribution (A18/M).
  • - Input voltage: 120-277 V (50 / 60 Hz), integral 0-10 V dimming driver.
  • - Pre-wired cable connects luminaire with WATER-STOP connection system, suitable for through wiring. Included cable glands accept cables from Ø0.35" up to Ø0.63".
  • - Stainless steel grounding tether included.
  • - Each rough-in kit is provided with a protective faceplate to avoid possible deformations during the installation in concrete to simplify installation.
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Product meets Buy American Act (BAA) requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finishing Lampholder Wattage Voltage CRI Kelvin Optic Beam
angle
Lightsource
lumen
output
[lm]
Luminaire
lumen
output
[lm]
L B Lifetime Downloads
High Power LEDS 120-277 V - Dimmable 0-10 V
072058 LED 21 W 120/277 V 80 3000 - 18° 3000 2001 L80 B10 60000 Download

Documentation: STRIP SQUARE+ INGROUND 800 (31.50") A/M - 072058

072059 LED 21 W 120/277 V 80 4000 - 18° 3200 2136 L80 B10 60000 Download

Documentation: STRIP SQUARE+ INGROUND 800 (31.50") A/M - 072059

072658 LED 43 W 120/277 V 80 3000 - 18° 5490 3769 L80 B10 60000 Download

Documentation: STRIP SQUARE+ INGROUND 800 (31.50") A/M - 072658

072659 LED 43 W 120/277 V 80 4000 - 18° 5860 4025 L80 B10 60000 Download

Documentation: STRIP SQUARE+ INGROUND 800 (31.50") A/M - 072659

Sources

LED 21 W
LED 43 W
  • Linear in-ground series. Fixtures consist of:
  • - Copper-free (<1%) aluminum die-cast end-caps, extruded, and anodized housing.
  • - Extra-clear, tempered, silk-screened, flat glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Custom MCPCB utilized to maximize heat dissipation and promote long LED life.
  • - High-transparency polycarbonate optics for optimized light transmission.
  • - Circular Intensive optics (C/I).
  • - Input voltage: 120-277 V (50 / 60 Hz), integral 0-10 V dimming driver.
  • - Pre-wired cable connects luminaire with WATER-STOP connection system, suitable for through wiring. Included cable glands accept cables from Ø0.35" up to Ø0.63".
  • - Stainless steel grounding tether included.
  • - Each rough-in kit is provided with a protective faceplate to avoid possible deformations during the installation in concrete to simplify installation.
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Product meets Buy American Act (BAA) requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finishing Lampholder Wattage Voltage CRI Kelvin Optic Beam
angle
Lightsource
lumen
output
[lm]
Luminaire
lumen
output
[lm]
L B Lifetime Downloads
High Power LEDS 120-277 V - Dimmable 0-10 V
072050 LED 21 W 120/277 V 80 3000 - 3000 2075 L80 B10 60000 Download

Documentation: STRIP SQUARE+ INGROUND 800 (31.50") C/I - 072050

072051 LED 21 W 120/277 V 80 4000 - 3200 2216 L80 B10 60000 Download

Documentation: STRIP SQUARE+ INGROUND 800 (31.50") C/I - 072051

072650 LED 43 W 120/277 V 80 3000 - 5490 3908 L80 B10 60000 Download

Documentation: STRIP SQUARE+ INGROUND 800 (31.50") C/I - 072650

072651 LED 43 W 120/277 V 80 4000 - 5860 4174 L80 B10 60000 Download

Documentation: STRIP SQUARE+ INGROUND 800 (31.50") C/I - 072651

Sources

LED 21 W
LED 43 W
  • Linear in-ground series. Fixtures consist of:
  • - Copper-free (<1%) aluminum die-cast end-caps, extruded, and anodized housing.
  • - Extra-clear, tempered, silk-screened, flat glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Custom MCPCB utilized to maximize heat dissipation and promote long LED life.
  • - High-transparency polycarbonate optics for optimized light transmission.
  • - Elliptical optics (ELL).
  • - Input voltage: 120-277 V (50 / 60 Hz), integral 0-10 V dimming driver.
  • - Pre-wired cable connects luminaire with WATER-STOP connection system, suitable for through wiring. Included cable glands accept cables from Ø0.35" up to Ø0.63".
  • - Stainless steel grounding tether included.
  • - Each rough-in kit is provided with a protective faceplate to avoid possible deformations during the installation in concrete to simplify installation.
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Product meets Buy American Act (BAA) requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finishing Lampholder Wattage Voltage CRI Kelvin Optic Beam
angle
Lightsource
lumen
output
[lm]
Luminaire
lumen
output
[lm]
L B Lifetime Downloads
High Power LEDS 120-277 V - Dimmable 0-10 V
072053 LED 21 W 120/277 V 80 3000 - 15°x45° 3000 2015 L80 B10 60000 Download

Documentation: STRIP SQUARE+ INGROUND 800 (31.50") ELL - 072053

072054 LED 21 W 120/277 V 80 4000 - 15°x45° 3200 2152 L80 B10 60000 Download

Documentation: STRIP SQUARE+ INGROUND 800 (31.50") ELL - 072054

072056 LED 21 W 120/277 V 80 3000 - 40°x60° 3000 2015 L80 B10 60000 Download

Documentation: STRIP SQUARE+ INGROUND 800 (31.50") ELL - 072056

072057 LED 21 W 120/277 V 80 4000 - 40°x60° 3200 2151 L80 B10 60000 Download

Documentation: STRIP SQUARE+ INGROUND 800 (31.50") ELL - 072057

072653 LED 43 W 120/277 V 80 3000 - 15°x45° 5490 3796 L80 B10 60000 Download

Documentation: STRIP SQUARE+ INGROUND 800 (31.50") ELL - 072653

072654 LED 43 W 120/277 V 80 4000 - 15°x45° 5860 4054 L80 B10 60000 Download

Documentation: STRIP SQUARE+ INGROUND 800 (31.50") ELL - 072654

072656 LED 43 W 120/277 V 80 3000 - 40°x60° 5490 3795 L80 B10 60000 Download

Documentation: STRIP SQUARE+ INGROUND 800 (31.50") ELL - 072656

072657 LED 43 W 120/277 V 80 4000 - 40°x60° 5860 4053 L80 B10 60000 Download

Documentation: STRIP SQUARE+ INGROUND 800 (31.50") ELL - 072657

Sources

LED 21 W
LED 43 W
  • Linear in-ground series. Fixtures consist of:
  • - Copper-free (<1%) aluminum die-cast end-caps, extruded, and anodized housing.
  • - Extra-clear, tempered, silk-screened, flat glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Custom MCPCB utilized to maximize heat dissipation and promote long LED life.
  • - High-transparency polycarbonate optics for optimized light transmission.
  • - Elliptical optics (ELL).
  • - RGBW (2700K) color mixing for high emotional impact scenographic effects.
  • - Input voltage: 48 V DC, separate driver for RGBW color mixing and/or dynamic Tunable White versions (ordered separately).
  • - Pre-wired cable connects luminaire with WATER-STOP connection system, suitable for through wiring. Included cable glands accept cables from Ø0.35" up to Ø0.63".
  • - Stainless steel grounding tether included.
  • - Each rough-in kit is provided with a protective faceplate to avoid possible deformations during the installation in concrete to simplify installation.
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Product meets Buy American Act (BAA) requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finishing Lampholder Wattage Voltage CRI Kelvin Optic Beam
angle
Lightsource
lumen
output
[lm]
Luminaire
lumen
output
[lm]
L B Lifetime Downloads
RGBW LED
072055 LED 28 W 80 RGBW 2700 - 15°x45° 2830 1520 L80 B10 60000 Download

Documentation: STRIP SQUARE+ INGROUND 800 RGBW (31.50" - 072055

Sources

LED 28 W
  • Linear in-ground series. Fixtures consist of:
  • - Copper-free (<1%) aluminum die-cast end-caps, extruded, and anodized housing.
  • - Extra-clear, tempered, silk-screened, flat glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Custom MCPCB utilized to maximize heat dissipation and promote long LED life.
  • - High-transparency polycarbonate optics for optimized light transmission.
  • - Elliptical optics (ELL).
  • - Dynamic Tunable White (TW) options enable smooth variations in color temperature, from 2700K to 6500K, in response to how a space is used.
  • - Input voltage: 48 V DC, separate driver for RGBW color mixing and/or dynamic Tunable White versions (ordered separately).
  • - Pre-wired cable connects luminaire with WATER-STOP connection system, suitable for through wiring. Included cable glands accept cables from Ø0.35" up to Ø0.63".
  • - Stainless steel grounding tether included.
  • - Each rough-in kit is provided with a protective faceplate to avoid possible deformations during the installation in concrete to simplify installation.
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Product meets Buy American Act (BAA) requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finishing Lampholder Wattage Voltage CRI Kelvin Optic Beam
angle
Lightsource
lumen
output
[lm]
Luminaire
lumen
output
[lm]
L B Lifetime Downloads
TunableWhite High Power LED
072052 LED 22 W 80 TW 2700-6500 - 15°x45° 3324 1655 L80 B10 60000 Download

Documentation: STRIP SQUARE+ INGROUND 800 TW (31.50") - 072052

Sources

LED 22 W
  • Linear in-ground series. Fixtures consist of:
  • - Copper-free (<1%) aluminum die-cast end-caps, extruded, and anodized housing.
  • - Extra-clear, tempered, silk-screened, flat glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Custom MCPCB utilized to maximize heat dissipation and promote long LED life.
  • - High-transparency polycarbonate optics for optimized light transmission.
  • - NEMA 5H x 4V light distribution (A18/M).
  • - Input voltage: 120-277 V (50 / 60 Hz), integral 0-10 V dimming driver.
  • - Pre-wired cable connects luminaire with WATER-STOP connection system, suitable for through wiring. Included cable glands accept cables from Ø0.35" up to Ø0.63".
  • - Stainless steel grounding tether included.
  • - Each rough-in kit is provided with a protective faceplate to avoid possible deformations during the installation in concrete to simplify installation.
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Product meets Buy American Act (BAA) requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finishing Lampholder Wattage Voltage CRI Kelvin Optic Beam
angle
Lightsource
lumen
output
[lm]
Luminaire
lumen
output
[lm]
L B Lifetime Downloads
High Power LEDS 120-277 V - Dimmable 0-10 V
072068 LED 27 W 120/277 V 80 3000 - 18° 4000 2660 L80 B10 60000 Download

Documentation: STRIP SQUARE+ INGROUND 1050(41.34") A/M - 072068

072069 LED 27 W 120/277 V 80 4000 - 18° 4260 2841 L80 B10 60000 Download

Documentation: STRIP SQUARE+ INGROUND 1050(41.34") A/M - 072069

072668 LED 55 W 120/277 V 80 3000 - 18° 6900 4740 L80 B10 60000 Download

Documentation: STRIP SQUARE+ INGROUND 1050(41.34") A/M - 072668

072669 LED 55 W 120/277 V 80 4000 - 18° 7370 5061 L80 B10 60000 Download

Documentation: STRIP SQUARE+ INGROUND 1050(41.34") A/M - 072669

Sources

LED 27 W
LED 55 W
  • Linear in-ground series. Fixtures consist of:
  • - Copper-free (<1%) aluminum die-cast end-caps, extruded, and anodized housing.
  • - Extra-clear, tempered, silk-screened, flat glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Custom MCPCB utilized to maximize heat dissipation and promote long LED life.
  • - High-transparency polycarbonate optics for optimized light transmission.
  • - Circular Intensive optics (C/I).
  • - Input voltage: 120-277 V (50 / 60 Hz), integral 0-10 V dimming driver.
  • - Pre-wired cable connects luminaire with WATER-STOP connection system, suitable for through wiring. Included cable glands accept cables from Ø0.35" up to Ø0.63".
  • - Stainless steel grounding tether included.
  • - Each rough-in kit is provided with a protective faceplate to avoid possible deformations during the installation in concrete to simplify installation.
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Product meets Buy American Act (BAA) requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finishing Lampholder Wattage Voltage CRI Kelvin Optic Beam
angle
Lightsource
lumen
output
[lm]
Luminaire
lumen
output
[lm]
L B Lifetime Downloads
High Power LEDS 120-277 V - Dimmable 0-10 V
072060 LED 27 W 120/277 V 80 3000 - 4000 2759 L80 B10 60000 Download

Documentation: STRIP SQUARE+ INGROUND 1050(41.34") C/I - 072060

072061 LED 27 W 120/277 V 80 4000 - 4260 2946 L80 B10 60000 Download

Documentation: STRIP SQUARE+ INGROUND 1050(41.34") C/I - 072061

072660 LED 55 W 120/277 V 80 3000 - 6900 4916 L80 B10 60000 Download

Documentation: STRIP SQUARE+ INGROUND 1050(41.34") C/I - 072660

072661 LED 55 W 120/277 V 80 4000 - 7370 5249 L80 B10 60000 Download

Documentation: STRIP SQUARE+ INGROUND 1050(41.34") C/I - 072661

Sources

LED 27 W
LED 55 W
  • Linear in-ground series. Fixtures consist of:
  • - Copper-free (<1%) aluminum die-cast end-caps, extruded, and anodized housing.
  • - Extra-clear, tempered, silk-screened, flat glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Custom MCPCB utilized to maximize heat dissipation and promote long LED life.
  • - High-transparency polycarbonate optics for optimized light transmission.
  • - Elliptical optics (ELL).
  • - Input voltage: 120-277 V (50 / 60 Hz), integral 0-10 V dimming driver.
  • - Pre-wired cable connects luminaire with WATER-STOP connection system, suitable for through wiring. Included cable glands accept cables from Ø0.35" up to Ø0.63".
  • - Stainless steel grounding tether included.
  • - Each rough-in kit is provided with a protective faceplate to avoid possible deformations during the installation in concrete to simplify installation.
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Product meets Buy American Act (BAA) requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finishing Lampholder Wattage Voltage CRI Kelvin Optic Beam
angle
Lightsource
lumen
output
[lm]
Luminaire
lumen
output
[lm]
L B Lifetime Downloads
High Power LEDS 120-277 V - Dimmable 0-10 V
072063 LED 27 W 120/277 V 80 3000 - 15°x45° 4000 2680 L80 B10 60000 Download

Documentation: STRIP SQUARE+ INGROUND 1050(41.34") ELL - 072063

072064 LED 27 W 120/277 V 80 4000 - 15°x45° 4260 2862 L80 B10 60000 Download

Documentation: STRIP SQUARE+ INGROUND 1050(41.34") ELL - 072064

072066 LED 27 W 120/277 V 80 3000 - 40°x60° 4000 2679 L80 B10 60000 Download

Documentation: STRIP SQUARE+ INGROUND 1050(41.34") ELL - 072066

072067 LED 27 W 120/277 V 80 4000 - 40°x60° 4260 2861 L80 B10 60000 Download

Documentation: STRIP SQUARE+ INGROUND 1050(41.34") ELL - 072067

072663 LED 55 W 120/277 V 80 3000 - 15°x45° 6900 4774 L80 B10 60000 Download

Documentation: STRIP SQUARE+ INGROUND 1050(41.34") ELL - 072663

072664 LED 55 W 120/277 V 80 4000 - 15°x45° 7370 5099 L80 B10 60000 Download

Documentation: STRIP SQUARE+ INGROUND 1050(41.34") ELL - 072664

072666 LED 55 W 120/277 V 80 3000 - 40°x60° 6900 4773 L80 B10 60000 Download

Documentation: STRIP SQUARE+ INGROUND 1050(41.34") ELL - 072666

072667 LED 55 W 120/277 V 80 4000 - 40°x60° 7370 5097 L80 B10 60000 Download

Documentation: STRIP SQUARE+ INGROUND 1050(41.34") ELL - 072667

Sources

LED 27 W
LED 55 W
  • Linear in-ground series. Fixtures consist of:
  • - Copper-free (<1%) aluminum die-cast end-caps, extruded, and anodized housing.
  • - Extra-clear, tempered, silk-screened, flat glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Custom MCPCB utilized to maximize heat dissipation and promote long LED life.
  • - High-transparency polycarbonate optics for optimized light transmission.
  • - Elliptical optics (ELL).
  • - RGBW (2700K) color mixing for high emotional impact scenographic effects.
  • - Input voltage: 48 V DC, separate driver for RGBW color mixing and/or dynamic Tunable White versions (ordered separately).
  • - Pre-wired cable connects luminaire with WATER-STOP connection system, suitable for through wiring. Included cable glands accept cables from Ø0.35" up to Ø0.63".
  • - Stainless steel grounding tether included.
  • - Each rough-in kit is provided with a protective faceplate to avoid possible deformations during the installation in concrete to simplify installation.
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Product meets Buy American Act (BAA) requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finishing Lampholder Wattage Voltage CRI Kelvin Optic Beam
angle
Lightsource
lumen
output
[lm]
Luminaire
lumen
output
[lm]
L B Lifetime Downloads
RGBW LED
072065 LED 37 W 80 RGBW 2700 - 15°x45° 3760 2103 L80 B10 60000 Download

Documentation: STRIP SQUARE+ INGROUND 1050 RGBW (41.34 - 072065

Sources

LED 37 W
  • Linear in-ground series. Fixtures consist of:
  • - Copper-free (<1%) aluminum die-cast end-caps, extruded, and anodized housing.
  • - Extra-clear, tempered, silk-screened, flat glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Custom MCPCB utilized to maximize heat dissipation and promote long LED life.
  • - High-transparency polycarbonate optics for optimized light transmission.
  • - Elliptical optics (ELL).
  • - Dynamic Tunable White (TW) options enable smooth variations in color temperature, from 2700K to 6500K, in response to how a space is used.
  • - Input voltage: 48 V DC, separate driver for RGBW color mixing and/or dynamic Tunable White versions (ordered separately).
  • - Pre-wired cable connects luminaire with WATER-STOP connection system, suitable for through wiring. Included cable glands accept cables from Ø0.35" up to Ø0.63".
  • - Stainless steel grounding tether included.
  • - Each rough-in kit is provided with a protective faceplate to avoid possible deformations during the installation in concrete to simplify installation.
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Product meets Buy American Act (BAA) requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finishing Lampholder Wattage Voltage CRI Kelvin Optic Beam
angle
Lightsource
lumen
output
[lm]
Luminaire
lumen
output
[lm]
L B Lifetime Downloads
TunableWhite High Power LED
072062 LED 28 W 80 TW 2700-6500 - 15°x45° 4432 2252 L80 B10 60000 Download

Documentation: STRIP SQUARE+ INGROUND 1050 TW (41.34") - 072062

Sources

LED 28 W
  • Linear in-ground series. Fixtures consist of:
  • - Copper-free (<1%) aluminum die-cast end-caps, extruded, and anodized housing.
  • - Extra-clear, tempered, silk-screened, flat glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Custom MCPCB utilized to maximize heat dissipation and promote long LED life.
  • - High-transparency polycarbonate optics for optimized light transmission.
  • - NEMA 5H x 4V light distribution (A18/M).
  • - Input voltage: 120-277 V (50 / 60 Hz), integral 0-10 V dimming driver.
  • - Pre-wired cable connects luminaire with WATER-STOP connection system, suitable for through wiring. Included cable glands accept cables from Ø0.35" up to Ø0.63".
  • - Stainless steel grounding tether included.
  • - Each rough-in kit is provided with a protective faceplate to avoid possible deformations during the installation in concrete to simplify installation.
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Product meets Buy American Act (BAA) requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finishing Lampholder Wattage Voltage CRI Kelvin Optic Beam
angle
Lightsource
lumen
output
[lm]
Luminaire
lumen
output
[lm]
L B Lifetime Downloads
High Power LEDS 120-277 V - Dimmable 0-10 V
072078 LED 33 W 120/277 V 80 3000 - 18° 5000 3324 L80 B10 60000 Download

Documentation: STRIP SQUARE+ INGROUND 1300(51.18") A/M - 072078

072079 LED 33 W 120/277 V 80 4000 - 18° 5400 3549 L80 B10 60000 Download

Documentation: STRIP SQUARE+ INGROUND 1300(51.18") A/M - 072079

072678 LED 67 W 120/277 V 80 3000 - 18° 8870 6086 L80 B10 60000 Download

Documentation: STRIP SQUARE+ INGROUND 1300(51.18") A/M - 072678

072679 LED 67 W 120/277 V 80 4000 - 18° 9470 6499 L80 B10 60000 Download

Documentation: STRIP SQUARE+ INGROUND 1300(51.18") A/M - 072679

Sources

LED 33 W
LED 67 W
  • Linear in-ground series. Fixtures consist of:
  • - Copper-free (<1%) aluminum die-cast end-caps, extruded, and anodized housing.
  • - Extra-clear, tempered, silk-screened, flat glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Custom MCPCB utilized to maximize heat dissipation and promote long LED life.
  • - High-transparency polycarbonate optics for optimized light transmission.
  • - Circular Intensive optics (C/I).
  • - Input voltage: 120-277 V (50 / 60 Hz), integral 0-10 V dimming driver.
  • - Pre-wired cable connects luminaire with WATER-STOP connection system, suitable for through wiring. Included cable glands accept cables from Ø0.35" up to Ø0.63".
  • - Stainless steel grounding tether included.
  • - Each rough-in kit is provided with a protective faceplate to avoid possible deformations during the installation in concrete to simplify installation.
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Product meets Buy American Act (BAA) requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finishing Lampholder Wattage Voltage CRI Kelvin Optic Beam
angle
Lightsource
lumen
output
[lm]
Luminaire
lumen
output
[lm]
L B Lifetime Downloads
High Power LEDS 120-277 V - Dimmable 0-10 V
072070 LED 33 W 120/277 V 80 3000 - 5000 3447 L80 B10 60000 Download

Documentation: STRIP SQUARE+ INGROUND 1300(51.18") C/I - 072070

072071 LED 33 W 120/277 V 80 4000 - 5400 3861 L80 B10 60000 Download

Documentation: STRIP SQUARE+ INGROUND 1300(51.18") C/I - 072071

072670 LED 67 W 120/277 V 80 3000 - 8870 6312 L80 B10 60000 Download

Documentation: STRIP SQUARE+ INGROUND 1300(51.18") C/I - 072670

072671 LED 67 W 120/277 V 80 4000 - 9470 6741 L80 B10 60000 Download

Documentation: STRIP SQUARE+ INGROUND 1300(51.18") C/I - 072671

Sources

LED 33 W
LED 67 W
  • Linear in-ground series. Fixtures consist of:
  • - Copper-free (<1%) aluminum die-cast end-caps, extruded, and anodized housing.
  • - Extra-clear, tempered, silk-screened, flat glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Custom MCPCB utilized to maximize heat dissipation and promote long LED life.
  • - High-transparency polycarbonate optics for optimized light transmission.
  • - Elliptical optics (ELL).
  • - Input voltage: 120-277 V (50 / 60 Hz), integral 0-10 V dimming driver.
  • - Pre-wired cable connects luminaire with WATER-STOP connection system, suitable for through wiring. Included cable glands accept cables from Ø0.35" up to Ø0.63".
  • - Stainless steel grounding tether included.
  • - Each rough-in kit is provided with a protective faceplate to avoid possible deformations during the installation in concrete to simplify installation.
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Product meets Buy American Act (BAA) requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finishing Lampholder Wattage Voltage CRI Kelvin Optic Beam
angle
Lightsource
lumen
output
[lm]
Luminaire
lumen
output
[lm]
L B Lifetime Downloads
High Power LEDS 120-277 V - Dimmable 0-10 V
072073 LED 33 W 120/277 V 80 3000 - 15°x45° 5000 3348 L80 B10 60000 Download

Documentation: STRIP SQUARE+ INGROUND 1300(51.18") ELL - 072073

072074 LED 33 W 120/277 V 80 4000 - 15°x45° 5400 3576 L80 B10 60000 Download

Documentation: STRIP SQUARE+ INGROUND 1300(51.18") ELL - 072074

072076 LED 33 W 120/277 V 80 3000 - 40°x60° 5000 3347 L80 B10 60000 Download

Documentation: STRIP SQUARE+ INGROUND 1300(51.18") ELL - 072076

072077 LED 33 W 120/277 V 80 4000 - 40°x60° 5400 3574 L80 B10 60000 Download

Documentation: STRIP SQUARE+ INGROUND 1300(51.18") ELL - 072077

072673 LED 67 W 120/277 V 80 3000 - 15°x45° 8870 6131 L80 B10 60000 Download

Documentation: STRIP SQUARE+ INGROUND 1300(51.18") ELL - 072673

072674 LED 67 W 120/277 V 80 4000 - 15°x45° 9470 6547 L80 B10 60000 Download

Documentation: STRIP SQUARE+ INGROUND 1300(51.18") ELL - 072674

072676 LED 67 W 120/277 V 80 3000 - 40°x60° 8870 6129 L80 B10 60000 Download

Documentation: STRIP SQUARE+ INGROUND 1300(51.18") ELL - 072676

072677 LED 67 W 120/277 V 80 4000 - 40°x60° 9470 6545 L80 B10 60000 Download

Documentation: STRIP SQUARE+ INGROUND 1300(51.18") ELL - 072677

Sources

LED 33 W
LED 67 W
  • Linear in-ground series. Fixtures consist of:
  • - Copper-free (<1%) aluminum die-cast end-caps, extruded, and anodized housing.
  • - Extra-clear, tempered, silk-screened, flat glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Custom MCPCB utilized to maximize heat dissipation and promote long LED life.
  • - High-transparency polycarbonate optics for optimized light transmission.
  • - Elliptical optics (ELL).
  • - RGBW (2700K) color mixing for high emotional impact scenographic effects.
  • - Input voltage: 48 V DC, separate driver for RGBW color mixing and/or dynamic Tunable White versions (ordered separately).
  • - Pre-wired cable connects luminaire with WATER-STOP connection system, suitable for through wiring. Included cable glands accept cables from Ø0.35" up to Ø0.63".
  • - Stainless steel grounding tether included.
  • - Each rough-in kit is provided with a protective faceplate to avoid possible deformations during the installation in concrete to simplify installation.
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Product meets Buy American Act (BAA) requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finishing Lampholder Wattage Voltage CRI Kelvin Optic Beam
angle
Lightsource
lumen
output
[lm]
Luminaire
lumen
output
[lm]
L B Lifetime Downloads
RGBW LED
072075 LED 46 W 80 RGBW 2700 - 15°x45° 4140 2545 L80 B10 60000 Download

Documentation: STRIP SQUARE+ INGROUND 1300 RGBW 51.18" - 072075

Sources

LED 46 W
  • Linear in-ground series. Fixtures consist of:
  • - Copper-free (<1%) aluminum die-cast end-caps, extruded, and anodized housing.
  • - Extra-clear, tempered, silk-screened, flat glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Custom MCPCB utilized to maximize heat dissipation and promote long LED life.
  • - High-transparency polycarbonate optics for optimized light transmission.
  • - Elliptical optics (ELL).
  • - Dynamic Tunable White (TW) options enable smooth variations in color temperature, from 2700K to 6500K, in response to how a space is used.
  • - Input voltage: 48 V DC, separate driver for RGBW color mixing and/or dynamic Tunable White versions (ordered separately).
  • - Pre-wired cable connects luminaire with WATER-STOP connection system, suitable for through wiring. Included cable glands accept cables from Ø0.35" up to Ø0.63".
  • - Stainless steel grounding tether included.
  • - Each rough-in kit is provided with a protective faceplate to avoid possible deformations during the installation in concrete to simplify installation.
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Product meets Buy American Act (BAA) requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finishing Lampholder Wattage Voltage CRI Kelvin Optic Beam
angle
Lightsource
lumen
output
[lm]
Luminaire
lumen
output
[lm]
L B Lifetime Downloads
TunableWhite High Power LED
072072 LED 35 W 80 TW 2700-6500 - 15°x45° 5540 2867 L80 B10 60000 Download

Documentation: STRIP SQUARE+ INGROUND 1300 TW (51.18") - 072072

Sources

LED 35 W

Product Family

to top
Products search
You can search for products in our catalog by entering here the name or the code of the product or accessory.
