MAGICLICK MAXI

IN
  • Ceiling- and wall- mount series. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free (<1%) precision die-cast aluminum housing and ring/faceplate.
  • - High transmittance, internally coated, pressed glass diffuser, thermally, and chemically quenched to strengthen the impact resistance and reduce the effect of rapid temperature changes.
  • - The ring/faceplate is integral with the diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Custom MCPCB utilized to maximize heat dissipation and promote long LED life.
  • - Tiltable LED board mounting bracket allows for quick and easy installation.
  • - 100% uniform diffused light emission.
  • - Input voltage: 120-277 V (50 / 60 Hz), integral 0-10 V dimming driver.
  • - Optional, integral, emergency battery-pack designed for a minimum operation of 90 minutes (EMPK versions).
  • - Standard hinge-style housing allows for a simplified installation.
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Product meets Buy American Act (BAA) requirements within ARRA.
  • - 5-year warranty.
MAGICLICK MAXI LED [20.23"]

MAGICLICK MAXI LED [20.23"]

Optic | Symmetric Extra-Wide
  • Ceiling- and wall- mount series. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free (<1%) precision die-cast aluminum housing and ring/faceplate.
  • - High transmittance, internally coated, pressed glass diffuser, thermally, and chemically quenched to strengthen the impact resistance and reduce the effect of rapid temperature changes.
  • - The ring/faceplate is integral with the diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Custom MCPCB utilized to maximize heat dissipation and promote long LED life.
  • - Tiltable LED board mounting bracket allows for quick and easy installation.
  • - 100% uniform diffused light emission.
  • - Input voltage: 120-277 V (50 / 60 Hz), integral driver.
  • - Standard hinge-style housing allows for a simplified installation.
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Product meets Buy American Act (BAA) requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finishing Lampholder Wattage Voltage CRI Kelvin Optic Beam
angle		 Lightsource
lumen
output
[lm]		 Luminaire
lumen
output
[lm]		 L B Lifetime Downloads
Mid Power LEDS 120-277 V
071193 LED 40 W 120/277 V 80 3000 - - 4262 1474 - - 60000 Download

Documentation: MAGICLICK MAXI LED [20.23"] - 071193
071194 LED 40 W 120/277 V 80 3000 - - 4262 1474 - - 60000 Download

Documentation: MAGICLICK MAXI LED [20.23"] - 071194
071195 LED 40 W 120/277 V 80 3000 - - 4262 1474 - - 60000 Download

Documentation: MAGICLICK MAXI LED [20.23"] - 071195
071196 LED 40 W 120/277 V 80 4000 - - 4492 1564 - - 60000 Download

Documentation: MAGICLICK MAXI LED [20.23"] - 071196
071197 LED 40 W 120/277 V 80 4000 - - 4492 1564 - - 60000 Download

Documentation: MAGICLICK MAXI LED [20.23"] - 071197
071198 LED 40 W 120/277 V 80 4000 - - 4492 1564 - - 60000 Download

Documentation: MAGICLICK MAXI LED [20.23"] - 071198
079800 LED 63 W 120/277 V 80 3000 - - 6696 2684 - - 40000 Download

Documentation: MAGICLICK MAXI LED [20.23"] - 079800
079801 LED 63 W 120/277 V 80 4000 - - 7057 2848 - - 40000 Download

Documentation: MAGICLICK MAXI LED [20.23"] - 079801
079802 LED 63 W 120/277 V 80 3000 - - 6696 2684 - - 40000 Download

Documentation: MAGICLICK MAXI LED [20.23"] - 079802
079803 LED 63 W 120/277 V 80 4000 - - 7057 2848 - - 40000 Download

Documentation: MAGICLICK MAXI LED [20.23"] - 079803
079804 LED 63 W 120/277 V 80 3000 - - 6696 2684 - - 40000 Download

Documentation: MAGICLICK MAXI LED [20.23"] - 079804
079805 LED 63 W 120/277 V 80 4000 - - 7057 2848 - - 40000 Download

Documentation: MAGICLICK MAXI LED [20.23"] - 079805

Sources

LED 40 W
LED 63 W
MAGICLICK MAXI LED EMPK [20.23"]

MAGICLICK MAXI LED EMPK [20.23"]

Optic | Symmetric Extra-Wide
  • Ceiling- and wall- mount series. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free (<1%) precision die-cast aluminum housing and ring/faceplate.
  • - High transmittance, internally coated, pressed glass diffuser, thermally, and chemically quenched to strengthen the impact resistance and reduce the effect of rapid temperature changes.
  • - The ring/faceplate is integral with the diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Custom MCPCB utilized to maximize heat dissipation and promote long LED life.
  • - Tiltable LED board mounting bracket allows for quick and easy installation.
  • - 100% uniform diffused light emission.
  • - Input voltage: 120-277 V (50 / 60 Hz), integral driver.
  • - Integral, emergency battery-pack designed for a minimum operation of 90 minutes (EMPK versions).
  • - Standard hinge-style housing allows for a simplified installation.
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Product meets Buy American Act (BAA) requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finishing Lampholder Wattage Voltage CRI Kelvin Optic Beam
angle		 Lightsource
lumen
output
[lm]		 Luminaire
lumen
output
[lm]		 L B Lifetime Downloads
Mid Power LEDS 120-277 V - EMPK
071115 LED 40 W 120/277 V 80 3000 - - 4262 1474 - - 60000 Download

Documentation: MAGICLICK MAXI LED EMPK [20.23"] - 071115
071116 LED 40 W 120/277 V 80 3000 - - 4262 1474 - - 60000 Download

Documentation: MAGICLICK MAXI LED EMPK [20.23"] - 071116
071117 LED 40 W 120/277 V 80 3000 - - 4262 1474 - - 60000 Download

Documentation: MAGICLICK MAXI LED EMPK [20.23"] - 071117
071118 LED 40 W 120/277 V 80 4000 - - 4492 1564 - - 60000 Download

Documentation: MAGICLICK MAXI LED EMPK [20.23"] - 071118
071119 LED 40 W 120/277 V 80 4000 - - 4492 1564 - - 60000 Download

Documentation: MAGICLICK MAXI LED EMPK [20.23"] - 071119
071120 LED 40 W 120/277 V 80 4000 - - 4492 1564 - - 60000 Download

Documentation: MAGICLICK MAXI LED EMPK [20.23"] - 071120

Sources

LED 40 W
