MAGICLICK OVAL

MAGICLICK OVAL LED [8.27"]

SYMMETRIC EXTRA WIDE REFLECTOR

Ceiling and wall mount series. Fixtures consist of:
- Multi-step powder-coat painting process, optimized against UV rays and corrosion.
- Copper-free die-cast aluminum housing, trim and faceplates.
- High transmittance, internally coated, soda-lime pressed glass diffuser, thermally and chemically quenched to strenghen the impact resistance and reduce the affect of rapid temperature changes.
- The trim is integral with the diffuser.
- Custom molded, anti-aging gasket(s).
- Stainless steel external hardware.
- Custom MCPCB utilized to maximize heat dissipation and promote a long LED life.
- 100% uniform diffused light emission.
- Input voltage: 120-277 V (50 / 60 Hz), integral driver.
- Standard hinge-style housing allows for a simplified installation.
- Consult factory for dimming options, custom finishes and non-cataloged CCT (Kelvin) options.
- 5-year warranty.
- Product meets Buy American requirements within ARRA.

Product codes

Part number	Lampholder	Wattage	Voltage	CRI	Kelvin	Optic	Optic Beam	Lightsource lumen output	Luminaire lumen output	L	B	Lifetime	Download
HIGH POWER LEDS 120-277 V
079372	LED	11 W	120-277V	-	3000	-	-	1278	608	L80	-	50000	Documentation: MAGICLICK OVAL LED [8.27"] - 079372
079374	LED	11 W	120-277V	-	3000	-	-	1278	608	L80	-	50000	Documentation: MAGICLICK OVAL LED [8.27"] - 079374
079376	LED	11 W	120-277V	-	3000	-	-	1278	608	L80	-	50000	Documentation: MAGICLICK OVAL LED [8.27"] - 079376
079390	LED	11 W	120-277V	-	4000	-	-	1320	675	L80	-	50000	Documentation: MAGICLICK OVAL LED [8.27"] - 079390
079392	LED	11 W	120-277V	-	4000	-	-	1320	675	L80	-	50000	Documentation: MAGICLICK OVAL LED [8.27"] - 079392
079394	LED	11 W	120-277V	-	4000	-	-	1320	675	L80	-	50000	Documentation: MAGICLICK OVAL LED [8.27"] - 079394

Sources

LED

11 W

SYMMETRIC EXTRA WIDE REFLECTOR

Ceiling and wall mount series. Fixtures consist of:
- Multi-step powder-coat painting process, optimized against UV rays and corrosion.
- Copper-free die-cast aluminum housing, trim and faceplates.
- High transmittance, internally coated, soda-lime pressed glass diffuser, thermally and chemically quenched to strenghen the impact resistance and reduce the affect of rapid temperature changes.
- The trim is integral with the diffuser.
- Custom molded, anti-aging gasket(s).
- Stainless steel external hardware.
- Custom MCPCB utilized to maximize heat dissipation and promote a long LED life.
- 100% uniform diffused light emission.
- Input voltage: 120-277 V (50 / 60 Hz), integral driver.
- Standard hinge-style housing allows for a simplified installation.
- Consult factory for dimming options, custom finishes and non-cataloged CCT (Kelvin) options.
- 5-year warranty.
- Product meets Buy American requirements within ARRA.

Product codes

Part number	Lampholder	Wattage	Voltage	CRI	Kelvin	Optic	Optic Beam	Lightsource lumen output	Luminaire lumen output	L	B	Lifetime	Download
HIGH POWER LEDS 120-277 V
079378	LED	11 W	120-277V	-	3000	-	-	1278	334	L80	-	50000	Documentation: MAGICLICK OVAL SHADE H LED [8.27"] - 079378
079380	LED	11 W	120-277V	-	3000	-	-	1278	334	L80	-	50000	Documentation: MAGICLICK OVAL SHADE H LED [8.27"] - 079380
079382	LED	11 W	120-277V	-	3000	-	-	1278	334	L80	-	50000	Documentation: MAGICLICK OVAL SHADE H LED [8.27"] - 079382
079396	LED	11 W	120-277V	-	4000	-	-	1320	370	L80	-	50000	Documentation: MAGICLICK OVAL SHADE H LED [8.27"] - 079396
079398	LED	11 W	120-277V	-	4000	-	-	1320	370	L80	-	50000	Documentation: MAGICLICK OVAL SHADE H LED [8.27"] - 079398
079400	LED	11 W	120-277V	-	4000	-	-	1320	370	L80	-	50000	Documentation: MAGICLICK OVAL SHADE H LED [8.27"] - 079400

Sources

LED

11 W

SYMMETRIC EXTRA WIDE REFLECTOR

Ceiling and wall mount series. Fixtures consist of:
- Multi-step powder-coat painting process, optimized against UV rays and corrosion.
- Copper-free die-cast aluminum housing, trim and faceplates.
- High transmittance, internally coated, soda-lime pressed glass diffuser, thermally and chemically quenched to strenghen the impact resistance and reduce the affect of rapid temperature changes.
- The trim is integral with the diffuser.
- Custom molded, anti-aging gasket(s).
- Stainless steel external hardware.
- Custom MCPCB utilized to maximize heat dissipation and promote a long LED life.
- 100% uniform diffused light emission.
- Input voltage: 120-277 V (50 / 60 Hz), integral driver.
- Standard hinge-style housing allows for a simplified installation.
- Consult factory for dimming options, custom finishes and non-cataloged CCT (Kelvin) options.
- 5-year warranty.
- Product meets Buy American requirements within ARRA.

Product codes

Part number	Lampholder	Wattage	Voltage	CRI	Kelvin	Optic	Optic Beam	Lightsource lumen output	Luminaire lumen output	L	B	Lifetime	Download
HIGH POWER LEDS 120-277 V
079384	LED	11 W	120-277V	-	3000	-	-	1278	377	L80	-	50000	Documentation: MAGICLICK OVAL SHADE V LED [8.27"] - 079384
079386	LED	11 W	120-277V	-	3000	-	-	1278	377	L80	-	50000	Documentation: MAGICLICK OVAL SHADE V LED [8.27"] - 079386
079388	LED	11 W	120-277V	-	3000	-	-	1278	377	L80	-	50000	Documentation: MAGICLICK OVAL SHADE V LED [8.27"] - 079388
079402	LED	11 W	120-277V	-	4000	-	-	1320	414	L80	-	50000	Documentation: MAGICLICK OVAL SHADE V LED [8.27"] - 079402
079404	LED	11 W	120-277V	-	4000	-	-	1320	414	L80	-	50000	Documentation: MAGICLICK OVAL SHADE V LED [8.27"] - 079404
079406	LED	11 W	120-277V	-	4000	-	-	1320	414	L80	-	50000	Documentation: MAGICLICK OVAL SHADE V LED [8.27"] - 079406

Sources

LED

11 W
