STEEL ROUND MAXI RAD

IN
  • In-ground step mark series. Fixtures consist of:
  • - Copper-free (<1%) die-cast aluminum housing and die-cast corrosion-resistant AISI 316 stainless steel dome (RAD versions).
  • - High transmittance, internally frosted, pressed glass diffuser, thermally, and chemically quenched to strengthen the impact resistance and reduce the effect of rapid temperature changes (RAD versions).
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - ustom MCPCB utilized to maximize heat dissipation and promote long LED life.
  • - Ground-level side-light emission (RAD 90°, 180°, and 360°).
  • - Input voltage: 120-277 V (50 / 60 Hz), integral driver.
  • - Pre-wired cable connects luminaire with WATER-STOP connection system, suitable for through wiring. Included cable glands accept cables from Ø0.35" up to Ø0.63".
  • - COMPACT reduced depth rough-in comes with formed steel bars to provide support in drive-over applications and is designed to encourage water drainage.
  • - Each rough-in kit is provided with a protective faceplate to avoid possible deformations during the installation in concrete to simplify installation.
  • - Standard easy-to-adjust mounting system that enables the fixture to be easily aimed even after installation.
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - hermoplastic compression-molded rough-in kit to be ordered separately.
  • - For outdoor inground applications, provide drainage gravel at least 12" below the rough-in or a suitable drainage system.
  • - Product meets Buy American Act (BAA) requirements within ARRA.
  • - 5-year warranty.
STEEL ROUND MAXI COMPACT LED 180°

STEEL ROUND MAXI COMPACT LED 180°

  • In-ground step mark series. Fixtures consist of:
  • - Copper-free (<1%) die-cast aluminum housing and die-cast corrosion-resistant AISI 316 stainless steel dome (RAD versions).
  • - High transmittance, internally frosted, pressed glass diffuser, thermally, and chemically quenched to strengthen the impact resistance and reduce the effect of rapid temperature changes (RAD versions).
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - ustom MCPCB utilized to maximize heat dissipation and promote long LED life.
  • - Ground-level side-light emission (RAD 90°, 180°, and 360°).
  • - Input voltage: 120-277 V (50 / 60 Hz), integral driver.
  • - Pre-wired cable connects luminaire with WATER-STOP connection system, suitable for through wiring. Included cable glands accept cables from Ø0.35" up to Ø0.63".
  • - COMPACT reduced depth rough-in comes with formed steel bars to provide support in drive-over applications and is designed to encourage water drainage.
  • - Each rough-in kit is provided with a protective faceplate to avoid possible deformations during the installation in concrete to simplify installation.
  • - Standard easy-to-adjust mounting system that enables the fixture to be easily aimed even after installation.
  • - hermoplastic compression-molded rough-in kit to be ordered separately.
  • - For outdoor inground applications, provide drainage gravel at least 12" below the rough-in or a suitable drainage system.
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Product meets Buy American Act (BAA) requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finishing Lampholder Wattage Voltage CRI Kelvin Optic Beam
angle		 Lightsource
lumen
output
[lm]		 Luminaire
lumen
output
[lm]		 L B Lifetime Downloads
High Power LEDS 120-277 V
074096 LED 12 W 120/277 V 80 3000 - - 648 306 - - 60000 Download

Documentation: STEEL ROUND MAXI COMPACT LED 180° - 074096
074284 LED 12 W 120/277 V 80 6000 - - 1080 382 - - 60000 Download

Documentation: STEEL ROUND MAXI COMPACT LED 180° - 074284

Sources

LED 12 W
STEEL ROUND MAXI COMPACT LED 360°

STEEL ROUND MAXI COMPACT LED 360°

  • In-ground step mark series. Fixtures consist of:
  • - Copper-free (<1%) die-cast aluminum housing and die-cast corrosion-resistant AISI 316 stainless steel dome (RAD versions).
  • - High transmittance, internally frosted, pressed glass diffuser, thermally, and chemically quenched to strengthen the impact resistance and reduce the effect of rapid temperature changes (RAD versions).
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - ustom MCPCB utilized to maximize heat dissipation and promote long LED life.
  • - Ground-level side-light emission (RAD 90°, 180°, and 360°).
  • - Input voltage: 120-277 V (50 / 60 Hz), integral driver.
  • - Pre-wired cable connects luminaire with WATER-STOP connection system, suitable for through wiring. Included cable glands accept cables from Ø0.35" up to Ø0.63".
  • - COMPACT reduced depth rough-in comes with formed steel bars to provide support in drive-over applications and is designed to encourage water drainage.
  • - Each rough-in kit is provided with a protective faceplate to avoid possible deformations during the installation in concrete to simplify installation.
  • - Standard easy-to-adjust mounting system that enables the fixture to be easily aimed even after installation.
  • - hermoplastic compression-molded rough-in kit to be ordered separately.
  • - For outdoor inground applications, provide drainage gravel at least 12" below the rough-in or a suitable drainage system.
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Product meets Buy American Act (BAA) requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finishing Lampholder Wattage Voltage CRI Kelvin Optic Beam
angle		 Lightsource
lumen
output
[lm]		 Luminaire
lumen
output
[lm]		 L B Lifetime Downloads
High Power LEDS 120-277 V
074098 LED 18 W 120/277 V 80 3000 - - 972 452 - - 60000 Download

Documentation: STEEL ROUND MAXI COMPACT LED 360° - 074098
074286 LED 18 W 120/277 V 80 6000 - - 1620 564 - - 60000 Download

Documentation: STEEL ROUND MAXI COMPACT LED 360° - 074286

Sources

LED 18 W
STEEL ROUND MAXI COMPACT LED 90°

STEEL ROUND MAXI COMPACT LED 90°

  • In-ground step mark series. Fixtures consist of:
  • - Copper-free (<1%) die-cast aluminum housing and die-cast corrosion-resistant AISI 316 stainless steel dome (RAD versions).
  • - High transmittance, internally frosted, pressed glass diffuser, thermally, and chemically quenched to strengthen the impact resistance and reduce the effect of rapid temperature changes (RAD versions).
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - ustom MCPCB utilized to maximize heat dissipation and promote long LED life.
  • - Ground-level side-light emission (RAD 90°, 180°, and 360°).
  • - Input voltage: 120-277 V (50 / 60 Hz), integral driver.
  • - Pre-wired cable connects luminaire with WATER-STOP connection system, suitable for through wiring. Included cable glands accept cables from Ø0.35" up to Ø0.63".
  • - COMPACT reduced depth rough-in comes with formed steel bars to provide support in drive-over applications and is designed to encourage water drainage.
  • - Each rough-in kit is provided with a protective faceplate to avoid possible deformations during the installation in concrete to simplify installation.
  • - Standard easy-to-adjust mounting system that enables the fixture to be easily aimed even after installation.
  • - hermoplastic compression-molded rough-in kit to be ordered separately.
  • - For outdoor inground applications, provide drainage gravel at least 12" below the rough-in or a suitable drainage system.
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Product meets Buy American Act (BAA) requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finishing Lampholder Wattage Voltage CRI Kelvin Optic Beam
angle		 Lightsource
lumen
output
[lm]		 Luminaire
lumen
output
[lm]		 L B Lifetime Downloads
High Power LEDS 120-277 V
074094 LED 6 W 120/277 V 80 3000 - - 324 146 - - 60000 Download

Documentation: STEEL ROUND MAXI COMPACT LED 90° - 074094
074282 LED 6 W 120/277 V 80 6000 - - 540 199 - - 60000 Download

Documentation: STEEL ROUND MAXI COMPACT LED 90° - 074282

Sources

LED 6 W
