STEEL ROUND MIDI RAD

IN
  • In-ground step mark series. Fixtures consist of:
  • - Copper-free die-cast aluminum housing and die-cast corrosion-resistant AISI 316 stainless steel dome (RAD versions).
  • - High transmittance, internally frosted, soda-lime pressed glass diffuser, thermally and chemically quenched to strenghen the impact resistance and reduce the affect of rapid temperature changes (RAD versions).
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Custom MCPCB utilized to maximize heat dissipation and promote a long LED life.
  • - Ground level side-emission light distribution (RAD 90°, 180°, and 360°).
  • - Input voltage: 120-277 V (50 / 60 Hz), integral driver.
  • - Pre-wired cable connects luminaire with WATER-STOP connection system, suitable for through wiring. Included cable glands accept cables from Ø0.35" up to Ø0.63".
  • - COMPACT reduced depth rough-in comes with formed steel bars to provide support in drive-over applications and is designed to encourage water drainage.
  • - Each rough-in kit is delivered with a protective cover to avoid possible deformations during the installation in concrete to simplify installation.
  • - Standard easy-to-adjust mounting system that enables the fixture to be easily aimed even after installation.
  • - Rough-in kit to be ordered separately.
  • - For outdoor inground applications, provide drainage gravel at least 12" below the rough-in or a suitable drainage system.
  • - Consult factory for dimming options, custom finishes and non-cataloged CCT (Kelvin) options.
  • - Product meets Buy American requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finish Lampholder Wattage Voltage CRI Kelvin Optic Optic
Beam
Lightsource
lumen
output
Luminaire
lumen
output
L B Lifetime Download
HIGH POWER LEDS 120-277 V
075968 LED 5.4 W 120-277V - 3000 - - 348 114 - - 60000 Download

Documentation: STEEL ROUND COMPACT LED 180° - 075968

075974 LED 5.4 W 120-277V - 4000 - - 470 159 - - 60000 Download

Documentation: STEEL ROUND COMPACT LED 180° - 075974

075980 LED 5.4 W 120-277V - 6000 - - 470 146 - - 60000 Download

Documentation: STEEL ROUND COMPACT LED 180° - 075980

Sources

LED 5.4 W
  • In-ground step mark series. Fixtures consist of:
  • - Copper-free die-cast aluminum housing and die-cast corrosion-resistant AISI 316 stainless steel dome (RAD versions).
  • - High transmittance, internally frosted, soda-lime pressed glass diffuser, thermally and chemically quenched to strenghen the impact resistance and reduce the affect of rapid temperature changes (RAD versions).
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Custom MCPCB utilized to maximize heat dissipation and promote a long LED life.
  • - Ground level side-emission light distribution (RAD 90°, 180°, and 360°).
  • - Input voltage: 120-277 V (50 / 60 Hz), integral driver.
  • - Pre-wired cable connects luminaire with WATER-STOP connection system, suitable for through wiring. Included cable glands accept cables from Ø0.35" up to Ø0.63".
  • - COMPACT reduced depth rough-in comes with formed steel bars to provide support in drive-over applications and is designed to encourage water drainage.
  • - Each rough-in kit is delivered with a protective cover to avoid possible deformations during the installation in concrete to simplify installation.
  • - Standard easy-to-adjust mounting system that enables the fixture to be easily aimed even after installation.
  • - Rough-in kit to be ordered separately.
  • - For outdoor inground applications, provide drainage gravel at least 12" below the rough-in or a suitable drainage system.
  • - Consult factory for dimming options, custom finishes and non-cataloged CCT (Kelvin) options.
  • - Product meets Buy American requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finish Lampholder Wattage Voltage CRI Kelvin Optic Optic
Beam
Lightsource
lumen
output
Luminaire
lumen
output
L B Lifetime Download
HIGH POWER LEDS 120-277 V
075970 LED 7.8 W 120-277V - 3000 - - 522 168 - - 60000 Download

Documentation: STEEL ROUND COMPACT LED 360° - 075970

075976 LED 7.8 W 120-277V - 4000 - - 705 214 - - 60000 Download

Documentation: STEEL ROUND COMPACT LED 360° - 075976

075982 LED 7.8 W 120-277V - 6000 - - 705 212 - - 60000 Download

Documentation: STEEL ROUND COMPACT LED 360° - 075982

Sources

LED 7.8 W
  • In-ground step mark series. Fixtures consist of:
  • - Copper-free die-cast aluminum housing and die-cast corrosion-resistant AISI 316 stainless steel dome (RAD versions).
  • - High transmittance, internally frosted, soda-lime pressed glass diffuser, thermally and chemically quenched to strenghen the impact resistance and reduce the affect of rapid temperature changes (RAD versions).
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Custom MCPCB utilized to maximize heat dissipation and promote a long LED life.
  • - Ground level side-emission light distribution (RAD 90°, 180°, and 360°).
  • - Input voltage: 120-277 V (50 / 60 Hz), integral driver.
  • - Pre-wired cable connects luminaire with WATER-STOP connection system, suitable for through wiring. Included cable glands accept cables from Ø0.35" up to Ø0.63".
  • - COMPACT reduced depth rough-in comes with formed steel bars to provide support in drive-over applications and is designed to encourage water drainage.
  • - Each rough-in kit is delivered with a protective cover to avoid possible deformations during the installation in concrete to simplify installation.
  • - Standard easy-to-adjust mounting system that enables the fixture to be easily aimed even after installation.
  • - Rough-in kit to be ordered separately.
  • - For outdoor inground applications, provide drainage gravel at least 12" below the rough-in or a suitable drainage system.
  • - Consult factory for dimming options, custom finishes and non-cataloged CCT (Kelvin) options.
  • - Product meets Buy American requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finish Lampholder Wattage Voltage CRI Kelvin Optic Optic
Beam
Lightsource
lumen
output
Luminaire
lumen
output
L B Lifetime Download
HIGH POWER LEDS 120-277 V
075966 LED 3.6 W 120-277V - 3000 - - 174 57 - - 60000 Download

Documentation: STEEL ROUND COMPACT LED 90° - 075966

075972 LED 3.6 W 120-277V - 4000 - - 235 75 - - 60000 Download

Documentation: STEEL ROUND COMPACT LED 90° - 075972

075978 LED 3.6 W 120-277V - 6000 - - 235 69 - - 60000 Download

Documentation: STEEL ROUND COMPACT LED 90° - 075978

Sources

LED 3.6 W
