STEEL ROUND MIDI

STEEL ROUND COMPACT LED ELL 10°X45°

ELLIPTICAL REFLECTOR

In-ground series. Fixtures consist of:
- Copper-free die-cast aluminum housing and die-cast corrosion-resistant AISI 316 stainless steel trim.
- Extra-clear, flat, tempered silk screened soda-lime glass diffuser.
- Custom molded, anti-aging gasket(s).
- Stainless steel external hardware.
- Custom MCPCB utilized to maximize heat dissipation and promote a long LED life.
- High-transmittance transparent optics.
- Standard aimable optic system (±7°).
- 10° x 45° beam angle (ELL).
- Input voltage: 120-277 V (50 / 60 Hz), integral driver.
- Pre-wired cable connects luminaire with WATER-STOP connection system, suitable for through wiring. Included cable glands accept cables from Ø0.35" up to Ø0.63".
- COMPACT reduced depth rough-in comes with formed steel bars to provide support in drive-over applications and is designed to encourage water drainage.
- Each rough-in kit is delivered with a protective cover to avoid possible deformations during the installation in concrete to simplify installation.
- Standard easy-to-adjust mounting system that enables the fixture to be easily aimed even after installation.
- Rough-in kit to be ordered separately.
- For outdoor inground applications, provide drainage gravel at least 12" below the rough-in or a suitable drainage system.
- Consult factory for dimming options, custom finishes and non-cataloged CCT (Kelvin) options.
- Consult factory for frosted or non-slip glass options.
- Product meets Buy American requirements within ARRA.
- 5-year warranty.

Product codes

Part number	Lampholder	Wattage	Voltage	CRI	Kelvin	Optic	Optic Beam	Lightsource lumen output	Luminaire lumen output	L	B	Lifetime	Download
HIGH POWER LEDS 120-277 V
075994	LED	7.6 W	120-277V	-	3000	-	10°x45°	582	256	-	-	60000	Documentation: STEEL ROUND COMPACT LED ELL 10°X45° - 075994
075996	LED	7.6 W	120-277V	-	4000	-	10°x45°	810	352	-	-	60000	Documentation: STEEL ROUND COMPACT LED ELL 10°X45° - 075996
075998	LED	7.6 W	120-277V	-	6000	-	10°x45°	810	328	-	-	60000	Documentation: STEEL ROUND COMPACT LED ELL 10°X45° - 075998

Sources

LED

7.6 W

INTENSIVE CIRCLE REFLECTOR

In-ground series. Fixtures consist of:
- Copper-free die-cast aluminum housing and die-cast corrosion-resistant AISI 316 stainless steel trim.
- Extra-clear, flat, tempered silk screened soda-lime glass diffuser.
- Custom molded, anti-aging gasket(s).
- Stainless steel external hardware.
- Custom MCPCB utilized to maximize heat dissipation and promote a long LED life.
- High-transmittance transparent optics.
- Standard aimable optic system (±7°).
- 8° x 8° beam angle (C/I).
- Input voltage: 120-277 V (50 / 60 Hz), integral driver.
- Pre-wired cable connects luminaire with WATER-STOP connection system, suitable for through wiring. Included cable glands accept cables from Ø0.35" up to Ø0.63".
- COMPACT reduced depth rough-in comes with formed steel bars to provide support in drive-over applications and is designed to encourage water drainage.
- Each rough-in kit is delivered with a protective cover to avoid possible deformations during the installation in concrete to simplify installation.
- Standard easy-to-adjust mounting system that enables the fixture to be easily aimed even after installation.
- Rough-in kit to be ordered separately.
- For outdoor inground applications, provide drainage gravel at least 12" below the rough-in or a suitable drainage system.
- Consult factory for dimming options, custom finishes and non-cataloged CCT (Kelvin) options.
- Consult factory for frosted or non-slip glass options.
- Product meets Buy American requirements within ARRA.
- 5-year warranty.

Product codes

Part number	Lampholder	Wattage	Voltage	CRI	Kelvin	Optic	Optic Beam	Lightsource lumen output	Luminaire lumen output	L	B	Lifetime	Download
HIGH POWER LEDS 120-277 V
075988	LED	7.6 W	120-277V	-	3000	-	8°	582	320	-	-	60000	Documentation: STEEL ROUND COMPACT LED I 8° - 075988
075990	LED	7.6 W	120-277V	-	4000	-	8°	810	467	-	-	60000	Documentation: STEEL ROUND COMPACT LED I 8° - 075990
075992	LED	7.6 W	120-277V	-	6000	-	8°	810	419	-	-	60000	Documentation: STEEL ROUND COMPACT LED I 8° - 075992

Sources

LED

7.6 W
