GUELL 4

IN
  • Long-lasting energy-efficient architectural, landscape and professional flood light series. Fixtures consist of:
  • - Copper-free precision die-cast aluminum housing, and adjustable steel mounting bracket.
  • - Extra-clear, flat, tempered silk-screened soda-lime glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - High-efficiency COB, combined with an optimized passive cooling system, provides a long LED life.
  • - Internal specular reflector coated with 5-layers of PVD 99.98% pure aluminum providing >95% reflection.
  • - NEMA 7H x 7V light distribution (S/W).
  • - NEMA 7H x 5V light distribution (Type II).
  • - Input voltage: 120-277 V (50 / 60 Hz), integral driver.
  • - Pre-wired factory sealed cable for external electrical connection included.
  • - Standard quick release latch(es) allow for tool-free access.
  • - Louver, frosted glass, protective grid and matching junction box plate accessories available (ordered separately).
  • - Consult factory for dimming options, custom finishes (please specify RAL color), and non-cataloged CCT (Kelvin) options including static colors.
  • - Consult factory for custom pre-wired factory sealed cable length options.
  • - Product meets Buy American Act requirements within ARRA.
  • - 5-year warranty.
GUELL 4 S/W

GUELL 4 S/W

Symmetric wide reflector
  • Long-lasting energy-efficient architectural, landscape and professional flood light series. Fixtures consist of:
  • - Copper-free precision die-cast aluminum housing, and adjustable steel mounting bracket.
  • - Extra-clear, flat, tempered silk-screened soda-lime glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - High-efficiency COB, combined with an optimized passive cooling system, provides a long LED life.
  • - Internal specular reflector coated with 5-layers of PVD 99.98% pure aluminum providing >95% reflection.
  • - NEMA 7H x 7V light distribution (S/W).
  • - Input voltage: 120-277 V (50 / 60 Hz), integral driver.
  • - Pre-wired factory sealed cable for external electrical connection included.
  • - Standard quick release latch(es) allow for tool-free access.
  • - Louver, frosted glass, protective grid and matching junction box plate accessories available (ordered separately).
  • - Consult factory for dimming options, custom finishes (please specify RAL color), and non-cataloged CCT (Kelvin) options including static colors.
  • - Consult factory for custom pre-wired factory sealed cable length options.
  • - Product meets Buy American Act requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finish Lampholder Wattage Voltage CRI Kelvin Optic Optic
Beam		 Lightsource
lumen
output		 Luminaire
lumen
output		 L B Lifetime Download
High Power LEDS 120-277 V
070589 LED 420 W 120-277 V 50/60 Hz 80 4000 - - 58452 53096 L70 B10 55000 Download

Documentation: GUELL 4 S/W - 070589

Sources

LED 420 W
GUELL 4 TYPE II

GUELL 4 TYPE II

Asymmetric wide reflector
  • Long-lasting energy-efficient architectural, landscape and professional flood light series. Fixtures consist of:
  • - Copper-free precision die-cast aluminum housing, and adjustable steel mounting bracket.
  • - Extra-clear, flat, tempered silk-screened soda-lime glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - High-efficiency COB, combined with an optimized passive cooling system, provides a long LED life.
  • - Internal specular reflector coated with 5-layers of PVD 99.98% pure aluminum providing >95% reflection.
  • - NEMA 7H x 5V light distribution (Type II).
  • - Input voltage: 120-277 V (50 / 60 Hz), integral driver.
  • - Pre-wired factory sealed cable for external electrical connection included.
  • - Standard quick release latch(es) allow for tool-free access.
  • - Louver, frosted glass, protective grid and matching junction box plate accessories available (ordered separately).
  • - Consult factory for dimming options, custom finishes (please specify RAL color), and non-cataloged CCT (Kelvin) options including static colors.
  • - Consult factory for custom pre-wired factory sealed cable length options.
  • - Product meets Buy American Act requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finish Lampholder Wattage Voltage CRI Kelvin Optic Optic
Beam		 Lightsource
lumen
output		 Luminaire
lumen
output		 L B Lifetime Download
High Power LEDS 120-277 V
070588 LED 420 W 120-277 V 50/60 Hz 80 4000 - - 58452 48892 L70 B10 55000 Download

Documentation: GUELL 4 TYPE II - 070588

Sources

LED 420 W
