GUELL ZERO

IN
  • Economical low-profile landscape flood light series. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free precision die-cast aluminum housing, ring/faceplate, and adjustable mounting arm.
  • - Extra-clear, flat, tempered silk-screened soda-lime glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - High-efficiency COB, combined with an optimized passive cooling system, provides a long LED life.
  • - NEMA 6H x 5V light distribution (S/W).
  • - Input voltage: 120-277 V (50 / 60 Hz), integral 1-10 V dimming driver.
  • - Pre-wired factory sealed cable for external electrical connection included.
  • - Standard robust ½” NPS knuckle mount with 180° adjustable swivel arm (SA versions) and rugged, locking teeth for a simplified installation.
  • - 5-year warranty.
  • Economical low-profile landscape flood light series. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free precision die-cast aluminum housing, ring/faceplate, and adjustable mounting arm.
  • - Extra-clear, flat, tempered silk-screened soda-lime glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - High-efficiency COB, combined with an optimized passive cooling system, provides a long LED life.
  • - NEMA 6H x 5V light distribution (S/W).
  • - Input voltage: 120-277 V (50 / 60 Hz), integral 1-10 V dimming driver.
  • - Pre-wired factory sealed cable for external electrical connection included.
  • - Standard robust ½” NPS knuckle mount with 180° adjustable swivel arm (SA versions) and rugged, locking teeth for a simplified installation.
  • - 5-year warranty.
Product codes
Part number Finish Lampholder Wattage Voltage CRI Kelvin Optic Optic
Beam
Lightsource
lumen
output
Luminaire
lumen
output
L B Lifetime Download
High Power LEDS 120-277 V - Dimmable 1-10 V
079843 LED 13 W 120-277 V 50/60 Hz 80 4000 - - 1927 1549 L80 B10 220000 Download

Documentation: GUELL ZERO SA S/W - 079843

079844 LED 13 W 120-277 V 50/60 Hz 80 4000 - - 1927 1549 L80 B10 220000 Download

Documentation: GUELL ZERO SA S/W - 079844

079845 LED 26 W 120-277 V 50/60 Hz 80 4000 - - 3619 2769 L80 B10 110000 Download

Documentation: GUELL ZERO SA S/W - 079845

079846 LED 26 W 120-277 V 50/60 Hz 80 4000 - - 3619 2769 L80 B10 110000 Download

Documentation: GUELL ZERO SA S/W - 079846

Sources

LED 13 W
LED 26 W
