GUELL 3

  • Long-lasting energy-efficient floodlight series. Fixtures consist of:
  • - Copper-free (<1%) precision die-cast aluminum housing, and adjustable steel mounting bracket.
  • - Extra-clear, tempered, silk-screened, flat glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - High-efficiency COB, combined with an optimized passive cooling system, provides a long LED life.
  • - Internal specular reflector coated with 5-layers of PVD 99.98% pure aluminum providing >95% reflection.
  • - NEMA 6H x 5V light distribution (Type II).
  • - Symmetric Wide optics (S/W).
  • - NEMA 7H x 5V light distribution (A50/W).
  • - Input voltage: 120-277 V (50 / 60 Hz), integral 0-10 V dimming driver.
  • - Pre-wired factory sealed cable for external electrical connection included.
  • - Standard quick release latch(es) allow for tool-free access.
  • - Standard heavy-duty slip-fitter (SF versions) for 2 3/8" OD pipe for a simplified installation.
  • - Louver, frosted glass, protective grid, wall support 19.69" / 39.37", single or double pole top support, and matching junction box plate accessories available (ordered separately).
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Contact factory for any Buy American Act (BAA) or Build America Buy America Act (BABAA) requirements.
  • - 5-year warranty.
GUELL 3 A50/W

GUELL 3 A50/W

Optic | Asymmetric Wide
  • Long-lasting energy-efficient floodlight series. Fixtures consist of:
  • - Copper-free (<1%) precision die-cast aluminum housing, and adjustable steel mounting bracket.
  • - Extra-clear, tempered, silk-screened, flat glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - High-efficiency COB, combined with an optimized passive cooling system, provides a long LED life.
  • - Internal specular reflector coated with 5-layers of PVD 99.98% pure aluminum providing >95% reflection.
  • - NEMA 7H x 5V light distribution (A50/W).
  • - Input voltage: 120-277 V (50 / 60 Hz), integral 0-10 V dimming driver.
  • - Pre-wired factory sealed cable for external electrical connection included.
  • - Standard quick release latch(es) allow for tool-free access.
  • - Louver, frosted glass, protective grid, wall support 19.69" / 39.37", single or double pole top support, and matching junction box plate accessories available (ordered separately).
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Contact factory for any Buy American Act (BAA) or Build America Buy America Act (BABAA) requirements.
  • - 5-year warranty.
Product codes
Part number Finishing Lampholder Wattage Voltage CRI Kelvin Optic Beam
angle		 Lightsource
lumen
output
[lm]		 Luminaire
lumen
output
[lm]		 L B Lifetime Downloads
Mid Power LEDS 120-277 V Dimmable 0-10 V
070438 LED 230 W 120/277 V 80 4000 Type III - 36256 27496 L80 B10 55000 Download

Documentation: GUELL 3 A50/W - 070438
070439 LED 305 W 120/277 V 80 4000 Type III - 48341 35814 L80 B10 55000 Download

Documentation: GUELL 3 A50/W - 070439

Sources

LED 230 W
LED 305 W
GUELL 3 A50/W SF

GUELL 3 A50/W SF

Optic | Asymmetric Wide
  • Long-lasting energy-efficient floodlight series. Fixtures consist of:
  • - Copper-free (<1%) precision die-cast aluminum housing, and adjustable steel mounting bracket.
  • - Extra-clear, tempered, silk-screened, flat glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - High-efficiency COB, combined with an optimized passive cooling system, provides a long LED life.
  • - Internal specular reflector coated with 5-layers of PVD 99.98% pure aluminum providing >95% reflection.
  • - NEMA 7H x 5V light distribution (A50/W).
  • - Input voltage: 120-277 V (50 / 60 Hz), integral 0-10 V dimming driver.
  • - Pre-wired factory sealed cable for external electrical connection included.
  • - Standard heavy-duty slip-fitter (SF versions) for 2 3/8" OD pipe for a simplified installation.
  • - Standard quick release latch(es) allow for tool-free access.
  • - Louver, frosted glass, protective grid, wall support 19.69" / 39.37", single or double pole top support, and matching junction box plate accessories available (ordered separately).
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Contact factory for any Buy American Act (BAA) or Build America Buy America Act (BABAA) requirements.
  • - 5-year warranty.
Product codes
Part number Finishing Lampholder Wattage Voltage CRI Kelvin Optic Beam
angle		 Lightsource
lumen
output
[lm]		 Luminaire
lumen
output
[lm]		 L B Lifetime Downloads
High Power LEDS 120-277 V Dimmable 0-10 V
070572 LED 230 W 120/277 V 80 4000 Type III - 36256 27496 L80 B10 55000 Download

Documentation: GUELL 3 A50/W SF - 070572
070573 LED 230 W 120/277 V 80 4000 Type III - 36256 27496 L80 B10 55000 Download

Documentation: GUELL 3 A50/W SF - 070573
070574 LED 305 W 120/277 V 80 4000 Type III - 48341 35814 L80 B10 55000 Download

Documentation: GUELL 3 A50/W SF - 070574
070575 LED 305 W 120/277 V 80 4000 Type III - 48341 35814 L80 B10 55000 Download

Documentation: GUELL 3 A50/W SF - 070575

Sources

LED 230 W
LED 305 W
GUELL 3 S/W

GUELL 3 S/W

Optic | Symmetric Wide
  • Long-lasting energy-efficient floodlight series. Fixtures consist of:
  • - Copper-free (<1%) precision die-cast aluminum housing, and adjustable steel mounting bracket.
  • - Extra-clear, tempered, silk-screened, flat glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - High-efficiency COB, combined with an optimized passive cooling system, provides a long LED life.
  • - Internal specular reflector coated with 5-layers of PVD 99.98% pure aluminum providing >95% reflection.
  • - Symmetric Wide optics (S/W).
  • - Input voltage: 120-277 V (50 / 60 Hz), integral 0-10 V dimming driver.
  • - Pre-wired factory sealed cable for external electrical connection included.
  • - Standard quick release latch(es) allow for tool-free access.
  • - Louver, frosted glass, protective grid, wall support 19.69" / 39.37", single or double pole top support, and matching junction box plate accessories available (ordered separately).
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Contact factory for any Buy American Act (BAA) or Build America Buy America Act (BABAA) requirements.
  • - 5-year warranty.
Product codes
Part number Finishing Lampholder Wattage Voltage CRI Kelvin Optic Beam
angle		 Lightsource
lumen
output
[lm]		 Luminaire
lumen
output
[lm]		 L B Lifetime Downloads
High Power LEDS 120-277 V Dimmable 0-10 V
070227 LED 165 W 120/277 V 80 4000 - - 21140 17645 L70 B10 130000 Download

Documentation: GUELL 3 S/W - 070227
070228 LED 240 W 120/277 V 80 4000 - - 31710 25296 L70 B10 130000 Download

Documentation: GUELL 3 S/W - 070228
070229 LED 320 W 120/277 V 80 4000 - - 42280 33822 L70 B10 130000 Download

Documentation: GUELL 3 S/W - 070229

Sources

LED 165 W
LED 240 W
LED 320 W
GUELL 3 S/W SF

GUELL 3 S/W SF

Optic | Symmetric Wide
  • Long-lasting energy-efficient floodlight series. Fixtures consist of:
  • - Copper-free (<1%) precision die-cast aluminum housing, and adjustable steel mounting bracket.
  • - Extra-clear, tempered, silk-screened, flat glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - High-efficiency COB, combined with an optimized passive cooling system, provides a long LED life.
  • - Internal specular reflector coated with 5-layers of PVD 99.98% pure aluminum providing >95% reflection.
  • - Symmetric Wide optics (S/W).
  • - Input voltage: 120-277 V (50 / 60 Hz), integral 0-10 V dimming driver.
  • - Pre-wired factory sealed cable for external electrical connection included.
  • - Standard heavy-duty slip-fitter (SF versions) for 2 3/8" OD pipe for a simplified installation.
  • - Standard quick release latch(es) allow for tool-free access.
  • - Louver, frosted glass, protective grid, wall support 19.69" / 39.37", single or double pole top support, and matching junction box plate accessories available (ordered separately).
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Contact factory for any Buy American Act (BAA) or Build America Buy America Act (BABAA) requirements.
  • - 5-year warranty.
Product codes
Part number Finishing Lampholder Wattage Voltage CRI Kelvin Optic Beam
angle		 Lightsource
lumen
output
[lm]		 Luminaire
lumen
output
[lm]		 L B Lifetime Downloads
High Power LEDS 120-277 V Dimmable 0-10 V
070576 LED 165 W 120/277 V 80 4000 Type II - 20168 17645 L70 B10 130000 Download

Documentation: GUELL 3 S/W SF - 070576
070577 LED 165 W 120/277 V 80 4000 Type II - 20168 17645 L70 B10 130000 Download

Documentation: GUELL 3 S/W SF - 070577
070578 LED 240 W 120/277 V 80 4000 Type II - 31710 25296 L70 B10 130000 Download

Documentation: GUELL 3 S/W SF - 070578
070579 LED 240 W 120/277 V 80 4000 Type II - 31710 25296 L70 B10 130000 Download

Documentation: GUELL 3 S/W SF - 070579
070580 LED 320 W 120/277 V 80 4000 Type II - 42280 33822 L70 B10 130000 Download

Documentation: GUELL 3 S/W SF - 070580
070581 LED 320 W 120/277 V 80 4000 Type II - 42280 33822 L70 B10 130000 Download

Documentation: GUELL 3 S/W SF - 070581

Sources

LED 165 W
LED 240 W
LED 320 W
GUELL 3 TYPE II

GUELL 3 TYPE II

  • Long-lasting energy-efficient floodlight series. Fixtures consist of:
  • - Copper-free (<1%) precision die-cast aluminum housing, and adjustable steel mounting bracket.
  • - Extra-clear, tempered, silk-screened, flat glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - High-efficiency COB, combined with an optimized passive cooling system, provides a long LED life.
  • - Internal specular reflector coated with 5-layers of PVD 99.98% pure aluminum providing >95% reflection.
  • - NEMA 6H x 5V light distribution (Type II).
  • - Input voltage: 120-277 V (50 / 60 Hz), integral 0-10 V dimming driver.
  • - Pre-wired factory sealed cable for external electrical connection included.
  • - Standard quick release latch(es) allow for tool-free access.
  • - Louver, frosted glass, protective grid, wall support 19.69" / 39.37", single or double pole top support, and matching junction box plate accessories available (ordered separately).
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Contact factory for any Buy American Act (BAA) or Build America Buy America Act (BABAA) requirements.
  • - 5-year warranty.
Product codes
Part number Finishing Lampholder Wattage Voltage CRI Kelvin Optic Beam
angle		 Lightsource
lumen
output
[lm]		 Luminaire
lumen
output
[lm]		 L B Lifetime Downloads
High Power LEDS 120-277 V Dimmable 0-10 V
070224 LED 165 W 120/277 V 80 4000 Type II - 21140 16586 L70 B10 130000 Download

Documentation: GUELL 3 TYPE II - 070224
070225 LED 240 W 120/277 V 80 4000 Type II - 31710 23778 L70 B10 130000 Download

Documentation: GUELL 3 TYPE II - 070225
070226 LED 320 W 120/277 V 80 4000 Type II - 42280 31793 L70 B10 130000 Download

Documentation: GUELL 3 TYPE II - 070226

Sources

LED 165 W
LED 240 W
LED 320 W
GUELL 3 TYPE II SF

GUELL 3 TYPE II SF

Optic | Asymmetric Wide
  • Long-lasting energy-efficient floodlight series. Fixtures consist of:
  • - Copper-free (<1%) precision die-cast aluminum housing, and adjustable steel mounting bracket.
  • - Extra-clear, tempered, silk-screened, flat glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - High-efficiency COB, combined with an optimized passive cooling system, provides a long LED life.
  • - Internal specular reflector coated with 5-layers of PVD 99.98% pure aluminum providing >95% reflection.
  • - NEMA 6H x 5V light distribution (Type II).
  • - Input voltage: 120-277 V (50 / 60 Hz), integral 0-10 V dimming driver.
  • - Pre-wired factory sealed cable for external electrical connection included.
  • - Standard heavy-duty slip-fitter (SF versions) for 2 3/8" OD pipe for a simplified installation.
  • - Standard quick release latch(es) allow for tool-free access.
  • - Louver, frosted glass, protective grid, wall support 19.69" / 39.37", single or double pole top support, and matching junction box plate accessories available (ordered separately).
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Contact factory for any Buy American Act (BAA) or Build America Buy America Act (BABAA) requirements.
  • - 5-year warranty.
Product codes
Part number Finishing Lampholder Wattage Voltage CRI Kelvin Optic Beam
angle		 Lightsource
lumen
output
[lm]		 Luminaire
lumen
output
[lm]		 L B Lifetime Downloads
High Power LEDS 120-277 V Dimmable 0-10 V
070582 LED 165 W 120/277 V 80 4000 Type II - 20168 16586 L70 B10 130000 Download

Documentation: GUELL 3 TYPE II SF - 070582
070583 LED 165 W 120/277 V 80 4000 Type II - 20168 16586 L70 B10 130000 Download

Documentation: GUELL 3 TYPE II SF - 070583
070584 LED 240 W 120/277 V 80 4000 Type II - 31710 23778 L70 B10 130000 Download

Documentation: GUELL 3 TYPE II SF - 070584
070585 LED 240 W 120/277 V 80 4000 Type II - 31710 23778 L70 B10 130000 Download

Documentation: GUELL 3 TYPE II SF - 070585
070586 LED 320 W 120/277 V 80 4000 Type II - 42280 31793 L70 B10 130000 Download

Documentation: GUELL 3 TYPE II SF - 070586
070587 LED 320 W 120/277 V 80 4000 Type II - 42280 31793 L70 B10 130000 Download

Documentation: GUELL 3 TYPE II SF - 070587

Sources

LED 165 W
LED 240 W
LED 320 W

Product Family

GUELL 1 GUELL 1
GUELL 2 GUELL 2
GUELL 4 GUELL 4
GUELL ZERO GUELL ZERO
Open filters Close filters
Welcome!
You can enter the PERFORMANCE iN LIGHTING world by consulting the sites available for each country, differentiated by language, services, and catalogue offerings. Choose the country or geographical area you are in.
Confirm USA/Canada (us) Change country
Products search
You can search for products in our catalog by entering here the name or the code of the product or accessory.
