GUELL 2

IN
  • Long-lasting energy-efficient architectural, landscape and professional flood light series. Fixtures consist of:
  • - Copper-free precision die-cast aluminum housing, and adjustable steel mounting bracket.
  • - Extra-clear, flat, tempered silk-screened soda-lime glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - High-efficiency COB, combined with an optimized passive cooling system, provides a long LED life.
  • - Internal specular reflector coated with 5-layers of PVD 99.98% pure aluminum providing >95% reflection.
  • - NEMA 5H x 5V light distribution (C/IW)
  • - NEMA 7H x 5V light distribution (S/W).
  • - NEMA 7H x 5V light distribution (Type II).
  • - Input voltage: 120-277 V (50 / 60 Hz), integral 0-10 V dimming driver.
  • - Pre-wired factory sealed cable for external electrical connection included.
  • - Standard quick release latch(es) allow for tool-free access.
  • - Standard heavy-duty slip-fitter (SF versions) for 2 3/8" OD pipe for a simplified installation.
  • - Louver, frosted glass, protective grid, wall support 19.69" / 39.37", single or double pole top support, and matching junction box plate accessories available (ordered separately).
  • - Consult factory for dimming options, custom finishes (please specify RAL color), and non-cataloged CCT (Kelvin) options.
  • - Consult factory for custom pre-wired factory sealed cable length options.
  • - Product meets Buy American Act requirements within ARRA.
  • - 5-year warranty.
GUELL 2 C/IW

GUELL 2 C/IW

Wide Circle Intensive Reflector
  • Long-lasting energy-efficient architectural, landscape and professional flood light series. Fixtures consist of:
  • - Copper-free precision die-cast aluminum housing, and adjustable steel mounting bracket.
  • - Extra-clear, flat, tempered silk-screened soda-lime glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - High-efficiency COB, combined with an optimized passive cooling system, provides a long LED life.
  • - Internal specular reflector coated with 5-layers of PVD 99.98% pure aluminum providing >95% reflection.
  • - NEMA 5H x 5V light distribution (C/IW)
  • - Input voltage: 120-277 V (50 / 60 Hz), integral 0-10 V dimming driver.
  • - Pre-wired factory sealed cable for external electrical connection included.
  • - Standard quick release latch(es) allow for tool-free access.
  • - Louver, frosted glass, protective grid, wall support 19.69" / 39.37", single or double pole top support, and matching junction box plate accessories available (ordered separately).
  • - Consult factory for dimming options, custom finishes (please specify RAL color), and non-cataloged CCT (Kelvin) options.
  • - Consult factory for custom pre-wired factory sealed cable length options.
  • - Product meets Buy American Act requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finish Lampholder Wattage Voltage CRI Kelvin Optic Optic
Beam		 Lightsource
lumen
output		 Luminaire
lumen
output		 L B Lifetime Download
High Power LEDS 120-277 V - Dimmable 0-10 V
070436 LED 90 W 120-277 V 50/60 Hz 80 4000 - - 10570 8210 L70 B10 150000 Download

Documentation: GUELL 2 C/IW - 070436
070437 LED 110 W 120-277 V 50/60 Hz 80 4000 - - 13958 10517 L70 B10 150000 Download

Documentation: GUELL 2 C/IW - 070437

Sources

LED 90 W
LED 110 W
GUELL 2 C/IW SF

GUELL 2 C/IW SF

Wide Circle Intensive Reflector
  • Long-lasting energy-efficient architectural, landscape and professional flood light series. Fixtures consist of:
  • - Copper-free precision die-cast aluminum housing, and adjustable steel mounting bracket.
  • - Extra-clear, flat, tempered silk-screened soda-lime glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - High-efficiency COB, combined with an optimized passive cooling system, provides a long LED life.
  • - Internal specular reflector coated with 5-layers of PVD 99.98% pure aluminum providing >95% reflection.
  • - NEMA 5H x 5V light distribution (C/IW)
  • - Input voltage: 120-277 V (50 / 60 Hz), integral 0-10 V dimming driver.
  • - Pre-wired factory sealed cable for external electrical connection included.
  • - Standard heavy-duty slip-fitter (SF versions) for 2 3/8" OD pipe for a simplified installation.
  • - Standard quick release latch(es) allow for tool-free access.
  • - Louver, frosted glass, protective grid, wall support 19.69" / 39.37", single or double pole top support, and matching junction box plate accessories available (ordered separately).
  • - Consult factory for dimming options, custom finishes (please specify RAL color), and non-cataloged CCT (Kelvin) options.
  • - Consult factory for custom pre-wired factory sealed cable length options.
  • - Product meets Buy American Act requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finish Lampholder Wattage Voltage CRI Kelvin Optic Optic
Beam		 Lightsource
lumen
output		 Luminaire
lumen
output		 L B Lifetime Download
High Power LEDS 120-277 V - Dimmable 0-10 V
070560 LED 90 W 120-277 V 50/60 Hz 80 4000 - - 11625 8210 L70 B10 150000 Download

Documentation: GUELL 2 C/IW SF - 070560
070561 LED 90 W 120-277 V 50/60 Hz 80 4000 - - 11625 8210 L70 B10 150000 Download

Documentation: GUELL 2 C/IW SF - 070561
070562 LED 110 W 120-277 V 50/60 Hz 80 4000 - - 14614 10517 L70 B10 130000 Download

Documentation: GUELL 2 C/IW SF - 070562
070563 LED 110 W 120-277 V 50/60 Hz 80 4000 - - 14614 10517 L70 B10 130000 Download

Documentation: GUELL 2 C/IW SF - 070563

Sources

LED 90 W
LED 110 W
GUELL 2 S/W

GUELL 2 S/W

SYMMETRIC WIDE REFLECTOR
  • Long-lasting energy-efficient architectural, landscape and professional flood light series. Fixtures consist of:
  • - Copper-free precision die-cast aluminum housing, and adjustable steel mounting bracket.
  • - Extra-clear, flat, tempered silk-screened soda-lime glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - High-efficiency COB, combined with an optimized passive cooling system, provides a long LED life.
  • - Internal specular reflector coated with 5-layers of PVD 99.98% pure aluminum providing >95% reflection.
  • - NEMA 7H x 5V light distribution (S/W).
  • - Input voltage: 120-277 V (50 / 60 Hz), integral 0-10 V dimming driver.
  • - Pre-wired factory sealed cable for external electrical connection included.
  • - Standard quick release latch(es) allow for tool-free access.
  • - Louver, frosted glass, protective grid, wall support 19.69" / 39.37", single or double pole top support, and matching junction box plate accessories available (ordered separately).
  • - Consult factory for dimming options, custom finishes (please specify RAL color), and non-cataloged CCT (Kelvin) options.
  • - Consult factory for custom pre-wired factory sealed cable length options.
  • - Product meets Buy American Act requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finish Lampholder Wattage Voltage CRI Kelvin Optic Optic
Beam		 Lightsource
lumen
output		 Luminaire
lumen
output		 L B Lifetime Download
High Power LEDS 120-277 V - Dimmable 0-10 V
070222 LED 90 W 120-277 V 80 4000 - - 10570 8937 L70 B10 150000 Download

Documentation: GUELL 2 S/W - 070222
070223 LED 110 W 120-277 V 80 4000 - - 13958 11137 L70 B10 130000 Download

Documentation: GUELL 2 S/W - 070223

Sources

LED 90 W
LED 110 W
GUELL 2 S/W SF

GUELL 2 S/W SF

SYMMETRIC WIDE REFLECTOR
  • Long-lasting energy-efficient architectural, landscape and professional flood light series. Fixtures consist of:
  • - Copper-free precision die-cast aluminum housing, and adjustable steel mounting bracket.
  • - Extra-clear, flat, tempered silk-screened soda-lime glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - High-efficiency COB, combined with an optimized passive cooling system, provides a long LED life.
  • - Internal specular reflector coated with 5-layers of PVD 99.98% pure aluminum providing >95% reflection.
  • - NEMA 7H x 5V light distribution (S/W).
  • - Input voltage: 120-277 V (50 / 60 Hz), integral 0-10 V dimming driver.
  • - Pre-wired factory sealed cable for external electrical connection included.
  • - Standard heavy-duty slip-fitter (SF versions) for 2 3/8" OD pipe for a simplified installation.
  • - Standard quick release latch(es) allow for tool-free access.
  • - Louver, frosted glass, protective grid, wall support 19.69" / 39.37", single or double pole top support, and matching junction box plate accessories available (ordered separately).
  • - Consult factory for dimming options, custom finishes (please specify RAL color), and non-cataloged CCT (Kelvin) options.
  • - Consult factory for custom pre-wired factory sealed cable length options.
  • - Product meets Buy American Act requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finish Lampholder Wattage Voltage CRI Kelvin Optic Optic
Beam		 Lightsource
lumen
output		 Luminaire
lumen
output		 L B Lifetime Download
High Power LEDS 120-277 V - Dimmable 0-10 V
070564 LED 90 W 120-277 V 50/60 Hz 80 4000 - - 10570 8937 L70 B10 150000 Download

Documentation: GUELL 2 S/W SF - 070564
070565 LED 90 W 120-277 V 50/60 Hz 80 4000 - - 10570 8937 L70 B10 150000 Download

Documentation: GUELL 2 S/W SF - 070565
070566 LED 110 W 120-277 V 50/60 Hz 80 4000 - - 13958 11137 L70 B10 130000 Download

Documentation: GUELL 2 S/W SF - 070566
070567 LED 110 W 120-277 V 50/60 Hz 80 4000 - - 13958 11137 L70 B10 130000 Download

Documentation: GUELL 2 S/W SF - 070567

Sources

LED 90 W
LED 110 W
GUELL 2 TYPE II

GUELL 2 TYPE II

  • Long-lasting energy-efficient architectural, landscape and professional flood light series. Fixtures consist of:
  • - Copper-free precision die-cast aluminum housing, and adjustable steel mounting bracket.
  • - Extra-clear, flat, tempered silk-screened soda-lime glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - High-efficiency COB, combined with an optimized passive cooling system, provides a long LED life.
  • - Internal specular reflector coated with 5-layers of PVD 99.98% pure aluminum providing >95% reflection.
  • - NEMA 7H x 5V light distribution (Type II).
  • - Input voltage: 120-277 V (50 / 60 Hz), integral 0-10 V dimming driver.
  • - Pre-wired factory sealed cable for external electrical connection included.
  • - Standard quick release latch(es) allow for tool-free access.
  • - Louver, frosted glass, protective grid, wall support 19.69" / 39.37", single or double pole top support, and matching junction box plate accessories available (ordered separately).
  • - Consult factory for dimming options, custom finishes (please specify RAL color), and non-cataloged CCT (Kelvin) options.
  • - Consult factory for custom pre-wired factory sealed cable length options.
  • - Product meets Buy American Act requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finish Lampholder Wattage Voltage CRI Kelvin Optic Optic
Beam		 Lightsource
lumen
output		 Luminaire
lumen
output		 L B Lifetime Download
High Power LEDS 120-277 V - Dimmable 0-10 V
070220 LED 90 W 120-277 V 80 4000 Type II - 10570 8720 L70 B10 150000 Download

Documentation: GUELL 2 TYPE II - 070220
070221 LED 110 W 120-277 V 80 4000 Type II - 13958 10844 L70 B10 130000 Download

Documentation: GUELL 2 TYPE II - 070221

Sources

LED 90 W
LED 110 W
GUELL 2 TYPE II SF

GUELL 2 TYPE II SF

Asymmetric Wide Reflector
  • Long-lasting energy-efficient architectural, landscape and professional flood light series. Fixtures consist of:
  • - Copper-free precision die-cast aluminum housing, and adjustable steel mounting bracket.
  • - Extra-clear, flat, tempered silk-screened soda-lime glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - High-efficiency COB, combined with an optimized passive cooling system, provides a long LED life.
  • - Internal specular reflector coated with 5-layers of PVD 99.98% pure aluminum providing >95% reflection.
  • - NEMA 7H x 5V light distribution (Type II).
  • - Input voltage: 120-277 V (50 / 60 Hz), integral 0-10 V dimming driver.
  • - Pre-wired factory sealed cable for external electrical connection included.
  • - Standard heavy-duty slip-fitter (SF versions) for 2 3/8" OD pipe for a simplified installation.
  • - Standard quick release latch(es) allow for tool-free access.
  • - Louver, frosted glass, protective grid, wall support 19.69" / 39.37", single or double pole top support, and matching junction box plate accessories available (ordered separately).
  • - Consult factory for dimming options, custom finishes (please specify RAL color), and non-cataloged CCT (Kelvin) options.
  • - Consult factory for custom pre-wired factory sealed cable length options.
  • - Product meets Buy American Act requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finish Lampholder Wattage Voltage CRI Kelvin Optic Optic
Beam		 Lightsource
lumen
output		 Luminaire
lumen
output		 L B Lifetime Download
High Power LEDS 120-277 V - Dimmable 0-10 V
070568 LED 90 W 120-277 V 50/60 Hz 80 4000 - - 10570 8720 L70 B10 150000 Download

Documentation: GUELL 2 TYPE II SF - 070568
070569 LED 90 W 120-277 V 50/60 Hz 80 4000 - - 10570 8720 L70 B10 150000 Download

Documentation: GUELL 2 TYPE II SF - 070569
070570 LED 110 W 120-277 V 50/60 Hz 80 4000 - - 13958 10844 L70 B10 130000 Download

Documentation: GUELL 2 TYPE II SF - 070570
070571 LED 110 W 120-277 V 50/60 Hz 80 4000 - - 13958 10844 L70 B10 130000 Download

Documentation: GUELL 2 TYPE II SF - 070571

Sources

LED 90 W
LED 110 W

Product Family

GUELL 1 GUELL 1
GUELL 3 GUELL 3
GUELL 4 GUELL 4
GUELL ZERO GUELL ZERO
to top
Request information
Products search
You can search for products in our catalog by entering here the name or the code of the product or accessory.
I cookie ci aiutano a fornire i nostri servizi. Utilizzando tali servizi, accetti l'utilizzo dei cookie da parte nostra. Info
