HEDO+

IN
  • Area and site lighting series. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free precision die-cast aluminum housing and top cap.
  • - Custom molded, anti-aging gasket(s).
  • - Micro-prismatic patterned, tempered, silk-screened, flat glass diffuser.
  • - Stainless steel external hardware.
  • - Custom MCPCB utilized to maximize heat dissipation and promote a long LED life.
  • - IESNA Type V light distribution.
  • - Input voltage: 120-277 V (50 / 60 Hz), integral 0-10 V dimming driver.
  • - Integral surge protector can withstand up to 10 kV transient line surge.
  • - Pre-wired factory sealed cable for external electrical connection included.
  • - Consult factory for dimming options, marine-grade, custom finishes (please specify RAL color), and non-cataloged CCT (Kelvin) options including static colors.
  • - Consult factory for custom pre-wired factory sealed cable length options.
  • - Consult factory for pole information.
  • - Consult factory for wall bracket accessory, multi-head pole top mounting, and other custom options.
  • - Product meets Buy American Act requirements within ARRA.
  • - 5-year warranty.
HEDO+ TYPE V

HEDO+ TYPE V

Extra wide circle reflector
  • Area and site lighting series. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free precision die-cast aluminum housing and top cap.
  • - Custom molded, anti-aging gasket(s).
  • - Micro-prismatic patterned, tempered, silk-screened, flat glass diffuser.
  • - Stainless steel external hardware.
  • - Custom MCPCB utilized to maximize heat dissipation and promote a long LED life.
  • - IESNA Type V light distribution.
  • - Input voltage: 120-277 V (50 / 60 Hz), integral 0-10 V dimming driver.
  • - Integral surge protector can withstand up to 10 kV transient line surge.
  • - Pre-wired factory sealed cable for external electrical connection included.
  • - Consult factory for dimming options, marine-grade, custom finishes (please specify RAL color), and non-cataloged CCT (Kelvin) options including static colors.
  • - Consult factory for custom pre-wired factory sealed cable length options.
  • - Consult factory for pole information.
  • - Consult factory for wall bracket accessory, multi-head pole top mounting, and other custom options.
  • - Product meets Buy American Act requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finish Lampholder Wattage Voltage CRI Kelvin Optic Optic
Beam		 Lightsource
lumen
output		 Luminaire
lumen
output		 L B Lifetime Download
High Power LEDS 120-277 V - Dimmable 0-10 V
072089 LED 23 W 120-277 V 50/60 Hz 80 3000 - - 3150 2080 L80 B10 100000 Download

Documentation: HEDO+ TYPE V - 072089
072090 LED 35 W 120-277 V 50/60 Hz 80 3000 - - 5355 3171 L80 B10 100000 Download

Documentation: HEDO+ TYPE V - 072090
072100 LED 23 W 120-277 V 50/60 Hz 80 4000 - - 3247 2145 L80 B10 100000 Download

Documentation: HEDO+ TYPE V - 072100
072102 LED 35 W 120-277 V 50/60 Hz 80 4000 - - 5519 3269 L80 B10 100000 Download

Documentation: HEDO+ TYPE V - 072102

Sources

LED 23 W
LED 35 W

Product Family

HEDO+ FT HEDO+ FT
