HEDO+ FT

  • Area and site lighting series. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free (<1%) precision die-cast aluminum housing and top cap.
  • - Custom molded, anti-aging gasket(s).
  • - High-transparency polycarbonate optics for optimized light transmission.
  • - Extra-clear, tempered, silk-screened, flat glass diffuser.
  • - Stainless steel external hardware.
  • - Custom MCPCB utilized to maximize heat dissipation and promote long LED life.
  • - Type II light distribution.
  • - Type V light distribution.
  • - Input voltage: 120-277 V (50 / 60 Hz), integral 0-10 V dimming driver.
  • - Pre-wired factory sealed cable for external electrical connection included.
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Contact factory for any Buy American Act (BAA) or Build America Buy America Act (BABAA) requirements.
  • - 5-year warranty.
HEDO+ FT TYPE II

HEDO+ FT TYPE II

Optic | IESNA Type distribution
  • Area and site lighting series. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free (<1%) precision die-cast aluminum housing and top cap.
  • - Custom molded, anti-aging gasket(s).
  • - High-transparency polycarbonate optics for optimized light transmission.
  • - Extra-clear, tempered, silk-screened, flat glass diffuser.
  • - Stainless steel external hardware.
  • - Custom MCPCB utilized to maximize heat dissipation and promote long LED life.
  • - Type II light distribution.
  • - Input voltage: 120-277 V (50 / 60 Hz), integral 0-10 V dimming driver.
  • - Pre-wired factory sealed cable for external electrical connection included.
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Contact factory for any Buy American Act (BAA) or Build America Buy America Act (BABAA) requirements.
  • - 5-year warranty.
Product codes
Part number Finishing Lampholder Wattage Voltage CRI Kelvin Optic Beam
angle		 Lightsource
lumen
output
[lm]		 Luminaire
lumen
output
[lm]		 L B Lifetime Downloads
High Power LEDS 120-277 V Dimmable 0-10 V
072080 LED 19 W 120/277 V 70 3000 Type II - 2740 2109 L90 B10 100000 HEDO+ FT TYPE II Download

Documentation: HEDO+ FT TYPE II - 072080
072081 LED 27 W 120/277 V 70 3000 Type II - 3813 2945 L90 B10 100000 HEDO+ FT TYPE II Download

Documentation: HEDO+ FT TYPE II - 072081
072082 LED 34 W 120/277 V 70 3000 Type II - 4886 3690 L90 B10 100000 HEDO+ FT TYPE II Download

Documentation: HEDO+ FT TYPE II - 072082
072083 LED 40 W 120/277 V 70 3000 Type II - 5719 4291 L90 B10 100000 HEDO+ FT TYPE II Download

Documentation: HEDO+ FT TYPE II - 072083
072091 LED 19 W 120/277 V 70 4000 Type II - 2833 2258 L90 B10 100000 HEDO+ FT TYPE II Download

Documentation: HEDO+ FT TYPE II - 072091
072092 LED 27 W 120/277 V 70 4000 Type II - 3942 3176 L90 B10 100000 HEDO+ FT TYPE II Download

Documentation: HEDO+ FT TYPE II - 072092
072093 LED 34 W 120/277 V 70 4000 Type II - 5143 3971 L90 B10 100000 HEDO+ FT TYPE II Download

Documentation: HEDO+ FT TYPE II - 072093
072094 LED 40 W 120/277 V 70 4000 Type II - 6021 4653 L90 B10 100000 HEDO+ FT TYPE II Download

Documentation: HEDO+ FT TYPE II - 072094

Sources

LED 19 W
LED 27 W
LED 34 W
LED 40 W
HEDO+ FT TYPE V

HEDO+ FT TYPE V

Optic | Circular Extra-Wide
  • Area and site lighting series. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free (<1%) precision die-cast aluminum housing and top cap.
  • - Custom molded, anti-aging gasket(s).
  • - High-transparency polycarbonate optics for optimized light transmission.
  • - Extra-clear, tempered, silk-screened, flat glass diffuser.
  • - Stainless steel external hardware.
  • - Custom MCPCB utilized to maximize heat dissipation and promote long LED life.
  • - Type V light distribution.
  • - Input voltage: 120-277 V (50 / 60 Hz), integral 0-10 V dimming driver.
  • - Pre-wired factory sealed cable for external electrical connection included.
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Contact factory for any Buy American Act (BAA) or Build America Buy America Act (BABAA) requirements.
  • - 5-year warranty.
Product codes
Part number Finishing Lampholder Wattage Voltage CRI Kelvin Optic Beam
angle		 Lightsource
lumen
output
[lm]		 Luminaire
lumen
output
[lm]		 L B Lifetime Downloads
High Power LEDS 120-277 V Dimmable 0-10 V
072084 LED 18 W 120/277 V 70 3000 Type V - 2862 2077 L90 B10 100000 HEDO+ FT TYPE V Download

Documentation: HEDO+ FT TYPE V - 072084
072085 LED 25 W 120/277 V 70 3000 Type V - 3975 2879 L90 B10 100000 HEDO+ FT TYPE V Download

Documentation: HEDO+ FT TYPE V - 072085
072086 LED 36 W 120/277 V 70 3000 Type V - 5724 4132 L90 B10 100000 HEDO+ FT TYPE V Download

Documentation: HEDO+ FT TYPE V - 072086
072087 LED 43 W 120/277 V 70 3000 Type V - 6837 4924 L90 B10 100000 HEDO+ FT TYPE V Download

Documentation: HEDO+ FT TYPE V - 072087
072088 LED 50 W 120/277 V 70 3000 Type V - 7882 5319 L90 B10 100000 HEDO+ FT TYPE V Download

Documentation: HEDO+ FT TYPE V - 072088
072095 LED 18 W 120/277 V 70 4000 Type V - 3006 2185 L90 B10 100000 HEDO+ FT TYPE V Download

Documentation: HEDO+ FT TYPE V - 072095
072096 LED 25 W 120/277 V 70 4000 Type V - 4175 3024 L90 B10 100000 HEDO+ FT TYPE V Download

Documentation: HEDO+ FT TYPE V - 072096
072097 LED 36 W 120/277 V 70 4000 Type V - 6012 4349 L90 B10 100000 HEDO+ FT TYPE V Download

Documentation: HEDO+ FT TYPE V - 072097
072098 LED 43 W 120/277 V 70 4000 Type V - 7181 5189 L90 B10 100000 HEDO+ FT TYPE V Download

Documentation: HEDO+ FT TYPE V - 072098
072099 LED 50 W 120/277 V 70 4000 Type V - 8279 5605 L90 B10 100000 HEDO+ FT TYPE V Download

Documentation: HEDO+ FT TYPE V - 072099

Sources

LED 18 W
LED 25 W
LED 36 W
LED 43 W
LED 50 W
