Q-WALL

  • Wall mount series. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free (<1%) extruded aluminum housing and Copper-free (<1%) precision die-cast aluminum ring/faceplate, bracket (WALL versions) and mounting plate.
  • - Copper-free (<1%) die-cast aluminum heat-sink passive cooling system.
  • - Extra-clear, tempered, silk-screened, flat glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - High-efficiency COB, combined with an optimized passive cooling system, provides a long LED life.
  • - Internal specular reflector coated with 5-layers of PVD 99.98% pure aluminum providing >95% reflection.
  • - Single (M) or dual (B) light emission.
  • - Circular Intensive optics (C/I).
  • - Circular Medium optics (C/M).
  • - Circular Wide optics (C/W).
  • - Input voltage: 120-277 V (50 / 60 Hz), integral 0-10 V dimming driver.
  • - Optional, integral, emergency battery-pack designed for a minimum operation of 90 minutes (EMPK versions).
  • - Standard hinged bracket for ease of installation: wiring can be completed by mounting the bracket ahead of the luminaire, then sliding luminaire onto the bracket using quick connectors system, then securing the luminaire by tightening the stainless steel set screws (WALL versions only).
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Contact factory for any Buy American Act (BAA) or Build America Buy America Act (BABAA) requirements.
  • - 5-year warranty.
Q-WALL B

Q-WALL B

Optic | Circular Intensive
  • Wall mount series. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free (<1%) extruded aluminum housing and Copper-free (<1%) precision die-cast aluminum ring/faceplate, bracket (WALL versions) and mounting plate.
  • - Copper-free (<1%) die-cast aluminum heat-sink passive cooling system.
  • - Extra-clear, tempered, silk-screened, flat glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - High-efficiency COB, combined with an optimized passive cooling system, provides a long LED life.
  • - Internal specular reflector coated with 5-layers of PVD 99.98% pure aluminum providing >95% reflection.
  • - Single (M) or dual (B) light emission.
  • - Circular Intensive optics (C/I).
  • - Circular Medium optics (C/M).
  • - Circular Wide optics (C/W).
  • - Input voltage: 120-277 V (50 / 60 Hz), integral 0-10 V dimming driver.
  • - Standard hinged bracket for ease of installation: wiring can be completed by mounting the bracket ahead of the luminaire, then sliding luminaire onto the bracket using quick connectors system, then securing the luminaire by tightening the stainless steel set screws (WALL versions only).
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Contact factory for any Buy American Act (BAA) or Build America Buy America Act (BABAA) requirements.
  • - 5-year warranty.
Product codes
Part number Finishing Lampholder Wattage Voltage CRI Kelvin Optic Beam
angle		 Lightsource
lumen
output
[lm]		 Luminaire
lumen
output
[lm]		 L B Lifetime Downloads
High Power LEDS 120-277 V Dimmable 0-10 V
070110 LED 60 W 120/277 V 80 3000 - 20° 6624 5755 L80 B10 55000 Download

Documentation: Q-WALL B - 070110
070111 LED 60 W 120/277 V 80 3000 - 20° 6624 5755 L80 B10 55000 Download

Documentation: Q-WALL B - 070111
070112 LED 60 W 120/277 V 80 3000 - 20° 6624 5755 L80 B10 55000 Download

Documentation: Q-WALL B - 070112
070113 LED 60 W 120/277 V 80 3000 - 40° 6624 5725 L80 B10 55000 Download

Documentation: Q-WALL B - 070113
070114 LED 60 W 120/277 V 80 3000 - 40° 6624 5725 L80 B10 55000 Download

Documentation: Q-WALL B - 070114
070115 LED 60 W 120/277 V 80 3000 - 40° 6624 5725 L80 B10 55000 Download

Documentation: Q-WALL B - 070115
070116 LED 60 W 120/277 V 80 3000 - 85° 6624 5796 L80 B10 55000 Download

Documentation: Q-WALL B - 070116
070117 LED 60 W 120/277 V 80 3000 - 85° 6624 5796 L80 B10 55000 Download

Documentation: Q-WALL B - 070117
070118 LED 60 W 120/277 V 80 3000 - 85° 6624 5796 L80 B10 55000 Download

Documentation: Q-WALL B - 070118
070119 LED 60 W 120/277 V 80 4000 - 20° 6904 6122 L80 B10 55000 Download

Documentation: Q-WALL B - 070119
070120 LED 60 W 120/277 V 80 4000 - 20° 6904 6122 L80 B10 55000 Download

Documentation: Q-WALL B - 070120
070121 LED 60 W 120/277 V 80 4000 - 20° 6904 6122 L80 B10 55000 Download

Documentation: Q-WALL B - 070121
070122 LED 60 W 120/277 V 80 4000 - 40° 6904 6090 L80 B10 55000 Download

Documentation: Q-WALL B - 070122
070123 LED 60 W 120/277 V 80 4000 - 40° 6904 6090 L80 B10 55000 Download

Documentation: Q-WALL B - 070123
070124 LED 60 W 120/277 V 80 4000 - 40° 6904 6090 L80 B10 55000 Download

Documentation: Q-WALL B - 070124
070125 LED 60 W 120/277 V 80 4000 - 85° 6904 6167 L80 B10 55000 Download

Documentation: Q-WALL B - 070125
070126 LED 60 W 120/277 V 80 4000 - 85° 6904 6167 L80 B10 55000 Download

Documentation: Q-WALL B - 070126
070127 LED 60 W 120/277 V 80 4000 - 85° 6904 6167 L80 B10 55000 Download

Documentation: Q-WALL B - 070127

Sources

LED 60 W
Q-WALL M

Q-WALL M

Optic | Circular Intensive
  • Wall mount series. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free (<1%) extruded aluminum housing and Copper-free (<1%) precision die-cast aluminum ring/faceplate, bracket (WALL versions) and mounting plate.
  • - Copper-free (<1%) die-cast aluminum heat-sink passive cooling system.
  • - Extra-clear, tempered, silk-screened, flat glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - High-efficiency COB, combined with an optimized passive cooling system, provides a long LED life.
  • - Internal specular reflector coated with 5-layers of PVD 99.98% pure aluminum providing >95% reflection.
  • - Single (M) or dual (B) light emission.
  • - Circular Intensive optics (C/I).
  • - Circular Medium optics (C/M).
  • - Circular Wide optics (C/W).
  • - Input voltage: 120-277 V (50 / 60 Hz), integral 0-10 V dimming driver.
  • - Standard hinged bracket for ease of installation: wiring can be completed by mounting the bracket ahead of the luminaire, then sliding luminaire onto the bracket using quick connectors system, then securing the luminaire by tightening the stainless steel set screws (WALL versions only).
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Contact factory for any Buy American Act (BAA) or Build America Buy America Act (BABAA) requirements.
  • - 5-year warranty.
Product codes
Part number Finishing Lampholder Wattage Voltage CRI Kelvin Optic Beam
angle		 Lightsource
lumen
output
[lm]		 Luminaire
lumen
output
[lm]		 L B Lifetime Downloads
High Power LEDS 120-277 V Dimmable 0-10 V
070092 LED 30 W 120/277 V 80 3000 - 20° 3312 2878 L80 B10 55000 Download

Documentation: Q-WALL M - 070092
070093 LED 30 W 120/277 V 80 3000 - 20° 3312 2878 L80 B10 55000 Download

Documentation: Q-WALL M - 070093
070094 LED 30 W 120/277 V 80 3000 - 20° 3312 2878 L80 B10 55000 Download

Documentation: Q-WALL M - 070094
070095 LED 30 W 120/277 V 80 3000 - 40° 3312 2863 L80 B10 55000 Download

Documentation: Q-WALL M - 070095
070096 LED 30 W 120/277 V 80 3000 - 40° 3312 2863 L80 B10 55000 Download

Documentation: Q-WALL M - 070096
070097 LED 30 W 120/277 V 80 3000 - 40° 3312 2863 L80 B10 55000 Download

Documentation: Q-WALL M - 070097
070098 LED 30 W 120/277 V 80 3000 - 85° 3312 2898 L80 B10 55000 Download

Documentation: Q-WALL M - 070098
070099 LED 30 W 120/277 V 80 3000 - 85° 3312 2898 L80 B10 55000 Download

Documentation: Q-WALL M - 070099
070100 LED 30 W 120/277 V 80 3000 - 85° 3312 2898 L80 B10 55000 Download

Documentation: Q-WALL M - 070100
070101 LED 30 W 120/277 V 80 4000 - 20° 3452 3061 L80 B10 55000 Download

Documentation: Q-WALL M - 070101
070102 LED 30 W 120/277 V 80 4000 - 20° 3452 3061 L80 B10 55000 Download

Documentation: Q-WALL M - 070102
070103 LED 30 W 120/277 V 80 4000 - 20° 3452 3061 L80 B10 55000 Download

Documentation: Q-WALL M - 070103
070104 LED 30 W 120/277 V 80 4000 - 40° 3452 3045 L80 B10 55000 Download

Documentation: Q-WALL M - 070104
070105 LED 30 W 120/277 V 80 4000 - 40° 3452 3045 L80 B10 55000 Download

Documentation: Q-WALL M - 070105
070106 LED 30 W 120/277 V 80 4000 - 40° 3452 3045 L80 B10 55000 Download

Documentation: Q-WALL M - 070106
070107 LED 30 W 120/277 V 80 4000 - 85° 3452 3084 L80 B10 55000 Download

Documentation: Q-WALL M - 070107
070108 LED 30 W 120/277 V 80 4000 - 85° 3452 3084 L80 B10 55000 Download

Documentation: Q-WALL M - 070108
070109 LED 30 W 120/277 V 80 4000 - 85° 3452 3084 L80 B10 55000 Download

Documentation: Q-WALL M - 070109

Sources

LED 30 W
Q-WALL M EMPK

Q-WALL M EMPK

Optic | Circular Intensive
  • Wall mount series. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free (<1%) extruded aluminum housing and Copper-free (<1%) precision die-cast aluminum ring/faceplate, bracket (WALL versions) and mounting plate.
  • - Copper-free (<1%) die-cast aluminum heat-sink passive cooling system.
  • - Extra-clear, tempered, silk-screened, flat glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - High-efficiency COB, combined with an optimized passive cooling system, provides a long LED life.
  • - Internal specular reflector coated with 5-layers of PVD 99.98% pure aluminum providing >95% reflection.
  • - Circular Intensive optics (C/I).
  • - Circular Medium optics (C/M).
  • - Circular Wide optics (C/W).
  • - Input voltage: 120-277 V (50 / 60 Hz), integral 0-10 V dimming driver.
  • - Integral, emergency battery-pack designed for a minimum operation of 90 minutes (EMPK versions).
  • - Standard hinged bracket for ease of installation: wiring can be completed by mounting the bracket ahead of the luminaire, then sliding luminaire onto the bracket using quick connectors system, then securing the luminaire by tightening the stainless steel set screws (WALL versions only).
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Contact factory for any Buy American Act (BAA) or Build America Buy America Act (BABAA) requirements.
  • - 5-year warranty.
Product codes
Part number Finishing Lampholder Wattage Voltage CRI Kelvin Optic Beam
angle		 Lightsource
lumen
output
[lm]		 Luminaire
lumen
output
[lm]		 L B Lifetime Downloads
High Power LEDS 120-277 V - EMPK Dimmable 0-10 V
071471 LED 30 W 120/277 V 80 3000 - 20° 3312 2878 L80 B10 55000 Download

Documentation: Q-WALL M EMPK - 071471
071472 LED 30 W 120/277 V 80 3000 - 20° 3312 2878 L80 B10 55000 Download

Documentation: Q-WALL M EMPK - 071472
071473 LED 30 W 120/277 V 80 3000 - 20° 3312 2878 L80 B10 55000 Download

Documentation: Q-WALL M EMPK - 071473
071474 LED 30 W 120/277 V 80 3000 - 40° 3312 2863 L80 B10 55000 Download

Documentation: Q-WALL M EMPK - 071474
071475 LED 30 W 120/277 V 80 3000 - 40° 3312 2863 L80 B10 55000 Download

Documentation: Q-WALL M EMPK - 071475
071476 LED 30 W 120/277 V 80 3000 - 40° 3312 2863 L80 B10 55000 Download

Documentation: Q-WALL M EMPK - 071476
071477 LED 30 W 120/277 V 80 3000 - 85° 3312 2898 L80 B10 55000 Download

Documentation: Q-WALL M EMPK - 071477
071478 LED 30 W 120/277 V 80 3000 - 85° 3312 2898 L80 B10 55000 Download

Documentation: Q-WALL M EMPK - 071478
071479 LED 30 W 120/277 V 80 3000 - 85° 3312 2898 L80 B10 55000 Download

Documentation: Q-WALL M EMPK - 071479
071480 LED 30 W 120/277 V 80 4000 - 20° 3452 3061 L80 B10 55000 Download

Documentation: Q-WALL M EMPK - 071480
071481 LED 30 W 120/277 V 80 4000 - 20° 3452 3061 L80 B10 55000 Download

Documentation: Q-WALL M EMPK - 071481
071482 LED 30 W 120/277 V 80 4000 - 20° 3452 3061 L80 B10 55000 Download

Documentation: Q-WALL M EMPK - 071482
071483 LED 30 W 120/277 V 80 4000 - 40° 3452 3045 L80 B10 55000 Download

Documentation: Q-WALL M EMPK - 071483
071484 LED 30 W 120/277 V 80 4000 - 40° 3452 3045 L80 B10 55000 Download

Documentation: Q-WALL M EMPK - 071484
071485 LED 30 W 120/277 V 80 4000 - 40° 3452 3045 L80 B10 55000 Download

Documentation: Q-WALL M EMPK - 071485
071486 LED 30 W 120/277 V 80 4000 - 85° 3452 3084 L80 B10 55000 Download

Documentation: Q-WALL M EMPK - 071486
071487 LED 30 W 120/277 V 80 4000 - 85° 3452 3084 L80 B10 55000 Download

Documentation: Q-WALL M EMPK - 071487
071488 LED 30 W 120/277 V 80 4000 - 85° 3452 3084 L80 B10 55000 Download

Documentation: Q-WALL M EMPK - 071488

Sources

LED 30 W
Q-WALL MINI

Q-WALL MINI

Optic | Circular Intensive
  • Wall mount series. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free (<1%) extruded aluminum housing and Copper-free (<1%) precision die-cast aluminum ring/faceplate, bracket (WALL versions) and mounting plate.
  • - Copper-free (<1%) die-cast aluminum heat-sink passive cooling system.
  • - Extra-clear, tempered, silk-screened, flat glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - High-efficiency COB, combined with an optimized passive cooling system, provides a long LED life.
  • - Internal specular reflector coated with 5-layers of PVD 99.98% pure aluminum providing >95% reflection.
  • - Circular Intensive optics (C/I).
  • - Circular Medium optics (C/M).
  • - Circular Wide optics (C/W).
  • - Input voltage: 120-277 V (50 / 60 Hz), integral 0-10 V dimming driver.
  • - Standard hinged bracket for ease of installation: wiring can be completed by mounting the bracket ahead of the luminaire, then sliding luminaire onto the bracket using quick connectors system, then securing the luminaire by tightening the stainless steel set screws (WALL versions only).
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Contact factory for any Buy American Act (BAA) or Build America Buy America Act (BABAA) requirements.
  • - 5-year warranty.
Product codes
Part number Finishing Lampholder Wattage Voltage CRI Kelvin Optic Beam
angle		 Lightsource
lumen
output
[lm]		 Luminaire
lumen
output
[lm]		 L B Lifetime Downloads
High Power LEDS 120-277 V Dimmable 0-10 V
079820 LED 30 W 120/277 V 80 3000 - 20° 3312 2876 L70 B10 55000 Download

Documentation: Q-WALL MINI - 079820
079821 LED 30 W 120/277 V 80 3000 - 20° 3312 2876 L70 B10 55000 Download

Documentation: Q-WALL MINI - 079821
079822 LED 30 W 120/277 V 80 3000 - 20° 3312 2876 L70 B10 55000 Download

Documentation: Q-WALL MINI - 079822
079823 LED 30 W 120/277 V 80 3000 - 40° 3312 2861 L70 B10 55000 Download

Documentation: Q-WALL MINI - 079823
079824 LED 30 W 120/277 V 80 3000 - 40° 3312 2861 L70 B10 55000 Download

Documentation: Q-WALL MINI - 079824
079825 LED 30 W 120/277 V 80 3000 - 40° 3312 2861 L70 B10 55000 Download

Documentation: Q-WALL MINI - 079825
079826 LED 30 W 120/277 V 80 3000 - 85° 3312 2897 L70 B10 55000 Download

Documentation: Q-WALL MINI - 079826
079827 LED 30 W 120/277 V 80 3000 - 85° 3312 2897 L70 B10 55000 Download

Documentation: Q-WALL MINI - 079827
079828 LED 30 W 120/277 V 80 3000 - 85° 3312 2897 L70 B10 55000 Download

Documentation: Q-WALL MINI - 079828
079829 LED 30 W 120/277 V 80 4000 - 20° 3452 3061 L70 B10 55000 Download

Documentation: Q-WALL MINI - 079829
079830 LED 30 W 120/277 V 80 4000 - 20° 3452 3061 L70 B10 55000 Download

Documentation: Q-WALL MINI - 079830
079831 LED 30 W 120/277 V 80 4000 - 20° 3452 3061 L70 B10 55000 Download

Documentation: Q-WALL MINI - 079831
079832 LED 30 W 120/277 V 80 4000 - 40° 3452 3045 L70 B10 55000 Download

Documentation: Q-WALL MINI - 079832
079833 LED 30 W 120/277 V 80 4000 - 40° 3452 3045 L70 B10 55000 Download

Documentation: Q-WALL MINI - 079833
079834 LED 30 W 120/277 V 80 4000 - 40° 3452 3045 L70 B10 55000 Download

Documentation: Q-WALL MINI - 079834
079835 LED 30 W 120/277 V 80 4000 - 85° 3452 3084 L70 B10 55000 Download

Documentation: Q-WALL MINI - 079835
079836 LED 30 W 120/277 V 80 4000 - 85° 3452 3084 L70 B10 55000 Download

Documentation: Q-WALL MINI - 079836
079837 LED 30 W 120/277 V 80 4000 - 85° 3452 3084 L70 B10 55000 Download

Documentation: Q-WALL MINI - 079837

Sources

LED 30 W

Product Family

Q-CEILING Q-CEILING
Q-LIGHT Q-LIGHT
Q-WALL MAXI Q-WALL MAXI
Open filters Close filters
Welcome!
You can enter the PERFORMANCE iN LIGHTING world by consulting the sites available for each country, differentiated by language, services, and catalogue offerings. Choose the country or geographical area you are in.
Confirm USA/Canada (us) Change country
Products search
You can search for products in our catalog by entering here the name or the code of the product or accessory.
