Q-CEILING

  • Ceiling mount series. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free (<1%) extruded aluminum housing and Copper-free (<1%) precision die-cast aluminum ring/faceplate, bracket and mounting plate.
  • - Extra-clear, tempered, silk-screened, flat glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - High-efficiency COB, combined with an optimized passive cooling system, provides a long LED life.
  • - Internal specular reflector coated with 5-layers of PVD 99.98% pure aluminum providing >95% reflection.
  • - Circular Intensive optics (C/I).
  • - Circular Medium optics (C/M).
  • - Diffuse light emission (SOFT).
  • - Input voltage: 120-277 V (50 / 60 Hz), integral 0-10 V dimming driver.
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Product meets Buy American Act (BAA) requirements within ARRA.
  • - 5-year warranty.
Q-CEILING

Q-CEILING

  • Ceiling mount series. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free (<1%) extruded aluminum housing and Copper-free (<1%) precision die-cast aluminum ring/faceplate, bracket and mounting plate.
  • - Extra-clear, tempered, silk-screened, flat glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - High-efficiency COB, combined with an optimized passive cooling system, provides a long LED life.
  • - Internal specular reflector coated with 5-layers of PVD 99.98% pure aluminum providing >95% reflection.
  • - Circular Intensive optics (C/I).
  • - Circular Medium optics (C/M).
  • - Input voltage: 120-277 V (50 / 60 Hz), integral 0-10 V dimming driver.
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Product meets Buy American Act (BAA) requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finishing Lampholder Wattage Voltage CRI Kelvin Optic Beam
angle		 Lightsource
lumen
output
[lm]		 Luminaire
lumen
output
[lm]		 L B Lifetime Downloads
High Power LEDS 120-277 V Dimmable 0-10 V
070128 LED 30 W 120/277 V 80 3000 - 20° 3312 2876 L80 B10 55000 Download

Documentation: Q-CEILING - 070128
070129 LED 30 W 120/277 V 80 3000 - 20° 3312 2876 L80 B10 55000 Download

Documentation: Q-CEILING - 070129
070130 LED 30 W 120/277 V 80 3000 - 20° 3312 2876 L80 B10 55000 Download

Documentation: Q-CEILING - 070130
070131 LED 30 W 120/277 V 80 3000 - 40° 3312 2861 L80 B10 55000 Download

Documentation: Q-CEILING - 070131
070132 LED 30 W 120/277 V 80 3000 - 40° 3312 2861 L80 B10 55000 Download

Documentation: Q-CEILING - 070132
070133 LED 30 W 120/277 V 80 3000 - 40° 3312 2861 L80 B10 55000 Download

Documentation: Q-CEILING - 070133
070134 LED 30 W 120/277 V 80 3000 - 85° 3312 2897 L80 B10 55000 Download

Documentation: Q-CEILING - 070134
070135 LED 30 W 120/277 V 80 3000 - 85° 3312 2897 L80 B10 55000 Download

Documentation: Q-CEILING - 070135
070136 LED 30 W 120/277 V 80 3000 - 85° 3312 2897 L80 B10 55000 Download

Documentation: Q-CEILING - 070136
070137 LED 30 W 120/277 V 80 4000 - 20° 3452 3061 L80 B10 55000 Download

Documentation: Q-CEILING - 070137
070138 LED 30 W 120/277 V 80 4000 - 20° 3452 3061 L80 B10 55000 Download

Documentation: Q-CEILING - 070138
070139 LED 30 W 120/277 V 80 4000 - 40° 3452 3045 L80 B10 55000 Download

Documentation: Q-CEILING - 070139
070140 LED 30 W 120/277 V 80 4000 - 40° 3452 3045 L80 B10 55000 Download

Documentation: Q-CEILING - 070140
070141 LED 30 W 120/277 V 80 4000 - 40° 3452 3045 L80 B10 55000 Download

Documentation: Q-CEILING - 070141
070142 LED 30 W 120/277 V 80 4000 - 85° 3452 3084 L80 B10 55000 Download

Documentation: Q-CEILING - 070142
070143 LED 30 W 120/277 V 80 4000 - 85° 3452 3084 L80 B10 55000 Download

Documentation: Q-CEILING - 070143
070144 LED 30 W 120/277 V 80 4000 - 85° 3452 3084 L80 B10 55000 Download

Documentation: Q-CEILING - 070144
070151 LED 30 W 120/277 V 80 4000 - 20° 3452 3061 L80 B10 55000 Download

Documentation: Q-CEILING - 070151

Sources

LED 30 W
Q-CEILING SOFT

Q-CEILING SOFT

Optic | Symmetric Extra-Wide
  • Ceiling mount series. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free (<1%) extruded aluminum housing and Copper-free (<1%) precision die-cast aluminum ring/faceplate, bracket and mounting plate.
  • - Extra-clear, tempered, silk-screened, flat glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - High-efficiency COB, combined with an optimized passive cooling system, provides a long LED life.
  • - Internal specular reflector coated with 5-layers of PVD 99.98% pure aluminum providing >95% reflection.
  • - Diffuse light emission (SOFT).
  • - Input voltage: 120-277 V (50 / 60 Hz), integral 0-10 V dimming driver.
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Product meets Buy American Act (BAA) requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finishing Lampholder Wattage Voltage CRI Kelvin Optic Beam
angle		 Lightsource
lumen
output
[lm]		 Luminaire
lumen
output
[lm]		 L B Lifetime Downloads
High Power LEDS 120-277 V Dimmable 0-10 V
070145 LED 30 W 120/277 V 80 3000 - - 3312 2270 L80 B10 55000 Download

Documentation: Q-CEILING SOFT - 070145
070146 LED 30 W 120/277 V 80 3000 - - 3312 2270 L80 B10 55000 Download

Documentation: Q-CEILING SOFT - 070146
070147 LED 30 W 120/277 V 80 3000 - - 3312 2270 L80 B10 55000 Download

Documentation: Q-CEILING SOFT - 070147
070148 LED 30 W 120/277 V 80 4000 - - 3452 2430 L80 B10 55000 Download

Documentation: Q-CEILING SOFT - 070148
070149 LED 30 W 120/277 V 80 4000 - - 3452 2430 L80 B10 55000 Download

Documentation: Q-CEILING SOFT - 070149
070150 LED 30 W 120/277 V 80 4000 - - 3452 2430 L80 B10 55000 Download

Documentation: Q-CEILING SOFT - 070150

Sources

LED 30 W
