MASK+

IN
  • Wall sconce series. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free precision die-cast aluminum housing and mounting plate.
  • - Frosted, tempered, silk-screened, flat glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Custom MCPCB utilized to maximize heat dissipation and promote long LED life.
  • - Single (M) or dual (B) light emission.
  • - Type V light distribution.
  • - Input voltage: 120-277 V (50 / 60 Hz), integral 0-10 V dimming driver.
  • - Rectangular mounting plate included (for use RACO 8660 or equivalent); 4” tall accessory plate for use with larger junction box applications available (order separately).
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Product meets Buy American Act (BAA) requirements within ARRA.
  • - 5-year warranty.
MASK+ B

MASK+ B

Optic | Symmetric Extra-Wide
  • Wall sconce series. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free precision die-cast aluminum housing and mounting plate.
  • - Frosted, tempered, silk-screened, flat glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Custom MCPCB utilized to maximize heat dissipation and promote long LED life.
  • - Single (M) or dual (B) light emission.
  • - Type V light distribution.
  • - Input voltage: 120-277 V (50 / 60 Hz), integral 0-10 V dimming driver.
  • - Rectangular mounting plate included (for use RACO 8660 or equivalent); 4” tall accessory plate for use with larger junction box applications available (order separately).
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Product meets Buy American Act (BAA) requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finishing Lampholder Wattage Voltage CRI Kelvin Optic Beam
angle
Lightsource
lumen
output
[lm]
Luminaire
lumen
output
[lm]
L B Lifetime Downloads
Mid Power LEDS 120-277 V - Dimmable 0-10 V
072035 LED 24 W 120/277 V 80 3000 Type V - 3104 1770 L70 B10 50000 Download

Documentation: MASK+ B - 072035

072036 LED 24 W 120/277 V 80 4000 Type V - 3336 1879 L70 B10 50000 Download

Documentation: MASK+ B - 072036

072037 LED 24 W 120/277 V 80 3000 Type V - 3104 1770 L70 B10 50000 Download

Documentation: MASK+ B - 072037

072038 LED 24 W 120/277 V 80 4000 Type V - 3336 1879 L70 B10 50000 Download

Documentation: MASK+ B - 072038

Sources

LED 24 W
MASK+ M

MASK+ M

Optic | Symmetric Extra-Wide
  • Wall sconce series. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free precision die-cast aluminum housing and mounting plate.
  • - Frosted, tempered, silk-screened, flat glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Custom MCPCB utilized to maximize heat dissipation and promote long LED life.
  • - Single (M) or dual (B) light emission.
  • - Type V light distribution.
  • - Input voltage: 120-277 V (50 / 60 Hz), integral 0-10 V dimming driver.
  • - Rectangular mounting plate included (for use RACO 8660 or equivalent); 4” tall accessory plate for use with larger junction box applications available (order separately).
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Product meets Buy American Act (BAA) requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finishing Lampholder Wattage Voltage CRI Kelvin Optic Beam
angle
Lightsource
lumen
output
[lm]
Luminaire
lumen
output
[lm]
L B Lifetime Downloads
Mid Power LEDS 120-277 V - Dimmable 0-10 V
072031 LED 12.5 W 120/277 V 80 3000 Type V - 1552 914 L70 B10 50000 Download

Documentation: MASK+ M - 072031

072032 LED 12.5 W 120/277 V 80 4000 Type V - 1668 971 L70 B10 50000 Download

Documentation: MASK+ M - 072032

072033 LED 12.5 W 120/277 V 80 3000 Type V - 1552 914 L70 B10 50000 Download

Documentation: MASK+ M - 072033

072034 LED 12.5 W 120/277 V 80 4000 Type V - 1668 971 L70 B10 50000 Download

Documentation: MASK+ M - 072034

Sources

LED 12.5 W
