Less is more
The HEDO+ transforms traditional lighting by blending contemporary designs with urban styles. This organic look delivers a powerful creative statement and, at the same time, low environmental impact. The exceptional minimalistic design will meld into most surroundings—a simple yet most effective lighting solution for your urban and residential projects. With proprietary optics and various lumen options, the Hedo+ FT offers precise and superb semi-cylindrical illumination. The discreet, clean form of HEDO+ is an architectural solution for practically every project you design.
Area and site lighting series. Fixtures consist of:
  • Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • Copper-free (<1%) precision die-cast aluminum housing and top cap.
  • Custom MCPCB utilized to maximize heat dissipation and promote long LED life.
  • Micro-prismatic patterned, tempered, silk-screened, flat glass diffuser (HEDO+) and extra-clear, tempered, silk-screened, flat glass diffuser including high-transmittance transparent optics (HEDO+ FT).
  • Custom molded, anti-aging gasket(s).
  • Stainless steel external hardware.
  • Pre-wired factory sealed cable for external electrical connection included.
  • Type II (FT models only) and Type V light distributions.
  • Input voltage: 120-277 V (50 / 60 Hz), integral 0-10 V dimming driver.
  • The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • UL Wet location listed. IP65 rated.
  • Product meets Buy American Act (BAA) requirements within ARRA.
  • Photometric data measured according to UNI EN 13032-1/4 and IES LM-79-08
  • The light distribution complies with the IESNA Full Cut-Off Classification and is eligible for all “Dark Sky” applications when aimed down.
  • Actual performance may differ as a result of the end-user environment and application. All values are design or typical values, measured under laboratory conditions at 25 °C. Specifications are subject to change without notice.
  • 5-year limited warranty. Complete warranty terms located at www.performanceinlighting.com
