STRIP SQUARE+ 528 A/M

Description

• Linear surface mount series. Fixtures consist of:
• - Copper-free aluminum die-cast end-caps, extruded, and anodized housing.
• - Copper-free aluminum extruded and anodized field-adjustable mounting bracket for aiming the luminaire.
• - Extra-clear, tempered, silk-screened, flat glass diffuser.
• - Custom molded, anti-aging gasket(s).
• - Stainless steel external hardware.
• - Custom MCPCB utilized to maximize heat dissipation and promote a long LED life.
• - High-transmittance transparent optics.
• - 9° x 9° beam angle (C/I).
• - 15° x 45° beam angle (ELL).
• - 40° x 60° beam angle (ELL).
• - NEMA 5H x 4V light distribution (A18/M).
• - 15° x 45° beam angle (RGBW).
• - 15° x 45° beam angle (2700K - 6500K Dynamic Tunable White).
• - Input voltage: 120-277 V (50 / 60 Hz), integral 0-10 V dimming driver.
• - Input voltage: 48 V DC, separate driver (Dynamic Color Change versions).
• - Pre-wired factory sealed cable for external electrical connection included.
• - Consult factory for custom pre-wired factory sealed cable length options.
• - Various lengths arm/brackets available. Consult factory for more information.
• - Consult factory for dimming options, marine-grade, custom finishes (please specify RAL color), and non-cataloged CCT (Kelvin) options including static colors.
• - Frosted (FRST) glass option available - add suffix to any part number.
• - Product meets Buy American Act requirements within ARRA.
• - 5-year warranty.
