STRIP SQUARE+

IN
  • Linear surface mount series. Fixtures consist of:
  • - Copper-free (<1%) aluminum die-cast end-caps, extruded, and anodized housing.
  • - Copper-free (<1%) aluminum extruded and anodized field-adjustable mounting bracket for aiming the luminaire.
  • - Extra-clear, tempered, silk-screened, flat glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Custom MCPCB utilized to maximize heat dissipation and promote long LED life.
  • - High-transparency polycarbonate optics for optimized light transmission.
  • - Circular Intensive optics (C/I).
  • - Elliptical optics (ELL).
  • - RGBW (2700K) color mixing for high emotional impact scenographic effects.
  • - Dynamic Tunable White (TW) options enable smooth variations in color temperature, from 2700K to 6500K, in response to how a space is used.
  • - NEMA 5H x 4V light distribution (A18/M).
  • - Input voltage: 120-277 V (50 / 60 Hz), integral 0-10 V dimming driver.
  • - Input voltage: 48 V DC, separate driver for RGBW color mixing and/or dynamic Tunable White versions (ordered separately).
  • - Pre-wired factory sealed cable for external electrical connection included.
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Product meets Buy American Act (BAA) requirements within ARRA.
  • - 5-year warranty.
  • Linear in-ground series. Fixtures consist of:
  • - Copper-free (<1%) aluminum die-cast end-caps, extruded, and anodized housing.
  • - Extra-clear, tempered, silk-screened, flat glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Custom MCPCB utilized to maximize heat dissipation and promote long LED life.
  • - High-transparency polycarbonate optics for optimized light transmission.
  • - Elliptical optics (ELL).
  • - RGBW (2700K) color mixing for high emotional impact scenographic effects.
  • - Input voltage: 48 V DC, separate driver for RGBW color mixing and/or dynamic Tunable White versions (ordered separately).
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Product meets Buy American Act (BAA) requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finishing Lampholder Wattage Voltage CRI Kelvin Optic Beam
angle
Lightsource
lumen
output
[lm]
Luminaire
lumen
output
[lm]
L B Lifetime Downloads
RGBW LED
070650 LED 37 W 80 RGBW 2700 - 15°x45° 3760 2103 L80 B10 60000 Download

Documentation: STRIP SQUARE+ 1032 RGBW (40.63") ELL - 070650

Sources

LED 37 W
  • Linear in-ground series. Fixtures consist of:
  • - Copper-free (<1%) aluminum die-cast end-caps, extruded, and anodized housing.
  • - Extra-clear, tempered, silk-screened, flat glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Custom MCPCB utilized to maximize heat dissipation and promote long LED life.
  • - High-transparency polycarbonate optics for optimized light transmission.
  • - Elliptical optics (ELL).
  • - Dynamic Tunable White (TW) options enable smooth variations in color temperature, from 2700K to 6500K, in response to how a space is used.
  • - Input voltage: 48 V DC, separate driver for RGBW color mixing and/or dynamic Tunable White versions (ordered separately).
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Product meets Buy American Act (BAA) requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finishing Lampholder Wattage Voltage CRI Kelvin Optic Beam
angle
Lightsource
lumen
output
[lm]
Luminaire
lumen
output
[lm]
L B Lifetime Downloads
TunableWhite High Power LED
070647 LED 28 W 80 TW 2700-6500 - 15°x45° 4432 2252 L80 B10 60000 Download

Documentation: STRIP SQUARE+ 1032 TW (40.63") ELL - 070647

Sources

LED 28 W
  • Linear surface mount series. Fixtures consist of:
  • - Copper-free (<1%) aluminum die-cast end-caps, extruded, and anodized housing.
  • - Copper-free (<1%) aluminum extruded and anodized field-adjustable mounting bracket for aiming the luminaire.
  • - Extra-clear, tempered, silk-screened, flat glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Custom MCPCB utilized to maximize heat dissipation and promote long LED life.
  • - High-transparency polycarbonate optics for optimized light transmission.
  • - Elliptical optics (ELL).
  • - RGBW (2700K) color mixing for high emotional impact scenographic effects.
  • - Input voltage: 48 V DC, separate driver for RGBW color mixing and/or dynamic Tunable White versions (ordered separately).
  • - Pre-wired factory sealed cable for external electrical connection included.
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Product meets Buy American Act (BAA) requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finishing Lampholder Wattage Voltage CRI Kelvin Optic Beam
angle
Lightsource
lumen
output
[lm]
Luminaire
lumen
output
[lm]
L B Lifetime Downloads
RGBW LED
070660 LED 46 W 80 RGBW 2700 - 15°x45° 4140 2545 L80 B10 60000 Download

Documentation: STRIP SQUARE+ 1284 RGBW (50.55") ELL - 070660

Sources

LED 46 W
  • Linear in-ground series. Fixtures consist of:
  • - Copper-free (<1%) aluminum die-cast end-caps, extruded, and anodized housing.
  • - Extra-clear, tempered, silk-screened, flat glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Custom MCPCB utilized to maximize heat dissipation and promote long LED life.
  • - High-transparency polycarbonate optics for optimized light transmission.
  • - Elliptical optics (ELL).
  • - Dynamic Tunable White (TW) options enable smooth variations in color temperature, from 2700K to 6500K, in response to how a space is used.
  • - Input voltage: 48 V DC, separate driver for RGBW color mixing and/or dynamic Tunable White versions (ordered separately).
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Product meets Buy American Act (BAA) requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finishing Lampholder Wattage Voltage CRI Kelvin Optic Beam
angle
Lightsource
lumen
output
[lm]
Luminaire
lumen
output
[lm]
L B Lifetime Downloads
TunableWhite High Power LED
070657 LED 35 W 80 TW 2700-6500 - 15°x45° 5540 2867 L80 B10 60000 Download

Documentation: STRIP SQUARE+ 1284 TW (50.55") ELL - 070657

Sources

LED 35 W
  • Linear in-ground series. Fixtures consist of:
  • - Copper-free (<1%) aluminum die-cast end-caps, extruded, and anodized housing.
  • - Extra-clear, tempered, silk-screened, flat glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Custom MCPCB utilized to maximize heat dissipation and promote long LED life.
  • - High-transparency polycarbonate optics for optimized light transmission.
  • - Elliptical optics (ELL).
  • - RGBW (2700K) color mixing for high emotional impact scenographic effects.
  • - Input voltage: 48 V DC, separate driver for RGBW color mixing and/or dynamic Tunable White versions (ordered separately).
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Product meets Buy American Act (BAA) requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finishing Lampholder Wattage Voltage CRI Kelvin Optic Beam
angle
Lightsource
lumen
output
[lm]
Luminaire
lumen
output
[lm]
L B Lifetime Downloads
RGBW LED
070630 LED 18.5 W 80 RGBW 2700 - 15°x45° 1880 1108 L80 B10 60000 Download

Documentation: STRIP SQUARE+ 528 RGBW (20.79") ELL - 070630

Sources

LED 18.5 W
  • Linear in-ground series. Fixtures consist of:
  • - Copper-free (<1%) aluminum die-cast end-caps, extruded, and anodized housing.
  • - Extra-clear, tempered, silk-screened, flat glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Custom MCPCB utilized to maximize heat dissipation and promote long LED life.
  • - High-transparency polycarbonate optics for optimized light transmission.
  • - Elliptical optics (ELL).
  • - Dynamic Tunable White (TW) options enable smooth variations in color temperature, from 2700K to 6500K, in response to how a space is used.
  • - Input voltage: 48 V DC, separate driver for RGBW color mixing and/or dynamic Tunable White versions (ordered separately).
  • - Stainless steel grounding tether included.
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Product meets Buy American Act (BAA) requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finishing Lampholder Wattage Voltage CRI Kelvin Optic Beam
angle
Lightsource
lumen
output
[lm]
Luminaire
lumen
output
[lm]
L B Lifetime Downloads
TunableWhite High Power LED
070627 LED 16 W 80 TW 2700-6500 - 15°x45° 2216 1142 L80 B10 60000 Download

Documentation: STRIP SQUARE+ 528 TW (20.79") ELL - 070627

Sources

LED 16 W
  • Linear in-ground series. Fixtures consist of:
  • - Copper-free (<1%) aluminum die-cast end-caps, extruded, and anodized housing.
  • - Extra-clear, tempered, silk-screened, flat glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Custom MCPCB utilized to maximize heat dissipation and promote long LED life.
  • - High-transparency polycarbonate optics for optimized light transmission.
  • - Elliptical optics (ELL).
  • - RGBW (2700K) color mixing for high emotional impact scenographic effects.
  • - Input voltage: 48 V DC, separate driver for RGBW color mixing and/or dynamic Tunable White versions (ordered separately).
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Product meets Buy American Act (BAA) requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finishing Lampholder Wattage Voltage CRI Kelvin Optic Beam
angle
Lightsource
lumen
output
[lm]
Luminaire
lumen
output
[lm]
L B Lifetime Downloads
RGBW LED
070640 LED 28 W 80 RGBW 2700 - 15°x45° 2830 1520 L80 B10 60000 Download

Documentation: STRIP SQUARE+ 780 RGBW (30.71") ELL - 070640

Sources

LED 28 W
  • Linear in-ground series. Fixtures consist of:
  • - Copper-free (<1%) aluminum die-cast end-caps, extruded, and anodized housing.
  • - Extra-clear, tempered, silk-screened, flat glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Custom MCPCB utilized to maximize heat dissipation and promote long LED life.
  • - High-transparency polycarbonate optics for optimized light transmission.
  • - Elliptical optics (ELL).
  • - Dynamic Tunable White (TW) options enable smooth variations in color temperature, from 2700K to 6500K, in response to how a space is used.
  • - Input voltage: 48 V DC, separate driver for RGBW color mixing and/or dynamic Tunable White versions (ordered separately).
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Product meets Buy American Act (BAA) requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finishing Lampholder Wattage Voltage CRI Kelvin Optic Beam
angle
Lightsource
lumen
output
[lm]
Luminaire
lumen
output
[lm]
L B Lifetime Downloads
TunableWhite High Power LED
070637 LED 22 W 80 TW 2700-6500 - 15°x45° 3324 1655 L80 B10 60000 Download

Documentation: STRIP SQUARE+ 780 TW (30.71") ELL - 070637

Sources

LED 22 W
  • Linear surface mount series. Fixtures consist of:
  • - Copper-free (<1%) aluminum die-cast end-caps, extruded, and anodized housing.
  • - Copper-free (<1%) aluminum extruded and anodized field-adjustable mounting bracket for aiming the luminaire.
  • - Extra-clear, tempered, silk-screened, flat glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Custom MCPCB utilized to maximize heat dissipation and promote long LED life.
  • - High-transparency polycarbonate optics for optimized light transmission.
  • - NEMA 5H x 4V light distribution (A18/M).
  • - Input voltage: 120-277 V (50 / 60 Hz), integral 0-10 V dimming driver.
  • - Pre-wired factory sealed cable for external electrical connection included.
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Product meets Buy American Act (BAA) requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finishing Lampholder Wattage Voltage CRI Kelvin Optic Beam
angle
Lightsource
lumen
output
[lm]
Luminaire
lumen
output
[lm]
L B Lifetime Downloads
High Power LEDS 120-277 V - Dimmable 0-10 V
070633 LED 14 W 120/277 V 80 3000 - 18° 2000 1374 L80 B10 60000 Download

Documentation: STRIP SQUARE+ 528 (20.79") A/M - 070633

070634 LED 14 W 120/277 V 80 4000 - 18° 2130 1468 L80 B10 60000 Download

Documentation: STRIP SQUARE+ 528 (20.79") A/M - 070634

070673 LED 30 W 120/277 V 80 3000 - 18° 3550 2437 L80 B10 60000 Download

Documentation: STRIP SQUARE+ 528 (20.79") A/M - 070673

070674 LED 30 W 120/277 V 80 4000 - 18° 3780 2602 L80 B10 60000 Download

Documentation: STRIP SQUARE+ 528 (20.79") A/M - 070674

Sources

LED 14 W
LED 30 W
  • Linear surface mount series. Fixtures consist of:
  • - Copper-free (<1%) aluminum die-cast end-caps, extruded, and anodized housing.
  • - Copper-free (<1%) aluminum extruded and anodized field-adjustable mounting bracket for aiming the luminaire.
  • - Extra-clear, tempered, silk-screened, flat glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Custom MCPCB utilized to maximize heat dissipation and promote long LED life.
  • - High-transparency polycarbonate optics for optimized light transmission.
  • - Circular Intensive optics (C/I).
  • - Input voltage: 120-277 V (50 / 60 Hz), integral 0-10 V dimming driver.
  • - Pre-wired factory sealed cable for external electrical connection included.
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Product meets Buy American Act (BAA) requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finishing Lampholder Wattage Voltage CRI Kelvin Optic Beam
angle
Lightsource
lumen
output
[lm]
Luminaire
lumen
output
[lm]
L B Lifetime Downloads
High Power LEDS 120-277 V - Dimmable 0-10 V
070625 LED 14 W 120/277 V 80 3000 - 2000 1425 L80 B10 60000 Download

Documentation: STRIP SQUARE+ 528 (20.79") C/I - 070625

070626 LED 14 W 120/277 V 80 4000 - 2130 1519 L80 B10 60000 Download

Documentation: STRIP SQUARE+ 528 (20.79") C/I - 070626

070665 LED 30 W 120/277 V 80 3000 - 3550 2527 L80 B10 60000 Download

Documentation: STRIP SQUARE+ 528 (20.79") C/I - 070665

070666 LED 30 W 120/277 V 80 4000 - 3780 2694 L80 B10 60000 Download

Documentation: STRIP SQUARE+ 528 (20.79") C/I - 070666

Sources

LED 14 W
LED 30 W
  • Linear surface mount series. Fixtures consist of:
  • - Copper-free (<1%) aluminum die-cast end-caps, extruded, and anodized housing.
  • - Copper-free (<1%) aluminum extruded and anodized field-adjustable mounting bracket for aiming the luminaire.
  • - Extra-clear, tempered, silk-screened, flat glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Custom MCPCB utilized to maximize heat dissipation and promote long LED life.
  • - High-transparency polycarbonate optics for optimized light transmission.
  • - Elliptical optics (ELL).
  • - Input voltage: 120-277 V (50 / 60 Hz), integral 0-10 V dimming driver.
  • - Pre-wired factory sealed cable for external electrical connection included.
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Product meets Buy American Act (BAA) requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finishing Lampholder Wattage Voltage CRI Kelvin Optic Beam
angle
Lightsource
lumen
output
[lm]
Luminaire
lumen
output
[lm]
L B Lifetime Downloads
High Power LEDS 120-277 V - Dimmable 0-10 V
070628 LED 14 W 120/277 V 80 3000 - 15°x45° 2000 1385 L80 B10 60000 Download

Documentation: STRIP SQUARE+ 528 (20.79") ELL - 070628

070629 LED 14 W 120/277 V 80 4000 - 15°x45° 2130 1479 L80 B10 60000 Download

Documentation: STRIP SQUARE+ 528 (20.79") ELL - 070629

070631 LED 14 W 120/277 V 80 3000 - 40°x60° 2000 1384 L80 B10 60000 Download

Documentation: STRIP SQUARE+ 528 (20.79") ELL - 070631

070632 LED 14 W 120/277 V 80 4000 - 40°x60° 2130 1478 L80 B10 60000 Download

Documentation: STRIP SQUARE+ 528 (20.79") ELL - 070632

070668 LED 30 W 120/277 V 80 3000 - 15°x45° 3550 2455 L80 B10 60000 Download

Documentation: STRIP SQUARE+ 528 (20.79") ELL - 070668

070669 LED 30 W 120/277 V 80 4000 - 15°x45° 3780 2622 L80 B10 60000 Download

Documentation: STRIP SQUARE+ 528 (20.79") ELL - 070669

070671 LED 30 W 120/277 V 80 3000 - 40°x60° 3550 2454 L80 B10 60000 Download

Documentation: STRIP SQUARE+ 528 (20.79") ELL - 070671

070672 LED 30 W 120/277 V 80 4000 - 40°x60° 3780 2621 L80 B10 60000 Download

Documentation: STRIP SQUARE+ 528 (20.79") ELL - 070672

Sources

LED 14 W
LED 30 W
  • Linear surface mount series. Fixtures consist of:
  • - Copper-free (<1%) aluminum die-cast end-caps, extruded, and anodized housing.
  • - Copper-free (<1%) aluminum extruded and anodized field-adjustable mounting bracket for aiming the luminaire.
  • - Extra-clear, tempered, silk-screened, flat glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Custom MCPCB utilized to maximize heat dissipation and promote long LED life.
  • - High-transparency polycarbonate optics for optimized light transmission.
  • - NEMA 5H x 4V light distribution (A18/M).
  • - Input voltage: 120-277 V (50 / 60 Hz), integral 0-10 V dimming driver.
  • - Pre-wired factory sealed cable for external electrical connection included.
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Product meets Buy American Act (BAA) requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finishing Lampholder Wattage Voltage CRI Kelvin Optic Beam
angle
Lightsource
lumen
output
[lm]
Luminaire
lumen
output
[lm]
L B Lifetime Downloads
High Power LEDS 120-277 V - Dimmable 0-10 V
070643 LED 21 W 120/277 V 80 3000 - 18° 3000 2001 L80 B10 60000 Download

Documentation: STRIP SQUARE+ 780 (30.71") A/M - 070643

070644 LED 21 W 120/277 V 80 4000 - 18° 3200 2136 L80 B10 60000 Download

Documentation: STRIP SQUARE+ 780 (30.71") A/M - 070644

070683 LED 43 W 120/277 V 80 3000 - 18° 5490 3769 L80 B10 60000 Download

Documentation: STRIP SQUARE+ 780 (30.71") A/M - 070683

070684 LED 43 W 120/277 V 80 4000 - 18° 5860 4025 L80 B10 60000 Download

Documentation: STRIP SQUARE+ 780 (30.71") A/M - 070684

Sources

LED 21 W
LED 43 W
  • Linear surface mount series. Fixtures consist of:
  • - Copper-free (<1%) aluminum die-cast end-caps, extruded, and anodized housing.
  • - Copper-free (<1%) aluminum extruded and anodized field-adjustable mounting bracket for aiming the luminaire.
  • - Extra-clear, tempered, silk-screened, flat glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Custom MCPCB utilized to maximize heat dissipation and promote long LED life.
  • - High-transparency polycarbonate optics for optimized light transmission.
  • - Circular Intensive optics (C/I).
  • - Input voltage: 120-277 V (50 / 60 Hz), integral 0-10 V dimming driver.
  • - Pre-wired factory sealed cable for external electrical connection included.
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Product meets Buy American Act (BAA) requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finishing Lampholder Wattage Voltage CRI Kelvin Optic Beam
angle
Lightsource
lumen
output
[lm]
Luminaire
lumen
output
[lm]
L B Lifetime Downloads
High Power LEDS 120-277 V - Dimmable 0-10 V
070635 LED 21 W 120/277 V 80 3000 - 3000 2075 L80 B10 60000 Download

Documentation: STRIP SQUARE+ 780 (30.71") C/I - 070635

070636 LED 21 W 120/277 V 80 4000 - 3200 2216 L80 B10 60000 Download

Documentation: STRIP SQUARE+ 780 (30.71") C/I - 070636

070675 LED 43 W 120/277 V 80 3000 - 5490 3908 L80 B10 60000 Download

Documentation: STRIP SQUARE+ 780 (30.71") C/I - 070675

070676 LED 43 W 120/277 V 80 4000 - 5860 4174 L80 B10 60000 Download

Documentation: STRIP SQUARE+ 780 (30.71") C/I - 070676

Sources

LED 21 W
LED 43 W
  • Linear surface mount series. Fixtures consist of:
  • - Copper-free (<1%) aluminum die-cast end-caps, extruded, and anodized housing.
  • - Copper-free (<1%) aluminum extruded and anodized field-adjustable mounting bracket for aiming the luminaire.
  • - Extra-clear, tempered, silk-screened, flat glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Custom MCPCB utilized to maximize heat dissipation and promote long LED life.
  • - High-transparency polycarbonate optics for optimized light transmission.
  • - Elliptical optics (ELL).
  • - Input voltage: 120-277 V (50 / 60 Hz), integral 0-10 V dimming driver.
  • - Pre-wired factory sealed cable for external electrical connection included.
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Product meets Buy American Act (BAA) requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finishing Lampholder Wattage Voltage CRI Kelvin Optic Beam
angle
Lightsource
lumen
output
[lm]
Luminaire
lumen
output
[lm]
L B Lifetime Downloads
High Power LEDS 120-277 V - Dimmable 0-10 V
070638 LED 21 W 120/277 V 80 3000 - 15°x45° 3000 2015 L80 B10 60000 Download

Documentation: STRIP SQUARE+ 780 (30.71") ELL - 070638

070639 LED 21 W 120/277 V 80 4000 - 15°x45° 3200 2152 L80 B10 60000 Download

Documentation: STRIP SQUARE+ 780 (30.71") ELL - 070639

070641 LED 21 W 120/277 V 80 3000 - 40°x60° 3000 2015 L80 B10 60000 Download

Documentation: STRIP SQUARE+ 780 (30.71") ELL - 070641

070642 LED 21 W 120/277 V 80 4000 - 40°x60° 3200 2151 L80 B10 60000 Download

Documentation: STRIP SQUARE+ 780 (30.71") ELL - 070642

070678 LED 43 W 120/277 V 80 3000 - 15°x45° 5490 3796 L80 B10 60000 Download

Documentation: STRIP SQUARE+ 780 (30.71") ELL - 070678

070679 LED 43 W 120/277 V 80 4000 - 15°x45° 5860 4054 L80 B10 60000 Download

Documentation: STRIP SQUARE+ 780 (30.71") ELL - 070679

070681 LED 43 W 120/277 V 80 3000 - 40°x60° 5490 3795 L80 B10 60000 Download

Documentation: STRIP SQUARE+ 780 (30.71") ELL - 070681

070682 LED 43 W 120/277 V 80 4000 - 40°x60° 5860 4053 L80 B10 60000 Download

Documentation: STRIP SQUARE+ 780 (30.71") ELL - 070682

Sources

LED 21 W
LED 43 W
  • Linear surface mount series. Fixtures consist of:
  • - Copper-free (<1%) aluminum die-cast end-caps, extruded, and anodized housing.
  • - Copper-free (<1%) aluminum extruded and anodized field-adjustable mounting bracket for aiming the luminaire.
  • - Extra-clear, tempered, silk-screened, flat glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Custom MCPCB utilized to maximize heat dissipation and promote long LED life.
  • - High-transparency polycarbonate optics for optimized light transmission.
  • - NEMA 5H x 4V light distribution (A18/M).
  • - Input voltage: 120-277 V (50 / 60 Hz), integral 0-10 V dimming driver.
  • - Pre-wired factory sealed cable for external electrical connection included.
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Product meets Buy American Act (BAA) requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finishing Lampholder Wattage Voltage CRI Kelvin Optic Beam
angle
Lightsource
lumen
output
[lm]
Luminaire
lumen
output
[lm]
L B Lifetime Downloads
High Power LEDS 120-277 V - Dimmable 0-10 V
070653 LED 27 W 120/277 V 80 3000 - 18° 4000 2660 L80 B10 60000 Download

Documentation: STRIP SQUARE+ 1032 (40.63") A/M - 070653

070654 LED 27 W 120/277 V 80 4000 - 18° 4260 2841 L80 B10 60000 Download

Documentation: STRIP SQUARE+ 1032 (40.63") A/M - 070654

070693 LED 55 W 120/277 V 80 3000 - 18° 6900 4740 L80 B10 60000 Download

Documentation: STRIP SQUARE+ 1032 (40.63") A/M - 070693

070694 LED 55 W 120/277 V 80 4000 - 18° 7370 5061 L80 B10 60000 Download

Documentation: STRIP SQUARE+ 1032 (40.63") A/M - 070694

Sources

LED 27 W
LED 55 W
  • Linear surface mount series. Fixtures consist of:
  • - Copper-free (<1%) aluminum die-cast end-caps, extruded, and anodized housing.
  • - Copper-free (<1%) aluminum extruded and anodized field-adjustable mounting bracket for aiming the luminaire.
  • - Extra-clear, tempered, silk-screened, flat glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Custom MCPCB utilized to maximize heat dissipation and promote long LED life.
  • - High-transparency polycarbonate optics for optimized light transmission.
  • - Circular Intensive optics (C/I).
  • - Input voltage: 120-277 V (50 / 60 Hz), integral 0-10 V dimming driver.
  • - Pre-wired factory sealed cable for external electrical connection included.
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Product meets Buy American Act (BAA) requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finishing Lampholder Wattage Voltage CRI Kelvin Optic Beam
angle
Lightsource
lumen
output
[lm]
Luminaire
lumen
output
[lm]
L B Lifetime Downloads
High Power LEDS 120-277 V - Dimmable 0-10 V
070645 LED 27 W 120/277 V 80 3000 - 4000 2759 L80 B10 60000 Download

Documentation: STRIP SQUARE+ 1032 (40.63") C/I - 070645

070646 LED 27 W 120/277 V 80 4000 - 4260 2946 L80 B10 60000 Download

Documentation: STRIP SQUARE+ 1032 (40.63") C/I - 070646

070685 LED 55 W 120/277 V 80 3000 - 6900 4916 L80 B10 60000 Download

Documentation: STRIP SQUARE+ 1032 (40.63") C/I - 070685

070686 LED 55 W 120/277 V 80 4000 - 7370 5249 L80 B10 60000 Download

Documentation: STRIP SQUARE+ 1032 (40.63") C/I - 070686

Sources

LED 27 W
LED 55 W
  • Linear surface mount series. Fixtures consist of:
  • - Copper-free (<1%) aluminum die-cast end-caps, extruded, and anodized housing.
  • - Copper-free (<1%) aluminum extruded and anodized field-adjustable mounting bracket for aiming the luminaire.
  • - Extra-clear, tempered, silk-screened, flat glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Custom MCPCB utilized to maximize heat dissipation and promote long LED life.
  • - High-transparency polycarbonate optics for optimized light transmission.
  • - Elliptical optics (ELL).
  • - Input voltage: 120-277 V (50 / 60 Hz), integral 0-10 V dimming driver.
  • - Pre-wired factory sealed cable for external electrical connection included.
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Product meets Buy American Act (BAA) requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finishing Lampholder Wattage Voltage CRI Kelvin Optic Beam
angle
Lightsource
lumen
output
[lm]
Luminaire
lumen
output
[lm]
L B Lifetime Downloads
High Power LEDS 120-277 V - Dimmable 0-10 V
070648 LED 27 W 120/277 V 80 3000 - 15°x45° 4000 2680 L80 B10 60000 Download

Documentation: STRIP SQUARE+ 1032 (40.63") ELL - 070648

070649 LED 27 W 120/277 V 80 4000 - 15°x45° 4260 2862 L80 B10 60000 Download

Documentation: STRIP SQUARE+ 1032 (40.63") ELL - 070649

070651 LED 27 W 120/277 V 80 3000 - 40°x60° 4000 2679 L80 B10 60000 Download

Documentation: STRIP SQUARE+ 1032 (40.63") ELL - 070651

070652 LED 27 W 120/277 V 80 4000 - 40°x60° 4260 2861 L80 B10 60000 Download

Documentation: STRIP SQUARE+ 1032 (40.63") ELL - 070652

070688 LED 55 W 120/277 V 80 3000 - 15°x45° 6900 4774 L80 B10 60000 Download

Documentation: STRIP SQUARE+ 1032 (40.63") ELL - 070688

070689 LED 55 W 120/277 V 80 4000 - 15°x45° 7370 5099 L80 B10 60000 Download

Documentation: STRIP SQUARE+ 1032 (40.63") ELL - 070689

070691 LED 55 W 120/277 V 80 3000 - 40°x60° 6900 4773 L80 B10 60000 Download

Documentation: STRIP SQUARE+ 1032 (40.63") ELL - 070691

070692 LED 55 W 120/277 V 80 4000 - 40°x60° 7370 5097 L80 B10 60000 Download

Documentation: STRIP SQUARE+ 1032 (40.63") ELL - 070692

Sources

LED 27 W
LED 55 W
  • Linear surface mount series. Fixtures consist of:
  • - Copper-free (<1%) aluminum die-cast end-caps, extruded, and anodized housing.
  • - Copper-free (<1%) aluminum extruded and anodized field-adjustable mounting bracket for aiming the luminaire.
  • - Extra-clear, tempered, silk-screened, flat glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Custom MCPCB utilized to maximize heat dissipation and promote long LED life.
  • - High-transparency polycarbonate optics for optimized light transmission.
  • - NEMA 5H x 4V light distribution (A18/M).
  • - Input voltage: 120-277 V (50 / 60 Hz), integral 0-10 V dimming driver.
  • - Pre-wired factory sealed cable for external electrical connection included.
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Product meets Buy American Act (BAA) requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finishing Lampholder Wattage Voltage CRI Kelvin Optic Beam
angle
Lightsource
lumen
output
[lm]
Luminaire
lumen
output
[lm]
L B Lifetime Downloads
High Power LEDS 120-277 V - Dimmable 0-10 V
070663 LED 33 W 120/277 V 80 3000 - 18° 5000 3324 L80 B10 60000 Download

Documentation: STRIP SQUARE+ 1284 (50.55") A/M - 070663

070664 LED 33 W 120/277 V 80 4000 - 18° 5400 3549 L80 B10 60000 Download

Documentation: STRIP SQUARE+ 1284 (50.55") A/M - 070664

070703 LED 67 W 120/277 V 80 3000 - 18° 8870 6086 L80 B10 60000 Download

Documentation: STRIP SQUARE+ 1284 (50.55") A/M - 070703

070704 LED 67 W 120/277 V 80 4000 - 18° 9470 6499 L80 B10 60000 Download

Documentation: STRIP SQUARE+ 1284 (50.55") A/M - 070704

Sources

LED 33 W
LED 67 W
  • Linear surface mount series. Fixtures consist of:
  • - Copper-free (<1%) aluminum die-cast end-caps, extruded, and anodized housing.
  • - Copper-free (<1%) aluminum extruded and anodized field-adjustable mounting bracket for aiming the luminaire.
  • - Extra-clear, tempered, silk-screened, flat glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Custom MCPCB utilized to maximize heat dissipation and promote long LED life.
  • - High-transparency polycarbonate optics for optimized light transmission.
  • - Circular Intensive optics (C/I).
  • - Input voltage: 120-277 V (50 / 60 Hz), integral 0-10 V dimming driver.
  • - Pre-wired factory sealed cable for external electrical connection included.
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Product meets Buy American Act (BAA) requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finishing Lampholder Wattage Voltage CRI Kelvin Optic Beam
angle
Lightsource
lumen
output
[lm]
Luminaire
lumen
output
[lm]
L B Lifetime Downloads
High Power LEDS 120-277 V - Dimmable 0-10 V
070655 LED 33 W 120/277 V 80 3000 - 5000 3447 L80 B10 60000 Download

Documentation: STRIP SQUARE+ 1284 (50.55") C/I - 070655

070656 LED 33 W 120/277 V 80 4000 - 5400 3861 L80 B10 60000 Download

Documentation: STRIP SQUARE+ 1284 (50.55") C/I - 070656

070695 LED 67 W 120/277 V 80 3000 - 8870 6312 L80 B10 60000 Download

Documentation: STRIP SQUARE+ 1284 (50.55") C/I - 070695

070696 LED 67 W 120/277 V 80 4000 - 9470 6741 L80 B10 60000 Download

Documentation: STRIP SQUARE+ 1284 (50.55") C/I - 070696

Sources

LED 33 W
LED 67 W
  • Linear surface mount series. Fixtures consist of:
  • - Copper-free (<1%) aluminum die-cast end-caps, extruded, and anodized housing.
  • - Copper-free (<1%) aluminum extruded and anodized field-adjustable mounting bracket for aiming the luminaire.
  • - Extra-clear, tempered, silk-screened, flat glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Custom MCPCB utilized to maximize heat dissipation and promote long LED life.
  • - High-transparency polycarbonate optics for optimized light transmission.
  • - Elliptical optics (ELL).
  • - Input voltage: 120-277 V (50 / 60 Hz), integral 0-10 V dimming driver.
  • - Pre-wired factory sealed cable for external electrical connection included.
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Product meets Buy American Act (BAA) requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finishing Lampholder Wattage Voltage CRI Kelvin Optic Beam
angle
Lightsource
lumen
output
[lm]
Luminaire
lumen
output
[lm]
L B Lifetime Downloads
High Power LEDS 120-277 V - Dimmable 0-10 V
070658 LED 33 W 120/277 V 80 3000 - 15°x45° 5000 3348 L80 B10 60000 Download

Documentation: STRIP SQUARE+ 1284 (50.55") ELL - 070658

070659 LED 33 W 120/277 V 80 4000 - 15°x45° 5400 3576 L80 B10 60000 Download

Documentation: STRIP SQUARE+ 1284 (50.55") ELL - 070659

070661 LED 33 W 120/277 V 80 3000 - 40°x60° 5000 3347 L80 B10 60000 Download

Documentation: STRIP SQUARE+ 1284 (50.55") ELL - 070661

070662 LED 33 W 120/277 V 80 4000 - 40°x60° 5400 3574 L80 B10 60000 Download

Documentation: STRIP SQUARE+ 1284 (50.55") ELL - 070662

070698 LED 67 W 120/277 V 80 3000 - 15°x45° 8870 6131 L80 B10 60000 Download

Documentation: STRIP SQUARE+ 1284 (50.55") ELL - 070698

070699 LED 67 W 120/277 V 80 4000 - 15°x45° 9470 6547 L80 B10 60000 Download

Documentation: STRIP SQUARE+ 1284 (50.55") ELL - 070699

070701 LED 67 W 120/277 V 80 3000 - 40°x60° 8870 6129 L80 B10 60000 Download

Documentation: STRIP SQUARE+ 1284 (50.55") ELL - 070701

070702 LED 67 W 120/277 V 80 4000 - 40°x60° 9470 6545 L80 B10 60000 Download

Documentation: STRIP SQUARE+ 1284 (50.55") ELL - 070702

Sources

LED 33 W
LED 67 W
to top
Products search
You can search for products in our catalog by entering here the name or the code of the product or accessory.
