STRIP SQUARE+ 780 (30.71") C/I
STRIP SQUARE+ 780 (30.71") C/I
STRIP SQUARE+ 780 (30.71") C/I - 1
STRIP SQUARE+ 780 (30.71") C/I - 2
Part number 070675
Lampholder: LED
Wattage: 43 W
Finishing: GR-EV1 / Anodized aluminum / Matt
Degree of protection: IP66
CRI: 80
Kelvin: 3000
Optic: Circular Intensive
Beam angle:
Nema Type: 1H x1V
Luminaire lumen output [lm]: 3908 lm
L: L80
B: B10
Lifetime: 60000 h
cULus:
Voltage: 120/277 V
Min. ambient temperature [°C]: -25
Max. ambient temperature [°C]: 40

Description

  • Linear surface mount series. Fixtures consist of:
  • - Copper-free (<1%) aluminum die-cast end-caps, extruded, and anodized housing.
  • - Copper-free (<1%) aluminum extruded and anodized field-adjustable mounting bracket for aiming the luminaire.
  • - Extra-clear, tempered, silk-screened, flat glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Custom MCPCB utilized to maximize heat dissipation and promote long LED life.
  • - High-transparency polycarbonate optics for optimized light transmission.
  • - Circular Intensive optics (C/I).
  • - Input voltage: 120-277 V (50 / 60 Hz), integral 0-10 V dimming driver.
  • - Pre-wired factory sealed cable for external electrical connection included.
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Product meets Buy American Act (BAA) requirements within ARRA.
  • - 5-year warranty.

Technical drawings

Tech Design STRIP SQUARE+ 780 (30.71") C/I 1++
