TYK+ 10

  • Long-lasting floodlighting for landscape and any architecture, also applying dynamic color. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free (<1%) precision die-cast aluminum housing, and adjustable stainless steel mounting bracket.
  • - Stainless steel graduated ferrules for aiming purposes on both sides of the fixture.
  • - Extra-clear, tempered, silk-screened, flat glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - ustom MCPCB utilized to maximize heat dissipation and promote long LED life.
  • - High-transparency polycarbonate optics for optimized light transmission.
  • - Circular Intensive optics (C/I).
  • - Circular Medium optics (C/M).
  • - RGBW (4000K) color mixing for high emotional impact scenographic effects.
  • - Dynamic Tunable White (TW) options enable smooth variations in color temperature, from 2700K to 5700K, in response to how a space is used.
  • - NEMA 5H x 5V light distribution (C/IW)
  • - Elliptical optics (ELL).
  • - Input voltage: 120V (50 / 60 Hz) integral driver, 120-277V (50 / 60 Hz) remote driver (RM versions).
  • - Input voltage: 48 V DC, separate driver for RGBW color mixing and/or dynamic Tunable White versions (ordered separately).
  • - Standard tear-proof nickel-plated brass cable gland M16x1.5 for cables Ø0.2” - Ø0.4”.
  • - Pre-wired factory sealed cable for external electrical connection included.
  • - Standard robust ½” NPS knuckle mount with 180° adjustable swivel arm (SA versions) and rugged, locking teeth for a simplified installation.
  • - Matching junction box plate optional accessory available (ordered separately).
  • - The TYK+ 10 RM versions to be powered solely with the power supply units available as accessories (ordered separately).
  • - Maximum cable length of 10 meters between the power supply unit and the related floodlights.
  • - RM (Remote Driver) version are granted for a – 40°F working temperature.
  • - SA version add -RM for remote driver.
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Product meets Buy American Act (BAA) requirements within ARRA.
  • - 5-year warranty.
  • Long-lasting floodlighting for landscape and any architecture, also applying dynamic color. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free (<1%) precision die-cast aluminum housing, and adjustable stainless steel mounting bracket.
  • - Stainless steel graduated ferrules for aiming purposes on both sides of the fixture.
  • - Extra-clear, tempered, silk-screened, flat glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - ustom MCPCB utilized to maximize heat dissipation and promote long LED life.
  • - High-transparency polycarbonate optics for optimized light transmission.
  • - Circular Intensive optics (C/I).
  • - Input voltage: 120V (50 / 60 Hz) integral driver, 120-277V (50 / 60 Hz) remote driver (RM versions).
  • - Standard tear-proof nickel-plated brass cable gland M16x1.5 for cables Ø0.2” - Ø0.4”.
  • - Pre-wired factory sealed cable for external electrical connection included.
  • - Standard robust ½” NPS knuckle mount with 180° adjustable swivel arm (SA versions) and rugged, locking teeth for a simplified installation.
  • - Matching junction box plate optional accessory available (ordered separately).
  • - The TYK+ 10 RM versions to be powered solely with the power supply units available as accessories (ordered separately).
  • - Maximum cable length of 10 meters between the power supply unit and the related floodlights.
  • - RM (Remote Driver) version are granted for a – 40°F working temperature.
  • - SA version add -RM for remote driver.
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Product meets Buy American Act (BAA) requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finishing Lampholder Wattage Voltage CRI Kelvin Optic Beam
angle
Lightsource
lumen
output
[lm]
Luminaire
lumen
output
[lm]
L B Lifetime Downloads
High Power LEDS 120 V
078000 LED 8 W 120 V 80 3000 Type V 10° 650 518 L90 B10 75000 Download

Documentation: TYK+ 10 C/I - 078000

078001 LED 8 W 120 V 80 4000 Type V 10° 700 560 L90 B10 75000 Download

Documentation: TYK+ 10 C/I - 078001

Sources

LED 8 W

TYK+ 10 C/IW

Optic | Circular Intensive-Wide
  • Long-lasting floodlighting for landscape and any architecture, also applying dynamic color. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free (<1%) precision die-cast aluminum housing, and adjustable stainless steel mounting bracket.
  • - Stainless steel graduated ferrules for aiming purposes on both sides of the fixture.
  • - Extra-clear, tempered, silk-screened, flat glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - ustom MCPCB utilized to maximize heat dissipation and promote long LED life.
  • - High-transparency polycarbonate optics for optimized light transmission.
  • - NEMA 5H x 5V light distribution (C/IW)
  • - Input voltage: 120V (50 / 60 Hz) integral driver, 120-277V (50 / 60 Hz) remote driver (RM versions).
  • - Standard tear-proof nickel-plated brass cable gland M16x1.5 for cables Ø0.2” - Ø0.4”.
  • - Pre-wired factory sealed cable for external electrical connection included.
  • - Standard robust ½” NPS knuckle mount with 180° adjustable swivel arm (SA versions) and rugged, locking teeth for a simplified installation.
  • - Matching junction box plate optional accessory available (ordered separately).
  • - The TYK+ 10 RM versions to be powered solely with the power supply units available as accessories (ordered separately).
  • - Maximum cable length of 10 meters between the power supply unit and the related floodlights.
  • - RM (Remote Driver) version are granted for a – 40°F working temperature.
  • - SA version add -RM for remote driver.
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Product meets Buy American Act (BAA) requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finishing Lampholder Wattage Voltage CRI Kelvin Optic Beam
angle
Lightsource
lumen
output
[lm]
Luminaire
lumen
output
[lm]
L B Lifetime Downloads
High Power LEDS 120 V
078004 LED 8 W 120 V 80 3000 Type V 65° 650 542 L90 B10 75000 Download

Documentation: TYK+ 10 C/IW - 078004

078005 LED 8 W 120 V 80 4000 Type V 65° 700 585 L90 B10 75000 Download

Documentation: TYK+ 10 C/IW - 078005

Sources

LED 8 W
  • Long-lasting floodlighting for landscape and any architecture, also applying dynamic color. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free (<1%) precision die-cast aluminum housing, and adjustable stainless steel mounting bracket.
  • - Stainless steel graduated ferrules for aiming purposes on both sides of the fixture.
  • - Extra-clear, tempered, silk-screened, flat glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - ustom MCPCB utilized to maximize heat dissipation and promote long LED life.
  • - High-transparency polycarbonate optics for optimized light transmission.
  • - Circular Medium optics (C/M).
  • - Input voltage: 120V (50 / 60 Hz) integral driver, 120-277V (50 / 60 Hz) remote driver (RM versions).
  • - Standard tear-proof nickel-plated brass cable gland M16x1.5 for cables Ø0.2” - Ø0.4”.
  • - Pre-wired factory sealed cable for external electrical connection included.
  • - Standard robust ½” NPS knuckle mount with 180° adjustable swivel arm (SA versions) and rugged, locking teeth for a simplified installation.
  • - Matching junction box plate optional accessory available (ordered separately).
  • - The TYK+ 10 RM versions to be powered solely with the power supply units available as accessories (ordered separately).
  • - Maximum cable length of 10 meters between the power supply unit and the related floodlights.
  • - RM (Remote Driver) version are granted for a – 40°F working temperature.
  • - SA version add -RM for remote driver.
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Product meets Buy American Act (BAA) requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finishing Lampholder Wattage Voltage CRI Kelvin Optic Beam
angle
Lightsource
lumen
output
[lm]
Luminaire
lumen
output
[lm]
L B Lifetime Downloads
High Power LEDS 120 V
078002 LED 8 W 120 V 80 3000 Type V 34° 650 554 L90 B10 75000 Download

Documentation: TYK+ 10 C/M - 078002

078003 LED 8 W 120 V 80 4000 Type V 34° 700 598 L90 B10 75000 Download

Documentation: TYK+ 10 C/M - 078003

Sources

LED 8 W
  • Long-lasting floodlighting for landscape and any architecture, also applying dynamic color. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free (<1%) precision die-cast aluminum housing, and adjustable stainless steel mounting bracket.
  • - Stainless steel graduated ferrules for aiming purposes on both sides of the fixture.
  • - Extra-clear, tempered, silk-screened, flat glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - ustom MCPCB utilized to maximize heat dissipation and promote long LED life.
  • - High-transparency polycarbonate optics for optimized light transmission.
  • - Elliptical optics (ELL).
  • - Input voltage: 120V (50 / 60 Hz) integral driver, 120-277V (50 / 60 Hz) remote driver (RM versions).
  • - Standard tear-proof nickel-plated brass cable gland M16x1.5 for cables Ø0.2” - Ø0.4”.
  • - Pre-wired factory sealed cable for external electrical connection included.
  • - Standard robust ½” NPS knuckle mount with 180° adjustable swivel arm (SA versions) and rugged, locking teeth for a simplified installation.
  • - Matching junction box plate optional accessory available (ordered separately).
  • - The TYK+ 10 RM versions to be powered solely with the power supply units available as accessories (ordered separately).
  • - Maximum cable length of 10 meters between the power supply unit and the related floodlights.
  • - RM (Remote Driver) version are granted for a – 40°F working temperature.
  • - SA version add -RM for remote driver.
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Product meets Buy American Act (BAA) requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finishing Lampholder Wattage Voltage CRI Kelvin Optic Beam
angle
Lightsource
lumen
output
[lm]
Luminaire
lumen
output
[lm]
L B Lifetime Downloads
High Power LEDS 120 V
078006 LED 8 W 120 V 80 3000 Type I 9°x70° 650 439 L90 B10 75000 Download

Documentation: TYK+ 10 ELL - 078006

078007 LED 8 W 120 V 80 4000 Type I 9°x70° 700 474 L90 B10 75000 Download

Documentation: TYK+ 10 ELL - 078007

078008 LED 8 W 120 V 80 3000 Type I 70°x9° 650 439 L90 B10 75000 Download

Documentation: TYK+ 10 ELL - 078008

078009 LED 8 W 120 V 80 4000 Type I 70°x9° 700 474 L90 B10 75000 Download

Documentation: TYK+ 10 ELL - 078009

Sources

LED 8 W
  • Long-lasting floodlighting for landscape and any architecture, also applying dynamic color. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free (<1%) precision die-cast aluminum housing, and adjustable stainless steel mounting bracket.
  • - Stainless steel graduated ferrules for aiming purposes on both sides of the fixture.
  • - Extra-clear, tempered, silk-screened, flat glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - ustom MCPCB utilized to maximize heat dissipation and promote long LED life.
  • - High-transparency polycarbonate optics for optimized light transmission.
  • - Circular Medium optics (C/M).
  • - RGBW (4000K) color mixing for high emotional impact scenographic effects.
  • - Input voltage: 48 V DC, separate driver for RGBW color mixing and/or dynamic Tunable White versions (ordered separately).
  • - Standard tear-proof nickel-plated brass cable gland M16x1.5 for cables Ø0.2” - Ø0.4”.
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Product meets Buy American Act (BAA) requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finishing Lampholder Wattage Voltage CRI Kelvin Optic Beam
angle
Lightsource
lumen
output
[lm]
Luminaire
lumen
output
[lm]
L B Lifetime Downloads
RGBW LED
078071 LED 6 W 80 RGBW 4000 Type V 30° 196 170 L90 B10 24000 Download

Documentation: TYK+ 10 RGBW C/M - 078071

Sources

LED 6 W
  • Long-lasting floodlighting for landscape and any architecture, also applying dynamic color. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free (<1%) precision die-cast aluminum housing, and adjustable stainless steel mounting bracket.
  • - Stainless steel graduated ferrules for aiming purposes on both sides of the fixture.
  • - Extra-clear, tempered, silk-screened, flat glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - ustom MCPCB utilized to maximize heat dissipation and promote long LED life.
  • - High-transparency polycarbonate optics for optimized light transmission.
  • - Circular Intensive optics (C/I).
  • - Input voltage: 120V (50 / 60 Hz) integral driver, 120-277V (50 / 60 Hz) remote driver (RM versions).
  • - Standard tear-proof nickel-plated brass cable gland M16x1.5 for cables Ø0.2” - Ø0.4”.
  • - Pre-wired factory sealed cable for external electrical connection included.
  • - Standard robust ½” NPS knuckle mount with 180° adjustable swivel arm (SA versions) and rugged, locking teeth for a simplified installation.
  • - Matching junction box plate optional accessory available (ordered separately).
  • - The TYK+ 10 RM versions to be powered solely with the power supply units available as accessories (ordered separately).
  • - Maximum cable length of 10 meters between the power supply unit and the related floodlights.
  • - RM (Remote Driver) version are granted for a – 40°F working temperature.
  • - SA version add -RM for remote driver.
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Product meets Buy American Act (BAA) requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finishing Lampholder Wattage Voltage CRI Kelvin Optic Beam
angle
Lightsource
lumen
output
[lm]
Luminaire
lumen
output
[lm]
L B Lifetime Downloads
Power LED
078010 LED 6 W 80 3000 Type V 10° 650 518 L90 B10 75000 Download

Documentation: TYK+ 10 RM C/I - 078010

078011 LED 6 W 80 4000 Type V 10° 700 560 L90 B10 75000 Download

Documentation: TYK+ 10 RM C/I - 078011

Sources

LED 6 W
  • Long-lasting floodlighting for landscape and any architecture, also applying dynamic color. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free (<1%) precision die-cast aluminum housing, and adjustable stainless steel mounting bracket.
  • - Stainless steel graduated ferrules for aiming purposes on both sides of the fixture.
  • - Extra-clear, tempered, silk-screened, flat glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - ustom MCPCB utilized to maximize heat dissipation and promote long LED life.
  • - High-transparency polycarbonate optics for optimized light transmission.
  • - NEMA 5H x 5V light distribution (C/IW)
  • - Input voltage: 120V (50 / 60 Hz) integral driver, 120-277V (50 / 60 Hz) remote driver (RM versions).
  • - Standard tear-proof nickel-plated brass cable gland M16x1.5 for cables Ø0.2” - Ø0.4”.
  • - Pre-wired factory sealed cable for external electrical connection included.
  • - Standard robust ½” NPS knuckle mount with 180° adjustable swivel arm (SA versions) and rugged, locking teeth for a simplified installation.
  • - Matching junction box plate optional accessory available (ordered separately).
  • - The TYK+ 10 RM versions to be powered solely with the power supply units available as accessories (ordered separately).
  • - Maximum cable length of 10 meters between the power supply unit and the related floodlights.
  • - RM (Remote Driver) version are granted for a – 40°F working temperature.
  • - SA version add -RM for remote driver.
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Product meets Buy American Act (BAA) requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finishing Lampholder Wattage Voltage CRI Kelvin Optic Beam
angle
Lightsource
lumen
output
[lm]
Luminaire
lumen
output
[lm]
L B Lifetime Downloads
Power LED
078014 LED 6 W 80 3000 Type V 65° 650 542 L90 B10 75000 Download

Documentation: TYK+ 10 RM C/IW - 078014

078015 LED 6 W 80 4000 Type V 65° 700 585 L90 B10 75000 Download

Documentation: TYK+ 10 RM C/IW - 078015

Sources

LED 6 W
  • Long-lasting floodlighting for landscape and any architecture, also applying dynamic color. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free (<1%) precision die-cast aluminum housing, and adjustable stainless steel mounting bracket.
  • - Stainless steel graduated ferrules for aiming purposes on both sides of the fixture.
  • - Extra-clear, tempered, silk-screened, flat glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - ustom MCPCB utilized to maximize heat dissipation and promote long LED life.
  • - High-transparency polycarbonate optics for optimized light transmission.
  • - Circular Medium optics (C/M).
  • - Input voltage: 120V (50 / 60 Hz) integral driver, 120-277V (50 / 60 Hz) remote driver (RM versions).
  • - Standard tear-proof nickel-plated brass cable gland M16x1.5 for cables Ø0.2” - Ø0.4”.
  • - Pre-wired factory sealed cable for external electrical connection included.
  • - Standard robust ½” NPS knuckle mount with 180° adjustable swivel arm (SA versions) and rugged, locking teeth for a simplified installation.
  • - Matching junction box plate optional accessory available (ordered separately).
  • - The TYK+ 10 RM versions to be powered solely with the power supply units available as accessories (ordered separately).
  • - Maximum cable length of 10 meters between the power supply unit and the related floodlights.
  • - RM (Remote Driver) version are granted for a – 40°F working temperature.
  • - SA version add -RM for remote driver.
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Product meets Buy American Act (BAA) requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finishing Lampholder Wattage Voltage CRI Kelvin Optic Beam
angle
Lightsource
lumen
output
[lm]
Luminaire
lumen
output
[lm]
L B Lifetime Downloads
Power LED
078012 LED 6 W 80 3000 Type V 34° 650 554 L90 B10 75000 Download

Documentation: TYK+ 10 RM C/M - 078012

078013 LED 6 W 80 4000 Type V 34° 700 598 L90 B10 75000 Download

Documentation: TYK+ 10 RM C/M - 078013

Sources

LED 6 W
  • Long-lasting floodlighting for landscape and any architecture, also applying dynamic color. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free (<1%) precision die-cast aluminum housing, and adjustable stainless steel mounting bracket.
  • - Stainless steel graduated ferrules for aiming purposes on both sides of the fixture.
  • - Extra-clear, tempered, silk-screened, flat glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - ustom MCPCB utilized to maximize heat dissipation and promote long LED life.
  • - High-transparency polycarbonate optics for optimized light transmission.
  • - Elliptical optics (ELL).
  • - Input voltage: 120V (50 / 60 Hz) integral driver, 120-277V (50 / 60 Hz) remote driver (RM versions).
  • - Standard tear-proof nickel-plated brass cable gland M16x1.5 for cables Ø0.2” - Ø0.4”.
  • - Pre-wired factory sealed cable for external electrical connection included.
  • - Standard robust ½” NPS knuckle mount with 180° adjustable swivel arm (SA versions) and rugged, locking teeth for a simplified installation.
  • - Matching junction box plate optional accessory available (ordered separately).
  • - The TYK+ 10 RM versions to be powered solely with the power supply units available as accessories (ordered separately).
  • - Maximum cable length of 10 meters between the power supply unit and the related floodlights.
  • - RM (Remote Driver) version are granted for a – 40°F working temperature.
  • - SA version add -RM for remote driver.
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Product meets Buy American Act (BAA) requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finishing Lampholder Wattage Voltage CRI Kelvin Optic Beam
angle
Lightsource
lumen
output
[lm]
Luminaire
lumen
output
[lm]
L B Lifetime Downloads
Power LED
078016 LED 6 W 80 3000 Type I 9°x70° 650 439 L90 B10 75000 Download

Documentation: TYK+ 10 RM ELL - 078016

078017 LED 6 W 80 4000 Type I 9°x70° 700 474 L90 B10 75000 Download

Documentation: TYK+ 10 RM ELL - 078017

078018 LED 6 W 80 3000 Type I 70°x9° 650 439 L90 B10 75000 Download

Documentation: TYK+ 10 RM ELL - 078018

078019 LED 6 W 80 4000 Type I 70°x9° 700 474 L90 B10 75000 Download

Documentation: TYK+ 10 RM ELL - 078019

Sources

LED 6 W
  • Long-lasting floodlighting for landscape and any architecture, also applying dynamic color. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free (<1%) precision die-cast aluminum housing, and adjustable stainless steel mounting bracket.
  • - Stainless steel graduated ferrules for aiming purposes on both sides of the fixture.
  • - Extra-clear, tempered, silk-screened, flat glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - ustom MCPCB utilized to maximize heat dissipation and promote long LED life.
  • - High-transparency polycarbonate optics for optimized light transmission.
  • - Circular Intensive optics (C/I).
  • - Input voltage: 120V (50 / 60 Hz) integral driver, 120-277V (50 / 60 Hz) remote driver (RM versions).
  • - Standard tear-proof nickel-plated brass cable gland M16x1.5 for cables Ø0.2” - Ø0.4”.
  • - Pre-wired factory sealed cable for external electrical connection included.
  • - Standard robust ½” NPS knuckle mount with 180° adjustable swivel arm (SA versions) and rugged, locking teeth for a simplified installation.
  • - Matching junction box plate optional accessory available (ordered separately).
  • - The TYK+ 10 RM versions to be powered solely with the power supply units available as accessories (ordered separately).
  • - Maximum cable length of 10 meters between the power supply unit and the related floodlights.
  • - RM (Remote Driver) version are granted for a – 40°F working temperature.
  • - SA version add -RM for remote driver.
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Product meets Buy American Act (BAA) requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finishing Lampholder Wattage Voltage CRI Kelvin Optic Beam
angle
Lightsource
lumen
output
[lm]
Luminaire
lumen
output
[lm]
L B Lifetime Downloads
High Power LEDS 120 V
078020 LED 8 W 120 V 80 3000 Type V 10° 650 518 L90 B10 75000 Download

Documentation: TYK+ 10 SA C/I - 078020

078021 LED 8 W 120 V 80 4000 Type V 10° 700 560 L90 B10 75000 Download

Documentation: TYK+ 10 SA C/I - 078021

Sources

LED 8 W
  • Long-lasting floodlighting for landscape and any architecture, also applying dynamic color. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free (<1%) precision die-cast aluminum housing, and adjustable stainless steel mounting bracket.
  • - Stainless steel graduated ferrules for aiming purposes on both sides of the fixture.
  • - Extra-clear, tempered, silk-screened, flat glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - ustom MCPCB utilized to maximize heat dissipation and promote long LED life.
  • - High-transparency polycarbonate optics for optimized light transmission.
  • - NEMA 5H x 5V light distribution (C/IW)
  • - Input voltage: 120V (50 / 60 Hz) integral driver, 120-277V (50 / 60 Hz) remote driver (RM versions).
  • - Standard tear-proof nickel-plated brass cable gland M16x1.5 for cables Ø0.2” - Ø0.4”.
  • - Pre-wired factory sealed cable for external electrical connection included.
  • - Standard robust ½” NPS knuckle mount with 180° adjustable swivel arm (SA versions) and rugged, locking teeth for a simplified installation.
  • - Matching junction box plate optional accessory available (ordered separately).
  • - The TYK+ 10 RM versions to be powered solely with the power supply units available as accessories (ordered separately).
  • - Maximum cable length of 10 meters between the power supply unit and the related floodlights.
  • - RM (Remote Driver) version are granted for a – 40°F working temperature.
  • - SA version add -RM for remote driver.
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Product meets Buy American Act (BAA) requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finishing Lampholder Wattage Voltage CRI Kelvin Optic Beam
angle
Lightsource
lumen
output
[lm]
Luminaire
lumen
output
[lm]
L B Lifetime Downloads
High Power LEDS 120 V
078024 LED 8 W 120 V 80 3000 Type V 65° 650 542 L90 B10 75000 Download

Documentation: TYK+ 10 SA C/IW - 078024

078025 LED 8 W 120 V 80 4000 Type V 65° 700 585 L90 B10 75000 Download

Documentation: TYK+ 10 SA C/IW - 078025

Sources

LED 8 W
  • Long-lasting floodlighting for landscape and any architecture, also applying dynamic color. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free (<1%) precision die-cast aluminum housing, and adjustable stainless steel mounting bracket.
  • - Stainless steel graduated ferrules for aiming purposes on both sides of the fixture.
  • - Extra-clear, tempered, silk-screened, flat glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - ustom MCPCB utilized to maximize heat dissipation and promote long LED life.
  • - High-transparency polycarbonate optics for optimized light transmission.
  • - Circular Medium optics (C/M).
  • - Input voltage: 120V (50 / 60 Hz) integral driver, 120-277V (50 / 60 Hz) remote driver (RM versions).
  • - Standard tear-proof nickel-plated brass cable gland M16x1.5 for cables Ø0.2” - Ø0.4”.
  • - Pre-wired factory sealed cable for external electrical connection included.
  • - Standard robust ½” NPS knuckle mount with 180° adjustable swivel arm (SA versions) and rugged, locking teeth for a simplified installation.
  • - Matching junction box plate optional accessory available (ordered separately).
  • - The TYK+ 10 RM versions to be powered solely with the power supply units available as accessories (ordered separately).
  • - Maximum cable length of 10 meters between the power supply unit and the related floodlights.
  • - RM (Remote Driver) version are granted for a – 40°F working temperature.
  • - SA version add -RM for remote driver.
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Product meets Buy American Act (BAA) requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finishing Lampholder Wattage Voltage CRI Kelvin Optic Beam
angle
Lightsource
lumen
output
[lm]
Luminaire
lumen
output
[lm]
L B Lifetime Downloads
High Power LEDS 120 V
078022 LED 8 W 120 V 80 3000 Type V 34° 650 554 L90 B10 75000 Download

Documentation: TYK+ 10 SA C/M - 078022

078023 LED 8 W 120 V 80 4000 Type V 34° 700 598 L90 B10 75000 Download

Documentation: TYK+ 10 SA C/M - 078023

Sources

LED 8 W
  • Long-lasting floodlighting for landscape and any architecture, also applying dynamic color. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free (<1%) precision die-cast aluminum housing, and adjustable stainless steel mounting bracket.
  • - Stainless steel graduated ferrules for aiming purposes on both sides of the fixture.
  • - Extra-clear, tempered, silk-screened, flat glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - ustom MCPCB utilized to maximize heat dissipation and promote long LED life.
  • - High-transparency polycarbonate optics for optimized light transmission.
  • - Elliptical optics (ELL).
  • - Input voltage: 120V (50 / 60 Hz) integral driver, 120-277V (50 / 60 Hz) remote driver (RM versions).
  • - Standard tear-proof nickel-plated brass cable gland M16x1.5 for cables Ø0.2” - Ø0.4”.
  • - Pre-wired factory sealed cable for external electrical connection included.
  • - Standard robust ½” NPS knuckle mount with 180° adjustable swivel arm (SA versions) and rugged, locking teeth for a simplified installation.
  • - Matching junction box plate optional accessory available (ordered separately).
  • - The TYK+ 10 RM versions to be powered solely with the power supply units available as accessories (ordered separately).
  • - Maximum cable length of 10 meters between the power supply unit and the related floodlights.
  • - RM (Remote Driver) version are granted for a – 40°F working temperature.
  • - SA version add -RM for remote driver.
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Product meets Buy American Act (BAA) requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finishing Lampholder Wattage Voltage CRI Kelvin Optic Beam
angle
Lightsource
lumen
output
[lm]
Luminaire
lumen
output
[lm]
L B Lifetime Downloads
High Power LEDS 120 V
078026 LED 8 W 120 V 80 3000 Type I 9°x70° 650 439 L90 B10 75000 Download

Documentation: TYK+ 10 SA ELL - 078026

078027 LED 8 W 120 V 80 4000 Type I 9°x70° 700 474 L90 B10 75000 Download

Documentation: TYK+ 10 SA ELL - 078027

078028 LED 8 W 120 V 80 3000 Type I 70°x9° 650 439 L90 B10 75000 Download

Documentation: TYK+ 10 SA ELL - 078028

078029 LED 8 W 120 V 80 4000 Type I 70°x9° 700 474 L90 B10 75000 Download

Documentation: TYK+ 10 SA ELL - 078029

Sources

LED 8 W
  • Long-lasting floodlighting for landscape and any architecture, also applying dynamic color. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free (<1%) precision die-cast aluminum housing, and adjustable stainless steel mounting bracket.
  • - Stainless steel graduated ferrules for aiming purposes on both sides of the fixture.
  • - Extra-clear, tempered, silk-screened, flat glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - ustom MCPCB utilized to maximize heat dissipation and promote long LED life.
  • - High-transparency polycarbonate optics for optimized light transmission.
  • - Circular Medium optics (C/M).
  • - Dynamic Tunable White (TW) options enable smooth variations in color temperature, from 2700K to 5700K, in response to how a space is used.
  • - Input voltage: 48 V DC, separate driver for RGBW color mixing and/or dynamic Tunable White versions (ordered separately).
  • - Standard tear-proof nickel-plated brass cable gland M16x1.5 for cables Ø0.2” - Ø0.4”.
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Product meets Buy American Act (BAA) requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finishing Lampholder Wattage Voltage CRI Kelvin Optic Beam
angle
Lightsource
lumen
output
[lm]
Luminaire
lumen
output
[lm]
L B Lifetime Downloads
TunableWhite Power LED
078070 LED 5 W 90 TW 2700-5700 Type V 30° 500 443 L90 B10 50000 Download

Documentation: TYK+ 10 TW C/M - 078070

Sources

LED 5 W

Product Family

to top
Products search
You can search for products in our catalog by entering here the name or the code of the product or accessory.
