TYK+ 20

IN
  • Long-lasting floodlighting for landscape and any architecture, also applying dynamic color. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free (<1%) precision die-cast aluminum housing, and adjustable stainless steel mounting bracket.
  • - Stainless steel graduated ferrules for aiming purposes on both sides of the fixture.
  • - Extra-clear, tempered, silk-screened, flat glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Custom MCPCB utilized to maximize heat dissipation and promote long LED life.
  • - High-transparency polycarbonate optics for optimized light transmission.
  • - Circular Intensive optics (C/I).
  • - Circular Medium optics (C/M).
  • - RGBW (4000K) color mixing for high emotional impact scenographic effects.
  • - NEMA 5H x 5V light distribution (C/IW)
  • - Elliptical optics (ELL).
  • - Input voltage: 120-277 V (50 / 60 Hz), integral 0-10 V dimming driver.
  • - Input voltage: 48 V DC, separate driver for RGBW color mixing and/or dynamic Tunable White versions (ordered separately).
  • - Standard tear-proof nickel-plated brass cable gland M20x1.5 for cables Ø0.4” - Ø0.55”.
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Product meets Buy American Act (BAA) requirements within ARRA.
  • - 5-year warranty.
TYK+ 20 C/I

TYK+ 20 C/I

Optic | Circular Intensive
  • Long-lasting floodlighting for landscape and any architecture, also applying dynamic color. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free (<1%) precision die-cast aluminum housing, and adjustable stainless steel mounting bracket.
  • - Stainless steel graduated ferrules for aiming purposes on both sides of the fixture.
  • - Extra-clear, tempered, silk-screened, flat glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Custom MCPCB utilized to maximize heat dissipation and promote long LED life.
  • - High-transparency polycarbonate optics for optimized light transmission.
  • - Circular Intensive optics (C/I).
  • - Input voltage: 120-277 V (50 / 60 Hz), integral 0-10 V dimming driver.
  • - Standard tear-proof nickel-plated brass cable gland M20x1.5 for cables Ø0.4” - Ø0.55”.
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Product meets Buy American Act (BAA) requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finishing Lampholder Wattage Voltage CRI Kelvin Optic Beam
angle		 Lightsource
lumen
output
[lm]		 Luminaire
lumen
output
[lm]		 L B Lifetime Downloads
High Power LEDS 120-277 V - Dimmable 0-10 V
078030 LED 20 W 120/277 V 80 3000 Type V 10° 1980 1711 L90 B10 90000 Download

Documentation: TYK+ 20 C/I - 078030
078031 LED 20 W 120/277 V 80 4000 Type V 10° 2200 1847 L90 B10 90000 Download

Documentation: TYK+ 20 C/I - 078031
078038 LED 35 W 120/277 V 80 3000 Type V 10° 3600 2835 L90 B10 90000 Download

Documentation: TYK+ 20 C/I - 078038
078039 LED 35 W 120/277 V 80 4000 Type V 10° 4000 3060 L90 B10 90000 Download

Documentation: TYK+ 20 C/I - 078039
078046 LED 50 W 120/277 V 80 3000 Type V 10° 4900 3916 L90 B10 50000 Download

Documentation: TYK+ 20 C/I - 078046
078047 LED 50 W 120/277 V 80 4000 Type V 10° 5500 4227 L90 B10 50000 Download

Documentation: TYK+ 20 C/I - 078047

Sources

LED 20 W
LED 35 W
LED 50 W
TYK+ 20 C/IW

TYK+ 20 C/IW

Optic | Circular Intensive-Wide
  • Long-lasting floodlighting for landscape and any architecture, also applying dynamic color. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free (<1%) precision die-cast aluminum housing, and adjustable stainless steel mounting bracket.
  • - Stainless steel graduated ferrules for aiming purposes on both sides of the fixture.
  • - Extra-clear, tempered, silk-screened, flat glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Custom MCPCB utilized to maximize heat dissipation and promote long LED life.
  • - High-transparency polycarbonate optics for optimized light transmission.
  • - NEMA 5H x 5V light distribution (C/IW)
  • - Input voltage: 120-277 V (50 / 60 Hz), integral 0-10 V dimming driver.
  • - Standard tear-proof nickel-plated brass cable gland M20x1.5 for cables Ø0.4” - Ø0.55”.
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Product meets Buy American Act (BAA) requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finishing Lampholder Wattage Voltage CRI Kelvin Optic Beam
angle		 Lightsource
lumen
output
[lm]		 Luminaire
lumen
output
[lm]		 L B Lifetime Downloads
High Power LEDS 120-277 V - Dimmable 0-10 V
078034 LED 20 W 120/277 V 80 3000 Type V 65° 1980 1858 L90 B10 90000 Download

Documentation: TYK+ 20 C/IW - 078034
078035 LED 20 W 120/277 V 80 4000 Type V 65° 2200 2006 L90 B10 90000 Download

Documentation: TYK+ 20 C/IW - 078035
078042 LED 35 W 120/277 V 80 3000 Type V 65° 3600 3078 L90 B10 90000 Download

Documentation: TYK+ 20 C/IW - 078042
078043 LED 35 W 120/277 V 80 4000 Type V 65° 4000 3323 L90 B10 90000 Download

Documentation: TYK+ 20 C/IW - 078043
078050 LED 50 W 120/277 V 80 3000 Type V 65° 4900 4252 L90 B10 50000 Download

Documentation: TYK+ 20 C/IW - 078050
078051 LED 50 W 120/277 V 80 4000 Type V 65° 5500 4590 L90 B10 50000 Download

Documentation: TYK+ 20 C/IW - 078051

Sources

LED 20 W
LED 35 W
LED 50 W
TYK+ 20 C/M

TYK+ 20 C/M

Optic | Circular Medium
  • Long-lasting floodlighting for landscape and any architecture, also applying dynamic color. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free (<1%) precision die-cast aluminum housing, and adjustable stainless steel mounting bracket.
  • - Stainless steel graduated ferrules for aiming purposes on both sides of the fixture.
  • - Extra-clear, tempered, silk-screened, flat glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Custom MCPCB utilized to maximize heat dissipation and promote long LED life.
  • - High-transparency polycarbonate optics for optimized light transmission.
  • - Circular Medium optics (C/M).
  • - Input voltage: 120-277 V (50 / 60 Hz), integral 0-10 V dimming driver.
  • - Standard tear-proof nickel-plated brass cable gland M20x1.5 for cables Ø0.4” - Ø0.55”.
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Product meets Buy American Act (BAA) requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finishing Lampholder Wattage Voltage CRI Kelvin Optic Beam
angle		 Lightsource
lumen
output
[lm]		 Luminaire
lumen
output
[lm]		 L B Lifetime Downloads
High Power LEDS 120-277 V - Dimmable 0-10 V
078032 LED 20 W 120/277 V 80 3000 Type V 34° 1980 1913 L90 B10 90000 Download

Documentation: TYK+ 20 C/M - 078032
078033 LED 20 W 120/277 V 80 4000 Type V 34° 2200 2065 L90 B10 90000 Download

Documentation: TYK+ 20 C/M - 078033
078040 LED 35 W 120/277 V 80 3000 Type V 34° 3600 3169 L90 B10 90000 Download

Documentation: TYK+ 20 C/M - 078040
078041 LED 35 W 120/277 V 80 4000 Type V 34° 4000 3421 L90 B10 90000 Download

Documentation: TYK+ 20 C/M - 078041
078048 LED 50 W 120/277 V 80 3000 Type V 34° 4900 4377 L90 B10 50000 Download

Documentation: TYK+ 20 C/M - 078048
078049 LED 50 W 120/277 V 80 4000 Type V 34° 5500 4725 L90 B10 50000 Download

Documentation: TYK+ 20 C/M - 078049

Sources

LED 20 W
LED 35 W
LED 50 W
TYK+ 20 ELL

TYK+ 20 ELL

Optic | Elliptical
  • Long-lasting floodlighting for landscape and any architecture, also applying dynamic color. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free (<1%) precision die-cast aluminum housing, and adjustable stainless steel mounting bracket.
  • - Stainless steel graduated ferrules for aiming purposes on both sides of the fixture.
  • - Extra-clear, tempered, silk-screened, flat glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Custom MCPCB utilized to maximize heat dissipation and promote long LED life.
  • - High-transparency polycarbonate optics for optimized light transmission.
  • - Elliptical optics (ELL).
  • - Input voltage: 120-277 V (50 / 60 Hz), integral 0-10 V dimming driver.
  • - Standard tear-proof nickel-plated brass cable gland M20x1.5 for cables Ø0.4” - Ø0.55”.
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Product meets Buy American Act (BAA) requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finishing Lampholder Wattage Voltage CRI Kelvin Optic Beam
angle		 Lightsource
lumen
output
[lm]		 Luminaire
lumen
output
[lm]		 L B Lifetime Downloads
High Power LEDS 120-277 V - Dimmable 0-10 V
078036 LED 20 W 120/277 V 80 3000 Type I 35°x65° 1980 1255 L90 B10 90000 Download

Documentation: TYK+ 20 ELL - 078036
078037 LED 20 W 120/277 V 80 4000 Type I 35°x65° 2200 1354 L90 B10 90000 Download

Documentation: TYK+ 20 ELL - 078037
078044 LED 35 W 120/277 V 80 3000 Type I 35°x65° 3600 1933 L90 B10 90000 Download

Documentation: TYK+ 20 ELL - 078044
078045 LED 35 W 120/277 V 80 4000 Type I 35°x65° 4000 2087 L90 B10 90000 Download

Documentation: TYK+ 20 ELL - 078045
078052 LED 50 W 120/277 V 80 3000 Type I 35°x65° 4900 2691 L90 B10 50000 Download

Documentation: TYK+ 20 ELL - 078052
078053 LED 50 W 120/277 V 80 4000 Type I 35°x65° 5500 2905 L90 B10 50000 Download

Documentation: TYK+ 20 ELL - 078053

Sources

LED 20 W
LED 35 W
LED 50 W
TYK+ 20 RGBW C/M

TYK+ 20 RGBW C/M

Optic | Circular Medium
  • Long-lasting floodlighting for landscape and any architecture, also applying dynamic color. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free (<1%) precision die-cast aluminum housing, and adjustable stainless steel mounting bracket.
  • - Stainless steel graduated ferrules for aiming purposes on both sides of the fixture.
  • - Extra-clear, tempered, silk-screened, flat glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Custom MCPCB utilized to maximize heat dissipation and promote long LED life.
  • - High-transparency polycarbonate optics for optimized light transmission.
  • - Circular Medium optics (C/M).
  • - RGBW (4000K) color mixing for high emotional impact scenographic effects.
  • - Input voltage: 48 V DC, separate driver for RGBW color mixing and/or dynamic Tunable White versions (ordered separately).
  • - Standard tear-proof nickel-plated brass cable gland M16x1.5 for cables Ø0.2” - Ø0.4”.
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Product meets Buy American Act (BAA) requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finishing Lampholder Wattage Voltage CRI Kelvin Optic Beam
angle		 Lightsource
lumen
output
[lm]		 Luminaire
lumen
output
[lm]		 L B Lifetime Downloads
RGBW LED
078072 LED 37 W 80 RGBW 4000 Type V 30° 1832 1477 L80 B10 50000 Download

Documentation: TYK+ 20 RGBW C/M - 078072

Sources

LED 37 W
