TYK+ 30

IN
  • - Long-lasting energy-efficient flood and accent light series for lighting landscapes, trees, columns, monuments, and architectural details.
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free precision die-cast aluminum housing, and adjustable stainless steel mounting bracket.
  • - Stainless steel graduated ferrules for aiming purposes on both sides of the fixture.
  • - Extra-clear, tempered, silk-screened, flat glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Custom MCPCB utilized to maximize heat dissipation and promote long LED life.
  • - NEMA 2H X 2V light distribution (C/I)
  • - NEMA 4H X 4V light distribution (C/M)
  • - NEMA 5H X 5V light distribution (C/IW)
  • - NEMA 5H X 5V light distribution (ELL).
  • - High-transmittance transparent optics.
  • - Input voltage: 120-277 V (50 / 60 Hz), integral 0-10 V dimming driver.
  • - Standard tear-proof nickelled brass cable gland M20x1.5 for cables Ø0,4” - Ø0,55”.
  • - Consult factory for dimming options, marine-grade, custom finishes (please specify RAL color), and non-cataloged CCT (Kelvin) options including static colors.
  • - Consult factory for additional optic options.
  • - Product meets Buy American Act requirements within ARRA.
  • - 5-year warranty.
  • Long-lasting energy-efficient flood and accent light series for lighting landscapes, trees, columns, monuments, and architectural details.
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free precision die-cast aluminum housing, and adjustable stainless steel mounting bracket.
  • - Stainless steel graduated ferrules for aiming purposes on both sides of the fixture.
  • - Extra-clear, tempered, silk-screened, flat glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Custom MCPCB utilized to maximize heat dissipation and promote long LED life.
  • - High-transmittance transparent optics.
  • - NEMA 3H x 3V light distribution (C/I).
  • - Input voltage: 120-277 V (50 / 60 Hz), integral 0-10 V dimming driver.
  • - Standard tear-proof nickelled brass cable gland M20x1.5 for cables Ø0,4” - Ø0,55”.
  • - Five optional finishes available. Add finish suffix to any part number for textured Black (BK-81), Iron gray (AN-96), Aluminum metallic (GR-94), White (WH-87), Iron rust (RB-10) when not standard.
  • - Consult factory for dimming options, marine-grade, custom finishes (please specify RAL color), and non-cataloged CCT (Kelvin) options including static colors.
  • - Consult factory for additional optic options.
  • - Product meets Buy American Act requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finish Lampholder Wattage Voltage CRI Kelvin Optic Optic
Beam
Lightsource
lumen
output
Luminaire
lumen
output
L B Lifetime Download
High Power LEDS 120-277 V - Dimmable 0-10 V
078054 LED 60 W 120/277 V 80 3000 Type V 10° 6100 5135 L90 B10 90000 Download

Documentation: TYK+ 30 C/I - 078054

078055 LED 60 W 120/277 V 80 4000 Type V 10° 6810 5543 L90 B10 90000 Download

Documentation: TYK+ 30 C/I - 078055

078062 LED 85 W 120/277 V 80 3000 Type V 10° 8300 6547 L90 B10 50000 Download

Documentation: TYK+ 30 C/I - 078062

078063 LED 85 W 120/277 V 80 4000 Type V 10° 9200 7067 L90 B10 50000 Download

Documentation: TYK+ 30 C/I - 078063

Sources

LED 60 W
LED 85 W
TYK+ 30 C/IW

TYK+ 30 C/IW

Intensive circle wide reflector
  • Long-lasting energy-efficient flood and accent light series for lighting landscapes, trees, columns, monuments, and architectural details.
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free precision die-cast aluminum housing, and adjustable stainless steel mounting bracket.
  • - Stainless steel graduated ferrules for aiming purposes on both sides of the fixture.
  • - Extra-clear, tempered, silk-screened, flat glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Custom MCPCB utilized to maximize heat dissipation and promote long LED life.
  • - High-transmittance transparent optics.
  • - NEMA 5H x 5V light distribution (C/IW)
  • - Input voltage: 120-277 V (50 / 60 Hz), integral 0-10 V dimming driver.
  • - Standard tear-proof nickelled brass cable gland M20x1.5 for cables Ø0,4” - Ø0,55”.
  • - Five optional finishes available. Add finish suffix to any part number for textured Black (BK-81), Iron gray (AN-96), Aluminum metallic (GR-94), White (WH-87), Iron rust (RB-10) when not standard.
  • - Consult factory for dimming options, marine-grade, custom finishes (please specify RAL color), and non-cataloged CCT (Kelvin) options including static colors.
  • - Consult factory for additional optic options.
  • - Product meets Buy American Act requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finish Lampholder Wattage Voltage CRI Kelvin Optic Optic
Beam
Lightsource
lumen
output
Luminaire
lumen
output
L B Lifetime Download
High Power LEDS 120-277 V - Dimmable 0-10 V
078058 LED 60 W 120/277 V 80 3000 Type V 65° 6100 5575 L90 B10 90000 Download

Documentation: TYK+ 30 C/IW - 078058

078059 LED 60 W 120/277 V 80 4000 Type V 65° 6810 6019 L90 B10 90000 Download

Documentation: TYK+ 30 C/IW - 078059

078066 LED 85 W 120/277 V 80 3000 Type V 65° 8300 7109 L90 B10 50000 Download

Documentation: TYK+ 30 C/IW - 078066

078067 LED 85 W 120/277 V 80 4000 Type V 65° 9200 7674 L90 B10 50000 Download

Documentation: TYK+ 30 C/IW - 078067

Sources

LED 60 W
LED 85 W
  • Long-lasting energy-efficient flood and accent light series for lighting landscapes, trees, columns, monuments, and architectural details.
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free precision die-cast aluminum housing, and adjustable stainless steel mounting bracket.
  • - Stainless steel graduated ferrules for aiming purposes on both sides of the fixture.
  • - Extra-clear, tempered, silk-screened, flat glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Custom MCPCB utilized to maximize heat dissipation and promote long LED life.
  • - High-transmittance transparent optics.
  • - NEMA 4H x 4V light distribution (C/M).
  • - Input voltage: 120-277 V (50 / 60 Hz), integral 0-10 V dimming driver.
  • - Standard tear-proof nickelled brass cable gland M20x1.5 for cables Ø0,4” - Ø0,55”.
  • - Five optional finishes available. Add finish suffix to any part number for textured Black (BK-81), Iron gray (AN-96), Aluminum metallic (GR-94), White (WH-87), Iron rust (RB-10) when not standard.
  • - Consult factory for dimming options, marine-grade, custom finishes (please specify RAL color), and non-cataloged CCT (Kelvin) options including static colors.
  • - Consult factory for additional optic options.
  • - Product meets Buy American Act requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finish Lampholder Wattage Voltage CRI Kelvin Optic Optic
Beam
Lightsource
lumen
output
Luminaire
lumen
output
L B Lifetime Download
High Power LEDS 120-277 V - Dimmable 0-10 V
078056 LED 60 W 120/277 V 80 3000 Type V 34° 6100 5739 L90 B10 90000 Download

Documentation: TYK+ 30 C/M - 078056

078057 LED 60 W 120/277 V 80 4000 Type V 34° 6810 6195 L90 B10 90000 Download

Documentation: TYK+ 30 C/M - 078057

078064 LED 85 W 120/277 V 80 3000 Type V 34° 8300 7318 L90 B10 50000 Download

Documentation: TYK+ 30 C/M - 078064

078065 LED 85 W 120/277 V 80 4000 Type V 34° 9200 7899 L90 B10 50000 Download

Documentation: TYK+ 30 C/M - 078065

Sources

LED 60 W
LED 85 W
  • Long-lasting energy-efficient flood and accent light series for lighting landscapes, trees, columns, monuments, and architectural details.
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free precision die-cast aluminum housing, and adjustable stainless steel mounting bracket.
  • - Stainless steel graduated ferrules for aiming purposes on both sides of the fixture.
  • - Extra-clear, tempered, silk-screened, flat glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Custom MCPCB utilized to maximize heat dissipation and promote long LED life.
  • - High-transmittance transparent optics.
  • - NEMA 4H x 3V light distribution (ELL).
  • - Input voltage: 120-277 V (50 / 60 Hz), integral 0-10 V dimming driver.
  • - Standard tear-proof nickelled brass cable gland M20x1.5 for cables Ø0,4” - Ø0,55”.
  • - Five optional finishes available. Add finish suffix to any part number for textured Black (BK-81), Iron gray (AN-96), Aluminum metallic (GR-94), White (WH-87), Iron rust (RB-10) when not standard.
  • - Consult factory for dimming options, marine-grade, custom finishes (please specify RAL color), and non-cataloged CCT (Kelvin) options including static colors.
  • - Consult factory for additional optic options.
  • - Product meets Buy American Act requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finish Lampholder Wattage Voltage CRI Kelvin Optic Optic
Beam
Lightsource
lumen
output
Luminaire
lumen
output
L B Lifetime Download
High Power LEDS 120-277 V - Dimmable 0-10 V
078060 LED 60 W 120/277 V 80 3000 Type V 35°x65° 6100 3487 L90 B10 90000 Download

Documentation: TYK+ 30 ELL - 078060

078061 LED 60 W 120/277 V 80 4000 Type V 35°x65° 6810 3764 L90 B10 90000 Download

Documentation: TYK+ 30 ELL - 078061

078068 LED 85 W 120/277 V 80 3000 Type V 35°x65° 8300 4446 L90 B10 50000 Download

Documentation: TYK+ 30 ELL - 078068

078069 LED 85 W 120/277 V 80 4000 Type V 35°x65° 9200 4779 L90 B10 50000 Download

Documentation: TYK+ 30 ELL - 078069

Sources

LED 60 W
LED 85 W
