BLIZ OVAL

Wall mount series. Fixtures consist of:
- Multi-step powder-coat painting process, optimized against UV rays and corrosion.
- Copper-free (<1%) precision die-cast aluminum housing and ring/faceplate.
- High transmittance, internally coated, pressed glass diffuser, thermally, and chemically quenched to strengthen the impact resistance and reduce the effect of rapid temperature changes.
- Custom molded, anti-aging gasket(s).
- Stainless steel external hardware.
- Custom MCPCB utilized to maximize heat dissipation and promote long LED life.
- 100% uniform diffused light emission.
- Input voltage: 120-277 V (50 / 60 Hz), integral 0-10 V dimming driver.
- The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
- Contact factory for any Buy American Act (BAA) or Build America Buy America Act (BABAA) requirements.
- 5-year warranty.

Optic | Symmetric Extra-Wide

Wall mount series. Fixtures consist of:
- Multi-step powder-coat painting process, optimized against UV rays and corrosion.
- Copper-free (<1%) precision die-cast aluminum housing and ring/faceplate.
- High transmittance, internally coated, pressed glass diffuser, thermally, and chemically quenched to strengthen the impact resistance and reduce the effect of rapid temperature changes.
- Custom molded, anti-aging gasket(s).
- Stainless steel external hardware.
- Custom MCPCB utilized to maximize heat dissipation and promote long LED life.
- 100% uniform diffused light emission.
- Input voltage: 120-277 V (50 / 60 Hz), integral 0-10 V dimming driver.
- The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
- Contact factory for any Buy American Act (BAA) or Build America Buy America Act (BABAA) requirements.
- 5-year warranty.

Product codes

Part number	Lampholder	Wattage	Voltage	CRI	Kelvin	Optic	Beam angle	Lightsource lumen output [lm]	Luminaire lumen output [lm]	L	B	Lifetime	Downloads
Mid Power LEDS 120-277 V Dimmable 0-10 V
070705	LED	24 W	120/277 V	80	3000	-	-	3480	2111	L80	B10	60000	Documentation: BLIZ OVAL - 070705
070706	LED	24 W	120/277 V	80	4000	-	-	3600	2131	L80	B10	60000	Documentation: BLIZ OVAL - 070706
070707	LED	24 W	120/277 V	80	3000	-	-	3480	2111	L80	B10	60000	Documentation: BLIZ OVAL - 070707
070708	LED	24 W	120/277 V	80	4000	-	-	3600	2131	L80	B10	60000	Documentation: BLIZ OVAL - 070708
070709	LED	24 W	120/277 V	80	3000	-	-	3480	2111	L80	B10	60000	Documentation: BLIZ OVAL - 070709
070710	LED	24 W	120/277 V	80	4000	-	-	3600	2131	L80	B10	60000	Documentation: BLIZ OVAL - 070710

Sources

LED

24 W
