BLIZ ROUND

IN
  • Ceiling- and wall- mount series. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free precision die-cast aluminum housing and ring/faceplate.
  • - High transmittance, internally coated, pressed glass diffuser, thermally, and chemically quenched to strengthen the impact resistance and reduce the effect of rapid temperature changes.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Custom MCPCB utilized to maximize heat dissipation and promote a long LED life.
  • - 100% uniform diffused light emission.
  • - Input voltage: 120-277 V (50 / 60 Hz), integral 0-10 V dimming driver.
  • - Optional, integral, high-frequency motion-sensor operating at a frequency of 5.8 GHz +/- 75 MHz (HF versions).
  • - Optional, integral, emergency battery-pack designed for a minimum operation of 90 minutes (EMPK versions).
  • - Five optional finishes available. Add finish suffix to any part number for textured Black (BK-81), Iron gray (AN96-96), Aluminum metallic (GR-94), White (WH-87), Iron rust (RB-10) when not standard.
  • - Consult factory for dimming options, marine-grade, custom finishes (please specify RAL color), and non-cataloged CCT (Kelvin) options including static colors.
  • - Product meets Buy American Act requirements within ARRA.
  • - 5-year warranty.
BLIZ ROUND 30

BLIZ ROUND 30

Symmetric extra wide reflector
  • Ceiling- and wall- mount series. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free precision die-cast aluminum housing and ring/faceplate.
  • - High transmittance, internally coated, pressed glass diffuser, thermally, and chemically quenched to strengthen the impact resistance and reduce the effect of rapid temperature changes.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Custom MCPCB utilized to maximize heat dissipation and promote a long LED life.
  • - 100% uniform diffused light emission.
  • - Input voltage: 120-277 V (50 / 60 Hz), integral 0-10 V dimming driver.
  • - Five optional finishes available. Add finish suffix to any part number for textured Black (BK-81), Iron gray (AN96-96), Aluminum metallic (GR-94), White (WH-87), Iron rust (RB-10) when not standard.
  • - Consult factory for dimming options, marine-grade, custom finishes (please specify RAL color), and non-cataloged CCT (Kelvin) options including static colors.
  • - Product meets Buy American Act requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finish Lampholder Wattage Voltage CRI Kelvin Optic Optic
Beam		 Lightsource
lumen
output		 Luminaire
lumen
output		 L B Lifetime Download
Mid Power LEDS 120-277 V - Dimmable 0-10 V
071433 LED 30 W 120-277 V 80 3000 - - 4236 2178 L80 - 60000 Download

Documentation: BLIZ ROUND 30 - 071433
071434 LED 30 W 120-277 V 80 3000 - - 4236 2178 L80 - 60000 Download

Documentation: BLIZ ROUND 30 - 071434
071435 LED 30 W 120-277 V 80 3000 - - 4236 2178 L80 - 60000 Download

Documentation: BLIZ ROUND 30 - 071435
071436 LED 30 W 120-277 V 80 4000 - - 4539 2343 L80 - 60000 Download

Documentation: BLIZ ROUND 30 - 071436
071437 LED 30 W 120-277 V 80 4000 - - 4539 2343 L80 - 60000 Download

Documentation: BLIZ ROUND 30 - 071437
071438 LED 30 W 120-277 V 80 4000 - - 4539 2343 L80 - 60000 Download

Documentation: BLIZ ROUND 30 - 071438

Sources

LED 30 W
BLIZ ROUND 30 EMPK

BLIZ ROUND 30 EMPK

Symmetric extra wide reflector
  • Ceiling- and wall- mount series. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free precision die-cast aluminum housing and ring/faceplate.
  • - High transmittance, internally coated, pressed glass diffuser, thermally, and chemically quenched to strengthen the impact resistance and reduce the effect of rapid temperature changes.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Custom MCPCB utilized to maximize heat dissipation and promote a long LED life.
  • - 100% uniform diffused light emission.
  • - Input voltage: 120-277 V (50 / 60 Hz), integral 0-10 V dimming driver.
  • - Integral, emergency battery-pack designed for a minimum operation of 90 minutes (EMPK versions).
  • - Five optional finishes available. Add finish suffix to any part number for textured Black (BK-81), Iron gray (AN96-96), Aluminum metallic (GR-94), White (WH-87), Iron rust (RB-10) when not standard.
  • - Consult factory for dimming options, marine-grade, custom finishes (please specify RAL color), and non-cataloged CCT (Kelvin) options including static colors.
  • - Product meets Buy American Act requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finish Lampholder Wattage Voltage CRI Kelvin Optic Optic
Beam		 Lightsource
lumen
output		 Luminaire
lumen
output		 L B Lifetime Download
Mid Power LEDS 120-277 V - EMPK - Dimmable 0-10 V
071439 LED 30 W 120-277 V 80 3000 - - 4236 2178 L80 - 60000 Download

Documentation: BLIZ ROUND 30 EMPK - 071439
071440 LED 30 W 120-277 V 80 3000 - - 4236 2178 L80 - 60000 Download

Documentation: BLIZ ROUND 30 EMPK - 071440
071441 LED 30 W 120-277 V 80 3000 - - 4236 2178 L80 - 60000 Download

Documentation: BLIZ ROUND 30 EMPK - 071441
071442 LED 30 W 120-277 V 80 4000 - - 4539 2343 L80 - 60000 Download

Documentation: BLIZ ROUND 30 EMPK - 071442
071443 LED 30 W 120-277 V 80 4000 - - 4539 2343 L80 - 60000 Download

Documentation: BLIZ ROUND 30 EMPK - 071443
071444 LED 30 W 120-277 V 80 4000 - - 4539 2343 L80 - 60000 Download

Documentation: BLIZ ROUND 30 EMPK - 071444

Sources

LED 30 W
BLIZ ROUND 30 HF

BLIZ ROUND 30 HF

Symmetric extra wide reflector
  • Ceiling- and wall- mount series. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free precision die-cast aluminum housing and ring/faceplate.
  • - High transmittance, internally coated, pressed glass diffuser, thermally, and chemically quenched to strengthen the impact resistance and reduce the effect of rapid temperature changes.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Custom MCPCB utilized to maximize heat dissipation and promote a long LED life.
  • - 100% uniform diffused light emission.
  • - Input voltage: 120-277 V (50 / 60 Hz), integral 0-10 V dimming driver.
  • - Integral, high-frequency motion-sensor operating at a frequency of 5.8 GHz +/- 75 MHz (HF versions).
  • - Five optional finishes available. Add finish suffix to any part number for textured Black (BK-81), Iron gray (AN96-96), Aluminum metallic (GR-94), White (WH-87), Iron rust (RB-10) when not standard.
  • - Consult factory for dimming options, marine-grade, custom finishes (please specify RAL color), and non-cataloged CCT (Kelvin) options including static colors.
  • - Product meets Buy American Act requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finish Lampholder Wattage Voltage CRI Kelvin Optic Optic
Beam		 Lightsource
lumen
output		 Luminaire
lumen
output		 L B Lifetime Download
Mid Power LEDS 120-277 V - Dimmable 0-10 V
071445 LED 30 W 120-277 V 80 3000 - - 4236 2178 L80 - 60000 Download

Documentation: BLIZ ROUND 30 HF - 071445
071446 LED 30 W 120-277 V 80 3000 - - 4236 2178 L80 - 60000 Download

Documentation: BLIZ ROUND 30 HF - 071446
071447 LED 30 W 120-277 V 80 3000 - - 4236 2178 L80 - 60000 Download

Documentation: BLIZ ROUND 30 HF - 071447
071448 LED 30 W 120-277 V 80 4000 - - 4539 2343 L80 - 60000 Download

Documentation: BLIZ ROUND 30 HF - 071448
071449 LED 30 W 120-277 V 80 4000 - - 4539 2343 L80 - 60000 Download

Documentation: BLIZ ROUND 30 HF - 071449
071450 LED 30 W 120-277 V 80 4000 - - 4539 2343 L80 - 60000 Download

Documentation: BLIZ ROUND 30 HF - 071450

Sources

LED 30 W
BLIZ ROUND 40

BLIZ ROUND 40

Symmetric extra wide reflector
  • Ceiling- and wall- mount series. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free precision die-cast aluminum housing and ring/faceplate.
  • - High transmittance, internally coated, pressed glass diffuser, thermally, and chemically quenched to strengthen the impact resistance and reduce the effect of rapid temperature changes.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Custom MCPCB utilized to maximize heat dissipation and promote a long LED life.
  • - 100% uniform diffused light emission.
  • - Input voltage: 120-277 V (50 / 60 Hz), integral 0-10 V dimming driver.
  • - Five optional finishes available. Add finish suffix to any part number for textured Black (BK-81), Iron gray (AN96-96), Aluminum metallic (GR-94), White (WH-87), Iron rust (RB-10) when not standard.
  • - Consult factory for dimming options, marine-grade, custom finishes (please specify RAL color), and non-cataloged CCT (Kelvin) options including static colors.
  • - Product meets Buy American Act requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finish Lampholder Wattage Voltage CRI Kelvin Optic Optic
Beam		 Lightsource
lumen
output		 Luminaire
lumen
output		 L B Lifetime Download
Mid Power LEDS 120-277 V - Dimmable 0-10 V
071451 LED 40 W 120-277 V 80 3000 - - 5100 2739 L80 - 60000 Download

Documentation: BLIZ ROUND 40 - 071451
071452 LED 40 W 120-277 V 80 3000 - - 5100 2739 L80 - 60000 Download

Documentation: BLIZ ROUND 40 - 071452
071453 LED 40 W 120-277 V 80 3000 - - 5100 2739 L80 - 60000 Download

Documentation: BLIZ ROUND 40 - 071453
071454 LED 40 W 120-277 V 80 4000 - - 5395 2912 L80 - 60000 Download

Documentation: BLIZ ROUND 40 - 071454
071455 LED 40 W 120-277 V 80 4000 - - 5395 2912 L80 - 60000 Download

Documentation: BLIZ ROUND 40 - 071455
071456 LED 40 W 120-277 V 80 4000 - - 5395 2912 L80 - 60000 Download

Documentation: BLIZ ROUND 40 - 071456

Sources

LED 40 W
BLIZ ROUND 40 EMPK

BLIZ ROUND 40 EMPK

Symmetric extra wide reflector
  • Ceiling- and wall- mount series. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free precision die-cast aluminum housing and ring/faceplate.
  • - High transmittance, internally coated, pressed glass diffuser, thermally, and chemically quenched to strengthen the impact resistance and reduce the effect of rapid temperature changes.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Custom MCPCB utilized to maximize heat dissipation and promote a long LED life.
  • - 100% uniform diffused light emission.
  • - Input voltage: 120-277 V (50 / 60 Hz), integral 0-10 V dimming driver.
  • - Integral, emergency battery-pack designed for a minimum operation of 90 minutes (EMPK versions).
  • - Five optional finishes available. Add finish suffix to any part number for textured Black (BK-81), Iron gray (AN96-96), Aluminum metallic (GR-94), White (WH-87), Iron rust (RB-10) when not standard.
  • - Consult factory for dimming options, marine-grade, custom finishes (please specify RAL color), and non-cataloged CCT (Kelvin) options including static colors.
  • - Product meets Buy American Act requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finish Lampholder Wattage Voltage CRI Kelvin Optic Optic
Beam		 Lightsource
lumen
output		 Luminaire
lumen
output		 L B Lifetime Download
Mid Power LEDS 120-277 V - EMPK - Dimmable 0-10 V
071457 LED 40 W 120-277 V 80 3000 - - 5100 2475 L80 - 60000 Download

Documentation: BLIZ ROUND 40 EMPK - 071457
071458 LED 40 W 120-277 V 80 3000 - - 5100 2475 L80 - 60000 Download

Documentation: BLIZ ROUND 40 EMPK - 071458
071459 LED 40 W 120-277 V 80 3000 - - 5100 2475 L80 - 60000 Download

Documentation: BLIZ ROUND 40 EMPK - 071459
071460 LED 40 W 120-277 V 80 4000 - - 5395 2631 L80 - 60000 Download

Documentation: BLIZ ROUND 40 EMPK - 071460
071461 LED 40 W 120-277 V 80 4000 - - 5395 2631 L80 - 60000 Download

Documentation: BLIZ ROUND 40 EMPK - 071461
071462 LED 40 W 120-277 V 80 4000 - - 5395 2631 L80 - 60000 Download

Documentation: BLIZ ROUND 40 EMPK - 071462

Sources

LED 40 W
BLIZ ROUND 40 HF

BLIZ ROUND 40 HF

Symmetric extra wide reflector
  • Ceiling- and wall- mount series. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free precision die-cast aluminum housing and ring/faceplate.
  • - High transmittance, internally coated, pressed glass diffuser, thermally, and chemically quenched to strengthen the impact resistance and reduce the effect of rapid temperature changes.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Custom MCPCB utilized to maximize heat dissipation and promote a long LED life.
  • - 100% uniform diffused light emission.
  • - Input voltage: 120-277 V (50 / 60 Hz), integral 0-10 V dimming driver.
  • - Integral, high-frequency motion-sensor operating at a frequency of 5.8 GHz +/- 75 MHz (HF versions).
  • - Five optional finishes available. Add finish suffix to any part number for textured Black (BK-81), Iron gray (AN96-96), Aluminum metallic (GR-94), White (WH-87), Iron rust (RB-10) when not standard.
  • - Consult factory for dimming options, marine-grade, custom finishes (please specify RAL color), and non-cataloged CCT (Kelvin) options including static colors.
  • - Product meets Buy American Act requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finish Lampholder Wattage Voltage CRI Kelvin Optic Optic
Beam		 Lightsource
lumen
output		 Luminaire
lumen
output		 L B Lifetime Download
Mid Power LEDS 120-277 V - Dimmable 0-10 V
071463 LED 40 W 120-277 V 80 3000 - - 5100 2739 L80 - 60000 Download

Documentation: BLIZ ROUND 40 HF - 071463
071464 LED 40 W 120-277 V 80 3000 - - 5100 2739 L80 - 60000 Download

Documentation: BLIZ ROUND 40 HF - 071464
071465 LED 40 W 120-277 V 80 3000 - - 5100 2739 L80 - 60000 Download

Documentation: BLIZ ROUND 40 HF - 071465
071466 LED 40 W 120-277 V 80 4000 - - 5395 2912 L80 - 60000 Download

Documentation: BLIZ ROUND 40 HF - 071466
071467 LED 40 W 120-277 V 80 4000 - - 5395 2912 L80 - 60000 Download

Documentation: BLIZ ROUND 40 HF - 071467
071468 LED 40 W 120-277 V 80 4000 - - 5395 2912 L80 - 60000 Download

Documentation: BLIZ ROUND 40 HF - 071468

Sources

LED 40 W

Product Family

BLIZ SQUARE 40 BLIZ SQUARE 40
BLIZ BLIZ
to top
Request information
Products search
You can search for products in our catalog by entering here the name or the code of the product or accessory.
I cookie ci aiutano a fornire i nostri servizi. Utilizzando tali servizi, accetti l'utilizzo dei cookie da parte nostra. Info
