BLIZ SQUARE 40

  • Ceiling- and wall- mount series. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free (<1%) die-cast aluminum housing, ring, and faceplates.
  • - High transmittance, internally coated, pressed glass diffuser, thermally, and chemically quenched to strengthen the impact resistance and reduce the effect of rapid temperature changes.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Custom MCPCB utilized to maximize heat dissipation and promote long LED life.
  • - 100% uniform diffused light emission.
  • - Input voltage: 120-277 V (50 / 60 Hz), integral 0-10 V dimming driver.
  • - Optional, integral, high-frequency motion-sensor operating at a frequency of 5.8 GHz +/- 75 MHz (HF versions). Standard daylight Photocell function for ROUND and SQUARE options.
  • - Optional, integral, emergency battery-pack designed for a minimum operation of 90 minutes (EMPK versions).
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Product meets Buy American Act (BAA) requirements within ARRA.
  • - 5-year warranty.
BLIZ SQUARE 40

BLIZ SQUARE 40

Optic | Symmetric Extra-Wide
  • Ceiling- and wall- mount series. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free (<1%) precision die-cast aluminum housing and ring/faceplate.
  • - High transmittance, internally coated, pressed glass diffuser, thermally, and chemically quenched to strengthen the impact resistance and reduce the effect of rapid temperature changes.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Custom MCPCB utilized to maximize heat dissipation and promote long LED life.
  • - 100% uniform diffused light emission.
  • - Input voltage: 120-277 V (50 / 60 Hz), integral 0-10 V dimming driver.
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Product meets Buy American Act (BAA) requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finishing Lampholder Wattage Voltage CRI Kelvin Optic Beam
angle		 Lightsource
lumen
output
[lm]		 Luminaire
lumen
output
[lm]		 L B Lifetime Downloads
Mid Power LEDS 120-277 V Dimmable 0-10 V
071645 LED 40 W 120/277 V 80 3000 - - 6732 2515 L80 B10 60000 Download

Documentation: BLIZ SQUARE 40 - 071645
071646 LED 40 W 120/277 V 80 3000 - - 6732 2515 L80 B10 60000 Download

Documentation: BLIZ SQUARE 40 - 071646
071647 LED 40 W 120/277 V 80 3000 - - 6732 2515 L80 B10 60000 Download

Documentation: BLIZ SQUARE 40 - 071647
071648 LED 40 W 120/277 V 80 4000 - - 6732 2495 L80 B10 60000 Download

Documentation: BLIZ SQUARE 40 - 071648
071649 LED 40 W 120/277 V 80 4000 - - 6732 2495 L80 B10 60000 Download

Documentation: BLIZ SQUARE 40 - 071649
071650 LED 40 W 120/277 V 80 4000 - - 6732 2495 L80 B10 60000 Download

Documentation: BLIZ SQUARE 40 - 071650

Sources

LED 40 W
BLIZ SQUARE 40 EMPK

BLIZ SQUARE 40 EMPK

Optic | Symmetric Extra-Wide
  • Ceiling- and wall- mount series. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free (<1%) precision die-cast aluminum housing and ring/faceplate.
  • - High transmittance, internally coated, pressed glass diffuser, thermally, and chemically quenched to strengthen the impact resistance and reduce the effect of rapid temperature changes.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Custom MCPCB utilized to maximize heat dissipation and promote long LED life.
  • - 100% uniform diffused light emission.
  • - Input voltage: 120-277 V (50 / 60 Hz), integral 0-10 V dimming driver.
  • - Integral, emergency battery-pack designed for a minimum operation of 90 minutes (EMPK versions).
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Product meets Buy American Act (BAA) requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finishing Lampholder Wattage Voltage CRI Kelvin Optic Beam
angle		 Lightsource
lumen
output
[lm]		 Luminaire
lumen
output
[lm]		 L B Lifetime Downloads
Mid Power LEDS 120-277 V - EMPK Dimmable 0-10 V
071652 LED 44 W 120/277 V 80 3000 - - 6732 2340 L80 B10 60000 Download

Documentation: BLIZ SQUARE 40 EMPK - 071652
071654 LED 44 W 120/277 V 80 3000 - - 6732 2340 L80 B10 60000 Download

Documentation: BLIZ SQUARE 40 EMPK - 071654
071656 LED 44 W 120/277 V 80 3000 - - 6732 2340 L80 B10 60000 Download

Documentation: BLIZ SQUARE 40 EMPK - 071656
071658 LED 44 W 120/277 V 80 4000 - - 6732 2322 L80 B10 60000 Download

Documentation: BLIZ SQUARE 40 EMPK - 071658
071660 LED 44 W 120/277 V 80 4000 - - 6732 2322 L80 B10 60000 Download

Documentation: BLIZ SQUARE 40 EMPK - 071660
071662 LED 44 W 120/277 V 80 4000 - - 6732 2322 L80 B10 60000 Download

Documentation: BLIZ SQUARE 40 EMPK - 071662

Sources

LED 44 W
BLIZ SQUARE 40 GRILL

BLIZ SQUARE 40 GRILL

Optic | Symmetric Extra-Wide
  • Ceiling- and wall- mount series. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free (<1%) precision die-cast aluminum housing and ring/faceplate.
  • - High transmittance, internally coated, pressed glass diffuser, thermally, and chemically quenched to strengthen the impact resistance and reduce the effect of rapid temperature changes.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Custom MCPCB utilized to maximize heat dissipation and promote long LED life.
  • - 100% uniform diffused light emission.
  • - Input voltage: 120-277 V (50 / 60 Hz), integral 0-10 V dimming driver.
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Product meets Buy American Act (BAA) requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finishing Lampholder Wattage Voltage CRI Kelvin Optic Beam
angle		 Lightsource
lumen
output
[lm]		 Luminaire
lumen
output
[lm]		 L B Lifetime Downloads
Mid Power LEDS 120-277 V Dimmable 0-10 V
071678 LED 40 W 120/277 V 80 3000 - - 6732 2515 L80 B10 60000 Download

Documentation: BLIZ SQUARE 40 GRILL - 071678
071680 LED 40 W 120/277 V 80 3000 - - 6732 2515 L80 B10 60000 Download

Documentation: BLIZ SQUARE 40 GRILL - 071680
071682 LED 40 W 120/277 V 80 3000 - - 6732 2515 L80 B10 60000 Download

Documentation: BLIZ SQUARE 40 GRILL - 071682
071684 LED 40 W 120/277 V 80 4000 - - 6732 2495 L80 B10 60000 Download

Documentation: BLIZ SQUARE 40 GRILL - 071684
071686 LED 40 W 120/277 V 80 4000 - - 6732 2495 L80 B10 60000 Download

Documentation: BLIZ SQUARE 40 GRILL - 071686
071688 LED 40 W 120/277 V 80 4000 - - 6732 2495 L80 B10 60000 Download

Documentation: BLIZ SQUARE 40 GRILL - 071688

Sources

LED 40 W
BLIZ SQUARE 40 GRILL EMPK

BLIZ SQUARE 40 GRILL EMPK

Optic | Symmetric Extra-Wide
  • Ceiling- and wall- mount series. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free (<1%) precision die-cast aluminum housing and ring/faceplate.
  • - High transmittance, internally coated, pressed glass diffuser, thermally, and chemically quenched to strengthen the impact resistance and reduce the effect of rapid temperature changes.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Custom MCPCB utilized to maximize heat dissipation and promote long LED life.
  • - 100% uniform diffused light emission.
  • - Input voltage: 120-277 V (50 / 60 Hz), integral 0-10 V dimming driver.
  • - Integral, emergency battery-pack designed for a minimum operation of 90 minutes (EMPK versions).
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Product meets Buy American Act (BAA) requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finishing Lampholder Wattage Voltage CRI Kelvin Optic Beam
angle		 Lightsource
lumen
output
[lm]		 Luminaire
lumen
output
[lm]		 L B Lifetime Downloads
Mid Power LEDS 120-277 V - EMPK Dimmable 0-10 V
071690 LED 44 W 120/277 V 80 3000 - - 6732 2340 L80 B10 60000 Download

Documentation: BLIZ SQUARE 40 GRILL EMPK - 071690
071692 LED 44 W 120/277 V 80 3000 - - 6732 2340 L80 B10 60000 Download

Documentation: BLIZ SQUARE 40 GRILL EMPK - 071692
071694 LED 44 W 120/277 V 80 3000 - - 6732 2340 L80 B10 60000 Download

Documentation: BLIZ SQUARE 40 GRILL EMPK - 071694
071696 LED 44 W 120/277 V 80 4000 - - 6732 2322 L80 B10 60000 Download

Documentation: BLIZ SQUARE 40 GRILL EMPK - 071696
071698 LED 44 W 120/277 V 80 4000 - - 6732 2322 L80 B10 60000 Download

Documentation: BLIZ SQUARE 40 GRILL EMPK - 071698
071700 LED 44 W 120/277 V 80 4000 - - 6732 2322 L80 B10 60000 Download

Documentation: BLIZ SQUARE 40 GRILL EMPK - 071700

Sources

LED 44 W
BLIZ SQUARE 40 GRILL HF

BLIZ SQUARE 40 GRILL HF

Optic | Symmetric Extra-Wide
  • Ceiling- and wall- mount series. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free (<1%) precision die-cast aluminum housing and ring/faceplate.
  • - High transmittance, internally coated, pressed glass diffuser, thermally, and chemically quenched to strengthen the impact resistance and reduce the effect of rapid temperature changes.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Custom MCPCB utilized to maximize heat dissipation and promote long LED life.
  • - 100% uniform diffused light emission.
  • - Input voltage: 120-277 V (50 / 60 Hz), integral 0-10 V dimming driver.
  • - Integral, high-frequency motion-sensor operating at a frequency of 5.8 GHz +/- 75 MHz (HF versions).
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Product meets Buy American Act (BAA) requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finishing Lampholder Wattage Voltage CRI Kelvin Optic Beam
angle		 Lightsource
lumen
output
[lm]		 Luminaire
lumen
output
[lm]		 L B Lifetime Downloads
Mid Power LEDS 120-277 V Dimmable 0-10 V
071702 LED 40 W 120/277 V 80 3000 - - 6732 2515 L80 B10 60000 Download

Documentation: BLIZ SQUARE 40 GRILL HF - 071702
071704 LED 40 W 120/277 V 80 3000 - - 6732 2515 L80 B10 60000 Download

Documentation: BLIZ SQUARE 40 GRILL HF - 071704
071712 LED 40 W 120/277 V 80 3000 - - 6732 2515 L80 B10 60000 Download

Documentation: BLIZ SQUARE 40 GRILL HF - 071712
071714 LED 40 W 120/277 V 80 4000 - - 6732 2495 L80 B10 60000 Download

Documentation: BLIZ SQUARE 40 GRILL HF - 071714
071719 LED 40 W 120/277 V 80 4000 - - 6732 2495 L80 B10 60000 Download

Documentation: BLIZ SQUARE 40 GRILL HF - 071719
071721 LED 40 W 120/277 V 80 4000 - - 6732 2495 L80 B10 60000 Download

Documentation: BLIZ SQUARE 40 GRILL HF - 071721

Sources

LED 40 W
BLIZ SQUARE 40 HF

BLIZ SQUARE 40 HF

Optic | Symmetric Extra-Wide
  • Ceiling- and wall- mount series. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free (<1%) precision die-cast aluminum housing and ring/faceplate.
  • - High transmittance, internally coated, pressed glass diffuser, thermally, and chemically quenched to strengthen the impact resistance and reduce the effect of rapid temperature changes.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Custom MCPCB utilized to maximize heat dissipation and promote long LED life.
  • - 100% uniform diffused light emission.
  • - Input voltage: 120-277 V (50 / 60 Hz), integral 0-10 V dimming driver.
  • - Integral, high-frequency motion-sensor operating at a frequency of 5.8 GHz +/- 75 MHz (HF versions).
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Product meets Buy American Act (BAA) requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finishing Lampholder Wattage Voltage CRI Kelvin Optic Beam
angle		 Lightsource
lumen
output
[lm]		 Luminaire
lumen
output
[lm]		 L B Lifetime Downloads
Mid Power LEDS 120-277 V Dimmable 0-10 V
071664 LED 40 W 120/277 V 80 3000 - - 6732 2515 L80 B10 60000 Download

Documentation: BLIZ SQUARE 40 HF - 071664
071666 LED 40 W 120/277 V 80 3000 - - 6732 2515 L80 B10 60000 Download

Documentation: BLIZ SQUARE 40 HF - 071666
071670 LED 40 W 120/277 V 80 3000 - - 6732 2515 L80 B10 60000 Download

Documentation: BLIZ SQUARE 40 HF - 071670
071672 LED 40 W 120/277 V 80 4000 - - 6732 2495 L80 B10 60000 Download

Documentation: BLIZ SQUARE 40 HF - 071672
071674 LED 40 W 120/277 V 80 4000 - - 6732 2495 L80 B10 60000 Download

Documentation: BLIZ SQUARE 40 HF - 071674
071676 LED 40 W 120/277 V 80 4000 - - 6732 2495 L80 B10 60000 Download

Documentation: BLIZ SQUARE 40 HF - 071676

Sources

LED 40 W

Product Family

BLIZ ROUND BLIZ ROUND
BLIZ BLIZ
BLIZ OVAL BLIZ OVAL
BLIZ ROUND CROSS BLIZ ROUND CROSS
BLIZ BOLLARD BLIZ BOLLARD
to top
Request information
Products search
You can search for products in our catalog by entering here the name or the code of the product or accessory.
