BLIZ

IN
BLIZ

BLIZ

SYMMETRIC EXTRA WIDE REFLECTOR
  • Surface-mount doorway and hallway lights and post mount series. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free die-cast aluminum housing, trim and faceplates.
  • - Copper-free aluminum extruded post.
  • - High transmittance, internally coated, soda-lime pressed glass diffuser, thermally and chemically quenched to strenghen the impact resistance and reduce the affect of rapid temperature changes.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Custom MCPCB utilized to maximize heat dissipation and promote a long LED life.
  • - Tiltable LED board mounting bracket allows for quick and easy installation.
  • - 100% uniform diffused light emission.
  • - Input voltage: 120-277 V (50 / 60 Hz), integral 0-10 V dimming driver.
  • - Consult factory for dimming options, custom finishes and non-cataloged CCT (Kelvin) options.
  • - Consult factory for custom signage options.
  • - Product meets Buy American requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finish Lampholder Wattage Voltage CRI Kelvin Optic Optic
Beam
Lightsource
lumen
output
Luminaire
lumen
output
L B Lifetime Download
MID POWER LEDS 120-277 V DIMMABLE 0-10V
070284 LED 19.5 W 120-277V 80 3000 - - 2100 995 L80 B10 60000 Download

Documentation: BLIZ - 070284

070285 LED 19.5 W 120-277V 80 3000 - - 2100 995 L80 B10 60000 Download

Documentation: BLIZ - 070285

070286 LED 19.5 W 120-277V 80 4000 - - 2200 1040 L80 B10 60000 Download

Documentation: BLIZ - 070286

070287 LED 19.5 W 120-277V 80 4000 - - 2200 1040 L80 B10 60000 Download

Documentation: BLIZ - 070287

Sources

LED 19.5 W
BLIZ GUARD

BLIZ GUARD

SYMMETRIC EXTRA WIDE REFLECTOR
  • Surface-mount doorway and hallway lights and post mount series. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free die-cast aluminum housing, trim and faceplates.
  • - Copper-free aluminum extruded post.
  • - High transmittance, internally coated, soda-lime pressed glass diffuser, thermally and chemically quenched to strenghen the impact resistance and reduce the affect of rapid temperature changes.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Custom MCPCB utilized to maximize heat dissipation and promote a long LED life.
  • - Tiltable LED board mounting bracket allows for quick and easy installation.
  • - 100% uniform diffused light emission.
  • - Input voltage: 120-277 V (50 / 60 Hz), integral 0-10 V dimming driver.
  • - Consult factory for dimming options, custom finishes and non-cataloged CCT (Kelvin) options.
  • - Consult factory for custom signage options.
  • - Product meets Buy American requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finish Lampholder Wattage Voltage CRI Kelvin Optic Optic
Beam
Lightsource
lumen
output
Luminaire
lumen
output
L B Lifetime Download
MID POWER LEDS 120-277 V DIMMABLE 0-10V
070288 LED 19.5 W 120-277V 80 3000 - - 2100 667 L80 B10 60000 Download

Documentation: BLIZ GUARD - 070288

070289 LED 19.5 W 120-277V 80 3000 - - 2100 667 L80 B10 60000 Download

Documentation: BLIZ GUARD - 070289

070290 LED 19.5 W 120-277V 80 4000 - - 2200 698 L80 B10 60000 Download

Documentation: BLIZ GUARD - 070290

070291 LED 19.5 W 120-277V 80 4000 - - 2200 698 L80 B10 60000 Download

Documentation: BLIZ GUARD - 070291

Sources

LED 19.5 W
BLIZ VISA

BLIZ VISA

SYMMETRIC EXTRA WIDE REFLECTOR
  • Surface-mount doorway and hallway lights and post mount series. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free die-cast aluminum housing, trim and faceplates.
  • - Copper-free aluminum extruded post.
  • - High transmittance, internally coated, soda-lime pressed glass diffuser, thermally and chemically quenched to strenghen the impact resistance and reduce the affect of rapid temperature changes.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Custom MCPCB utilized to maximize heat dissipation and promote a long LED life.
  • - Tiltable LED board mounting bracket allows for quick and easy installation.
  • - 100% uniform diffused light emission.
  • - Input voltage: 120-277 V (50 / 60 Hz), integral 0-10 V dimming driver.
  • - Consult factory for dimming options, custom finishes and non-cataloged CCT (Kelvin) options.
  • - Consult factory for custom signage options.
  • - Product meets Buy American requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finish Lampholder Wattage Voltage CRI Kelvin Optic Optic
Beam
Lightsource
lumen
output
Luminaire
lumen
output
L B Lifetime Download
MID POWER LEDS 120-277 V DIMMABLE 0-10V
070292 LED 19.5 W 120-277V 80 3000 - - 2100 607 L80 B10 60000 Download

Documentation: BLIZ VISA - 070292

070293 LED 19.5 W 120-277V 80 3000 - - 2100 607 L80 B10 60000 Download

Documentation: BLIZ VISA - 070293

070294 LED 19.5 W 120-277V 80 4000 - - 2200 635 L80 B10 60000 Download

Documentation: BLIZ VISA - 070294

070295 LED 19.5 W 120-277V 80 4000 - - 2200 635 L80 B10 60000 Download

Documentation: BLIZ VISA - 070295

Sources

LED 19.5 W
BLIZ VISA V

BLIZ VISA V

SYMMETRIC EXTRA WIDE REFLECTOR
  • Surface-mount doorway and hallway lights and post mount series. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free die-cast aluminum housing, trim and faceplates.
  • - Copper-free aluminum extruded post.
  • - High transmittance, internally coated, soda-lime pressed glass diffuser, thermally and chemically quenched to strenghen the impact resistance and reduce the affect of rapid temperature changes.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Custom MCPCB utilized to maximize heat dissipation and promote a long LED life.
  • - Tiltable LED board mounting bracket allows for quick and easy installation.
  • - 100% uniform diffused light emission.
  • - Input voltage: 120-277 V (50 / 60 Hz), integral 0-10 V dimming driver.
  • - Consult factory for dimming options, custom finishes and non-cataloged CCT (Kelvin) options.
  • - Consult factory for custom signage options.
  • - Product meets Buy American requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finish Lampholder Wattage Voltage CRI Kelvin Optic Optic
Beam
Lightsource
lumen
output
Luminaire
lumen
output
L B Lifetime Download
MID POWER LEDS 120-277 V DIMMABLE 0-10V
070296 LED 19.5 W 120-277V 80 3000 - - 2100 654 L80 B10 60000 Download

Documentation: BLIZ VISA V - 070296

070297 LED 19.5 W 120-277V 80 3000 - - 2100 654 L80 B10 60000 Download

Documentation: BLIZ VISA V - 070297

070298 LED 19.5 W 120-277V 80 4000 - - 2200 684 L80 B10 60000 Download

Documentation: BLIZ VISA V - 070298

070299 LED 19.5 W 120-277V 80 4000 - - 2200 684 L80 B10 60000 Download

Documentation: BLIZ VISA V - 070299

Sources

LED 19.5 W
