NIKKO+27 LA

Surface-mount doorway and hallway lights and post mount series. Fixtures consist of:
- Multi-step powder-coat painting process, optimized against UV rays and corrosion.
- Copper-free (<1%) die-cast aluminum housing, ring, and faceplates.
- High transmittance, internally coated, pressed glass diffuser, thermally, and chemically quenched to strengthen the impact resistance and reduce the effect of rapid temperature changes.
- Custom molded, anti-aging gasket(s).
- Stainless steel external hardware.
- High-efficiency COB, combined with an optimized passive cooling system, provides a long LED life.
- 100% uniform diffused light emission.
- Input voltage: 120-277 V (50 / 60 Hz), integral driver.
- The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
- Wall bracket and post accessories available (ordered separately).
- 5-year warranty.
- Product meets Buy American Act (BAA) requirements within ARRA.

Optic | Symmetric Extra-Wide

Surface-mount doorway and hallway lights and post mount series. Fixtures consist of:
- Multi-step powder-coat painting process, optimized against UV rays and corrosion.
- Copper-free (<1%) die-cast aluminum housing, ring, and faceplates.
- High transmittance, internally coated, pressed glass diffuser, thermally, and chemically quenched to strengthen the impact resistance and reduce the effect of rapid temperature changes.
- Custom molded, anti-aging gasket(s).
- Stainless steel external hardware.
- High-efficiency COB, combined with an optimized passive cooling system, provides a long LED life.
- 100% uniform diffused light emission.
- Input voltage: 120-277 V (50 / 60 Hz), integral driver.
- The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
- Wall bracket and post accessories available (ordered separately).
- 5-year warranty.
- Product meets Buy American Act (BAA) requirements within ARRA.

Product codes

Part number	Lampholder	Wattage	Voltage	CRI	Kelvin	Optic	Beam angle	Lightsource lumen output [lm]	Luminaire lumen output [lm]	L	B	Lifetime	Downloads
070620	E26	1x100 W	120/277 V	-	-	-	-	-	-	-	-	-	Documentation: NIKKO+27 LA - 070620
070621	E26	1x100 W	120/277 V	-	-	-	-	-	-	-	-	-	Documentation: NIKKO+27 LA - 070621
High Power LEDS 120-277 V
070616	LED	22 W	120/277 V	80	3000	-	-	2237	1203	L80	B10	94000	Documentation: NIKKO+27 LA - 070616
070617	LED	22 W	120/277 V	80	4000	-	-	2310	1271	L80	B10	94000	Documentation: NIKKO+27 LA - 070617
070618	LED	22 W	120/277 V	80	3000	-	-	2237	1203	L80	B10	94000	Documentation: NIKKO+27 LA - 070618
070619	LED	22 W	120/277 V	80	4000	-	-	2310	1271	L80	B10	94000	Documentation: NIKKO+27 LA - 070619

Sources

E26	1x100 W
LED	22 W
