NIKKO+21

IN
  • Surface-mount doorway and hallway lights and post mount series. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free die-cast aluminum housing, ring, and faceplates.
  • - Copper-free aluminum extruded post.
  • - High transmittance, internally coated, soda-lime pressed glass diffuser, thermally and chemically quenched to strengthen the impact resistance and reduce the effect of rapid temperature changes.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - High-efficiency COB, combined with an optimized passive cooling system, provides a long LED life.
  • - 100% uniform diffused light emission.
  • - Input voltage: 120-277 V (50 / 60 Hz), integral driver.
  • - Consult factory for dimming options, custom finishes, and non-cataloged CCT (Kelvin) options.
  • - Wall bracket and post accessories available (ordered separately).
  • - 5-year warranty.
  • - Product meets Buy American Act requirements within ARRA.
NIKKO+21 LED

NIKKO+21 LED

SYMMETRIC EXTRA WIDE REFLECTOR
  • Surface-mount doorway and hallway lights and post mount series. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free die-cast aluminum housing, ring, and faceplates.
  • - Copper-free aluminum extruded post.
  • - High transmittance, internally coated, soda-lime pressed glass diffuser, thermally and chemically quenched to strengthen the impact resistance and reduce the effect of rapid temperature changes.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - High-efficiency COB, combined with an optimized passive cooling system, provides a long LED life.
  • - 100% uniform diffused light emission.
  • - Input voltage: 120-277 V (50 / 60 Hz), integral driver.
  • - Wall bracket and post accessories available (ordered separately).
  • - Consult factory for dimming options, custom finishes, and non-cataloged CCT (Kelvin) options.
  • - 5-year warranty.
  • - Product meets Buy American Act requirements within ARRA.
Product codes
Part number Finish Lampholder Wattage Voltage CRI Kelvin Optic Optic
Beam
Lightsource
lumen
output
Luminaire
lumen
output
L B Lifetime Download
High Power LEDS 120-277 V
079556 LED 11 W 120-277 V - 3000 - - 1278 424 L80 - 50000 Download

Documentation: NIKKO+21 LED - 079556

079558 LED 11 W 120-277 V - 3000 - - 1278 424 L80 - 50000 Download

Documentation: NIKKO+21 LED - 079558

079560 LED 11 W 120-277 V - 3000 - - 1278 424 L80 - 50000 Download

Documentation: NIKKO+21 LED - 079560

079562 LED 11 W 120-277 V - 3000 - - 1278 424 L80 - 50000 Download

Documentation: NIKKO+21 LED - 079562

079580 LED 11 W 120-277 V - 4000 - - 1320 571 L80 - 50000 Download

Documentation: NIKKO+21 LED - 079580

079582 LED 11 W 120-277 V - 4000 - - 1320 571 L80 - 50000 Download

Documentation: NIKKO+21 LED - 079582

079584 LED 11 W 120-277 V - 4000 - - 1320 571 L80 - 50000 Download

Documentation: NIKKO+21 LED - 079584

079586 LED 11 W 120-277 V - 4000 - - 1320 571 L80 - 50000 Download

Documentation: NIKKO+21 LED - 079586

Sources

LED 11 W
NIKKO+21/G LED

NIKKO+21/G LED

SYMMETRIC EXTRA WIDE REFLECTOR
  • Surface-mount doorway and hallway lights and post mount series. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free die-cast aluminum housing, ring, and faceplates.
  • - Copper-free aluminum extruded post.
  • - High transmittance, internally coated, soda-lime pressed glass diffuser, thermally and chemically quenched to strengthen the impact resistance and reduce the effect of rapid temperature changes.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - High-efficiency COB, combined with an optimized passive cooling system, provides a long LED life.
  • - 100% uniform diffused light emission.
  • - Input voltage: 120-277 V (50 / 60 Hz), integral driver.
  • - Wall bracket and post accessories available (ordered separately).
  • - Consult factory for dimming options, custom finishes, and non-cataloged CCT (Kelvin) options.
  • - 5-year warranty.
  • - Product meets Buy American Act requirements within ARRA.
Product codes
Part number Finish Lampholder Wattage Voltage CRI Kelvin Optic Optic
Beam
Lightsource
lumen
output
Luminaire
lumen
output
L B Lifetime Download
High Power LEDS 120-277 V
079564 LED 11 W 120-277 V - 3000 - - 1278 234 L80 - 50000 Download

Documentation: NIKKO+21/G LED - 079564

079566 LED 11 W 120-277 V - 3000 - - 1278 234 L80 - 50000 Download

Documentation: NIKKO+21/G LED - 079566

079568 LED 11 W 120-277 V - 3000 - - 1278 234 L80 - 50000 Download

Documentation: NIKKO+21/G LED - 079568

079570 LED 11 W 120-277 V - 3000 - - 1278 234 L80 - 50000 Download

Documentation: NIKKO+21/G LED - 079570

079588 LED 11 W 120-277 V - 4000 - - 1320 316 L80 - 50000 Download

Documentation: NIKKO+21/G LED - 079588

079590 LED 11 W 120-277 V - 4000 - - 1320 316 L80 - 50000 Download

Documentation: NIKKO+21/G LED - 079590

079592 LED 11 W 120-277 V - 4000 - - 1320 316 L80 - 50000 Download

Documentation: NIKKO+21/G LED - 079592

079594 LED 11 W 120-277 V - 4000 - - 1320 316 L80 - 50000 Download

Documentation: NIKKO+21/G LED - 079594

Sources

LED 11 W
NIKKO+21/V LED

NIKKO+21/V LED

ASYMMETRIC EXTRA WIDE REFLECTOR
  • Surface-mount doorway and hallway lights and post mount series. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free die-cast aluminum housing, ring, and faceplates.
  • - Copper-free aluminum extruded post.
  • - High transmittance, internally coated, soda-lime pressed glass diffuser, thermally and chemically quenched to strengthen the impact resistance and reduce the effect of rapid temperature changes.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - High-efficiency COB, combined with an optimized passive cooling system, provides a long LED life.
  • - 100% uniform diffused light emission.
  • - Input voltage: 120-277 V (50 / 60 Hz), integral driver.
  • - Wall bracket and post accessories available (ordered separately).
  • - Consult factory for dimming options, custom finishes, and non-cataloged CCT (Kelvin) options.
  • - 5-year warranty.
  • - Product meets Buy American Act requirements within ARRA.
Product codes
Part number Finish Lampholder Wattage Voltage CRI Kelvin Optic Optic
Beam
Lightsource
lumen
output
Luminaire
lumen
output
L B Lifetime Download
High Power LEDS 120-277 V
079572 LED 11 W 120-277 V - 3000 - - 1278 208 L80 - 50000 Download

Documentation: NIKKO+21/V LED - 079572

079574 LED 11 W 120-277 V - 3000 - - 1278 208 L80 - 50000 Download

Documentation: NIKKO+21/V LED - 079574

079576 LED 11 W 120-277 V - 3000 - - 1278 208 L80 - 50000 Download

Documentation: NIKKO+21/V LED - 079576

079578 LED 11 W 120-277 V - 3000 - - 1278 208 L80 - 50000 Download

Documentation: NIKKO+21/V LED - 079578

079596 LED 11 W 120-277 V - 4000 - - 1320 277 L80 - 50000 Download

Documentation: NIKKO+21/V LED - 079596

079598 LED 11 W 120-277 V - 4000 - - 1320 277 L80 - 50000 Download

Documentation: NIKKO+21/V LED - 079598

079600 LED 11 W 120-277 V - 4000 - - 1320 277 L80 - 50000 Download

Documentation: NIKKO+21/V LED - 079600

079602 LED 11 W 120-277 V - 4000 - - 1320 277 L80 - 50000 Download

Documentation: NIKKO+21/V LED - 079602

Sources

LED 11 W

Product Family
