NIKKO+27

IN
  • Surface-mount doorway and hallway lights and post mount series. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free (<1%) die-cast aluminum housing, ring, and faceplates.
  • - Copper-free (<1%) aluminum extruded post.
  • - High transmittance, internally coated, pressed glass diffuser, thermally, and chemically quenched to strengthen the impact resistance and reduce the effect of rapid temperature changes.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - High-efficiency COB, combined with an optimized passive cooling system, provides a long LED life.
  • - 100% uniform diffused light emission.
  • - Input voltage: 120-277 V (50 / 60 Hz), integral driver.
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Wall bracket and post accessories available (ordered separately).
  • - 5-year warranty.
  • - Product meets Buy American Act (BAA) requirements within ARRA.
NIKKO+27 LED

NIKKO+27 LED

Optic | Symmetric Extra-Wide
  • Surface-mount doorway and hallway lights and post mount series. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free (<1%) die-cast aluminum housing, ring, and faceplates.
  • - Copper-free (<1%) aluminum extruded post.
  • - High transmittance, internally coated, pressed glass diffuser, thermally, and chemically quenched to strengthen the impact resistance and reduce the effect of rapid temperature changes.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - High-efficiency COB, combined with an optimized passive cooling system, provides a long LED life.
  • - 100% uniform diffused light emission.
  • - Input voltage: 120-277 V (50 / 60 Hz), integral driver.
  • - Wall bracket and post accessories available (ordered separately).
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - 5-year warranty.
  • - Product meets Buy American Act (BAA) requirements within ARRA.
Product codes
Part number Finishing Lampholder Wattage Voltage CRI Kelvin Optic Beam
angle		 Lightsource
lumen
output
[lm]		 Luminaire
lumen
output
[lm]		 L B Lifetime Downloads
High Power LEDS 120-277 V
079210 LED 22 W 120/277 V 80 4000 - - 2310 1309 L80 B10 94000 Download

Documentation: NIKKO+27 LED - 079210
079212 LED 22 W 120/277 V 80 4000 - - 2310 1309 L80 B10 94000 Download

Documentation: NIKKO+27 LED - 079212
079214 LED 22 W 120/277 V 80 4000 - - 2310 1309 L80 B10 94000 Download

Documentation: NIKKO+27 LED - 079214
079216 LED 22 W 120/277 V 80 4000 - - 2310 1309 L80 B10 94000 Download

Documentation: NIKKO+27 LED - 079216
079604 LED 22 W 120/277 V 80 3000 - - 2237 1248 L80 B10 94000 Download

Documentation: NIKKO+27 LED - 079604
079606 LED 22 W 120/277 V 80 3000 - - 2237 1248 L80 B10 94000 Download

Documentation: NIKKO+27 LED - 079606
079608 LED 22 W 120/277 V 80 3000 - - 2237 1248 L80 B10 94000 Download

Documentation: NIKKO+27 LED - 079608
079610 LED 22 W 120/277 V 80 3000 - - 2237 1248 L80 B10 94000 Download

Documentation: NIKKO+27 LED - 079610

Sources

LED 22 W
NIKKO+27/G LED

NIKKO+27/G LED

Optic | Symmetric Extra-Wide
  • Surface-mount doorway and hallway lights and post mount series. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free (<1%) die-cast aluminum housing, ring, and faceplates.
  • - Copper-free (<1%) aluminum extruded post.
  • - High transmittance, internally coated, pressed glass diffuser, thermally, and chemically quenched to strengthen the impact resistance and reduce the effect of rapid temperature changes.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - High-efficiency COB, combined with an optimized passive cooling system, provides a long LED life.
  • - 100% uniform diffused light emission.
  • - Input voltage: 120-277 V (50 / 60 Hz), integral driver.
  • - Wall bracket and post accessories available (ordered separately).
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - 5-year warranty.
  • - Product meets Buy American Act (BAA) requirements within ARRA.
Product codes
Part number Finishing Lampholder Wattage Voltage CRI Kelvin Optic Beam
angle		 Lightsource
lumen
output
[lm]		 Luminaire
lumen
output
[lm]		 L B Lifetime Downloads
High Power LEDS 120-277 V
079218 LED 22 W 120/277 V 80 4000 - - 2310 686 L80 B10 94000 Download

Documentation: NIKKO+27/G LED - 079218
079220 LED 22 W 120/277 V 80 4000 - - 2310 686 L80 B10 94000 Download

Documentation: NIKKO+27/G LED - 079220
079222 LED 22 W 120/277 V 80 4000 - - 2310 686 L80 B10 94000 Download

Documentation: NIKKO+27/G LED - 079222
079224 LED 22 W 120/277 V 80 4000 - - 2310 686 L80 B10 94000 Download

Documentation: NIKKO+27/G LED - 079224
079612 LED 22 W 120/277 V 80 3000 - - 2237 654 L80 B10 94000 Download

Documentation: NIKKO+27/G LED - 079612
079614 LED 22 W 120/277 V 80 3000 - - 2237 654 L80 B10 94000 Download

Documentation: NIKKO+27/G LED - 079614
079616 LED 22 W 120/277 V 80 3000 - - 2237 654 L80 B10 94000 Download

Documentation: NIKKO+27/G LED - 079616
079618 LED 22 W 120/277 V 80 3000 - - 2237 654 L80 B10 94000 Download

Documentation: NIKKO+27/G LED - 079618

Sources

LED 22 W
NIKKO+27/V LED

NIKKO+27/V LED

Optic | Asymmetric Extra-Wide
  • Surface-mount doorway and hallway lights and post mount series. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free (<1%) die-cast aluminum housing, ring, and faceplates.
  • - Copper-free (<1%) aluminum extruded post.
  • - High transmittance, internally coated, pressed glass diffuser, thermally, and chemically quenched to strengthen the impact resistance and reduce the effect of rapid temperature changes.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - High-efficiency COB, combined with an optimized passive cooling system, provides a long LED life.
  • - 100% uniform diffused light emission.
  • - Input voltage: 120-277 V (50 / 60 Hz), integral driver.
  • - Wall bracket and post accessories available (ordered separately).
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - 5-year warranty.
  • - Product meets Buy American Act (BAA) requirements within ARRA.
Product codes
Part number Finishing Lampholder Wattage Voltage CRI Kelvin Optic Beam
angle		 Lightsource
lumen
output
[lm]		 Luminaire
lumen
output
[lm]		 L B Lifetime Downloads
High Power LEDS 120-277 V
079226 LED 22 W 120/277 V 80 4000 - - 2310 687 L80 B10 94000 Download

Documentation: NIKKO+27/V LED - 079226
079228 LED 22 W 120/277 V 80 4000 - - 2310 687 L80 B10 94000 Download

Documentation: NIKKO+27/V LED - 079228
079230 LED 22 W 120/277 V 80 4000 - - 2310 687 L80 B10 94000 Download

Documentation: NIKKO+27/V LED - 079230
079232 LED 22 W 120/277 V 80 4000 - - 2310 687 L80 B10 94000 Download

Documentation: NIKKO+27/V LED - 079232
079620 LED 22 W 120/277 V 80 3000 - - 2237 654 L80 B10 94000 Download

Documentation: NIKKO+27/V LED - 079620
079622 LED 22 W 120/277 V 80 3000 - - 2237 654 L80 B10 94000 Download

Documentation: NIKKO+27/V LED - 079622
079624 LED 22 W 120/277 V 80 3000 - - 2237 654 L80 B10 94000 Download

Documentation: NIKKO+27/V LED - 079624
079626 LED 22 W 120/277 V 80 3000 - - 2237 654 L80 B10 94000 Download

Documentation: NIKKO+27/V LED - 079626

Sources

LED 22 W

Product Family

NIKKO+21 NIKKO+21
NIKKO+45 NIKKO+45
NIKKO+21 LA NIKKO+21 LA
NIKKO+27 LA NIKKO+27 LA
