STEEL SQUARE 20

  • In-ground series. Fixtures consist of:
  • - Copper-free (<1%) die-cast aluminum housing and die-cast corrosion-resistant AISI 316 stainless steel trim.
  • - Extra-clear, tempered, silk-screened, flat glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Custom MCPCB utilized to maximize heat dissipation and promote long LED life.
  • - High-transparency polycarbonate optics for optimized light transmission.
  • - Standard aimable optic system (±7°).
  • - Circular Intensive optics (C/I).
  • - Elliptical optics (ELL).
  • - Input voltage: 120-277 V (50 / 60 Hz), integral driver.
  • - Pre-wired cable connects luminaire with WATER-STOP connection system, suitable for through wiring. Included cable glands accept cables from Ø0.35" up to Ø0.63".
  • - Each rough-in kit is provided with a protective faceplate to avoid possible deformations during the installation in concrete to simplify installation.
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Thermoplastic compression-molded rough-in kit to be ordered separately.
  • - For outdoor inground applications, provide drainage gravel at least 12" below the rough-in or a suitable drainage system.
  • - Product meets Buy American Act (BAA) requirements within ARRA.
  • - 5-year warranty.
STEEL SQUARE 20 - 3 LED ELL 10°X45°

STEEL SQUARE 20 - 3 LED ELL 10°X45°

Optic | Elliptical - ELL
  • In-ground series. Fixtures consist of:
  • - Copper-free (<1%) die-cast aluminum housing and die-cast corrosion-resistant AISI 316 stainless steel trim.
  • - Extra-clear, tempered, silk-screened, flat glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Custom MCPCB utilized to maximize heat dissipation and promote long LED life.
  • - High-transparency polycarbonate optics for optimized light transmission.
  • - Standard aimable optic system (±7°).
  • - Elliptical optics (ELL).
  • - Input voltage: 120-277 V (50 / 60 Hz), integral driver.
  • - Pre-wired cable connects luminaire with WATER-STOP connection system, suitable for through wiring. Included cable glands accept cables from Ø0.35" up to Ø0.63".
  • - Each rough-in kit is provided with a protective faceplate to avoid possible deformations during the installation in concrete to simplify installation.
  • - Thermoplastic compression-molded rough-in kit to be ordered separately.
  • - For outdoor inground applications, provide drainage gravel at least 12" below the rough-in or a suitable drainage system.
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Product meets Buy American Act (BAA) requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finishing Lampholder Wattage Voltage CRI Kelvin Optic Beam
angle		 Lightsource
lumen
output
[lm]		 Luminaire
lumen
output
[lm]		 L B Lifetime Downloads
High Power LEDS 120-277 V
075318 LED 4.2 W 120/277 V 80 3000 - 10°x45° 255 144 - - 60000 Download

Documentation: STEEL SQUARE 20 - 3 LED ELL 10°X45° - 075318
075330 LED 4.2 W 120/277 V 80 4000 - 10°x45° 291 199 - - 60000 Download

Documentation: STEEL SQUARE 20 - 3 LED ELL 10°X45° - 075330
075342 LED 4.2 W 120/277 V 80 6000 - 10°x45° 300 199 - - 60000 Download

Documentation: STEEL SQUARE 20 - 3 LED ELL 10°X45° - 075342

Sources

LED 4.2 W
STEEL SQUARE 20 - 3 LED I 8°

STEEL SQUARE 20 - 3 LED I 8°

Optic | Circular Intensive
  • In-ground series. Fixtures consist of:
  • - Copper-free (<1%) die-cast aluminum housing and die-cast corrosion-resistant AISI 316 stainless steel trim.
  • - Extra-clear, tempered, silk-screened, flat glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Custom MCPCB utilized to maximize heat dissipation and promote long LED life.
  • - High-transparency polycarbonate optics for optimized light transmission.
  • - Standard aimable optic system (±7°).
  • - Circular Intensive optics (C/I).
  • - Input voltage: 120-277 V (50 / 60 Hz), integral driver.
  • - Pre-wired cable connects luminaire with WATER-STOP connection system, suitable for through wiring. Included cable glands accept cables from Ø0.35" up to Ø0.63".
  • - Each rough-in kit is provided with a protective faceplate to avoid possible deformations during the installation in concrete to simplify installation.
  • - Thermoplastic compression-molded rough-in kit to be ordered separately.
  • - For outdoor inground applications, provide drainage gravel at least 12" below the rough-in or a suitable drainage system.
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Product meets Buy American Act (BAA) requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finishing Lampholder Wattage Voltage CRI Kelvin Optic Beam
angle		 Lightsource
lumen
output
[lm]		 Luminaire
lumen
output
[lm]		 L B Lifetime Downloads
High Power LEDS 120-277 V
075316 LED 4.2 W 120/277 V 80 3000 - 8° 255 179 - - 60000 Download

Documentation: STEEL SQUARE 20 - 3 LED I 8° - 075316
075328 LED 4.2 W 120/277 V 80 4000 - 8° 291 246 - - 60000 Download

Documentation: STEEL SQUARE 20 - 3 LED I 8° - 075328
075340 LED 4.2 W 120/277 V 80 6000 - 8° 300 246 - - 60000 Download

Documentation: STEEL SQUARE 20 - 3 LED I 8° - 075340

Sources

LED 4.2 W
STEEL SQUARE 20 - 6 LED ELL 10°X45°

STEEL SQUARE 20 - 6 LED ELL 10°X45°

Optic | Elliptical - ELL
  • In-ground series. Fixtures consist of:
  • - Copper-free (<1%) die-cast aluminum housing and die-cast corrosion-resistant AISI 316 stainless steel trim.
  • - Extra-clear, tempered, silk-screened, flat glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Custom MCPCB utilized to maximize heat dissipation and promote long LED life.
  • - High-transparency polycarbonate optics for optimized light transmission.
  • - Standard aimable optic system (±7°).
  • - Elliptical optics (ELL).
  • - Input voltage: 120-277 V (50 / 60 Hz), integral driver.
  • - Pre-wired cable connects luminaire with WATER-STOP connection system, suitable for through wiring. Included cable glands accept cables from Ø0.35" up to Ø0.63".
  • - Each rough-in kit is provided with a protective faceplate to avoid possible deformations during the installation in concrete to simplify installation.
  • - Thermoplastic compression-molded rough-in kit to be ordered separately.
  • - For outdoor inground applications, provide drainage gravel at least 12" below the rough-in or a suitable drainage system.
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Product meets Buy American Act (BAA) requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finishing Lampholder Wattage Voltage CRI Kelvin Optic Beam
angle		 Lightsource
lumen
output
[lm]		 Luminaire
lumen
output
[lm]		 L B Lifetime Downloads
High Power LEDS 120-277 V
075322 LED 7.6 W 120/277 V 80 3000 - 10°x45° 510 278 - - 60000 Download

Documentation: STEEL SQUARE 20 - 6 LED ELL 10°X45° - 075322
075334 LED 7.6 W 120/277 V 80 4000 - 10°x45° 1509 379 - - 60000 Download

Documentation: STEEL SQUARE 20 - 6 LED ELL 10°X45° - 075334
075346 LED 7.6 W 120/277 V 80 6000 - 10°x45° 600 384 - - 60000 Download

Documentation: STEEL SQUARE 20 - 6 LED ELL 10°X45° - 075346

Sources

LED 7.6 W
STEEL SQUARE 20 - 6 LED I 8°

STEEL SQUARE 20 - 6 LED I 8°

Optic | Circular Intensive
  • In-ground series. Fixtures consist of:
  • - Copper-free (<1%) die-cast aluminum housing and die-cast corrosion-resistant AISI 316 stainless steel trim.
  • - Extra-clear, tempered, silk-screened, flat glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Custom MCPCB utilized to maximize heat dissipation and promote long LED life.
  • - High-transparency polycarbonate optics for optimized light transmission.
  • - Standard aimable optic system (±7°).
  • - Circular Intensive optics (C/I).
  • - Input voltage: 120-277 V (50 / 60 Hz), integral driver.
  • - Pre-wired cable connects luminaire with WATER-STOP connection system, suitable for through wiring. Included cable glands accept cables from Ø0.35" up to Ø0.63".
  • - Each rough-in kit is provided with a protective faceplate to avoid possible deformations during the installation in concrete to simplify installation.
  • - Thermoplastic compression-molded rough-in kit to be ordered separately.
  • - For outdoor inground applications, provide drainage gravel at least 12" below the rough-in or a suitable drainage system.
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Product meets Buy American Act (BAA) requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finishing Lampholder Wattage Voltage CRI Kelvin Optic Beam
angle		 Lightsource
lumen
output
[lm]		 Luminaire
lumen
output
[lm]		 L B Lifetime Downloads
High Power LEDS 120-277 V
075320 LED 7.6 W 120/277 V 80 3000 - 8° 510 346 - - 60000 Download

Documentation: STEEL SQUARE 20 - 6 LED I 8° - 075320
075332 LED 7.6 W 120/277 V 80 4000 - 8° 1509 487 - - 60000 Download

Documentation: STEEL SQUARE 20 - 6 LED I 8° - 075332
075344 LED 7.6 W 120/277 V 80 6000 - 8° 600 476 - - 60000 Download

Documentation: STEEL SQUARE 20 - 6 LED I 8° - 075344

Sources

LED 7.6 W
STEEL SQUARE 20 SIDE - 3 LED ELL 10°X45

STEEL SQUARE 20 SIDE - 3 LED ELL 10°X45

Optic | Elliptical - ELL
  • In-ground series. Fixtures consist of:
  • - Copper-free (<1%) die-cast aluminum housing and die-cast corrosion-resistant AISI 316 stainless steel trim.
  • - Extra-clear, tempered, silk-screened, flat glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Custom MCPCB utilized to maximize heat dissipation and promote long LED life.
  • - High-transparency polycarbonate optics for optimized light transmission.
  • - Standard aimable optic system (±7°).
  • - Elliptical optics (ELL).
  • - Input voltage: 120-277 V (50 / 60 Hz), integral driver.
  • - Pre-wired cable connects luminaire with WATER-STOP connection system, suitable for through wiring. Included cable glands accept cables from Ø0.35" up to Ø0.63".
  • - Each rough-in kit is provided with a protective faceplate to avoid possible deformations during the installation in concrete to simplify installation.
  • - Thermoplastic compression-molded rough-in kit to be ordered separately.
  • - For outdoor inground applications, provide drainage gravel at least 12" below the rough-in or a suitable drainage system.
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Product meets Buy American Act (BAA) requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finishing Lampholder Wattage Voltage CRI Kelvin Optic Beam
angle		 Lightsource
lumen
output
[lm]		 Luminaire
lumen
output
[lm]		 L B Lifetime Downloads
High Power LEDS 120-277 V
075314 LED 4.2 W 120/277 V 80 3000 - 10°x45° 255 146 - - 60000 Download

Documentation: STEEL SQUARE 20 SIDE - 3 LED ELL 10°X45 - 075314
075326 LED 4.2 W 120/277 V 80 4000 - 10°x45° 291 197 - - 60000 Download

Documentation: STEEL SQUARE 20 SIDE - 3 LED ELL 10°X45 - 075326
075338 LED 4.2 W 120/277 V 80 6000 - 10°x45° 300 197 - - 60000 Download

Documentation: STEEL SQUARE 20 SIDE - 3 LED ELL 10°X45 - 075338

Sources

LED 4.2 W
STEEL SQUARE 20 SIDE - 3 LED I8°

STEEL SQUARE 20 SIDE - 3 LED I8°

Optic | Circular Intensive
  • In-ground series. Fixtures consist of:
  • - Copper-free (<1%) die-cast aluminum housing and die-cast corrosion-resistant AISI 316 stainless steel trim.
  • - Extra-clear, tempered, silk-screened, flat glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Custom MCPCB utilized to maximize heat dissipation and promote long LED life.
  • - High-transparency polycarbonate optics for optimized light transmission.
  • - Standard aimable optic system (±7°).
  • - Circular Intensive optics (C/I).
  • - Input voltage: 120-277 V (50 / 60 Hz), integral driver.
  • - Pre-wired cable connects luminaire with WATER-STOP connection system, suitable for through wiring. Included cable glands accept cables from Ø0.35" up to Ø0.63".
  • - Each rough-in kit is provided with a protective faceplate to avoid possible deformations during the installation in concrete to simplify installation.
  • - Thermoplastic compression-molded rough-in kit to be ordered separately.
  • - For outdoor inground applications, provide drainage gravel at least 12" below the rough-in or a suitable drainage system.
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Product meets Buy American Act (BAA) requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finishing Lampholder Wattage Voltage CRI Kelvin Optic Beam
angle		 Lightsource
lumen
output
[lm]		 Luminaire
lumen
output
[lm]		 L B Lifetime Downloads
High Power LEDS 120-277 V
075312 LED 4.2 W 120/277 V 80 3000 - 8° 255 182 - - 60000 Download

Documentation: STEEL SQUARE 20 SIDE - 3 LED I8° - 075312
075324 LED 4.2 W 120/277 V 80 4000 - 8° 291 245 - - 60000 Download

Documentation: STEEL SQUARE 20 SIDE - 3 LED I8° - 075324
075336 LED 4.2 W 120/277 V 80 6000 - 8° 300 245 - - 60000 Download

Documentation: STEEL SQUARE 20 SIDE - 3 LED I8° - 075336

Sources

LED 4.2 W

Product Family

STEEL SQUARE 28 STEEL SQUARE 28
STEEL SQUARE 34 STEEL SQUARE 34
Open filters Close filters
Products search
You can search for products in our catalog by entering here the name or the code of the product or accessory.
