STEEL SQUARE 28

IN
  • In-ground series. Fixtures consist of:
  • - Copper-free die-cast aluminum housing and die-cast corrosion-resistant AISI 316 stainless steel trim.
  • - Extra-clear, tempered, silk-screened, flat glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Custom MCPCB utilized to maximize heat dissipation and promote long LED life.
  • - Standard aimable optic system (±7°).
  • - High-transparency polycarbonate optics for optimized light transmission.
  • - Circular Intensive optics (C/I).
  • - Elliptical optics (ELL).
  • - Input voltage: 120-277 V (50 / 60 Hz), integral driver.
  • - Pre-wired cable connects luminaire with WATER-STOP connection system, suitable for through wiring. Included cable glands accept cables from Ø0.35" up to Ø0.63".
  • - Each rough-in kit is provided with a protective faceplate to avoid possible deformations during the installation in concrete to simplify installation.
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Thermoplastic compression-molded rough-in kit to be ordered separately.
  • - For outdoor inground applications, provide drainage gravel at least 12" below the rough-in or a suitable drainage system.
  • - Product meets Buy American Act (BAA) requirements within ARRA.
  • - 5-year warranty.
STEEL SQUARE 28 - 12 LED ELL 10°X45°

STEEL SQUARE 28 - 12 LED ELL 10°X45°

Optic | Elliptical
  • In-ground series. Fixtures consist of:
  • - Copper-free die-cast aluminum housing and die-cast corrosion-resistant AISI 316 stainless steel trim.
  • - Extra-clear, tempered, silk-screened, flat glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Custom MCPCB utilized to maximize heat dissipation and promote long LED life.
  • - Standard aimable optic system (±7°).
  • - High-transparency polycarbonate optics for optimized light transmission.
  • - Elliptical optics (ELL).
  • - Input voltage: 120-277 V (50 / 60 Hz), integral driver.
  • - Pre-wired cable connects luminaire with WATER-STOP connection system, suitable for through wiring. Included cable glands accept cables from Ø0.35" up to Ø0.63".
  • - Each rough-in kit is provided with a protective faceplate to avoid possible deformations during the installation in concrete to simplify installation.
  • - Thermoplastic compression-molded rough-in kit to be ordered separately.
  • - For outdoor inground applications, provide drainage gravel at least 12" below the rough-in or a suitable drainage system.
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Product meets Buy American Act (BAA) requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finishing Lampholder Wattage Voltage CRI Kelvin Optic Beam
angle		 Lightsource
lumen
output
[lm]		 Luminaire
lumen
output
[lm]		 L B Lifetime Downloads
High Power LEDS 120-277 V
075456 LED 15.3 W 120/277 V 80 3000 - 10°x45° 1164 550 - - 60000 Download

Documentation: STEEL SQUARE 28 - 12 LED ELL 10°X45° - 075456
075468 LED 15.3 W 120/277 V 80 4000 - 10°x45° 1620 763 - - 60000 Download

Documentation: STEEL SQUARE 28 - 12 LED ELL 10°X45° - 075468
075480 LED 15.3 W 120/277 V 80 6000 - 10°x45° 1620 756 - - 60000 Download

Documentation: STEEL SQUARE 28 - 12 LED ELL 10°X45° - 075480

Sources

LED 15.3 W
STEEL SQUARE 28 - 12 LED I 8°

STEEL SQUARE 28 - 12 LED I 8°

Optic | Circular Intensive
  • In-ground series. Fixtures consist of:
  • - Copper-free die-cast aluminum housing and die-cast corrosion-resistant AISI 316 stainless steel trim.
  • - Extra-clear, tempered, silk-screened, flat glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Custom MCPCB utilized to maximize heat dissipation and promote long LED life.
  • - Standard aimable optic system (±7°).
  • - High-transparency polycarbonate optics for optimized light transmission.
  • - Circular Intensive optics (C/I).
  • - Input voltage: 120-277 V (50 / 60 Hz), integral driver.
  • - Pre-wired cable connects luminaire with WATER-STOP connection system, suitable for through wiring. Included cable glands accept cables from Ø0.35" up to Ø0.63".
  • - Each rough-in kit is provided with a protective faceplate to avoid possible deformations during the installation in concrete to simplify installation.
  • - Thermoplastic compression-molded rough-in kit to be ordered separately.
  • - For outdoor inground applications, provide drainage gravel at least 12" below the rough-in or a suitable drainage system.
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Product meets Buy American Act (BAA) requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finishing Lampholder Wattage Voltage CRI Kelvin Optic Beam
angle		 Lightsource
lumen
output
[lm]		 Luminaire
lumen
output
[lm]		 L B Lifetime Downloads
High Power LEDS 120-277 V
075454 LED 15.3 W 120/277 V 80 3000 - 8° 1164 686 - - 60000 Download

Documentation: STEEL SQUARE 28 - 12 LED I 8° - 075454
075466 LED 15.3 W 120/277 V 80 4000 - 8° 1620 939 - - 60000 Download

Documentation: STEEL SQUARE 28 - 12 LED I 8° - 075466
075478 LED 15.3 W 120/277 V 80 6000 - 8° 1620 929 - - 60000 Download

Documentation: STEEL SQUARE 28 - 12 LED I 8° - 075478

Sources

LED 15.3 W
STEEL SQUARE 28 - 18 LED ELL 10°X45°

STEEL SQUARE 28 - 18 LED ELL 10°X45°

Optic | Elliptical
  • In-ground series. Fixtures consist of:
  • - Copper-free die-cast aluminum housing and die-cast corrosion-resistant AISI 316 stainless steel trim.
  • - Extra-clear, tempered, silk-screened, flat glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Custom MCPCB utilized to maximize heat dissipation and promote long LED life.
  • - Standard aimable optic system (±7°).
  • - High-transparency polycarbonate optics for optimized light transmission.
  • - Elliptical optics (ELL).
  • - Input voltage: 120-277 V (50 / 60 Hz), integral driver.
  • - Pre-wired cable connects luminaire with WATER-STOP connection system, suitable for through wiring. Included cable glands accept cables from Ø0.35" up to Ø0.63".
  • - Each rough-in kit is provided with a protective faceplate to avoid possible deformations during the installation in concrete to simplify installation.
  • - Thermoplastic compression-molded rough-in kit to be ordered separately.
  • - For outdoor inground applications, provide drainage gravel at least 12" below the rough-in or a suitable drainage system.
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Product meets Buy American Act (BAA) requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finishing Lampholder Wattage Voltage CRI Kelvin Optic Beam
angle		 Lightsource
lumen
output
[lm]		 Luminaire
lumen
output
[lm]		 L B Lifetime Downloads
High Power LEDS 120-277 V
075460 LED 22.4 W 120/277 V 80 3000 - 10°x45° 1764 852 - - 60000 Download

Documentation: STEEL SQUARE 28 - 18 LED ELL 10°X45° - 075460
075472 LED 22.4 W 120/277 V 80 4000 - 10°x45° 2430 1148 - - 60000 Download

Documentation: STEEL SQUARE 28 - 18 LED ELL 10°X45° - 075472
075484 LED 22.4 W 120/277 V 80 6000 - 10°x45° 2430 1146 - - 60000 Download

Documentation: STEEL SQUARE 28 - 18 LED ELL 10°X45° - 075484

Sources

LED 22.4 W
STEEL SQUARE 28 - 18 LED I 8°

STEEL SQUARE 28 - 18 LED I 8°

Optic | Circular Intensive
  • In-ground series. Fixtures consist of:
  • - Copper-free die-cast aluminum housing and die-cast corrosion-resistant AISI 316 stainless steel trim.
  • - Extra-clear, tempered, silk-screened, flat glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Custom MCPCB utilized to maximize heat dissipation and promote long LED life.
  • - Standard aimable optic system (±7°).
  • - High-transparency polycarbonate optics for optimized light transmission.
  • - Circular Intensive optics (C/I).
  • - Input voltage: 120-277 V (50 / 60 Hz), integral driver.
  • - Pre-wired cable connects luminaire with WATER-STOP connection system, suitable for through wiring. Included cable glands accept cables from Ø0.35" up to Ø0.63".
  • - Each rough-in kit is provided with a protective faceplate to avoid possible deformations during the installation in concrete to simplify installation.
  • - Thermoplastic compression-molded rough-in kit to be ordered separately.
  • - For outdoor inground applications, provide drainage gravel at least 12" below the rough-in or a suitable drainage system.
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Product meets Buy American Act (BAA) requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finishing Lampholder Wattage Voltage CRI Kelvin Optic Beam
angle		 Lightsource
lumen
output
[lm]		 Luminaire
lumen
output
[lm]		 L B Lifetime Downloads
High Power LEDS 120-277 V
075458 LED 22.4 W 120/277 V 80 3000 - 8° 1764 1056 - - 60000 Download

Documentation: STEEL SQUARE 28 - 18 LED I 8° - 075458
075470 LED 22.4 W 120/277 V 80 4000 - 8° 2430 1465 - - 60000 Download

Documentation: STEEL SQUARE 28 - 18 LED I 8° - 075470
075482 LED 22.4 W 120/277 V 80 6000 - 8° 2430 1425 - - 60000 Download

Documentation: STEEL SQUARE 28 - 18 LED I 8° - 075482

Sources

LED 22.4 W
STEEL SQUARE 28 SIDE - 6 LED ELL 10°X45

STEEL SQUARE 28 SIDE - 6 LED ELL 10°X45

Optic | Elliptical
  • In-ground series. Fixtures consist of:
  • - Copper-free die-cast aluminum housing and die-cast corrosion-resistant AISI 316 stainless steel trim.
  • - Extra-clear, tempered, silk-screened, flat glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Custom MCPCB utilized to maximize heat dissipation and promote long LED life.
  • - Standard aimable optic system (±7°).
  • - High-transparency polycarbonate optics for optimized light transmission.
  • - Elliptical optics (ELL).
  • - Input voltage: 120-277 V (50 / 60 Hz), integral driver.
  • - Pre-wired cable connects luminaire with WATER-STOP connection system, suitable for through wiring. Included cable glands accept cables from Ø0.35" up to Ø0.63".
  • - Each rough-in kit is provided with a protective faceplate to avoid possible deformations during the installation in concrete to simplify installation.
  • - Thermoplastic compression-molded rough-in kit to be ordered separately.
  • - For outdoor inground applications, provide drainage gravel at least 12" below the rough-in or a suitable drainage system.
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Product meets Buy American Act (BAA) requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finishing Lampholder Wattage Voltage CRI Kelvin Optic Beam
angle		 Lightsource
lumen
output
[lm]		 Luminaire
lumen
output
[lm]		 L B Lifetime Downloads
High Power LEDS 120-277 V
075452 LED 7.6 W 120/277 V 80 3000 - 10°x45° 1509 277 - - 60000 Download

Documentation: STEEL SQUARE 28 SIDE - 6 LED ELL 10°X45 - 075452
075464 LED 7.6 W 120/277 V 80 4000 - 10°x45° 810 368 - - 60000 Download

Documentation: STEEL SQUARE 28 SIDE - 6 LED ELL 10°X45 - 075464
075476 LED 7.6 W 120/277 V 80 6000 - 10°x45° 810 364 - - 60000 Download

Documentation: STEEL SQUARE 28 SIDE - 6 LED ELL 10°X45 - 075476

Sources

LED 7.6 W
STEEL SQUARE 28 SIDE - 6 LED I 8°

STEEL SQUARE 28 SIDE - 6 LED I 8°

Optic | Circular Intensive
  • In-ground series. Fixtures consist of:
  • - Copper-free die-cast aluminum housing and die-cast corrosion-resistant AISI 316 stainless steel trim.
  • - Extra-clear, tempered, silk-screened, flat glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Custom MCPCB utilized to maximize heat dissipation and promote long LED life.
  • - Standard aimable optic system (±7°).
  • - High-transparency polycarbonate optics for optimized light transmission.
  • - Circular Intensive optics (C/I).
  • - Input voltage: 120-277 V (50 / 60 Hz), integral driver.
  • - Pre-wired cable connects luminaire with WATER-STOP connection system, suitable for through wiring. Included cable glands accept cables from Ø0.35" up to Ø0.63".
  • - Each rough-in kit is provided with a protective faceplate to avoid possible deformations during the installation in concrete to simplify installation.
  • - Thermoplastic compression-molded rough-in kit to be ordered separately.
  • - For outdoor inground applications, provide drainage gravel at least 12" below the rough-in or a suitable drainage system.
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Product meets Buy American Act (BAA) requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finishing Lampholder Wattage Voltage CRI Kelvin Optic Beam
angle		 Lightsource
lumen
output
[lm]		 Luminaire
lumen
output
[lm]		 L B Lifetime Downloads
High Power LEDS 120-277 V
075450 LED 7.6 W 120/277 V 80 3000 - 8° 1509 344 - - 60000 Download

Documentation: STEEL SQUARE 28 SIDE - 6 LED I 8° - 075450
075462 LED 7.6 W 120/277 V 80 4000 - 8° 810 465 - - 60000 Download

Documentation: STEEL SQUARE 28 SIDE - 6 LED I 8° - 075462
075474 LED 7.6 W 120/277 V 80 6000 - 8° 810 465 - - 60000 Download

Documentation: STEEL SQUARE 28 SIDE - 6 LED I 8° - 075474

Sources

LED 7.6 W

Product Family

STEEL SQUARE 20 STEEL SQUARE 20
STEEL SQUARE 34 STEEL SQUARE 34
to top
Request information
Products search
You can search for products in our catalog by entering here the name or the code of the product or accessory.
