STEEL SQUARE 34

  • In-ground series. Fixtures consist of:
  • - Copper-free (<1%) die-cast aluminum housing and die-cast corrosion-resistant AISI 316 stainless steel trim.
  • - Extra-clear, tempered, silk-screened, flat glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Custom MCPCB utilized to maximize heat dissipation and promote long LED life.
  • - High-transparency polycarbonate optics for optimized light transmission.
  • - Standard aimable optic system (±7°).
  • - Circular Intensive optics (C/I).
  • - Elliptical optics (ELL).
  • - Input voltage: 120-277 V (50 / 60 Hz), integral driver.
  • - Pre-wired cable connects luminaire with WATER-STOP connection system, suitable for through wiring. Included cable glands accept cables from Ø0.35" up to Ø0.63".
  • - Each rough-in kit is provided with a protective faceplate to avoid possible deformations during the installation in concrete to simplify installation.
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Thermoplastic compression-molded rough-in kit to be ordered separately.
  • - For outdoor inground applications, provide drainage gravel at least 12" below the rough-in or a suitable drainage system.
  • - Product meets Buy American Act (BAA) requirements within ARRA.
  • - 5-year warranty.
STEEL SQUARE 34 - 16 LED ELL 10°X45°

STEEL SQUARE 34 - 16 LED ELL 10°X45°

Optic | Elliptical - ELL
  • In-ground series. Fixtures consist of:
  • - Copper-free (<1%) die-cast aluminum housing and die-cast corrosion-resistant AISI 316 stainless steel trim.
  • - Extra-clear, tempered, silk-screened, flat glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Custom MCPCB utilized to maximize heat dissipation and promote long LED life.
  • - High-transparency polycarbonate optics for optimized light transmission.
  • - Standard aimable optic system (±7°).
  • - Elliptical optics (ELL).
  • - Input voltage: 120-277 V (50 / 60 Hz), integral driver.
  • - Pre-wired cable connects luminaire with WATER-STOP connection system, suitable for through wiring. Included cable glands accept cables from Ø0.35" up to Ø0.63".
  • - Each rough-in kit is provided with a protective faceplate to avoid possible deformations during the installation in concrete to simplify installation.
  • - Thermoplastic compression-molded rough-in kit to be ordered separately.
  • - For outdoor inground applications, provide drainage gravel at least 12" below the rough-in or a suitable drainage system.
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Product meets Buy American Act (BAA) requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finishing Lampholder Wattage Voltage CRI Kelvin Optic Beam
angle		 Lightsource
lumen
output
[lm]		 Luminaire
lumen
output
[lm]		 L B Lifetime Downloads
High Power LEDS 120-277 V
075740 LED 19.4 W 120/277 V 80 3000 - 10°x45° 1552 744 - - 60000 Download

Documentation: STEEL SQUARE 34 - 16 LED ELL 10°X45° - 075740
075752 LED 19.4 W 120/277 V 80 4000 - 10°x45° 2160 1024 - - 60000 Download

Documentation: STEEL SQUARE 34 - 16 LED ELL 10°X45° - 075752
075764 LED 19.4 W 120/277 V 80 6000 - 10°x45° 2160 1024 - - 60000 Download

Documentation: STEEL SQUARE 34 - 16 LED ELL 10°X45° - 075764

Sources

LED 19.4 W
STEEL SQUARE 34 - 16 LED I 8°

STEEL SQUARE 34 - 16 LED I 8°

Optic | Circular Intensive
  • In-ground series. Fixtures consist of:
  • - Copper-free (<1%) die-cast aluminum housing and die-cast corrosion-resistant AISI 316 stainless steel trim.
  • - Extra-clear, tempered, silk-screened, flat glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Custom MCPCB utilized to maximize heat dissipation and promote long LED life.
  • - High-transparency polycarbonate optics for optimized light transmission.
  • - Standard aimable optic system (±7°).
  • - Circular Intensive optics (C/I).
  • - Input voltage: 120-277 V (50 / 60 Hz), integral driver.
  • - Pre-wired cable connects luminaire with WATER-STOP connection system, suitable for through wiring. Included cable glands accept cables from Ø0.35" up to Ø0.63".
  • - Each rough-in kit is provided with a protective faceplate to avoid possible deformations during the installation in concrete to simplify installation.
  • - Thermoplastic compression-molded rough-in kit to be ordered separately.
  • - For outdoor inground applications, provide drainage gravel at least 12" below the rough-in or a suitable drainage system.
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Product meets Buy American Act (BAA) requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finishing Lampholder Wattage Voltage CRI Kelvin Optic Beam
angle		 Lightsource
lumen
output
[lm]		 Luminaire
lumen
output
[lm]		 L B Lifetime Downloads
High Power LEDS 120-277 V
075738 LED 19.4 W 120/277 V 80 3000 - 8° 1552 909 - - 60000 Download

Documentation: STEEL SQUARE 34 - 16 LED I 8° - 075738
075750 LED 19.4 W 120/277 V 80 4000 - 8° 2160 1268 - - 60000 Download

Documentation: STEEL SQUARE 34 - 16 LED I 8° - 075750
075762 LED 19.4 W 120/277 V 80 6000 - 8° 2160 1268 - - 60000 Download

Documentation: STEEL SQUARE 34 - 16 LED I 8° - 075762

Sources

LED 19.4 W
STEEL SQUARE 34 - 24 LED ELL 10°X45°

STEEL SQUARE 34 - 24 LED ELL 10°X45°

Optic | Elliptical - ELL
  • In-ground series. Fixtures consist of:
  • - Copper-free (<1%) die-cast aluminum housing and die-cast corrosion-resistant AISI 316 stainless steel trim.
  • - Extra-clear, tempered, silk-screened, flat glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Custom MCPCB utilized to maximize heat dissipation and promote long LED life.
  • - High-transparency polycarbonate optics for optimized light transmission.
  • - Standard aimable optic system (±7°).
  • - Elliptical optics (ELL).
  • - Input voltage: 120-277 V (50 / 60 Hz), integral driver.
  • - Pre-wired cable connects luminaire with WATER-STOP connection system, suitable for through wiring. Included cable glands accept cables from Ø0.35" up to Ø0.63".
  • - Each rough-in kit is provided with a protective faceplate to avoid possible deformations during the installation in concrete to simplify installation.
  • - Thermoplastic compression-molded rough-in kit to be ordered separately.
  • - For outdoor inground applications, provide drainage gravel at least 12" below the rough-in or a suitable drainage system.
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Product meets Buy American Act (BAA) requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finishing Lampholder Wattage Voltage CRI Kelvin Optic Beam
angle		 Lightsource
lumen
output
[lm]		 Luminaire
lumen
output
[lm]		 L B Lifetime Downloads
High Power LEDS 120-277 V
075744 LED 29 W 120/277 V 80 3000 - 10°x45° 2328 1087 - - 60000 Download

Documentation: STEEL SQUARE 34 - 24 LED ELL 10°X45° - 075744
075756 LED 29 W 120/277 V 80 4000 - 10°x45° 3240 1503 - - 60000 Download

Documentation: STEEL SQUARE 34 - 24 LED ELL 10°X45° - 075756
075768 LED 29 W 120/277 V 80 6000 - 10°x45° 3240 1509 - - 60000 Download

Documentation: STEEL SQUARE 34 - 24 LED ELL 10°X45° - 075768

Sources

LED 29 W
STEEL SQUARE 34 - 24 LED I 8°

STEEL SQUARE 34 - 24 LED I 8°

Optic | Circular Intensive
  • In-ground series. Fixtures consist of:
  • - Copper-free (<1%) die-cast aluminum housing and die-cast corrosion-resistant AISI 316 stainless steel trim.
  • - Extra-clear, tempered, silk-screened, flat glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Custom MCPCB utilized to maximize heat dissipation and promote long LED life.
  • - High-transparency polycarbonate optics for optimized light transmission.
  • - Standard aimable optic system (±7°).
  • - Circular Intensive optics (C/I).
  • - Input voltage: 120-277 V (50 / 60 Hz), integral driver.
  • - Pre-wired cable connects luminaire with WATER-STOP connection system, suitable for through wiring. Included cable glands accept cables from Ø0.35" up to Ø0.63".
  • - Each rough-in kit is provided with a protective faceplate to avoid possible deformations during the installation in concrete to simplify installation.
  • - Thermoplastic compression-molded rough-in kit to be ordered separately.
  • - For outdoor inground applications, provide drainage gravel at least 12" below the rough-in or a suitable drainage system.
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Product meets Buy American Act (BAA) requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finishing Lampholder Wattage Voltage CRI Kelvin Optic Beam
angle		 Lightsource
lumen
output
[lm]		 Luminaire
lumen
output
[lm]		 L B Lifetime Downloads
High Power LEDS 120-277 V
075742 LED 29 W 120/277 V 80 3000 - 8° 2328 1357 - - 60000 Download

Documentation: STEEL SQUARE 34 - 24 LED I 8° - 075742
075754 LED 29 W 120/277 V 80 4000 - 8° 3240 1882 - - 60000 Download

Documentation: STEEL SQUARE 34 - 24 LED I 8° - 075754
075766 LED 29 W 120/277 V 80 6000 - 8° 3240 1879 - - 60000 Download

Documentation: STEEL SQUARE 34 - 24 LED I 8° - 075766

Sources

LED 29 W
STEEL SQUARE 34 SIDE - 8 LED ELL 10°X45

STEEL SQUARE 34 SIDE - 8 LED ELL 10°X45

Optic | Elliptical - ELL
  • In-ground series. Fixtures consist of:
  • - Copper-free (<1%) die-cast aluminum housing and die-cast corrosion-resistant AISI 316 stainless steel trim.
  • - Extra-clear, tempered, silk-screened, flat glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Custom MCPCB utilized to maximize heat dissipation and promote long LED life.
  • - High-transparency polycarbonate optics for optimized light transmission.
  • - Standard aimable optic system (±7°).
  • - Elliptical optics (ELL).
  • - Input voltage: 120-277 V (50 / 60 Hz), integral driver.
  • - Pre-wired cable connects luminaire with WATER-STOP connection system, suitable for through wiring. Included cable glands accept cables from Ø0.35" up to Ø0.63".
  • - Each rough-in kit is provided with a protective faceplate to avoid possible deformations during the installation in concrete to simplify installation.
  • - Thermoplastic compression-molded rough-in kit to be ordered separately.
  • - For outdoor inground applications, provide drainage gravel at least 12" below the rough-in or a suitable drainage system.
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Product meets Buy American Act (BAA) requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finishing Lampholder Wattage Voltage CRI Kelvin Optic Beam
angle		 Lightsource
lumen
output
[lm]		 Luminaire
lumen
output
[lm]		 L B Lifetime Downloads
High Power LEDS 120-277 V
075736 LED 9.6 W 120/277 V 80 3000 - 10°x45° 776 372 - - 60000 Download

Documentation: STEEL SQUARE 34 SIDE - 8 LED ELL 10°X45 - 075736
075748 LED 9.6 W 120/277 V 80 4000 - 10°x45° 1080 514 - - 60000 Download

Documentation: STEEL SQUARE 34 SIDE - 8 LED ELL 10°X45 - 075748
075760 LED 9.6 W 120/277 V 80 6000 - 10°x45° 1080 514 - - 60000 Download

Documentation: STEEL SQUARE 34 SIDE - 8 LED ELL 10°X45 - 075760

Sources

LED 9.6 W
STEEL SQUARE 34 SIDE - 8 LED I 8°

STEEL SQUARE 34 SIDE - 8 LED I 8°

Optic | Circular Intensive
  • In-ground series. Fixtures consist of:
  • - Copper-free (<1%) die-cast aluminum housing and die-cast corrosion-resistant AISI 316 stainless steel trim.
  • - Extra-clear, tempered, silk-screened, flat glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Custom MCPCB utilized to maximize heat dissipation and promote long LED life.
  • - High-transparency polycarbonate optics for optimized light transmission.
  • - Standard aimable optic system (±7°).
  • - Circular Intensive optics (C/I).
  • - Input voltage: 120-277 V (50 / 60 Hz), integral driver.
  • - Pre-wired cable connects luminaire with WATER-STOP connection system, suitable for through wiring. Included cable glands accept cables from Ø0.35" up to Ø0.63".
  • - Each rough-in kit is provided with a protective faceplate to avoid possible deformations during the installation in concrete to simplify installation.
  • - Thermoplastic compression-molded rough-in kit to be ordered separately.
  • - For outdoor inground applications, provide drainage gravel at least 12" below the rough-in or a suitable drainage system.
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Product meets Buy American Act (BAA) requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finishing Lampholder Wattage Voltage CRI Kelvin Optic Beam
angle		 Lightsource
lumen
output
[lm]		 Luminaire
lumen
output
[lm]		 L B Lifetime Downloads
High Power LEDS 120-277 V
075734 LED 9.6 W 120/277 V 80 3000 - 8° 776 463 - - 60000 Download

Documentation: STEEL SQUARE 34 SIDE - 8 LED I 8° - 075734
075746 LED 9.6 W 120/277 V 80 4000 - 8° 1080 640 - - 60000 Download

Documentation: STEEL SQUARE 34 SIDE - 8 LED I 8° - 075746
075758 LED 9.6 W 120/277 V 80 6000 - 8° 1080 640 - - 60000 Download

Documentation: STEEL SQUARE 34 SIDE - 8 LED I 8° - 075758

Sources

LED 9.6 W

Product Family

STEEL SQUARE 20 STEEL SQUARE 20
STEEL SQUARE 28 STEEL SQUARE 28
to top
Request information
Products search
You can search for products in our catalog by entering here the name or the code of the product or accessory.
