QUASAR 30

  • Wall sconce series. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free (<1%) precision die-cast aluminum housing and mounting plate.
  • - Micro-prismatic patterned, tempered, silk-screened, flat glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - High-efficiency COB, combined with an optimized passive cooling system, provides a long LED life.
  • - Internal specular reflector coated with 5-layers of PVD 99.98% pure aluminum providing >95% reflection.
  • - Single (TECH) or dual (DOUBLE TECH) light emission.
  • - Type I light distribution.
  • - Input voltage: 120-277 V (50 / 60 Hz), integral 0-10 V dimming driver.
  • - Junction box mounting plate included (for 4" octagon box only, provided by others).
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Product meets Buy American Act (BAA) requirements within ARRA.
  • - 5-year warranty.
QUASAR 30 DOUBLE TECH

QUASAR 30 DOUBLE TECH

  • Wall sconce series. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free (<1%) precision die-cast aluminum housing and mounting plate.
  • - Micro-prismatic patterned, tempered, silk-screened, flat glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - High-efficiency COB, combined with an optimized passive cooling system, provides a long LED life.
  • - Internal specular reflector coated with 5-layers of PVD 99.98% pure aluminum providing >95% reflection.
  • - Single (TECH) or dual (DOUBLE TECH) light emission.
  • - Type I light distribution.
  • - Input voltage: 120-277 V (50 / 60 Hz), integral 0-10 V dimming driver.
  • - Junction box mounting plate included (for 4" octagon box only, provided by others).
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Product meets Buy American Act (BAA) requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finishing Lampholder Wattage Voltage CRI Kelvin Optic Beam
angle		 Lightsource
lumen
output
[lm]		 Luminaire
lumen
output
[lm]		 L B Lifetime Downloads
High Power LEDS 120-277 V Dimmable 0-10 V
070210 LED 35 W 120/277 V 80 3000 Type I - 5291 2046 L80 B10 60000 Download

Documentation: QUASAR 30 DOUBLE TECH - 070210
070211 LED 35 W 120/277 V 80 4000 Type I - 5539 2251 L80 B10 60000 Download

Documentation: QUASAR 30 DOUBLE TECH - 070211
070212 LED 35 W 120/277 V 80 3000 Type I - 5291 2046 L80 B10 60000 Download

Documentation: QUASAR 30 DOUBLE TECH - 070212
070213 LED 35 W 120/277 V 80 4000 Type I - 5539 2251 L80 B10 60000 Download

Documentation: QUASAR 30 DOUBLE TECH - 070213
070214 LED 35 W 120/277 V 80 3000 Type I - 5291 2046 L80 B10 60000 Download

Documentation: QUASAR 30 DOUBLE TECH - 070214
070215 LED 35 W 120/277 V 80 4000 Type I - 5539 2251 L80 B10 60000 Download

Documentation: QUASAR 30 DOUBLE TECH - 070215

Sources

LED 35 W
QUASAR 30 TECH

QUASAR 30 TECH

  • Wall sconce series. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free (<1%) precision die-cast aluminum housing and mounting plate.
  • - Micro-prismatic patterned, tempered, silk-screened, flat glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - High-efficiency COB, combined with an optimized passive cooling system, provides a long LED life.
  • - Internal specular reflector coated with 5-layers of PVD 99.98% pure aluminum providing >95% reflection.
  • - Single (TECH) or dual (DOUBLE TECH) light emission.
  • - Type I light distribution.
  • - Input voltage: 120-277 V (50 / 60 Hz), integral 0-10 V dimming driver.
  • - Junction box mounting plate included (for 4" octagon box only, provided by others).
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Product meets Buy American Act (BAA) requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finishing Lampholder Wattage Voltage CRI Kelvin Optic Beam
angle		 Lightsource
lumen
output
[lm]		 Luminaire
lumen
output
[lm]		 L B Lifetime Downloads
High Power LEDS 120-277 V Dimmable 0-10 V
070204 LED 22 W 120/277 V 80 3000 Type I - 2300 1350 L80 B10 60000 Download

Documentation: QUASAR 30 TECH - 070204
070205 LED 22 W 120/277 V 80 4000 Type I - 2408 1505 L80 B10 60000 Download

Documentation: QUASAR 30 TECH - 070205
070206 LED 22 W 120/277 V 80 3000 Type I - 2300 1350 L80 B10 60000 Download

Documentation: QUASAR 30 TECH - 070206
070207 LED 22 W 120/277 V 80 4000 Type I - 2408 1505 L80 B10 60000 Download

Documentation: QUASAR 30 TECH - 070207
070208 LED 22 W 120/277 V 80 3000 Type I - 2300 1350 L80 B10 60000 Download

Documentation: QUASAR 30 TECH - 070208
070209 LED 22 W 120/277 V 80 4000 Type I - 2408 1505 L80 B10 60000 Download

Documentation: QUASAR 30 TECH - 070209

Sources

LED 22 W
