QUASAR 10

  • Wall effect series. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free (<1%) precision die-cast aluminum housing and mounting plate.
  • - Extra-clear, tempered, silk-screened, flat glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Custom MCPCB utilized to maximize heat dissipation and promote long LED life.
  • - Surface effects light emission.
  • - Input voltage: 120-277 V (50 / 60 Hz), integral driver.
  • - Junction box mounting plate included (for 4" octagon box only, provided by others).
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Product meets Buy American Act (BAA) requirements within ARRA.
  • - 5-year warranty.
QUASAR 10 1NB+1WB

QUASAR 10 1NB+1WB

  • Wall effect series. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free (<1%) precision die-cast aluminum housing and mounting plate.
  • - Extra-clear, tempered, silk-screened, flat glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Custom MCPCB utilized to maximize heat dissipation and promote long LED life.
  • - Surface effects light emission.
  • - Input voltage: 120-277 V (50 / 60 Hz), integral driver.
  • - Junction box mounting plate included (for 4" octagon box only, provided by others).
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Product meets Buy American Act (BAA) requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finishing Lampholder Wattage Voltage CRI Kelvin Optic Beam
angle		 Lightsource
lumen
output
[lm]		 Luminaire
lumen
output
[lm]		 L B Lifetime Downloads
High Power LEDS 120-277 V
070186 LED 5.5 W 120/277 V 80 3000 - - 454 113 L80 B10 60000 Download

Documentation: QUASAR 10 1NB+1WB - 070186
070187 LED 5.5 W 120/277 V 80 4000 - - 538 141 L80 B10 60000 Download

Documentation: QUASAR 10 1NB+1WB - 070187
070188 LED 5.5 W 120/277 V 80 3000 - - 454 113 L80 B10 60000 Download

Documentation: QUASAR 10 1NB+1WB - 070188
070189 LED 5.5 W 120/277 V 80 4000 - - 538 141 L80 B10 60000 Download

Documentation: QUASAR 10 1NB+1WB - 070189
070190 LED 5.5 W 120/277 V 80 3000 - - 454 113 L80 B10 60000 Download

Documentation: QUASAR 10 1NB+1WB - 070190
070191 LED 5.5 W 120/277 V 80 4000 - - 538 141 L80 B10 60000 Download

Documentation: QUASAR 10 1NB+1WB - 070191
070361 LED 10 W 120/277 V 70 3000 - - 840 258 L80 B10 60000 Download

Documentation: QUASAR 10 1NB+1WB - 070361
070362 LED 10 W 120/277 V 70 4000 - - 940 287 L80 B10 60000 Download

Documentation: QUASAR 10 1NB+1WB - 070362
070363 LED 10 W 120/277 V 70 3000 - - 840 258 L80 B10 60000 Download

Documentation: QUASAR 10 1NB+1WB - 070363
070364 LED 10 W 120/277 V 70 4000 - - 940 287 L80 B10 60000 Download

Documentation: QUASAR 10 1NB+1WB - 070364
070365 LED 10 W 120/277 V 70 3000 - - 840 258 L80 B10 60000 Download

Documentation: QUASAR 10 1NB+1WB - 070365
070366 LED 10 W 120/277 V 70 4000 - - 940 287 L80 B10 60000 Download

Documentation: QUASAR 10 1NB+1WB - 070366

Sources

LED 5.5 W
LED 10 W
QUASAR 10 1WB

QUASAR 10 1WB

  • Wall effect series. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free (<1%) precision die-cast aluminum housing and mounting plate.
  • - Extra-clear, tempered, silk-screened, flat glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Custom MCPCB utilized to maximize heat dissipation and promote long LED life.
  • - Surface effects light emission.
  • - Input voltage: 120-277 V (50 / 60 Hz), integral driver.
  • - Junction box mounting plate included (for 4" octagon box only, provided by others).
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Product meets Buy American Act (BAA) requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finishing Lampholder Wattage Voltage CRI Kelvin Optic Beam
angle		 Lightsource
lumen
output
[lm]		 Luminaire
lumen
output
[lm]		 L B Lifetime Downloads
High Power LEDS 120-277 V
070180 LED 3.5 W 120/277 V 80 3000 - - 227 100 L80 B10 60000 Download

Documentation: QUASAR 10 1WB - 070180
070181 LED 3.5 W 120/277 V 80 4000 - - 269 122 L80 B10 60000 Download

Documentation: QUASAR 10 1WB - 070181
070182 LED 3.5 W 120/277 V 80 3000 - - 227 100 L80 B10 60000 Download

Documentation: QUASAR 10 1WB - 070182
070183 LED 3.5 W 120/277 V 80 4000 - - 269 122 L80 B10 60000 Download

Documentation: QUASAR 10 1WB - 070183
070184 LED 3.5 W 120/277 V 80 3000 - - 227 100 L80 B10 60000 Download

Documentation: QUASAR 10 1WB - 070184
070185 LED 3.5 W 120/277 V 80 4000 - - 269 122 L80 B10 60000 Download

Documentation: QUASAR 10 1WB - 070185
070349 LED 5 W 120/277 V 70 3000 - - 420 220 L80 B10 60000 Download

Documentation: QUASAR 10 1WB - 070349
070350 LED 5 W 120/277 V 70 4000 - - 470 244 L80 B10 60000 Download

Documentation: QUASAR 10 1WB - 070350
070351 LED 5 W 120/277 V 70 3000 - - 420 220 L80 B10 60000 Download

Documentation: QUASAR 10 1WB - 070351
070352 LED 5 W 120/277 V 70 4000 - - 470 244 L80 B10 60000 Download

Documentation: QUASAR 10 1WB - 070352
070353 LED 5 W 120/277 V 70 3000 - - 420 220 L80 B10 60000 Download

Documentation: QUASAR 10 1WB - 070353
070354 LED 5 W 120/277 V 70 4000 - - 470 244 L80 B10 60000 Download

Documentation: QUASAR 10 1WB - 070354

Sources

LED 3.5 W
LED 5 W
QUASAR 10 2WB

QUASAR 10 2WB

  • Wall effect series. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free (<1%) precision die-cast aluminum housing and mounting plate.
  • - Extra-clear, tempered, silk-screened, flat glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Custom MCPCB utilized to maximize heat dissipation and promote long LED life.
  • - Surface effects light emission.
  • - Input voltage: 120-277 V (50 / 60 Hz), integral driver.
  • - Junction box mounting plate included (for 4" octagon box only, provided by others).
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Product meets Buy American Act (BAA) requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finishing Lampholder Wattage Voltage CRI Kelvin Optic Beam
angle		 Lightsource
lumen
output
[lm]		 Luminaire
lumen
output
[lm]		 L B Lifetime Downloads
High Power LEDS 120-277 V
070192 LED 5.5 W 120/277 V 80 3000 - - 454 193 L80 B10 60000 Download

Documentation: QUASAR 10 2WB - 070192
070193 LED 5.5 W 120/277 V 80 4000 - - 538 235 L80 B10 60000 Download

Documentation: QUASAR 10 2WB - 070193
070194 LED 5.5 W 120/277 V 80 3000 - - 454 193 L80 B10 60000 Download

Documentation: QUASAR 10 2WB - 070194
070195 LED 5.5 W 120/277 V 80 4000 - - 538 235 L80 B10 60000 Download

Documentation: QUASAR 10 2WB - 070195
070196 LED 5.5 W 120/277 V 80 3000 - - 454 193 L80 B10 60000 Download

Documentation: QUASAR 10 2WB - 070196
070197 LED 5.5 W 120/277 V 80 4000 - - 538 235 L80 B10 60000 Download

Documentation: QUASAR 10 2WB - 070197
070355 LED 10 W 120/277 V 70 3000 - - 840 428 L80 B10 60000 Download

Documentation: QUASAR 10 2WB - 070355
070356 LED 10 W 120/277 V 70 4000 - - 940 476 L80 B10 60000 Download

Documentation: QUASAR 10 2WB - 070356
070357 LED 10 W 120/277 V 70 3000 - - 840 428 L80 B10 60000 Download

Documentation: QUASAR 10 2WB - 070357
070358 LED 10 W 120/277 V 70 4000 - - 940 476 L80 B10 60000 Download

Documentation: QUASAR 10 2WB - 070358
070359 LED 10 W 120/277 V 70 3000 - - 840 428 L80 B10 60000 Download

Documentation: QUASAR 10 2WB - 070359
070360 LED 10 W 120/277 V 70 4000 - - 940 476 L80 B10 60000 Download

Documentation: QUASAR 10 2WB - 070360

Sources

LED 5.5 W
LED 10 W
QUASAR 10 4WB

QUASAR 10 4WB

  • Wall effect series. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free (<1%) precision die-cast aluminum housing and mounting plate.
  • - Extra-clear, tempered, silk-screened, flat glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Custom MCPCB utilized to maximize heat dissipation and promote long LED life.
  • - Surface effects light emission.
  • - Input voltage: 120-277 V (50 / 60 Hz), integral driver.
  • - Junction box mounting plate included (for 4" octagon box only, provided by others).
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Product meets Buy American Act (BAA) requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finishing Lampholder Wattage Voltage CRI Kelvin Optic Beam
angle		 Lightsource
lumen
output
[lm]		 Luminaire
lumen
output
[lm]		 L B Lifetime Downloads
High Power LEDS 120-277 V
070198 LED 10 W 120/277 V 80 3000 - - 988 329 L80 B10 60000 Download

Documentation: QUASAR 10 4WB - 070198
070199 LED 10 W 120/277 V 80 4000 - - 1076 402 L80 B10 60000 Download

Documentation: QUASAR 10 4WB - 070199
070200 LED 10 W 120/277 V 80 3000 - - 988 329 L80 B10 60000 Download

Documentation: QUASAR 10 4WB - 070200
070201 LED 10 W 120/277 V 80 4000 - - 1076 402 L80 B10 60000 Download

Documentation: QUASAR 10 4WB - 070201
070202 LED 10 W 120/277 V 80 3000 - - 988 329 L80 B10 60000 Download

Documentation: QUASAR 10 4WB - 070202
070203 LED 10 W 120/277 V 80 4000 - - 1076 402 L80 B10 60000 Download

Documentation: QUASAR 10 4WB - 070203

Sources

LED 10 W

Product Family

QUASAR 20 QUASAR 20
QUASAR 30 QUASAR 30
QUASAR 60 QUASAR 60
QUASAR 30 CEILING QUASAR 30 CEILING
